This European standard specifies the design, dimensions and technical requirements for connections and pipelines for storing potable water for inland navigation vessels.
These are:
- a fixed connection on the supply side;
- pipeline;
- a fixed connection on the consumer side;
- a connection for retrofitting inland navigation vessels that have a closure device level with the deck (internal pipe thread pursuant to EN ISO 228 1), consisting of a connecting part with a threaded connection and fixed coupling.
Necessary measures to prevent electrostatic charge and overfilling are not governed by the standard.
National regulations apply to drinking water supply plants. The requirements of this European standard supplement these regulations.
Fahrzeuge der Binnenschifffahrt - Anschlüsse und Schlauchleitungen für das Bunkern von Trinkwasser
Diese Europäische Norm legt Bauart, Maße und technische Anforderungen von Anschlüssen und Schlauchleitungen für das Bunkern von Trinkwasser für Fahrzeuge der Binnenschifffahrt fest.
Dies sind:
- versorgerseitiger Festanschluss;
- Schlauchleitung;
- verbraucherseitiger Festanschluss;
- Anschluss zur Nachrüstung von Fahrzeugen der Binnenschifffahrt, die einen decksgleichen Verschluss (Rohrinnengewinde nach EN ISO 228 1) haben, bestehend aus Anschlussstück mit Gewindestutzen und Festkupplung.
Notwendige Maßnahmen zur Verhinderung der elektrostatischen Aufladung und der Überfüllung werden in der Norm nicht geregelt.
Für Trinkwasserversorgungsanlagen gelten nationale Bestimmungen. Die Anforderungen dieser Europäischen Norm ergänzen diese Bestimmungen.
Bateaux de navigation intérieure - Raccords et tuyaux flexibles pour le ravitaillement en eau potable
La présente Norme européenne définit le type, les dimensions et les exigences techniques des raccordements et des tuyaux flexibles pour le ravitaillement en eau potable des bateaux de navigation intérieure.
Il s’agit :
- du raccordement fixe côté fournisseur ;
- du tuyau flexible ;
- du raccordement fixe côté consommateur ;
- du raccordement de post-équipement des bateaux de navigation intérieure disposant d’une fermeture au même niveau que le pont (filetage de tuyauterie intérieur conforme à l’EN ISO 228-1), qui se compose d’une pièce de raccordement avec embout fileté et d’un raccord fixe.
Les mesures nécessaires pour éviter toute charge électrostatique et tout risque de remplissage excessif ne sont pas traitées dans cette norme.
Concernant les installations d’alimentation en eau potable, les dispositions nationales s’appliquent. Les exigences de la présente Norme européenne complètent ces dispositions.
Plovila za celinske vode - Povezave in cevni priključki za dobavo pitne vode
Ta evropski standard določa zasnovo, mere in tehnične zahteve za povezave in cevovode za shranjevanje pitne vode za plovila za celinske vode.
Ti so:
– stalna povezava na dovodni strani;
– cevovod;
– stalna povezava na strani porabe;
– povezava za nameščanje opreme na plovila za celinske vode z zaporno napravo, ki je poravnana s palubo (navoj notranje cevi je v skladu s standardom EN ISO 228 1), ki je sestavljena iz povezovalnega elementa s povezavo z navojem in stalnega spoja.
Ukrepi, ki so potrebni za preprečevanje kopičenja elektrostatičnega naboja in prenapolnjenosti, niso zajeti v tem standardu.
Nacionalni predpisi veljajo za obrate za dovajanje pitne vode. Zahteve tega evropskega standarda dopolnjujejo te predpise.
