INTRODUCTION
With the global introduction of High definition (HD) TV services, receivers, and consumer
recording equipment, the need has arisen for a universal recording interface to connect
receivers and recorders.
This International Standard presents a comprehensive proposal for this interface including
content protection 62H [2 ]63H [3 ] 0F . The proposal – intended as a guideline – leverages existing
standards IEC 62481-1, and 64H [4] in the field, ensuring interoperability between receivers and
recorders.
*
Recorder
Recording
Receiver
interface
IEC  1338/09
NOTE * HDMI (High-Definition Multimedia Interface)1F is a digital interface for the connection between source
device and monitor provided by HDMI Licensing, LLC.
Figure 1 – High definition reception and recording

The starting point for the proposal is an in-home configuration depicted in 65HFigure 1. The
assumption is that both the receiver (e.g. STB) as well as the recorder (e.g. BD-recorder) are
connected to the display via an HDMI interface 66H [4]. The proposed recording interface
connects the recorder to the receiver and carries compressed signals only. Obviously, the
receiver functionality can be integrated into the display.
The proposed interface recognises the fact that a large amount of content will be made
available in the form of a Pay-TV and thus be protected via a Conditional Access (CA) system.
The required CA functionality is assumed to be contained in the receiver.
