EN 15254-2:2009

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Razširjena uporaba rezultatov preskusov požarne odpornosti - Nenosilne stene - 2. del: Zidovje in bloki iz mavcaErweiterter Anwendungsbereich der Ergebnisse aus Feuerwiderstandsprüfungen - Nichttragende Wände - Teil 2: Mauersteine und Gips-WandbauplattenApplication étendue des résultats d'essais de résistance au feu - Murs non porteurs - Partie 2: Maçonnerie et carreaux de plâtreExtended application of results from fire resistance tests - Non-loadbearing walls - Part 2: Masonry and Gypsum Blocks91.060.10Stene. Predelne stene. FasadeWalls. Partitions. Facades13.220.50Požarna odpornost gradbenih materialov in elementovFire-resistance of building materials and elementsICS:Ta slovenski standard je istoveten z:EN 15254-2:2009SIST EN 15254-2:2009en,de01-december-2009SIST EN 15254-2:2009SLOVENSKI
STANDARD
EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 15254-2July 2009ICS 13.220.50 English VersionExtended application of results from fire resistance tests - Non-loadbearing walls - Part 2: Masonry and Gypsum BlocksApplication étendue des résultats d'essais de résistance aufeu - Murs non porteurs - Partie 2: Maçonnerie et carreauxde plâtreErweiterter Anwendungsbereich der Ergebnisse ausFeuerwiderstandsprüfungen - Nichttragende Wände - Teil2: Mauersteine und Gips-WandbauplattenThis European Standard was approved by CEN on 16 May 2009.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the CEN Management Centre or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as theofficial versions.CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland,France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal,Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre:
Avenue Marnix 17,
B-1000 Brussels© 2009 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 15254-2:2009: ESIST EN 15254-2:2009

EN 771-4, Specification for masonry units — Part 4: Autoclaved aerated concrete masonry units EN 772-16, Methods of test for masonry units — Part 16: Determination of dimensions EN 998-1, Specification for mortar for masonry — Part 1: Rendering and plastering mortar EN 998-2, Specification for mortar for masonry — Part 2: Masonry mortar EN 1363-1, Fire resistance tests — Part 1: General requirements EN 1363-2, Fire resistance tests — Part 2: Alternative and additional procedures EN 1364-1, Fire resistance tests for non-loadbearing elements — Part 1: Walls EN 1996-1-1, Eurocode 6 — Design of masonry structures — Part 1-1: General rules for reinforced and unreinforced masonry structures EN 1996-1-2:2005, Eurocode 6 — Design of masonry structures — Part 1-2: General rules — Structural fire design EN 1996-3, Eurocode 6 — Design of masonry structures — Part 3: Simplified calculation methods for unreinforced masonry structures EN 12859, Gypsum blocks — Definitions, requirements and test methods EN 12860, Gypsum based adhesive for gypsum blocks — Definitions, requirements and test methods EN 13501-2, Fire classification of construction products and building elements — Part 2: Classification using data from fire resistance tests, excluding ventilation services EN 15318, Design and application of gypsum blocks SIST EN 15254-2:2009

3.2 historic test data test data generated by fire resistance tests that have been undertaken by an accredited and/or Notified Test Laboratory or by a laboratory officially recognised by national fire authorities in accordance with European and/or former and current national standards based on the temperature-time curve identical to the one specified in EN 1363-1 (and defined in ISO 834)
NOTE 1 Previously existing test data is acceptable even though the test may not have been carried out using the plate thermometer.
NOTE 2 This data may only be used as described in this European Standard. NOTE 3 Previously existing test data is acceptable provided that there has been no change to the product since this data was generated.
3.3 reference test fire resistance test in accordance with EN 1364-1, and where applicable EN 1363-2, on which the extended application is based and the results of which are used as the main source of data for the extended application 3.4 test result outcome of a testing process and its associated procedures detailed within a specific test standard (which may include some processing of the results from the testing of a number of specimens) NOTE A test result is expressed in terms of one or more fire performance parameter(s). 4 General principles 4.1 General (1) The fire resistance behaviour of masonry mainly depends on:  masonry unit material - clay, calcium silicate, autoclaved aerated concrete, dense/lightweight aggregate concrete or gypsum;  type of unit - solid or hollow (type of holes, percentage and direction of holes), shell and web thickness;  dimensions of units, especially the height;  gross density of units;  strength of units;  type of mortar - general purpose, thin layer or lightweight mortar;  type of perpend joint – filled or unfilled perpend joint, especially for unplastered walls;  use of finishes; SIST EN 15254-2:2009

(5) Whenever a parameter change goes beyond the limits defined in this document, a new reference test is needed. 4.2 Classifications In some cases there are different extended application rules given for the classifications EI, E and E-W respectively and for the classification EI-M as defined in EN 13501-2. 4.3 Additional information For the classification according to these extended application rules additional information on material properties and additional measurements during the test procedure according to EN 1363-1, EN 1364-1 and EN 1363-2 or historic standard national fire test methods are necessary:  measurement of the deflection of the test specimen at least in mid height, to allow for an extrapolation for height, see 5.5 4;  gross dry density, compressive strength and moisture content of the units (i.e. difference between density of the units at the start of the fire test and the gross dry density of the units, related to the gross dry density of the units, in percent by mass);
 percentage of voids, web and shell thickness and combined thickness according to EN 772-16 for perforated units;  gross dry density and compressive strength of the mortar;  thickness of unfilled perpend joints in unplastered or unrendered walls;  thickness and type of plaster or render in rendered walls. NOTE The measurement of the temperature within the test specimen at least in mid height across the wall thickness is advised to allow for a future calculation of fire resistances according to EN 1996-1-2. Thermocouples should be placed at least in depths of 10, 30 and 50 mm from the exposed side and then every 50 mm.
...
