EUROPEAN STANDARD DRAFT
prEN 50436-7
NORME EUROPÉENNE
EUROPÄISCHE NORM
April 2023
ICS 43.040.10; 71.040.40 Will supersede EN 50436-7:2016
English Version
Alcohol interlocks - Test methods and performance requirements
- Part 7: Installation document
Ethylotests anti-démarrage - Méthodes d'essais et Alkohol-Interlocks - Prüfverfahren und Anforderungen an
exigences de performance - Partie 7: Document das Betriebsverhalten - Teil 7: Einbaudokument
d'installation
This draft European Standard is submitted to CENELEC members for enquiry.
Deadline for CENELEC: 2023-07-21.

It has been drawn up by CLC/BTTF 116-2.

If this draft becomes a European Standard, CENELEC members are bound to comply with the CEN/CENELEC Internal Regulations which
stipulate the conditions for giving this European Standard the status of a national standard without any alteration.

This draft European Standard was established by CENELEC in three official versions (English, French, German).
A version in any other language made by translation under the responsibility of a CENELEC member into its own language and notified to
the CEN-CENELEC Management Centre has the same status as the official versions.

CENELEC members are the national electrotechnical committees of Austria, Belgium, Bulgaria, Croatia, Cyprus, the Czech Republic,
Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, the
Netherlands, Norway, Poland, Portugal, Republic of North Macedonia, Romania, Serbia, Slovakia, Slovenia, Spain, Sweden, Switzerland,
Türkiye and the United Kingdom.

Recipients of this draft are invited to submit, with their comments, notification of any relevant patent rights of which they are aware and to
provide supporting documentation.

Warning : This document is not a European Standard. It is distributed for review and comments. It is subject to change without notice and
shall not be referred to as a European Standard.

European Committee for Electrotechnical Standardization
Comité Européen de Normalisation Electrotechnique
Europäisches Komitee für Elektrotechnische Normung
CEN-CENELEC Management Centre: Rue de la Science 23, B-1040 Brussels
© 2023 CENELEC All rights of exploitation in any form and by any means reserved worldwide for CENELEC Members.
Project: 75536 Ref. No. prEN 50436-7:2023 E

oSIST prEN 50436-7:2023
prEN 50436-7:2023 (E)
1 Contents Page
2 European foreword . 3
3 Introduction . 4
4 1 Scope . 5
5 2 Normative references . 5
6 3 Terms and definitions . 5
7 4 Installation of an alcohol interlock . 7
8 5 Time behaviour . 8
9 6 Layout and contents of the installation document . 8
10 6.1 General . 8
11 General content and layout . 9
6.2
12 6.3 Header . 9
13 6.4 Footer . 10
14 6.4.1 General . 10
15 6.4.2 Document identification number . 10
16 6.5 Connection schematics . 10
17 Safety risks at installation and items to be considered . 10
6.6
18 6.7 Assembly instruction . 10
19 6.8 Modification of vehicle operation . 11
20 6.9 Mounting position of alcohol interlock handset and alcohol interlock control unit . 11
21 Annex A (informative) Time behaviour . 12
22 Annex B (normative) General layout of the installation document . 13
23 Annex C (normative) Connection schematics . 14
24 Annex D (informative) Assembly instruction . 16
25 Bibliography . 18
26 Figures
27 Figure 1 — Traditional installation schematics for an alcohol interlock . 8
28 Figure A.1 — Time behaviour diagram . 12
29 Figure D.1 — Location of ground installation point . 16
30 Figure D.2 — Taking apart to reach an installation point by minimizing damages . 16
31 Figure D.3 — Location of the connector and of the pins in the connector . 17
32 Tables
33 Table B.1 — Layout of the installation document . 13
34 Table C.1 — Information of the connection schematics . 14
oSIST prEN 50436-7:2023
prEN 50436-7:2023 (E)
35 European foreword
36 This document (prEN 50436-7:2023) has been prepared by CLC/BTTF 116-2 “Alcohol Interlocks”.
37 This document is currently submitted to the Enquiry.
38 The following dates are proposed:
• latest date by which the existence of this (doa) dor + 6 months
document has to be announced at national
level
• latest date by which this document has to be (dop) dor + 12 months
implemented at national level by publication of
an identical national standard or by
endorsement
• latest date by which the national standards (dow) dor + 36 months
conflicting with this document have to be (to be confirmed or
withdrawn modified when voting)
39 This document will supersede EN 50436-7:2016 and all of their amendments and corrigenda (if any).
40 prEN 50463-7:2023 includes the following significant technical changes with respect to EN 50436-7:2016:
41 — Clause 2, Normative references: ISO 16750-2:2012 was added;
42 — Clause 6.7, Assembly instruction: details of the databus connection were updated;
43 — Clause 6.9, Mounting position of alcohol interlock handset ans alcohol interlock control unit: complete
44 clause was updated to define the responsibility for installation of retrofitted devices;
45 — Table C.1, Information of the connection schematics: cell of item 1 under the column “Function” was
46 updated to differentiate between “operational mode” and “low power consumption”;
47 — Footnote “a” and footnote “c” of Table C.1 were updated;
48 — Bibliography: item 1 was replaced with the information of the published standard.
oSIST prEN 50436-7:2023
prEN 50436-7:2023 (E)
49 Introduction
50 The purpose of alcohol interlocks is to enhance traffic safety by preventing persons with alcohol
51 concentrations exceeding a set limit value from driving a motor vehicle. EN 50436 series specifies test
52 methods and essential performance requirements for alcohol interlocks and gives guidance for authorities,
53 decision makers, purchasers and users.
54 There are several ways in which alcohol interlocks may be used:
55 — installed in a vehicle as a general preventive measure for the promotion of traffic safety, on a voluntary
56 basis or required legally in certain vehicles (e.g. vehicles for children transport); or
57 — in vehicles as ordered by a court or an administrative authority as part of a drink-driving offender
58 programme; or
59 — for persons subject to a medical or rehabilitation programme.
60 Alcohol interlocks are often intended for aftermarket installation. For this purpose, they are connected to the
61 electric and control circuits of the vehicle.
62 This installation of an alcohol interlock should not interfere with the proper performance of the vehicle, should
63 not impair the safety and security of the vehicle and should be as straightforward as possible. Additionally,
64 the installation costs should be low in relation to the total cost of the alcohol interlock.
65 Therefore, it is desirable to have a standardized installation document to give the necessary details to the
66 technicians installing an alcohol interlock into a certain vehicle model, even if the responsibility for the safe
67 installation will remain on the alcohol interlock installer.
oSIST prEN 50436-7:2023
prEN 50436-7:2023 (E)
68 1 Scope
69 This document defines the content and the layout of an installation document providing necessary and useful
70 information about the aftermarket installation of an alcohol interlock into a vehicle. It details the type of the
71 vehicle, connection schematics, accessibility instructions and recommendations to avoid safety risks.
72 The contents and layout ensures that the information document is easy to use for installers in different
73 countries and can be available in paper or electronic format.
74 This document is applicable to alcohol interlocks according to EN 50436-1 and EN 50436-2.
75 This document is mostly intended for vehicle manufacturers and manufacturers of alcohol interlocks.
76 This document does not apply to:
77 — the process of handling the installation documents;
78 — the installation process;
79 — information related to education and training for installers;
80 — general performance requirements for alcohol interlocks (see EN 50436-1 and EN 50436-2);
81 — the installation of the alcohol interlock during the production of the vehicle.
82 2 Normative references
83 The following documents are referred to in the text in such a way that some or all of their content constitutes
84 requirements of this document. For dated references, only the edition cited applies. For undated references,
85 the latest edition of the referenced document (including any amendments) applies.
86 EN 50436-1:2014, Alcohol interlocks - Test methods and performance requirements - Part 1: Instruments for
87 drink-driving-offender programs
88 EN 50436-2:2014, Alcohol interlocks - Test methods and performance requirements - Part 2: Instruments
89 having a mouthpiece and measuring breath alcohol for general preventive use
90 EN ISO 216, Writing paper and certain classes of printed matter - Trimmed sizes - A and B series, and
91 indication of machine direction (ISO 216)
92 ISO 16750-2:2012, Road vehicles — Environmental conditions and testing for electrical and electronic
93 equipment — Part 2: Electrical loads
94 3 Terms and definitions
95 For the purposes of this document, the following terms and definitions apply.
96 ISO and IEC maintain terminology databases for use in standardization at the following addresses:
97 — ISO Online browsing platform: available at https://www.iso.org/obp/
98 — IEC Electropedia: available at https://www.electropedia.org/
