ISO 9284:2013

Overview

ISO 9284:2013 is an international standard developed by the International Organization for Standardization (ISO) that specifies the operational and technical requirements for test-sieving machines used with abrasive grains. These test-sieving machines are essential for determining the size distribution of bonded and coated abrasive macrograins. The standard also provides guidance on the installation, verification, and maintenance of these machines to ensure reproducible and accurate granulometric analysis.

This standard is critical for manufacturers and quality control laboratories involved in abrasive grain production and testing, as it ensures consistency and reliability in particle size distribution measurements.

Key Topics

• Scope and Application
  The standard applies to machines used for the mechanical sieving of abrasive macrograins, focusing on operational requirements and machine design.

• Machine Technical Requirements
  Requirements cover the construction of the test-sieving machine, including:

  • Support and structural frame
  • Electric motor and gear transmission for converting rotary motion into eccentric movement
  • An impact hammer for vertical shocks during sieving
  • Timer-controlled switches to set precise sieving duration
  • Retention mechanisms for sieves and collection receptacles
  • Protective covers with inserts to absorb hammer impacts

• Sieving Stack and Dimensions
  ISO 9284:2013 mandates specific sieve dimensions and setup:

  • Diameter of control sieves: 200 mm
  • Height of control sieves: 50 mm
  • Sieve stacking must allow prescribed movements to occur freely.

• Duration and Operation Control
  The standard requires machines to have a timing mechanism to ensure a consistent and reproducible sieving duration.

• Installation Guidelines
  Proper installation is vital for machine performance, including:

  • Placement on a sufficiently massive, vibration-isolated concrete base
  • Horizontal positioning of the machine
  • Use of vibration-absorbing panels under the base to prevent external vibration interference
  • Correct anchoring to the base in accordance with manufacturer and ISO specifications

• Periodic Verification and Maintenance
  To maintain accuracy and efficiency, regular checks are advised on key components such as:

  • Hammer impact performance
  • Timer accuracy
  • General upkeep based on manufacturer recommendations

Applications

• Abrasive Industry Quality Control
  Ensures consistent particle size distribution of abrasive macrograins used in bonded (e.g., grinding wheels) and coated abrasives (e.g., sandpapers).

• Research and Development
  Facilitates detailed granulometric analysis needed in abrasive product design and improvement.

• Laboratory Testing
  Provides standardized procedures and machine requirements to achieve reproducible testing results essential for certification, compliance, and product specification adherence.

• Manufacturing Process Monitoring
  Real-time verification of abrasive grain size distribution to maintain production quality.

Related Standards

ISO 9284:2013 references and complements several key ISO standards related to abrasive grain testing and sieving, including:

• ISO 2591-1:1988 – Control Sieving – Part 1: Methods using control metal wire cloth and perforated metal plate sieves
• ISO 6344-1 – Coated Abrasives – Granulometry – Part 1: Control of granulometric distribution
• ISO 6344-2 – Coated Abrasives – Granulometry – Part 2: Determination of macrograin distribution P12 to P220
• ISO 8486-1 – Bonded Abrasives – Granulometric determination and designation – Part 1: Macrograins F4 to F220

These standards collectively define methods, specifications, and test conditions that ensure precise particle size distribution analysis in abrasives manufacturing.

By adhering to ISO 9284:2013, companies benefit from enhanced reproducibility in test results, improved equipment reliability, and compliance with globally recognized quality standards, making it indispensable for abrasive grain testing and control.
