EN 474-1:2006+A3:2013

SLOVENSKI STANDARD
01-januar-2014
Stroji za zemeljska dela - Varnost - 1. del: Splošne zahteve
Earth-moving machinery - Safety - Part 1: General requirements
Erdbaumaschinen - Sicherheit - Teil 1: Allgemeine Anforderungen
Engins de terrassement - Sécurité - Partie 1: Prescriptions générales
Ta slovenski standard je istoveten z: EN 474-1:2006+A3:2013
ICS:
53.100 Stroji za zemeljska dela Earth-moving machinery
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

EUROPEAN STANDARD
EN 474-1:2006+A3
NORME EUROPÉENNE
EUROPÄISCHE NORM
March 2013
ICS 53.100 Supersedes EN 474-1:2006+A1:2009
English Version
Earth-moving machinery - Safety - Part 1: General requirements
Engins de terrassement - Sécurité - Partie 1: Prescriptions Erdbaumaschinen - Sicherheit - Teil 1: Allgemeine
générales Anforderungen
This European Standard was approved by CEN on 17 April 2006 and includes Amendment 1 approved by CEN on 4 January 2009 and
Amendment 3 approved by CEN on 6 January 2013.

CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European
Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national
standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.

This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under
the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the
official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland,
Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta,
Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and United Kingdom.

EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMAL IS A T IO N

EUROPÄISCHES KOMITEE FÜR NORMUN G

Management Centre: Avenue Marnix 17, B-1000 Brussels
© 2013 CEN All rights of exploitation in any form and by any means reserved worldwide Ref. No. EN 474-1:2006+A3:2013: E
for CEN national Members.
Contents Page
Foreword . 3
Introduction . 5
1 Scope . 6
2 Normative references . 6
3 Terms and definitions . 9
4 List of significant hazards . 10
5 Safety requirements and/or measures . 11
6 Verification of safety requirements/measures . 29
7 Information for use . 29
Annex A (normative) List of significant hazards . 34
Annex B (normative) Requirements for attachment and attachment bracket . 38
Annex C (informative) Requirements for no-text safety signs . 41
Annex D (normative) Requirements for elevating operator's station . 44
Annex E (normative) Requirements for lifting device(s) used for object handling application . 46
Annex F (normative) Requirements for earth-moving machinery used in underground working in
non-explosive atmosphere . 53
%Annex ZA& (informative) !Relationship between this European Standard and the Essential
Requirements of EU Directive 2006/42/EC . 56
Bibliography. 57

Foreword
This document (EN 474-1:2006+A3:2013) has been prepared by Technical Committee CEN/TC 151
“Construction equipment and building material machines — Safety”, the secretariat of which is held by DIN.
This European Standard shall be given the status of a national standard, either by publication of an identical
text or by endorsement, at the latest by September 2013, and conflicting national standards shall be
withdrawn at the latest by September 2013.
Attention is drawn to the possibility that some of the elements of this document may be the subject of patent
rights. CEN [and/or CENELEC] shall not be held responsible for identifying any or all such patent rights.
This document includes Amendment 1, approved by CEN on 2009-01-04 and Amendment 3, approved by
CEN on 2013-01-06.
This European Standard supersedes %EN 474-1:2006+A1:2009&.
The start and finish of text introduced or altered by amendment is indicated in the text by tags   and
%&.
This document has been prepared under a mandate given to CEN by the European Commission and the
European Free Trade Association, and supports essential requirements of EU Directive.
!For relationship with EU Directive(s), see %informative Annex ZA&, which are integral parts of this
document."
EN 474 "Earth-moving machinery — Safety" comprises the following parts:
 Part 1: General requirements
 Part 2: Requirements for tractor-dozers
 Part 3: Requirements for loaders
 Part 4: Requirements for backhoe-loaders
 Part 5: Requirements for hydraulic excavators
 Part 6: Requirements for dumpers
 Part 7: Requirements for scrapers
 Part 8: Requirements for graders
 Part 9: Requirements for pipe-layers
 Part 10: Requirements for trenchers
 Part 11: Requirements for earth and landfill compactors
 Part 12: Requirements for cable excavators
For specific machines covered by other parts of the standard, this European Standard is intended for use in
combination with relevant other parts of the series.
According to the CEN/CENELEC Internal Regulations, the national standards organisations of the following
countries are bound to implement this European Standard: Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech
Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece,
Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal,
Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and the United Kingdom.

Introduction
This part of EN 474 is a type C standard as stated in EN ISO 12100-1:2003.
The machinery concerned and the extent to which hazards, hazardous situations and events are covered are
indicated in the scope of this European Standard.
When provisions of this type C standard are different from those which are stated in type A or B standards, the
provisions of this type C standard take precedence over the provisions of the other standards, for machines
that have been designed and built according to the provisions of this type C standard.
1 Scope
1 )
This %European Standard& specifies the general safety requirements for earth-moving machinery
described in EN ISO 6165:2006, except rollers and horizontal directional drill.
NOTE 1 Rollers are covered by EN 500.
NOTE 2 Horizontal directional drills are covered by EN 791.
This %European Standard& also applies to derivative machinery (see 3.1.2) designed primarily for use
with equipment to loosen, pick-up, move, transport, distribute and grade earth and rock.
This %European Standard& gives the common safety requirements for earth-moving machinery families
and is intended to be used in conjunction with one of the EN 474 parts 2 to 12. These machine specific parts
(EN 474-2 to -12) do not repeat the requirements from !EN 474-1:2006+A1:2009", but add or replace the
requirements for the family in question.
NOTE 3 The requirements specified in this part of the standard are common to two or more families of earth- moving
machinery.
Specific requirements in EN 474 parts 2 to 12 take precedence over the respective requirements of
!EN 474-1:2006+A1:2009".
For multipurpose machinery the parts of the standard that cover the specific functions and applications have
to be used e.g. a compact loader also used as a trencher shall use the relevant requirements of EN 474 parts
1, 3 and 10.
The standard also covers general requirements for attachments intended to be used with earth moving
machine families covered in the scope.
!Except for part 12 this European Standard does not deal" with the electrical hazards related to the main
circuits and drives of machinery when the principal source of energy is electrical.
!This European Standard does not deal with towing of trailers."
This European Standard deals with all significant hazards, hazardous situations and events relevant to earth-
moving machinery, when used as intended and under conditions of misuse which are reasonably foreseeable
by the manufacturer (see Clause 4). This European Standard specifies the appropriate technical measures to
eliminate or reduce risks arising from the significant hazards, hazardous situations and events during
commissioning, operation and maintenance of earth-moving machinery.
This European Standard is not applicable to earth moving machines, which are manufactured before the date
of publication of this European Standard by CEN.
2 Normative references
%The following documents, in whole or in part, are normatively referenced in this document and are
indispensable for its application. For dated references, only the edition cited applies. For undated references,
the latest edition of the referenced document (including any amendments) applies.&
EN 286-2:1992, Simple unfired pressure vessels designed to contain air or nitrogen — Part 2: Pressure
vessels for air braking and auxiliary systems for motor vehicles and their trailers

1) For travelling on public roads the national traffic regulations apply until harmonised requirements are available. (A
CEN-standard is under preparation.)
EN 287-1:2004, Qualification test of welders — Fusion welding — Part 1: Steels
!deleted text"
EN 982:1996, Safety of machinery — Safety requirements for fluid power systems and their components —
Hydraulics
EN 1677-2:2000, Components for slings — Safety — Part 2: Forged steel lifting hooks with latch, Grade 8
!EN 12643:1997+A1:2008", Earth-moving machinery — Rubber-tyred machines — Steering
requirements (ISO 5010:1992, modified)
EN 13309:2000, Construction machinery — Electromagnetic compatibility of machines with internal electrical
power supply
!deleted text"
EN 60529:1991, Degrees of protection provided by enclosures (IP code) (IEC 60529:1989)
EN 61310-1:1995, Safety of machinery — Indication, marking and actuation — Part 1: Requirements for
visual, auditory and tactile signals (IEC 61310-1:1995)
EN ISO 2860:1999, Earth-moving machinery — Minimum access dimensions (ISO 2860:1992)
EN ISO 2867:2006, Earth-moving machinery — Access systems (ISO 2867:2006)
!EN ISO 3411:2007, Earth-moving machinery — Physical dimensions of operators and minimum operator
space envelope (ISO 3411:2007)"
!EN ISO 3449:2008, Earth-moving machinery — Falling-object protective structures — Laboratory tests and
performance requirements (ISO 3449:2005)"
EN ISO 3450:1996, Earth-moving machinery — Braking systems of rubber-tyred machines — System and
performance requirements and test procedures (ISO 3450:1996)
EN ISO 3457:2003, Earth-moving machinery — Guards — Definitions and requirements (ISO 3457:2003)
!EN ISO 3471:2008, Earth-moving machinery — Roll-over protective structures — Laboratory tests and
performance requirements (ISO 3471:2008)"
EN ISO 4871:1996, Acoustics — Declaration and verification of noise emission values of machinery and
equipment (ISO 4871:1996)
EN ISO 5353:1998, Earth-moving machinery, and tractors and machinery for agriculture and forestry — Seat
index point (ISO 5353:1995)
EN ISO 6165:2006, Earth-moving machinery — Basic types — !deleted text" Identification and terms and
definitions (ISO 6165:2006)
EN ISO 6682:1995, Earth-moving machinery — Zones of comfort and reach for controls (ISO 6682:1986
including Amendment 1:1989)
EN ISO 6683:2005, Earth-moving machinery — Seat belts and seat belt anchorages — Performance
requirements and tests (ISO 6683:2005)
EN ISO 7096:2000, Earth-moving machinery — Laboratory evaluation of operator seat vibration
(ISO 7096:2000)
!EN ISO 11688-1:1998, Acoustics — Recommended practice for the design of low-noise machinery and
equipment — Part 1: Planning (ISO/TR 11688-1:1995)"
EN ISO 12100-1:2003, Safety of machinery — Basic concepts, general principles for design — Part 1: Basic
terminology, methodology (ISO 12100-1:2003)
EN ISO 12100-2:2003, Safety of machinery — Basic concepts, general principles for design — Part 2:
Technical principles (ISO 12100-2:2003)
EN ISO 13732-1:2006, Ergonomics of the thermal environment — Methods for the assessment of human
responses to contact with surfaces — Part 1: Hot surfaces (ISO 13732-1:2006)
!EN ISO 13849-1:2008, Safety of machinery — Safety-related parts of control systems — Part 1: General
principles for design (ISO 13849-1:2006)"
ISO 3795:1989, Road vehicles, and tractors and machinery for agriculture and forestry — Determination of
burning behaviour of interior materials
ISO 3864-1:2002, Graphical symbols — Safety colours and safety signs — Part 1: Design principles for safety
signs in work places and public areas
ISO 3864-2:2004, Graphical symbols — Safety colours and safety signs — Part 2: Design principles for
product safety labels
!ISO 4250-3:2006", Earth-mover tyres and rims — Part 3: Rims
ISO 5006:2006, Earth-moving machinery — Operator's field of view — Test method and performance criteria
ISO 6011:2003, Earth-moving machinery — Visual display of machine operation
ISO 6014:1986, Earth-moving machinery — Determination of ground speed
ISO 6016:1998, Earth-moving machinery — Methods of measuring the masses of whole machines, their
equipment and components
!ISO 6395:2008, Earth-moving machinery — Determination of sound power level — Dynamic test
conditions"
!ISO 6396:2008", Earth-moving machinery — Determination of emission sound pressure level at
operator's position — Dynamic test conditions
ISO 6405-1:2004, Earth-moving machinery — Symbols for operator controls and other displays — Part 1:
Common symbols
ISO 6405-2:1993, Earth-moving machinery — Symbols for operator controls and other displays — Part 2:
Specific symbols for machines, equipment and accessories
ISO 6749:1984, Earth-moving machinery — Preservation and storage
ISO 8643:1997, Earth-moving machinery — Hydraulic excavator and backhoe loader boom-lowering control
device — Requirements and tests
ISO 9533:1989, Earth-moving machinery — Machine mounted forward and reverse audible warning alarm —
Sound test method
!ISO/DIS 10263-2:2007, Earth-moving machinery — Operator enclosure environment — Part 2: Air filter
element test method"
!ISO/DIS 10263-3:2007, Earth-moving machinery — Operator enclosure environment — Part 3:
Pressurization test method"
!ISO/DIS 10263-4:2007, Earth-moving machinery — Operator enclosure environment — Part 4: Heating,
ventilating and air conditioning (HVAC) test method and performance"
ISO 10264:1990, Earth-moving machinery — Key-locked starting systems
!ISO 10265:2008", Earth-moving machinery — Crawler machines — Performance requirements and test
procedures for braking systems
ISO 10532:1995, Earth-moving machinery — Machine-mounted retrieval device — Performance requirements
ISO 10533:1993, Earth-moving machinery — Lift-arm support devices
ISO 10570:2004, Earth-moving machinery — Articulated frame lock — Performance requirements
ISO 10968:2004, Earth-moving machinery — Operator's controls
ISO 11112:1995, Earth-moving machinery — Operator's seat — Dimensions and requirements
ISO 11862:1993, Earth-moving machinery — Auxiliary starting aid electrical connector
ISO 12508:1994, Earth-moving machinery — Operator station and maintenance areas — Bluntness of edges
ISO 12509:2004, Earth-moving machinery — Lighting, signalling and marking lights, and reflex-reflector
devices
ISO 13333:1994, Earth-moving machinery — Dumper body support and operator's cab tilt support devices
ISO 14396:2002, Reciprocating internal combustion engines — Determination and method for the
measurement of engine power — Additional requirements for exhaust emission tests in accordance with
ISO 8178
ISO 14401-1:2004, Earth-moving machinery — Field of vision of surveillance and rear-view mirrors — Part 1:
Test methods
ISO 14401-2:2004, Earth-moving machinery — Field of vision of surveillance and rear-view mirrors — Part 2:
Performance criteria
ISO 15817:2005, Earth-moving machinery — Safety requirements for remote operator control
!ISO 15998:2008", Earth-moving machinery — Machine-control systems (MCS) using electronic
components — Performance criteria and tests for functional safety
3 Terms and definitions
For the purposes of this %document&, the terms and definitions given in EN ISO 12100-1:2003 and the
following apply.
Earth-moving machinery and their families are defined in EN ISO 6165:2006.
NOTE Definitions used in EN and ISO standards referred to in this European Standard are also valid for this
document.
3.1
earth-moving machinery
self-propelled or towed machine on wheels, crawler or legs, having equipment and/or attachment (working
tool), primarily designed to perform excavating, loading, transporting, spreading, compacting or trenching of
earth, rock or similar materials
NOTE An earth-moving machine is normally operated by a ride-on operator but can also be remote – or pedestrian –
controlled.
3.1.1
compact machine
earth-moving machinery having an operating mass (see ISO 6016:1998) of 4 500 kg or less, or compact
excavators having an operating mass (see ISO 6016:1998) of 6 000 kg or less
3.1.2
derivative machinery
earth-moving machinery fitted with equipment and/or attachment which modifies its function
NOTE For the European Economic Area (EEA) the equipment or attachment or a piece of equipment as defined in
ISO 6016:1998 which modifies the function of the machine and is intended to be assembled by the operator can be
"interchangeable equipment" in the sense of the Machinery Directive.
3.2
attachment (working tool)
component or assembly of components, which can be mounted onto the base machine or equipment
(see ISO 6746-1:2003, ISO 6746-2:2003 and ISO 6016:1998) for a specific use
3.3
attachment bracket
device to facilitate quick interchange of attachments
3.4
object handling
application of earth-moving machinery comprising lifting, lowering and transporting of a load by use of lifting
accessories, whereby the assistance of a person or the operator of the machine is required for hooking,
unhooking or stabilising (whilst transporting) the load
NOTE 1 If the load is picked-up by a self-acting device and no assistance of a person is required for hooking,
unhooking and stabilising the load, this work is considered as usual earth-moving application.
NOTE 2 Lifting accessories are, e.g., wire ropes, chains or textile straps; loads in object handling application are, e.g.,
pipes, vessels; self-acting devices are, e.g., grabs, clamshell buckets, log clamps, vacuum lifting device, magnetic plate
and fork.
3.5
maximum rated operating/lift capacity in object handling
maximum capacity which can be lifted at least in one position of the working range as specified by the
manufacturer (e.g. on the rated object handling capacity table) in the most stable configuration (e.g. outriggers
down)
NOTE The term "rated operating capacity" is defined in ISO 14397-1:2002 and used in
!EN 474-3:2006+A1:2009" and !EN 474-4:2006+A1:2009". The term "rated lift capacity" is defined in
ISO 10567:1992 and used in !EN 474-5:2006+A1:2009". Both terms are equivalent.
4 List of significant hazards
See Annex A.
NOTE Annex A (normative) contains all the significant hazards, hazardous situations and events, as far as they are
dealt with in this European Standard, identified by risk assessment as common to two or more machinery families and
which require action to eliminate or reduce the risk.
5 Safety requirements and/or measures
5.1 General
Earth-moving machinery shall comply with the safety requirements and/or protective measures of this
European Standard, as far as not modified by requirements of the relevant specific part of the standard series.
In addition, the machine shall be designed according to the principles of EN ISO 12100-1:2003 and
EN ISO 12100-2:2003 for hazards relevant but not significant which are not dealt with by this European
Standard.
5.2 Access
5.2.1 General requirements
Adequate access systems shall be provided to the operator's station and areas where routine maintenance
has to be performed by the operator as described in the operator's manual. Access system shall comply with
EN ISO 2867:2006.
Effect of mud on the means of access shall be minimised by adequate design.
5.2.2 Access to articulated machines
On machines with articulated frames and in the fully articulated steering position, a minimum clearance of 150
mm for the lower limbs shall be provided !between firm structures and components with" relative
movement in the path of the access systems to the operator's station, as illustrated in Figure 1.
Dimensions in millimetres
Figure 1 — Minimum clearance of lower limbs at access to the operator's station on machines with
articulated steering
5.2.3 Access system on crawler machines with step(s)
Access step(s) integrated in the track frame shall meet the requirements as stated below (see also Figure 2).
A step of an access system can be retracted under an angle of ≤ 15°, if at least the basic dimension of riser
height dimension B, and the tread depth F according to Figure 1 and Table 1 of EN ISO 2867:2006 is met,
measured from the outer edges of the track shoes.
In such a case, taken into account the limited view during egress, the step width shall be at least as wide as
the minimum in accordance with Table 1 of EN ISO 2867:2006.

Key
B ≤ 400 mm
F1 ≥ 130 mm
Q maximum retraction of a step
Figure 2 — Dimensions access step
5.3 Operator's station
5.3.1 General requirements
5.3.1.1 Machinery equipment
!The driving position of ride-on drivers shall be designed and constructed in such a way that a driver's cab
may be fitted, provided this does not increase the risk and there is room for it."
Machines with an operating mass less than 1 500 kg are not required to have a cab.
Machines with an operating mass greater than or equal to 1 500 kg shall be equipped with a cab, unless the
foreseeable adverse weather conditions allow all-year operation without a cab (negotiated between
manufacturer and user).
Machines shall be equipped with a cab and a contamination protective system if the machine is intended for
use in unhealthy environments, e.g. contaminated areas (negotiated between manufacturer and user).
See 5.14.1.
If a hazard due to projection of splinters exists, e.g. operation with a hydraulic- or demolition-hammer, an
adequate protection such as bullet proof glass, mesh guard or an equivalent protection is required.
5.3.1.2 Minimum space
The minimum space available to the operator shall be as defined in !EN ISO 3411:2007" (except as
amended in 5.3.2.5).
For compact machines the minimum space envelope width (dimension 920 mm in !EN ISO 3411:2007,
Figure 4") may be reduced to 650 mm.
The minimum space and location of the controls at the operator's station shall meet the requirements
specified in EN ISO 6682:1995.
5.3.1.3 Moving parts
Measures shall be taken to avoid accidental contact from the operating position with moving parts, e.g. the
wheels, or tracks or working equipment and/or attachment in accordance with relevant subclauses of 5.14.
5.3.1.4 Engine exhaust
The engine exhaust system shall release the exhaust gas away from the operator and the air inlet of the cab.
5.3.1.5 Instruction storage
A space intended for the safekeeping of the operator’s manual and other instructions shall be provided near
the operator's station. The space shall be lockable, unless the operator's station can be locked.
5.3.1.6 Sharp edges
The operator's space within the operator's station, e.g. ceiling, inner walls, instrument panels and access to
the operator's station shall not present any sharp edges or acute angles/corners. Radius of corners and
bluntness of edges shall comply with ISO 12508:1994 to avoid sharp edges (see also 5.14.6).
5.3.2 Operator's station equipped with a cab
5.3.2.1 Climatic conditions
The cab shall protect the operator against foreseeable adverse climatic conditions. Provisions shall be made
to install a ventilation system, an adjustable heating system and a system for defrosting windows. For details
see 5.3.2.6 to 5.3.2.8.
5.3.2.2 Pipes and hoses
Pipes and hoses located inside the cab which contain fluids that are dangerous, for example because of their
pressure (greater than 5 MPa), temperature (greater than 50°C) shall be guarded, see EN ISO 3457:2003,
Clause 9.
NOTE As far as possible pipes and hoses should be placed outside the cab.
Parts or components placed between pipes or hoses and the operator, which divert e.g. a hazardous spray of
fluid, can be considered as a sufficient protection device.
5.3.2.3 Primary access opening
A primary access opening shall be provided. The dimensions shall comply with EN ISO 2867:2006, Figure 4
and Table 4.
5.3.2.4 Alternative opening (emergency exit)
An alternative opening shall be provided on a side other than that of the primary opening. The dimensions
shall comply with EN ISO 2867:2006, Clause 11. A window panel or another door is acceptable if they are
easy to open or remove without the use of keys or tools. Latches may be used if they can be opened from the
inside without the use of keys or tools. The break of a suitable size of glass pane is considered equivalent to
an alternative opening. In such a case the necessary pane hammer, immediately accessible to the operator,
shall be provided and stored in the cab.
When the window panel is used as an emergency exit it shall bear an appropriate marking according to
Figure 8 of EN 61310-1:1995.
5.3.2.5 Space envelope height
The minimum space envelope height R as defined in !Figure 4 of EN ISO 3411:2007" and measured
from the seat index point (SIP), as defined in EN ISO 5353:1998, shall meet the values given in Table 1.
Table 1 — Space envelope height related to machine classification
Minimum space envelope height
Machine classification
mm from the SIP
Compact machines 920
All other machines 1 000
The minimum dimensions given in Table 1 are also required for machines having a front or rear window which
are located (in an opened position) above the operator's seat.
5.3.2.6 Heating and ventilation system
If a heating system is fitted it shall either:
a) comply with !ISO/DIS 10263-4:2007", or
b) have the capability of increasing the temperature of the air inside the cab and maintain a temperature of +
18°C at expected ambient temperature the machine is intended for. The minimum capacity of the heating
system shall have a ∆T of 25°C (∆T of 25 K) within 30 min. The test shall run starting with the engine at
working temperature as specified by the manufacturer. Measurement of the system capacity shall be
made at three points. The three points shall be located in a vertical plane through the SIP and parallel to
the longitudinal axis of the machine as follows (see Figure 3):
1) at filament position centre-point as defined in ISO 5006:2006;
2) at the SIP as defined in EN ISO 5353:1998;
3) 100 mm above floor plate and 600 mm in front of SIP.
Figure 3 — Location of measuring points
c) Alternatively, the heating capacity can be determined by calculation.
The ventilation system shall be capable of providing the cab with filtered fresh air at the minimum of 43 m /h.
The filter shall be tested according to !ISO/DIS 10263-2:2007".
NOTE The filter element selection depends on the intended operating environment conditions.
5.3.2.7 Defrosting system
Machine with a cab shall provide facilities to defrost the front and rear window(s), for example by means of a
heating system or a particular defrosting device.
NOTE A testing method of windscreen defrosting system is described in !ISO/DIS 10263-5:2007".
5.3.2.8 Pressurisation system
Where a cab is provided with a pressurisation system, it shall be tested according to
!ISO/DIS 10263-3:2007" and shall provide an interior relative pressure of at least 50 Pa.
5.3.2.9 Doors and windows
Doors, windows and flaps shall be securely held in their functional positions; measures shall be taken for
preventing inadvertent opening. Doors shall be retained at their intended operating position(s) by a positive
engagement device. A primary opening designed to be held securely open as an intended operating position,
shall be releasable from the operator's station.
Windows shall be made of safety glass or other material which provides similar safety performance (see e.g.
ECE R43).
Roof windows do not need additional mechanical safeguarding.
The front and rear window(s) shall be fitted with motorised windscreen wiper(s) and washer(s). The tank of the
window washer(s) shall be easily accessible.
5.3.2.10 Inner lighting
The cab shall be fitted with a fixed inner lighting system and be able to function with the engine at a stop, to
make it possible to illuminate the operator's station and to read the operation manual in darkness.
5.3.3 Roll-over protective structures (ROPS)
5.3.3.1 General
Earth-moving machinery shall be equipped with a roll-over protective structure (ROPS). The ROPS shall
comply with !EN ISO 3471:2008".
!deleted text"
5.3.3.2 ROPS for derivative machinery
For derivative machinery, the ROPS shall be designed taking into account the operating mass
(see ISO 6016:1998) of the derivative machinery in the heaviest configuration as specified by the
manufacturer.
5.3.4 Falling-object protective structures (FOPS)
!Earth-moving machinery above 15 kW shall be fitted with a falling-object protective structure (FOPS),
when they are intended for applications where there is a risk of falling objects.
NOTE 1 The following machines are normally not used for applications with a risk of falling objects: scrapers, pipe-
layers, trenchers and landfill compactors.
If FOPS is fitted it shall comply with EN ISO 3449:2008. For machines not covered by EN ISO 3449:2008 the
corresponding protection shall be provided when they are intended for applications where there is a risk of
falling objects.
NOTE 2 For excavators, see EN 474-5:2006+A1:2009 and EN 474-12:2006+A1:2008."
5.3.5 Elevating operator's station
See Annex D.
5.3.6 Replacement of operator protective structure
In case any part of the protective structure (e.g. ROPS, TOPS, FOPS) is affected by a plastic deformation
and/or rupture (e.g. by roll-over, tip-over or object impact), the protective structure has to be replaced
according to manufacturer's specifications. See also 7.2.
5.4 Seats
5.4.1 Operator's seat
5.4.1.1 General requirement
Machinery with provision for a seated operator shall be fitted with an adjustable seat that supports the
operator in a position, which allows the operator to control the machine under intended operating conditions.
5.4.1.2 Dimensions
The seat dimensions shall comply with ISO 11112:1995.
5.4.1.3 Adjustment
!All adjustments to accommodate the operator's size shall comply with ISO 11112:1995, Table 1, except
vertical adjustment (ISO 11112:1995, Table 1, h ) where a minimum value of 60 mm shall be used. The
adjustment shall be possible without the use of any tool."
For compact machines (see 3.1.1) the following seat adjustments apply:
 either the fore and aft adjustment (see ISO 11112:1995, Table 1, l ) shall be at least ± 35 mm or the
corresponding adjustment of frequently used operator's controls shall be provided;
 vertical adjustment (ISO 11112:1995, Table 1, h ) is not required.
5.4.1.4 Vibration
The operator's seat shall meet the requirements of EN ISO 7096:2000 with regard to its ability to reduce the
vibration transmitted to the operator.
!NOTE Comparative data for vibration can be found in e.g. ISO/TR 25398. "
5.4.1.5 Restraint system
Machines fitted with ROPS or TOPS (tip over protective structure) shall have an operator restraint system that
meets the requirements specified in EN ISO 6683:2005.
5.4.2 Additional seat
5.4.2.1 Instructor's seat
If an additional seat for an instructor is installed in the operator's station, it shall be padded and provide
adequate space for the instructor. The instructor shall also have available a conveniently placed handhold.
!The instructor's seat shall fulfil the requirements of the safety structures as specified in 5.3.3 (ROPS)
and 5.3.4 (FOPS)."
5.4.2.2 Second operator's seat
If a second operator's seat is required for a specific machine, which can be frequently or alternatively used by
the operator to perform the application of the machine, this seat shall fulfil the requirements for seats as
specified in 5.4 and the safety structures as specified in 5.3.3 (ROPS) and 5.3.4 (FOPS).
5.5 Operator's controls and indicators
5.5.1 General
The controls (hand levers, pedals, switches etc.) and indicators of the machine, equipment, attachment, shall
be chosen, designed, constructed and arranged according to ISO 10968:2004, so that:
a) they are of easy access, in accordance with EN ISO 6682:1995 and ISO 10968:2004;
b) neutral positions of controls shall be in accordance with 5.3 of ISO 10968:2004;
c) they are clearly identified (see ISO 6405-1:2004 and ISO 6405-2:1993) in the operator's station and
explained in the operation manual (see 7.2);
d) the movement of the controls to activate the functions and indicators shall correspond to the intended
effect or common practice whenever possible;
e) the normal engine stop device shall be within the zone of reach (see EN ISO 6682:1995);
f) when a control is designed and constructed to carry out several functions of the machine, e.g. keyboard,
joystick control, the activated function shall be clearly identified;
g) for requirements on joy-sticks, see also ISO 10968:2004;
h) for safety related functions of control system(s) having no electronic components, the principles outlined in
!EN ISO 13849-1:2008" shall be used or methods giving similar protection;
i) !where there is more than one control position the control system shall be designed in such a way that
the use of one of them precludes the use of the other(s) (except for stop controls and emergency
stops). "
5.5.2 !Starting/stopping system"
!The starting/stopping system of earth-moving machinery shall be provided with a starting/stopping device
(e.g. key) and shall comply with ISO 10264:1990 or have a similar protection against unauthorized use.
Earth-moving machines shall be so designed that hazardous movement of the machine or its working
equipment and/or attachment shall not be possible without action on the controls whilst starting/stopping the
engine.
If the visibility from the operator's station to the rear by direct or indirect view cannot be achieved in
accordance with 5.8.1, the machine shall be equipped with an acoustic and/or visual warning signal activated
automatically when the reversing command is given, combined with a delay in starting the reverse movement,
leaving sufficient time for an exposed person to leave the danger zone.
NOTE When drafting this text it was not possible to define clear criteria for the necessary delay time as it depends on
different parameters. In the idea of the drafters a delay of 3 s (that may be achieved completely or in part in the reaction
time of the machine) will in general be appropriate. "
5.5.3 Inadvertent activation
!Controls, which can cause a hazard due to inadvertent activation, shall be so arranged or deactivated or
guarded as to minimise the risk, when the operator gets into or out of the operator's station." The
deactivation device shall either be self-acting or acting by compulsory actuation of the relevant device.
5.5.4 Pedals
Pedals shall have an appropriate size, shape and be adequately spaced. The pedals shall have a slip-
resistant surface and be easy to clean.
If the pedals of an earth-moving machine have the same function (clutch, brake, and accelerator) as on a
motor vehicle, they shall be arranged in the same manner to avoid the risk of confusion.
5.5.5 Emergency attachment lowering
If the engine is stopped it shall be possible to:
a) lower the equipment/attachment to the ground/frame;
b) see the equipment/attachment lowering from the operator actuating position of the lowering control;
c) release the residual pressure in each hydraulic and pneumatic circuit, which can cause a risk.
The means to lower the attachment and the device to release the residual pressure can be located outside the
operator's station and shall be described in the operation manual.
5.5.6 Uncontrolled motion
Machine and equipment or attachment movement from the holding position, other than by actuation of the
controls by the operator, due to drift or creep (e.g. by leaking) or when power supply stops, shall be limited to
the extent that it can not create a risk to exposed persons.
5.5.7 Remote control
Remote operator controlled earth-moving machinery shall comply with the requirements as specified in
ISO 15817:2005.
5.5.8 Control panels, indicators and symbols
5.5.8.1 Control panels
The operator shall be able to see from the operator's station, in both daylight and darkness, the necessary
indicators to check the proper function of the machine. Glare shall be minimised.
5.5.8.2 Operating instrumentation
Control indicators for safe and proper operation of the machine, shall follow the safety colours and safety
signs/requirements according to ISO 6011:2003.
5.5.8.3 Symbols
Symbols for use on operator controls and other displays on earth-moving machinery shall follow,
e.g. ISO 6405-1:2004 or ISO 6405-2:1993.
5.5.9 Controls of ride-on machinery accessible from ground level
On ride-on machinery where controls are accessible from the ground, means shall be provided to minimise
the possibility to actuate the controls from the ground (e.g. protection by door, guard or by locking systems).
5.6 Steering system
5.6.1 General
The steering system shall be such that the movement of the steering control shall correspond to the intended
direction of steering.
5.6.2 Rubber-tyred machines
Steering system of rubber-tyred machinery with a forward/reverse travel speed greater than 20 km/h shall
comply with !EN 12643:1997+A1:2008".
5.6.3 Crawler machines
Steering system of crawler machines with a forward/reverse travel speed greater than 20 km/h shall be
gradual.
5.7 Brake systems
Earth-moving machines shall be equipped with service brake system, secondary brake system and parking
brake system, efficient under all conditions of service, load, speed, terrain and slope, according to the
intended use of the machine.
Brake systems shall comply with the following requirements:
 for wheeled machines with EN ISO 3450:1996;
 for crawler machines with !ISO 10265:2008".
5.8 Visibility
5.8.1 Operator's field of view
Earth-moving machines shall be designed in accordance with ISO 5006:2006 so that the operator has
sufficient visibility from the operator's station in relation to the travel and work areas of the machine that are
necessary for the intended use of the machine. The travel mode as specified in ISO 5006:2006 is considered
to be representative for testing visibility in both travel and operating modes.
NOTE It is sufficient to measure the machine with the most challenging standard attachment within the limits of the
intended use.
Earth-moving machines shall be equipped with rear view mirrors according to ISO 14401-1:2004 and
ISO 14401-2:2004.
5.8.2 Lighting, signalling and marking lights, and reflex-reflector devices
Work lights and reflex-reflector devices shall be provided and shall comply with ISO 12509:2004. Lighting,
signalling and marking lights, if provided, shall comply with the appropriate clauses of ISO 12509:2004.
5.9 Warning devices and safety signs
Earth-moving machinery shall be equipped with:
 an audible warning device (horn) controlled from the operator's station, the A-weighed sound pressure
level of which shall be greater than or equal to 93 dB. The value shall be measured 7 m from the foremost
point of the machine with equipment/attachment in its travel position as defined in !ISO 6395:2008".
The test procedure shall be in accordance with ISO 9533:1989;
 safety signs (see Annex C for examples. See also 7.1).
5.10 Tyres and rims
Rubber-tyred earth-moving machinery shall have tyre and rim load performance adapted to the purpose and
application.
Rims shall have clear identifi
...
