INTERNATIONAL STANDARD ISO 15614-13:2021(E)
Specification and qualification of welding procedures for
metallic materials — Welding procedure test —
Part 13:
Upset (resistance butt) and flash welding
1 Scope
This document specifies tests for the qualification of welding procedure specifications applicable to
upset (resistance butt) welding and flash welding of metallic materials, e.g. with solid, tubular, flat or
circular cross-section. Its basic principles can also be applied to other resistance welding processes
when this is stated in the specification.
This document defines the conditions for carrying out tests and the limits of validity of a qualified
welding procedure for all the practical welding operations that it covers.
It covers the following resistance welding processes, as defined in ISO 4063:
— 24 flash welding, using direct current or alternating current with various movement sequences,
constant flashing and pulsed flashing;
— 25 resistance upset welding, using direct current or alternating current with various pressure
sequences.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
ISO 669, Resistance welding — Resistance welding equipment — Mechanical and electrical requirements
ISO 4136, Destructive tests on welds in metallic materials — Transverse tensile test
ISO 5173, Destructive tests on welds in metallic materials — Bend tests
ISO 6520-2, Welding and allied processes — Classification of geometric imperfections in metallic materials
— Part 2: Welding with pressure
ISO 6892-1, Metallic materials — Tensile testing — Part 1: Method of test at room temperature
ISO 9015-1, Destructive tests on welds in metallic materials — Hardness testing — Part 1: Hardness test on
arc welded joints
ISO 9015-2, Destructive tests on welds in metallic materi
...
