EN 10305-3:2010

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Präzisionsstahlrohre - Technische Lieferbedingungen - Teil 3: Geschweißte maßgewalzte RohreTubes de précision en acier - Conditions techniques de livraison - Partie 3: Tubes soudés calibrésSteel tubes for precision applications - Technical delivery conditions - Part 3: Welded cold sized tubes77.140.75Jeklene cevi in cevni profili za posebne nameneSteel pipes and tubes for specific useICS:Ta slovenski standard je istoveten z:EN 10305-3:2010SIST EN 10305-3:2010en01-marec-2010SIST EN 10305-3:2010SLOVENSKI
STANDARDSIST EN 10305-3:20031DGRPHãþD

EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 10305-3
January 2010 ICS 77.140.75 Supersedes EN 10305-3:2002English Version
Steel tubes for precision applications - Technical delivery conditions - Part 3: Welded cold sized tubes
Tubes de précision en acier - Conditions techniques de livraison - Partie 3 : Tubes soudés calibrés à froid
Präzisionsstahlrohre - Technische Lieferbedingungen -Teil 3: Geschweißte maßgewalzte Rohre This European Standard was approved by CEN on 22 November 2009.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2010 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 10305-3:2010: ESIST EN 10305-3:2010

Technical delivery conditions, consists of the following parts:  Part 1: Seamless cold drawn tubes  Part 2: Welded cold drawn tubes  Part 3: Welded cold sized tubes  Part 4: Seamless cold drawn tubes for hydraulic and pneumatic power systems  Part 5: Welded cold sized square and rectangular tubes  Part 6: Welded cold drawn tubes for hydraulic and pneumatic power systems According to the CEN/CENELEC Internal Regulations, the national standards organizations of the following countries are bound to implement this European Standard: Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and the United Kingdom.
NOTE This document may also be applied to other types (excluding square and rectangular) of cross section. Tubes according to this document are characterized by having precisely defined tolerances on dimensions and a specified maximum surface roughness. Typical fields of application are in the vehicle, furniture and general engineering industries. 2 Normative references The following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 10020:2000, Definition and classification of grades of steel EN 10021:2006, General technical delivery conditions for steel products EN 10027-1, Designation systems for steels — Part 1: Steel names EN 10027-2, Designation systems for steels — Part 2: Numerical system EN 10052:1993, Vocabulary of heat treatment terms for ferrous products EN 10168, Steel products — Inspection documents — List of information and description EN 10204, Metallic products — Types of inspection documents EN 10246-11), Non-destructive testing of steel tubes — Part 1: Automatic electromagnetic testing of seamless and welded (except submerged arc-welded) ferromagnetic steel tubes for verification of hydraulic leak-tightness EN 10246-32), Non-destructive testing of steel tubes — Part 3: Automatic eddy current testing of seamless and welded (except submerged arc-welded) steel tubes for the detection of imperfections EN 10246-53), Non-destructive testing of steel tubes — Part 5: Automatic full peripheral magnetic transducer/flux leakage testing of seamless and welded (except submerged arc welded) ferromagnetic steel tubes for the detection of longitudinal imperfections
1) Under revision to become EN ISO 10893-1, Non-destructive testing of steel tubes
Part 1: Automated electromagnetic testing of seamless and welded (except submerged arc-welded) steel tubes for the verification of hydraulic leak-tightness instead of the hydrostatic test (ISO/DIS 10893-1:2009). 2) Under revision to become EN ISO 10893-2, Non-destructive testing of steel tubes
Part 2: Automated eddy current testing of seamless and welded (except submerged arc-welded) steel tubes for the detection of imperfections (ISO/DIS 10893-2:2009). 3) Under revision to become EN ISO 10893-3, Non-destructive testing of steel tubes
Part 3: Automated full peripheral flux leakage testing of seamless and welded (except submerged arc-welded) ferromagnetic steel tubes for the detection of longitudinal and/or transversal imperfections (ISO/DIS 10893-3:2009). SIST EN 10305-3:2010

(ISO 6892-1:2009) EN ISO 8492, Metallic materials — Tube — Flattening test (ISO 8492:1998) EN ISO 8493, Metallic materials — Tube — Drift-expanding test (ISO 8493:1998) 3 Terms and definitions For the purposes of this document, the terms and definitions given in EN 10020:2000, EN 10021:2006,
EN 10052:1993, EN 10266:2003 and the following apply. 3.1 employer organization for which a person works on a regular basis
NOTE The employer can be either the tube manufacturer or a third party organization providing non-destructive testing (NDT) services. 3.2 manufacturer party to produce and to deliver tubes in accordance with this document NOTE Where tubes are delivered by a supplier, see EN 10021:2006, Clause 6. 3.3
imperfection discontinuity in the wall or on the pipe surfaces detectable by methods described in this document
4) Under revision to become EN ISO 10893-10, Non-destructive testing of steel tubes
Part 10: Automated full peripheral ultrasonic testing of seamless and welded (except submerged arc-welded) steel tubes for the detection of longitudinal and/or transversal imperfections (ISO/DIS 10893-10:2009). 5) Under revision to become EN ISO 10893-11, Non-destructive testing of steel tubes
Part 11: Automated ultrasonic testing of weld seam of welded steel tubes for the detection of longitudinal and/or transversal imperfections (ISO/DIS 10893-11:2009). SIST EN 10305-3:2010

b) the steel number in accordance with EN 10027-2. 6 Information to be supplied by the purchaser 6.1 Mandatory information The following information shall be obtained by the manufacturer at the time of enquiry and order: a) the quantity (mass or total length or number); b) the term “tube”; c) the dimensions (see 8.5.1); d) the steel designation (see 5.2); e) the delivery condition including the surface condition (see 7.2.1 and 7.2.2); f) the length and the type of tube length (see 8.5.2). SIST EN 10305-3:2010

only (see 10.1); 24) more restrictive requirement on flattening test (see 11.2); 25) alternative marking (see Clause 12); 26) delivery without corrosion protection (see Clause 13); SIST EN 10305-3:2010

The tubes shall be manufactured from strip by electric welding. The tubes shall not contain strip end welds except for tubes to be supplied coiled for which the delivery conditions +A or +N may be specified.
Possible surface conditions are: a) S1 (black); b) S2 (pickled); c) S3 (cold rolled); d) S4 (coated to an agreed condition). NOTE The surface conditions S1 and S3 apply for the strip. The surface condition S2 and S4 may apply for the strip or the tube; the purchaser should, where necessary, indicate the required condition at the time of enquiry and order. 7.2.2
Tubes made of the steel grades E155, E195, E235, E275 and E355 shall be supplied in the delivery condition +CR1 or +A or +N (see Table 1). Tubes made of the grades E190, E220, E260, E320, E370 and E420 shall be supplied in the delivery condition +CR2. 7.2.3
All non-destructive testing (NDT) activities shall be carried out by qualified and competent level 1, 2 and/or 3 personnel authorized to operate by the employer.
The qualification shall be in accordance with EN 10256 or, at least, an equivalent to it. It is recommended that the level 3 personnel be certified in accordance with EN 473 or, at least, an equivalent to it. The operating authorization issued by the employer shall be in accordance with a written procedure. NDT operations shall be authorized by a level 3 NDT individual approved by the employer. SIST EN 10305-3:2010

Description Welded and cold sized +CR1
Normally not heat treated, but suitable for final annealing. b +CR2
Not intended for heat treatment after the welding and sizing. c Soft annealed +A After welding and sizing the tubes are annealed in a controlled atmosphere. Normalized +N After welding and sizing the tubes are normalized in a controlled atmosphere. a In accordance with EN 10027-1. b After annealing or normalizing, the resulting mechanical properties meet the requirements specified in Table 4 for the delivery condition +A or +N, respectively.
c If further heat treatment is applied, the resulting mechanical properties may be outside the specified
requirements. 8 Requirements 8.1 General The tubes, when supplied in a delivery condition indicated in Table 1 and inspected in accordance with Clauses 9, 10 and 11, shall comply with the requirements of this document. In addition, the general technical delivery requirements specified in EN 10021 apply. 8.2 Chemical composition The cast analysis reported by the steel producer shall apply and comply with the requirements of Table 2. A steel grade not specified in this document may be specified (see option 1). Option 1:
A steel grade not specified in this document with a maximum total content of alloying elements of
5 % and agreed chemical composition, mechanical properties and delivery condition, is specified. NOTE When subsequently welding tubes produced in accordance with this document, account should be taken of the fact that the behaviour of the steel during and after welding is dependent not only on the steel composition and the delivery condition, but also on the conditions of preparing for and carrying out the welding. Option 2: The composition of the specified steel grade shall be such that it is suitable for hot-dip galvanizing (see e.g. EN ISO 1461 for guidance). SIST EN 10305-3:2010
...
