EN 137:2006

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Respiratory protective devices - Self-contained open-circuit compressed air breathing apparatus with full face mask - Requirements, testing, markingAppareils de protection respiratoire - Appareils de protection respiratoire autonomes a circuit ouvert, a air comprimé avec masque complet - Exigences, essais, marquageAtemschutzgeräte - Behältergeräte mit Druckluft (Pressluftatmer) mit Vollmaske - Anforderungen, Prüfung, KennzeichnungTa slovenski standard je istoveten z:EN 137:2006SIST EN 137:2006en13.340.30Varovalne dihalne napraveRespiratory protective devicesICS:SIST EN 137:19961DGRPHãþDSLOVENSKI
STANDARDSIST EN 137:200601-december-2006

EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 137November 2006ICS 13.340.30Supersedes EN 137:1993
English VersionRespiratory protective devices - Self-contained open-circuitcompressed air breathing apparatus with full face mask -Requirements, testing, markingAppareils de protection respiratoire - Appareils deprotection respiratoire autonomes à circuit ouvert, à aircomprimé avec masque complet - Exigences, essais,marquageAtemschutzgeräte - Behältergeräte mit Druckluft(Pressluftatmer) mit Vollmaske - Anforderungen, Prüfung,KennzeichnungThis European Standard was approved by CEN on 22 September 2006.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the Central Secretariat or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the Central Secretariat has the same status as the officialversions.CEN members are the national standards bodies of Austria, Belgium, Cyprus, Czech Republic, Denmark, Estonia, Finland, France,Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania,Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2006 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 137:2006: E

Second medium pressure connector.32 A.1 General.32 A.2 Requirements.32

Ambient
air bypass device.34 B.1 General.34 B.2 Requirements.34 B.3 Information supplied by the manufacturer.34 Annex C (normative)
Requirements for static and dynamic pressure for apparatus with thread connector in accordance with EN 148-3.35 C.1 General.35 C.2 Static pressure.35 C.3 Dynamic pressure.35 C.4 Exhalation valve.35 C.5 Testing of dynamic pressure.36 Annex D (informative)
Marking.37 Annex ZA (informative)
Relationship between this European Standard and the Essential Requirements of EU Directive 89/686/EEC (PPE).38 Bibliography.41

1 Scope This European Standard specifies minimum performance requirements for self-contained open-circuit compressed air breathing apparatus with full face mask used as respiratory protective devices, except escape apparatus and diving apparatus. Such equipment is intended for use in work situations where the risk on over pressurisation of the pressure vessels with their valves due to hot environmental conditions is low. Laboratory and practical performance tests are included for the assessment of compliance with the requirements. 2 Normative references The following referenced documents are indispensable for the application of this European Standard. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 132:1998, Respiratory protective devices — Definitions of terms and pictograms EN 134:1998, Respiratory protective devices — Nomenclature of components EN 136:1998, Respiratory protective devices — Full face masks — Requirements, testing, marking EN 144-1, Respiratory protective devices — Gas cylinder valves — Part 1: Thread connections for insert connector EN 144-2, Respiratory protective devices — Gas cylinder valves — Part 2: Outlet connections EN 148-3, Respiratory protective devices — Threads for facepieces — Part 3: Thread connection M 45 x 3 EN 469, Protective clothing for firefighters — Performance requirements for protective clothing for firefighting EN 837-1:1996, Pressure gauges — Part 1: Bourdon tube pressure gauges — Dimensions, metrology, requirements and testing EN 12021, Respiratory protective devices — Compressed air for breathing apparatus EN 13274-2:2001, Respiratory protective devices — Methods of test — Part 2: Practical performance tests EN 13274-3, Respiratory protective devices — Methods of test — Part 3: Determination of breathing resistance EN 13274-4, Respiratory protective devices — Methods of test — Part 4: Flame tests EN 13274-5, Respiratory protective devices — Methods of test — Part 5: Climatic conditions EN 50020, Electrical apparatus for potentially explosive atmospheres — Intrinsic safety "i" EN 60079-0, Electrical apparatus for explosive gas atmospheres — Part 0: General requirements (IEC 60079-0:2004) EN 61000-6-2, Electromagnetic compatibility (EMC) — Part 6-2: Generic standards — Immunity for industrial environments (IEC 61000-6-2:2005)

The pressure vessels shall be charged to not more than 50 % of filling pressure during conditioning. Testing shall be done in accordance with 7.3. 7 Testing 7.1 General If no special measuring devices or measuring methods are specified commonly used methods and devices should be applied. Before performing tests involving human subjects account should be taken of any national regulations concerning the medical history, examination or supervision of the test subjects. Positive pressure apparatus shall be tested as complete apparatus including the full face mask as supplied by the applicant. If not otherwise specified, two apparatus shall be tested. 7.2 Nominal values and tolerances Unless otherwise specified the values stated in this European Standard are expressed as nominal values. Except for temperature limits, values which are not stated as maxima or minima shall be subject to a tolerance of ± 5 %. Unless otherwise specified the ambient temperature for testing shall be from 16 °C to 32 °C and the temperature limits shall be subject to an accuracy of ± 1 °C. 7.3 Visual inspection The visual inspection shall be made by the test house prior to laboratory or practical performance tests. This may entail a certain amount of dismantling in accordance with the manufacturer’s instructions for maintena
...
