SEMICONDUCTOR DEVICES –
MICRO-ELECTROMECHANICAL DEVICES –

Part 34: Test methods for MEMS piezoresistive
pressure-sensitive device on wafer

1 Scope
This part of IEC 62047 describes test conditions and test methods of electric character, static
performances and thermal performances for MEMS pressure-sensitive devices. This
document applies to test for both open and closed loop piezoresistive MEMS pressure
devices on wafer.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their
content constitutes requirements of this document. For dated references, only the edition
cited applies. For undated references, the latest edition of the referenced document (including
any amendments) applies.
IEC 61193-2, Quality assessment systems – Part 2: Selection and use of sampling plans for
inspection of electronic components and packages
IEC 60747-14-3, Semiconductor devices – Part 14-3: Semiconductor sensors – Pressure
sensors
3 Terms and definitions
For the purposes of this document, the terms and definitions given in IEC 60747-14-3 and the
following apply.
ISO and IEC maintain terminological databases for use in standardization at the following
addresses:
• IEC Electropedia: available at http://www.electropedia.org/
• ISO Online browsing platform: available at http://www.iso.org/obp
3.1
piezoresistive pressure-sensitive device
device that transforms pressure signal into electric signal due to piezoresistive effect, usually
including cavity-membrane structure on silicon substrate and Wheatstone bridge in the
membrane fabricated by MEMS technology
[SOURCE: IEC 62047-33: –, 3.1]
3.2
closed loop piezoresistive pressure-sensitive device
piezoresistive pressure-sensitive device that employs closed loop Wheatstone bridge for
signal detection
– 6 – IEC 62047-34:2019 © IEC 2019
3.3
open loop piezoresistive pressure-sensitive device
piezoresistive pressure-sensitive device that employs open loop Wheatstone bridge for signal
detection
3.4
output under normal pressure
output of the pressure-sensitive device under the standard reference atmosphere
pressure(101,3 kPa)
3.5
zero output
output of the pressure-sensitive device when the pressure difference between both sides of
the membrane structure is zero
4 Test conditions
4.1 Atmospheric conditions
The measurement of characteristics shall be carried out under the following atmospheric
conditions unless otherwise specified.
a) Standard atmospheric conditions
...

Questions, Comments and Discussion

Ask us and Technical Secretary will try to provide an answer. You can facilitate discussion about the standard in here.
