EN 1806:2006

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Chimneys - Clay/ceramic flue blocks for single wall chimneys - Requirements and test methodsConduits de fumée - Boisseaux en terre cuite/céramique pour conduits de fumée simple paroi - Exigences et méthodes d'essaiAbgasanlagen - Keramik - Formblöcke für einschalige Abgasanlagen - Anforderungen und PrüfmethodenTa slovenski standard je istoveten z:EN 1806:2006SIST EN 1806:2006en91.100.25Ceramic building products91.060.40Dimniki, jaški, kanaliChimneys, shafts, ductsICS:SIST EN 1806:20011DGRPHãþDSLOVENSKI
STANDARDSIST EN 1806:200601-oktober-2006

EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 1806July 2006ICS 91.060.40; 91.100.25Supersedes EN 1806:2000
English VersionChimneys - Clay/ceramic flue blocks for single wall chimneys -Requirements and test methodsConduits de fumée - Boisseaux en terre cuite/céramiquepour conduits de fumée simple paroi - Exigences etméthodes d'essaiAbgasanlagen - Keramik - Formblöcke für einschaligeAbgasanlagen - Anforderungen und PrüfmethodenThis European Standard was approved by CEN on 19 June 2006.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the Central Secretariat or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the Central Secretariat has the same status as the officialversions.CEN members are the national standards bodies of Austria, Belgium, Cyprus, Czech Republic, Denmark, Estonia, Finland, France,Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania,Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2006 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 1806:2006: E

Measurement of the coefficient of friction of chimneys.39 Annex B (normative)
Thermal resistance.41 B.1 Method 1 : simplified calculation for flue blocks without cavities.41 B.2 Method 2 : thermal resistance of flue blocks with or without cavities.41 B.2.1 General.41 B.2.2 Data.42 B.2.3 Specific conditions for the cavities.43 B.2.4 Calculations.46 B.3 Method Approximate thermal resistance values.46 Annex C (normative)
Sampling procedures for an AQL of 10 % and Inspection Level S2.47 C.1 Acceptability determination.47 C.1.1 General.47 C.1.2 Single sampling.47 C.1.3 Double sampling.47 C.2 Normal inspection.47 C.3 Normal to reduced inspection.49 C.4 Reduced to normal inspection.49 C.5 Tightened inspection.49 C.6 Tightened to normal inspection.50 C.7 Discontinuation of inspection.50 Annex ZA (informative)
Clauses of this European Standard addressing the provisions of EU Construction Products Directives.51 ZA.1 Scope and relevant characteristics.51 ZA.2 Procedure of attestation of conformity of clay/ceramic flue blocks.54 ZA.2.1 System of attestation of conformity.54 ZA.2.2 EC certificate and declaration of conformity.54 ZA.3 CE Marking and labelling.55 Bibliography.59

angle flue block flue blocks designed to facilitate a change in angle of the axis of a flue (see Figure 2). 3.2
bonding extension part of a flue block which is designed to be bonded into adjacent masonry walls, and forms no part of the chimney 3.3
bonding flue block flue blocks designed to be built wholly or partially into a masonry wall and having a bonding extension
Bonding flue block Non-bonding flue block Figure 1 — Examples of flue block shape 3.4
entry flue block flue block connecting the chimney to the connecting flue pipe or the chimney to the appliance (see Figure 6)

Figure 2 — Examples of angle flue block 3.5
family group of products for which the test for one or more characteristics from any one product within the family are valid for all other products within the family 3.6
flue blocks with attached insulation flue blocks with insulation factory-fitted to the outer walls (see Figure 5).
Figure 3 — Examples of transfer flue blocks 3.7 flue blocks with insulation in vertical perforations flue blocks with perforations within the wall specially designed to house rigid insulation (see Figure 4).

Figure 4 — Example of flue block with insulation in vertical perforations 3.8
nominal height numerical designation of the height in millimetres of a standard flue block excluding any projecting spigot, which is a convenient round number NOTE For a bonding flue block, this is the co-ordinating height which equates to the nominal height of masonry building blocks for walls into which such a flue block is designed to be built.
Figure 5 — Example of flue block with attached insulation

nominal size numerical designation of size which is a convenient round number equal to or approximately equal to either:  the internal diameter in millimetres of flue blocks with circular section flue; or  the internal width in millimetres of flue blocks with square section flue; or  the internal width and breadth in millimetres of the internal transverse dimensions of flue blocks with rectangular section flue.
Figure 6 — Example of entry flue block 3.10
non-bonding flue block flue blocks designed not to be built into a masonry wall with a bonding extension 3.11 straight flue block flue blocks designed to be used in a vertical section of a chimney having the ends perpendicular to the axis of the flue (see Figure 1). 3.12
transfer flue block flue block which changes the cross-section of the flue from rectangular to circular (see Figure 3). 4 Types of flue blocks Clay/ceramic flue blocks shall be designated according to Clause 19. A non-exhaustive list of abbreviated designation for clay/ceramic flue blocks, according to temperature, pressure, sootfire resistance and condensate resistance (wet and dry conditions) is given in Table 1.

type
pressure resistance conditions pressure leakage rate
working°C test °C
Pa m3
.s-1.m–2 x10-3 FB1 N2 Non-bonding 600 1 000 N2 Yes Dry 20 3 FB1 N1 Non-bonding 600 1 000 N1 Yes Dry 40 2 FB2 N2 Non-bonding 600 700 N2 No Dry 20 3 FB2 N1 Non-bonding 600 700 N1 No Dry 40 2 FB3 N2 Non-bonding 400 500 N2 No Dry & wet 20 3 FB3 N1 Non-bonding 400 500 N1 No Dry & wet 40 2 FB4 N2 Non-bonding 300 350 N2 No Dry & wet 20 3 FB4 N1 Non-bonding 300 350 N1 No Dry & wet 40 2 FB5 N2 Non-bonding 200 250 N2 No Dry & wet 20 3 FB5 N1 Non-bonding 200 250 N1 No Dry & wet 40 2 FB6 Bonding 300 350 N2 No Dry 20 3 NOTE A flue block may be designated in one or more types provided that it complies with the appropriate requirements of each type. 5 Materials 5.1 Flue blocks Flue blocks shall be manufactured from suitable clay/ceramic material which, when fired, meet the performance requirements given in this standard. Flue blocks may be unglazed or glazed on the interior and/or exterior. When glazed, they need not be glazed on the jointing surfaces. 5.2 Insulation 5.2.1 General All information on reaction to fire shall be made available according to the relevant European product standard.

= χ . H . G/ 100
(1) where F is the minimum load in kN;
χ is the safety factor equal to 5;
H is the height of chimney in m;
G is the weight per metre in kg/m.

The flue block which forms part of a multi-wall chimney shall not be tested for the distance to combustible materials. The flue block that forms a chimney shall be tested for the distance to combustible materials. For the latter, the distance to combustible material shall be declared in accordance with 18.8. The manufacturer may declare a distance to combustible material that reflects installation practice in individual member states' regulations. The surface temperature of the combustible material shall be equal to or less than 100 °C for an ambient air temperature of 20 °C. NOTE This distance should not be less than the distance under normal operating conditions. 15.2 External to external For complete chimneys which convey products of combustion to the atmosphere, the resistance to fire external to external shall be evaluated according to the provision valid in the intended place of use of the flue blocks until a European test method is available. 16 Resistance to freeze/thaw When subject to regulation, the freeze/thaw resistance of the flue block shall be tested according to EN 14297. The product shall not present any damage of type 7, 8, 9 and 10 in accordance with EN 14297:2004, Table 1.

Relevant requirements clauses Initial type testing Factory production control Item 17.2
17.4 Straight flue blocks 7.1,8, 9, 10, 13,12, 14, 15 and 16 6.1, 6.2, 6.4, 6.5, 6.6 and 11 Angle blocks 7.2, 8.2, 10 and 16 6.1, 6.3, and 11 Sampling and testing of any batch shall be completed prior to removal from the works and shall be in accordance with ISO 2859-1 at an AQL of 10 % and inspection level S2. Isolated batches of units shall be assessed in accordance with tightened inspection procedures, with a maximum batch size of 1 200 (see Annex C). Batches rejected under the sampling procedure specified above may be resubmitted once, after removal of units with previously undetected visible defects, under the tightened inspection procedures, in respect only of the defect that caused initial rejection.

Key H Nominal height of the flue block in mm L Test length of the flue block in mm D Deviation from straightness in mm H - L = 50 mm Figure 7 — Terms for deviation
...
