ASTM F3627-24

This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: F3627 − 23 F3627 − 24
Standard Guide for
Premises Design Considering Snow and Ice Management
for the Reduction of Pedestrian Slips
This standard is issued under the fixed designation F3627; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope
1.1 This guide covers design, planning, construction, renovation, maintenance, and risk management considerations of the
physical exterior property with regard to snow and ice management for the purpose of reducing the risk of pedestrian slips. The
provisions in this guide may also apply to the analysis of existing properties.
1.2 Conformance with this guide may reduce, but will not eliminate, the potential for slip incidents in which the presence or
accumulation of snow and ice on walkways may be a contributing factor.
1.3 Units—The values stated in inch-pound units are to be regarded as the standard. The values given in parentheses are
mathematical conversions to SI units that are provided for information only and are not considered standard.
1.4 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility
of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of
regulatory limitations prior to use.
1.5 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
2. Referenced Documents
2.1 ASTM Standards:
F1646 Terminology Relating to Walkway Safety and Footwear
F2966 Guide for Snow and Ice Control for Walkway Surfaces
2.2 ANSI Standards:
ANSI/ASCA A1000 System Requirements for Snow and Ice Management Services
ANSI/NEMA Z535.2 Standard for Environmental and Facility Safety Signs
ANSI/SIMA-10-2020 Standard Practice for Procuring and Planning Snow and Ice Management Services
This guide is under the jurisdiction of ASTM Committee F13 on Pedestrian/Walkway Safety and Footwear and is the direct responsibility of Subcommittee F13.50 on
Walkway Surfaces.
Current edition approved Oct. 15, 2023Feb. 1, 2024. Published November 2023February 2024. Originally approved in 2023. Last previous edition approved in 2023 as
F3627 – 23. DOI: 10.1520/F3627-23.10.1520/F3627-24.
For referenced ASTM standards, visit the ASTM website, www.astm.org, or contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM Standards
volume information, refer to the standard’s Document Summary page on the ASTM website.
Available from American National Standards Institute (ANSI), 25 W. 43rd St., 4th Floor, New York, NY 10036, http://www.ansi.org.
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
F3627 − 24
3. Terminology
3.1 Definitions—See Terminology F1646 for the following terms used in this practice: element, fair, ramp, sidewalk, slip resistant,
walkway, and walkway surface hardware.
3.2 Definitions:
3.2.1 anti-icing, v—the process of applying an appropriate granular or liquid deicing product prior to the onset of a snow or ice
event to make a reasonable effort to prevent the bonding of snow/ice to pavement or concrete surfaces. ANSI/ASCA A1000
3.3 Definitions of Terms Specific to This Standard:
3.2.1 anti-icing, v—the process of applying an appropriate granular or liquid deicing product prior to the onset of a snow or ice
event to make a reasonable effort to prevent the bonding of snow/ice to pavement or concrete surfaces. ANSI/ASCA A1000
3.3.1 anti-icing materials, n—dry or liquid snow and ice control materials applied before a snow or ice event intended to prevent
precipitation from bonding with the pavement/walkway surface or weaken bonds formed for easier removal.
3.3.2 bonding, n—process of snow or ice adhering to an underlying surface.
3.3.3 deicing materials, n—snow- and ice-melting products applied on top of a layer of snow or ice or both that may be bonded
to the underlying surface.
3.3.4 drainage path, n—the route excess surface water or groundwater flows from land by means of gutters, ditches, pipes,
culverts, manmade and natural channels, or subsurface drains.
3.3.5 obstructions, n—low roadway/walkway objects that may be hit by plows.
3.3.5.1 Discussion—
Examples of obstructions include wheel stops, speed bumps, protruding drainage and utility features, landscape islands/curbs,
accessible ramps, built-up curb ramps (ramps protruding from the face of the curb into the parking lot), low-lying vegetation, cart
corrals, light posts, and signposts.
3.3.6 refreeze conditions, n—circumstances or factors that can cause snow or ice that has been melted or thawed to freeze again.
3.3.7 snow pile, n—accumulation of piled snow that has been relocated or removed from another location (also referred to as
stockpiled snow).
4. Summary of Guide
4.1 This guide addresses planning, risk management, design, construction, renovation, and ongoing maintenance of walkways in
areas exposed to snow, ice, and temperatures that can result in the formation of ice on walkways. The reduction of snow and ice
accumulation on walkways should aid in reducing the risk of slip incidents.
5. Significance and Use
5.1 This guide is intended to act as an aid during the planning, risk management, design, renovation, construction, and ongoing
maintenance phases of a project by persons/entities involved (including, engineers, architects, project management personnel/
facilities management, contractors, inspectors, risk managers, safety committees, government agencies, and snow removal
companies and owners) to reduce snow and ice slip hazards on walkway surfaces. This guide is also intended to complement
aspects from Guide F2966 to promote the management of snow and ice on premises using prevention through design strategies.
6. Procedure
6.1 Evaluate jurisdictional requirements during design and site analysis, which could include snow pile placement and the use of
de-icing or anti-icing materials.
6.2 Site Design:
F3627 − 24
6.2.1 Site Snow and Ice Assessment—The entity that is designing or planning spaces with walkway surfaces should assess weather
patterns for typical and worst-case scenarios of ice and snowfall accumulation, including the effect of seasonal accumulation, so
that the frequency and amount of snow and ice are part of the design criteria.
6.2.2 Site Design to Avoid or Minimize Snow and Ice Accumulation—Some surfaces, such as permeable pavements and heated
pavements may reduce the accumulation of snow and ice. Such systems must be installed and maintained in accordance with
manufacturers’ instructions to perform as intended (that is, use of sand is not recommended on permeable pavements to eliminate
clogging).
6.2.3 Site Feature Layout—During the initial phases of site layout, the purpose and intended function(s) of the site should remain
paramount in the design process. The typical layout of site features includes considerations for required parking, egress discharge
routes, accessibility, loading and unloading, and both vehicular and pedestrian circulation.
6.2.4 Snow Pile Placement—The design of parking and walkway facilities should consider snow pile placement to minimize the
impacts of snow and ice on pedestrian safety. Following snow accumulations, snow piles may be required to be created within or
around the parking lot and premises. It is recommended that down gradient or drained lawn areas or landscaped buffer areas
adjacent to parking areas be provided for snow pile storage as the primary design option. Snow piles that should be placed on
parking facilities may reduce the parking capacity of the parking lot and, therefore, consideration should be given to the potential
location and size of these piles. With snow pile storage, the effects of prevailing winds/blowing snow should also be considered.
The addition of subsequent snowfall should also be taken into consideration, allowing room for such when practical. Parking stalls
should be arranged such that the furthest parking stalls from these facilities are unobstructed and easily accessible to snow-plowing
equipment and are readily drained without water draining across drive aisles and other walkways. One example of this is avoiding
the placement of undrained islands at the ends of parking stall aisles in parking areas where meltwater accumulations can refreeze.
6.2.4.1 Typically, snow pile size is determined by the amount of snow being piled, the size of the area being cleared, and the
equipment used to create the pile.
6.2.4.2 Snow removal from a site as a primary means of control should only be considered for properties where no snow storage
is possible or the design recommendations to limit refreezing hazards cannot be implemented.
6.2.4.3 Piles should be placed away from buildings and site features that will be accessed by those visiting the site and in areas
that will not drain onto or across pedestrian pathways (minimizing intrusion on driving lanes and pedestrian walkways).
6.2.4.4 Snow pile placement should not adversely impact pedestrian lines of sight.
6.2.4.5 Snow pile placement should not adversely impact vehicular lines of sight.
6.2.5 Initial Grading and Drainage Layout—Having considered the placement of snow piles in initial horizontal lot layout, this
consideration should continue in the initial grading analysis of a site. Typically, grading design of a site is an iterative process that
requires consideration of the surrounding roadways, adjacent properties, and their uses and drainage characteristics with the intent
to develop grading lines across the site that connect these features to determine the initial site grading. This iterative process usually
results in the determination of basic parking lot and walkway grading and their interaction with finished floor elevations of
buildings and other control grades throughout the site. Throughout this process, snow pile storage locations and catch basin layouts
should be continually considered. The following are a few principles that will help in this regard:
6.2.5.1 Meltwater from snow piles should flow to a drainage feature and away from walkways,
6.2.5.2 Site design should consider obstructions to snow removal and snow storage,
6.2.5.3 Grades should create conditions of water flow away from buildings to a drainage path consistent with jurisdictionally
adopted codes, and
6.2.5.4 Grading should direct meltwater away from parking and walkway surfaces.
6.2.6 For developed sites with onsite catch basins, snow piles should be placed either at the lowest point near the basin or adjacent
to storm drains feeding to the basin. Care should be taken not to:
F3627 − 24
6.2.6.1 Block or cover storm drain inlets,
6.2.6.2 Stockpile snow directly into basins,
6.2.6.3 Block or cover the inlet or outlet within the basin, and
6.2.6.4 Locate stockpiled snow that will drain across or onto a walkway and potentially refreeze.
6.2.7 Features to Avoid—Parking lot features that may impede efficient snow removal operations include wheel stops,
ground-mounted signs, lighting without foundations above grade, and other obstructions. While it is common practice to provide
stakes d
...
