EN 12449:2016

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Baker in bakrove zlitine - Nevarjene cevi z okroglim prerezom za splošno uporaboKupfer und Kupferlegierungen - Nahtlose Rundrohre zur allgemeinen VerwendungCuivre et alliages de cuivre - Tubes ronds sans soudure pour usages générauxCopper and copper alloys - Seamless, round tubes for general purposes77.150.30Bakreni izdelkiCopper products23.040.15Cevi iz neželeznih kovinNon-ferrous metal pipesICS:Ta slovenski standard je istoveten z:EN 12449:2016SIST EN 12449:2016en,fr,de01-julij-2016SIST EN 12449:2016SLOVENSKI
STANDARDSIST EN 12449:20121DGRPHãþD

EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 12449
May
t r s x ICS
t uä r v rä s w Supersedes EN
s t v v {ã t r s tEnglish Version
Copper and copper alloys æ Seamlessá round tubes for general purposes Cuivre et alliages de cuivre æ Tubes ronds sans soudure pour usages généraux
Kupfer und Kupferlegierungen æ Nahtlose Rundrohre zur allgemeinen Verwendung This European Standard was approved by CEN on
t z February
t r s xä
egulations which stipulate the conditions for giving this European Standard the status of a national standard without any alterationä Upætoædate lists and bibliographical references concerning such national standards may be obtained on application to the CENæCENELEC Management Centre or to any CEN memberä
translation under the responsibility of a CEN member into its own language and notified to the CENæCENELEC Management Centre has the same status as the official versionsä
CEN members are the national standards bodies of Austriaá Belgiumá Bulgariaá Croatiaá Cyprusá Czech Republicá Denmarká Estoniaá Finlandá Former Yugoslav Republic of Macedoniaá Franceá Germanyá Greeceá Hungaryá Icelandá Irelandá Italyá Latviaá Lithuaniaá Luxembourgá Maltaá Netherlandsá Norwayá Polandá Portugalá Romaniaá Slovakiaá Sloveniaá Spainá Swedená Switzerlandá Turkey and United Kingdomä
EUROPEAN COMMITTEE FOR STANDARDIZATION COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
CEN-CENELEC Management Centre:
Avenue Marnix 17,
B-1000 Brussels
t r s x CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Membersä Refä Noä EN
s t v v {ã t r s x ESIST EN 12449:2016

or Tube EN 12449 —
CW352H
— H075 — OD22 × 2,0 Denomination Number of this European Standard Material designation Material condition designation Nominal cross-sectional dimensions in millimetres SIST EN 12449:2016

Tube EN 12449 — CuZn37 — MS — ID30 × 2,5
or
Tube EN 12449 — CW508L — MS — ID30 × 2,5 5 Ordering information In order to facilitate the enquiry, order and confirmation of order procedures between the purchaser and the supplier, the purchaser shall state on his enquiry and order the following information: a) quantity of product required (number of pieces, length or mass); b) denomination (Tube); c) number of this European Standard (EN 12449); d) material designation (see Tables 1 to 8); e) material condition designation (see 4.2 and Tables 9 to 15) if it is other than M; f) nominal cross-sectional dimensions [either outside diameter (OD) and wall thickness or inside diameter (ID) and wall thickness] (see 6.3); g) length, either nominal together with tolerance required, or fixed length (see 6.3.4). NOTE 1 It is advised that the product designation, as described in 4.3, is used for items b) to f). In addition, the purchaser shall also state on the enquiry and order any of the following, if required: h) whether the tubes are for sea water application (see Table 3). If so, the composition limits required; i) test method to be used for the measurement of hardness, i.e. Vickers or Brinell (see 8.3); j) where dimensional tolerances are to be applied, if not on the outside diameter and wall thickness (see 6.3.1); k) whether the tubes are required to pass a drift expanding test (see 6.5.1); l) whether the tubes are required to pass a stress corrosion resistance test (see 6.5.2); m) whether the tubes are required to meet a grain size requirement (see 6.5.3); if so, the grain size limits required; NOTE 2 It is advised to agree the grain size limits between the purchaser and the supplier. n) whether the tubes are required to pass freedom from defects tests (see 6.5.4); if so, which test method is to be used (see 8.5), if the choice is not to be left to the discretion of the supplier, and the acceptance criteria if they are not to be left to the discretion of the supplier; o) whether deburring is required (see 6.4); p) whether special surface quality is required (see 6.4); SIST EN 12449:2016

1 000 m Tube EN 12449 — CuNi10Fe1Mn — H075 — OD22 × 2,0
— fixed length 3 000 mm
or
1 000 m Tube EN 12449 — CW352H — H075 — OD22 × 2,0
— fixed length 3 000 mm 6 Requirements 6.1 Composition The composition shall conform to the requirements for the appropriate material given in Tables 1 to 8. 6.2 Mechanical properties The properties shall conform to the appropriate requirements given in Tables 9 to 15. The tests shall be carried out in accordance with either 8.2 (tensile test) or 8.3 (hardness test). Products in stress relieved condition shall conform to the same mechanical property requirements as for non stress relieved material. 6.3 Dimensions and tolerances 6.3.1 General The geometrical properties of the tubes are defined by outside diameter or inside diameter, wall thickness and length. Normally, tolerances for cross-sectional dimensions are applied on the outside diameter (see 6.3.2) and wall thickness (see 6.3.3) but other possibilities may be agreed between the purchaser and the supplier at the time of the enquiry and order [see Clause 5, list entry j)]. Normally, tubes are supplied in lengths with tolerances agreed between the purchaser and the supplier at the time of the enquiry and order [see Clause 5, list entry g)] but tubes may be ordered as "fixed lengths" (see 6.3.4). 6.3.2 Outside or inside diameter The diameter of the tubes shall conform to the tolerances given in Table 17. 6.3.3 Wall thickness The wall thickness, measured at any point, shall conform to the tolerances given in Table 18. SIST EN 12449:2016
...
