(ISO 15614-1:2004) EN ISO 17638:2009, Non-destructive testing of welds — Magnetic particle testing (ISO 17638:2003) EN ISO 17663:2009, Welding — Quality requirements for heat treatment in connection with welding and allied processes (ISO 17663:2009) EN ISO 23277:2009, Non-destructive testing of welds — Penetrant testing of welds — Acceptance levels (ISO 23277:2006) EN ISO 23278:2009, Non-destructive testing of welds — Magnetic particle testing of welds — Acceptance levels (ISO 23278:2006) CEN ISO/TR 15608, Welding — Guidelines for a metallic material grouping system (ISO/TR 15608:2005) 3 Terms and definitions For the purposes of this document the terms and definitions given in EN 12952-1:2001 and the following apply. 3.1 cold forming for ferritic steels, it is forming at temperatures below the maximum permissible temperature for post-weld heat treatment and for austenitic materials it is forming at temperatures below 300 °C NOTE See Table 10.4-2. 3.2 hot forming for ferritic steels, it is forming at temperatures at or above the maximum permissible temperature for post-weld heat treatment SIST EN 12952-5:2012

EN 1759-1:2004. Bolted flanges in accordance with c) shall not be used where the bolts would be exposed to gases of combustion. 6.1.3 Material for header ends Header ends shall be forged or machined from steel of a grade compatible with the bodies of the headers and profiled as shown in EN 12952-3:2011, Figure 10.3-1. SIST EN 12952-5:2012

is the required minimum thickness at the extrados, in mm; eact is the nominal thickness of the supplied tube minus the supplier's maximum negative thickness tolerance, in mm; rb
is the radius of the bend measured to the centre-line of the tube in mm; do
is the nominal outside diameter of the tube, in mm. When the measured value on the tube bend is less than eext reference shall be made to the minimum calculated thickness given in EN 12952-3:2011, 11.3. The thinning on the extrados of bends formed in two stages i.e. hot formed after initial hot or cold bending, shall not exceed 30 % of the thickness of the straight tube local to the bend as measured during a procedure test. 7.3.5 Thickening at the tube bend intrados for tubes of nominal outside diameter above 80 mm and including 142 mm The thickness at any point after bending shall not be less than that given by equation: 1/25,0/2obobactint−−×=drdree (7.2) where eint
is the required minimum thickness at the intrados, in mm; eact is the nominal thickness of the supplied tube minus the supplier's maximum negative thickness tolerance, in mm; rb
is the radius of the bend measured to the centre-line of the tube, in mm; do
is the nominal outside diameter of the tube, in mm. When the measured value on the tube bend is less than eint reference shall be made to the minimum calculated thickness given in EN 12952-3:2011, 11.3. 7.3.6 Thinning/thickening at the tube bend extrados/intrados for tubes of nominal outside diameter
greater than 142 mm For tubes above 142 mm diameter comparison shall be made directly with the calculated thickness given in EN 12952-3:2011, 11.3. The calculated thickness shall be stated on the drawing. SIST EN 12952-5:2012

Key a departure from circularity u b ratio rb/do Figure 7.3-1 — Limits of departure from circularity for single operation bending SIST EN 12952-5:2012

Key a departure from circularity u b ratio rb/do Figure 7.3-2 — Limits of departure from circularity for double operation bending 7.3.8 Post bend heat treatment of tube bends The post-bend heat treatment (PBHT) of hot or cold formed bends shall be in accordance with the following rules: a) all hot formed tube bends and cold formed bends requiring heat treatment after bending, including bends hot formed after cold bending, shall be heat treated in accordance with the requirements of 7.3.9 except as defined in b) or e) below; b) hot formed tube bends in steel group 1, with outside diameters of 80 mm or less, need not receive a post-bend heat treatment if it can be demonstrated that the bending operation was completed within the normalizing range as defined in the relevant base material standard, or data sheet, as appropriate; c) all cold bent tube bends with thinning greater than 25 % as measured in the procedure test, shall be heat treated in accordance with the requirements of 7.3.9; d) PBHT of cold formed tube bends in accordance with Table 7.3-2 shall be carried out in accordance with the requirements of 7.3.9; Table 7.3-2 — Post-bend heat treatment applicable to cold formed tube bends do mm Bend ratio Heat treatment do > 142 rb/do > 2,5 No post-bend heat treatment required do > 142 rb/do ≤ 2,5 Stress relieve do ≤ 142 rb/do > 1,3 No post-bend heat treatment required do ≤ 142 rb/do ≤ 1,3 Stress relieve
do, do2, do3, do4, -------etc is the actual outside diameter of the tube at the position being measured. NOTE For clarity, the ripples have been exaggerated. Figure 7.3-3 — Ripples on tube bends For such ripples to be acceptable, both the following conditions shall be satisfied: Amplitude of the ripples hm = 0,5 (do2 + do4) – do3 < 0,03 do
(7.4) Wave pitch a > 12 hm
(7.5) SIST EN 12952-5:2012
the tolerances given in Table 7.4-1. Table 7.4-1 — Offset of middle lines for longitudinal joints in cylindrical components Plate thickness ea mm Offset of middle lines mm ea ≤ 10 ≤ 1 10 < ea ≤ 50 ≤ ea/10 or 3, whichever is the smaller e
...
