INTERNATIONAL STANDARD ISO 17987-2:2016(E)
Road vehicles — Local Interconnect Network (LIN) —
Part 2:
Transport protocol and network layer services
1 Scope
This document specifies a transport protocol and network layer services tailored to meet the
requirements of LIN-based vehicle network systems on local interconnect networks. The protocol
specifies an unconfirmed communication.
The LIN protocol supports the standardized service primitive interface as specified in ISO 14229-2.
This document provides the transport protocol and network layer services to support different
application layer implementations like
— normal communication messages, and
— diagnostic communication messages.
The transport layer defines transportation of data that is contained in one or more frames. The
transport layer messages are transported by diagnostic frames. A standardized API is specified for the
transport layer.
Use of the transport layer is targeting systems where diagnostics are performed on the backbone bus
(e.g. CAN) and where the system builder wants to use the same diagnostic capabilities on the LIN sub-
bus clusters. The messages are in fact identical to the ISO 15765-2 and the PDUs carrying the messages
are very similar.
The goals of the transport layer are
— low load on LIN master node,
— to provide full (or a subset thereof) diagnostics directly on the LIN slave nodes, and
— targeting clusters built with powerful LIN nodes (not the mainstream low cost).
A typical system configuration is shown in Figure 1.
Figure 1 — Typical system setup for a LIN cluster using the transport layer
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
ISO 14229-1, Road vehicles — Unified diagnostic services (UDS) — Part 1: Specification and requirements
ISO 14229-2, Road vehicles — Unified diagnostic services (UDS) — Part 2: Session layer services
ISO 14229-7:2015, Road vehicles — Unified diagnostic services (UDS) — Part 7: UDS on local interconnect
network (UDSonLIN)
ISO 17987-3:2016, Road vehicles — Local Interconnect Network (LIN) — Part 3: Protocol specification
3 Terms, definitions, symbols and abbreviated terms
3.1 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO/IEC 7498-1 and the
following apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— IEC Electropedia: available at http://www.electropedia.org/
— ISO Online browsing platform: available at http://www.iso.org/obp
3.1.1
broadcast NAD
slave node receiving a message with a NAD equal to the broadcast NAD 7F the message is received
and processed
2 © ISO 2016 – All rights reserved

3.1.2
configured NAD
value in the range of (01 to 7D ) which is assigned to each slave node
16 16
Note 1 to entry: The assignment of configured NAD to each slave node is defined in the LDF. The configured NAD
is used for node configuration and identification services, as well as UDS services according to ISO 14229-7.
Note 2 to entry: When communication is initialized configured NADs of slave nodes may be identical. The master
shall assign unique configured NADs to all slave nodes before diagnostic communication begins.
Note 3 to entry: Setting or altering the configured NAD in a slave node can be done by the following ways:
— the master node assigns a new configured NAD to a slave node supporting the “Assign NAD” service;
— an API call in a slave node assigns the configured NAD;
— the configured NAD is assigned with a static configuration.
3.1.3
functional NAD
(7E )
used to broadcast diagnostic requests
3.1.4
initial NAD
constant/static value in the range of (01 to 7D )
16 16
Note 1 to entry: initial NAD value may be derived from a pin configuration, EEPROM or slave node position
detection algorithm before entering the operational state (regular LIN communication).
Note 2 to entry: The combination of initial NAD, Supplier ID and Function ID unique for each slave node is used in
the “Assign NAD” command allowing an unambiguous configured NAD assignment.
Note 3 to entry: If no initial NAD is defined for a slave node (LDF, NCF) the value is identical to the configured NAD.
3.1.5
P2 timing parameter
application timing parameter for the ECU(s) and the external test equipment
3.1.6
P2* timing parameter
enhanced response timing parameter for the ECU(s) application after response pending frame
transmission
3.1.7
P4 timing parameter
timing parameter for the ECU(s) application defining the time between reception of a request and the
final response
3.1.8
proprietary NAD
NAD values in the range [80 – FF ] are used for not standardized communication purpose, such as
16 16
Tier-1 slave node diagnostics
3.2 Symbols
% percentage
µs microsecond
ms millisecond
| The vertical bar indicates choice. Either the left hand side or the right hand side of the vertical
bar shall appear
3.3 Abbreviated terms
API application programmers interface
BNF Bachus-Naur format
CAN Controller Area Network
CF ConsecutiveFrame
FF FirstFrame
LDF LIN description file
L_Data data link data
MRF master request frame
N_AI network address information
N_As network layer timing parameter As
N_As timeout on As
max
N_Cr network layer timing parameter Cr
N_Cr timeout on Cr
max
N_Cs network layer timing parameter Cs
N_Cs timeout on Cs
max
N_Data network data
N_PCI network protocol control information
N_PCItype network protocol control information type
N_PDU network protocol data unit
N_SA network source address
N_SDU network service data unit
N_TAtype network target address type
N_USData network layer LIN data transfer service name
NAD node address for slave nodes
4 © ISO 2016 – All rights reserved

NCF node capability file
NCL node capability language
NRC negative response code
NWL network layer
OBD on-board diagnostics
OSI Open Systems Interconnection
PDU protocol data unit
PID protected identifier
RSID response service identifier
SF SingleFrame
SID service identifier
SN SequenceNumber
SRF slave response frame
ST SeparationTime minimum
min
4 Conventions
ISO 17987 (all parts) and ISO 14229-7 are based on the conventions specified in the OSI Service
Conventions (ISO/IEC 10731) as they apply for physical layer, protocol, transport protocol and network
layer services and diagnostic services.
5 Network management
5.1 Network management general information
Network management in a LIN cluster refers to cluster wake up and go-to-sleep only. Other network
management features, for example, configuration detection and limp home management are left to the
application.
5.2 LIN node communication state diagram
The state diagram in Figure 2 shows the behaviour model for LIN communication state.
— Bus Sleep
Bus Sleep state is entered after first connection to power source and the system initialization, reset
or when a go-to-sleep command is transmitted by the master or received by the slave node. The
level on the bus is set to recessive. Only the wake up signal may be transmitted on the cluster.
— Operational
The protocol behaviour (transmitting and receiving frames) specified in this document only applies
to the Operational state.
NOTE The LIN “Bus Sleep” state does not necessarily correlate to the node’s power state.
Figure 2 — LIN node communication state diagram
5.3 Wake up
5.3.1 Wake up general information
Any node in a sleeping LIN cluster may request a wake up, by transmitting a wake up signal. The wake
up signal is started by forcing the bus to the dominant state for 250 µs to 5 ms, and is valid with the
return of the bus signal to the recessive state.
5.3.2 Master generated wake up
The master node may issue a break field, e.g. by issuing an ordinary header since the break acts as a
wake up signal (in this case, the master shall be aware of that this frame may not be processed by the
slave nodes since they may not yet awake and ready to listen to headers).
Every slave node (connected to power) should detect the wake up signal (a dominant pulse longer than
150 µs followed by a rising edge of the bus signal) and be ready to listen to bus commands within
100 ms, measured from the ending edge of the dominant pulse (see Figure 3). The check for the rising
edge shall be done by the transceiver and also could be done by the microcontroller LIN interface.
A detection threshold of 150 µs combined with a 250 µs pulse generation gives a detection margin that
is enough for uncalibrated slave nodes. Following the detection of the wake up pulse, the Slave task
machine (ISO 17987-3:2016, 7.5.3) shall start and enter into the idle state. During the idle state, the slave
shall never issue a dominant level pulse on the bus until the state machine enters into an active state.
5.3.3 Slave generated wake up
If the node that transmitted the wake up signal is a slave node, it shall be ready to receive or transmit
frames immediately. The master node shall also wake up and, when the slave nodes are ready (>100 ms),
start transmitting headers to find out the cause (using signals) of the wake up.
6 © ISO 2016 – All rights reserved

Figure 3 — Wake up signal reception in slave nodes
The master node shall detect the wake up signal (a dominant pulse longer than 150 µs followed by a
rising edge of the bus signal) and be ready to start communication within a time that is decided by the
cluster designer or application specific. The check for the rising edge shall be done by the transceiver
and also could be done by the microcontroller LIN interface.
If the master node does not transmit a break field (i.e. starts to transmit a frame) or if the node issuing
the wake up signal does not receive a wakeup signal (from another node) within 150 ms to 250 ms
from the wake up signal, the node issuing the wake up signal shall transmit a new wake up signal
(see Figure 4). In case the slave node transmits a wake up signal in the same time as the master node
transmits a break field, the slave shall receive and recognize this break field.
Figure 4 — One block of wake up signals
After three (failing) requests, the node shall wait minimum 1,5 s before issuing a fourth wake up signal.
The reason for this longer duration is to allow the cluster to communicate in case the waking slave node
has problems, e.g. if the slave node has problems with reading the bus it probably retransmit the wake
up signal infinitely. There is no restriction of how many times a slave may transmit the wake up signal.
However, it is recommended that a slave node transmits not more than one block of three wake up signals
for each wake up condition. Figure 5 shows how wake up signals are transmitted over a longer time
Figure 5 — Wake up signals over long time
5.4 Go-to-sleep
The master sets each node in the cluster instantly into bus sleep state by transmitting a go-to-sleep
command. The request does not necessarily enforce the slave nodes into a low-power mode. The slave
node application may still be active after the go-to-sleep command has been received. This behaviour
is application specific. The go-to-sleep command is a master request frame with the first data field
(Byte 1) set to 00 and the rest set to FF (see Table 1). The slave nodes shall ignore the data fields
16 16
Byte 2 to Byte 8 and interpret only the first data field (Byte 1).
Table 1 — Go-to-sleep command
LIN frame
Byte 1 Byte 2 Byte 3 Byte 4 Byte 5 Byte 6 Byte 7 Byte 8
00 FF FF FF FF FF FF FF
16 16 16 16 16 16 16 16
The normal way for setting the cluster to sleep is that the master node transmits the go-to-sleep
command. In case of bus inactivity, a slave node shall be able to receive/transmit frames for 4 s. The
slave node shall automatically enter bus sleep mode earliest 4 s and latest 10 s of bus inactivity. Bus
inactivity is defined as no transitions between recessive and dominant bit values. Bus activity is the
inverse.
NOTE LIN transceivers normally have filters to remove short spikes on the bus. The transition here refers to
the signal after this filter.
6 Network layer overview
6.1 General
This document specifies an unconfirmed network layer communication protocol for the exchange of
data between network nodes, e.g. from ECU to ECU, or between external test equipment and an ECU. If
the data to be transferred do not fit into a single LIN frame, a segmentation method is provided.
In order to describe the function of the network layer, services provided to higher layers and the
internal operation of the network layer shall be considered.
All network layer services have the same general structure. To define the services, three types of
service primitives are specified:
— a service request primitive, used by higher communication layers or the application to pass control
information and data required to be transmitted to the network layer;
— a service indication primitive, used by the network layer to pass status information and received
data to upper communication layers or the application;
— a service confirmation primitive, used by the network layer to pass status information to higher
communication layers or the application.
This service specification does not specify an application programming interface, but only a set of
service primitives that are independent of any implementation.
8 © ISO 2016 – All rights reserved

6.2 Format description of network layer services
All network layer services have the same general format. Service primitives are written in the form:
service_name.type  (
parameter A,
parameter B
[,parameter C, .]
)
where service_name is the name of the service, e.g. N_USData, type indicates the type of the service
primitive, and “parameter A, parameter B [parameter C, .]” are the N_SDU as a list of values passed by
the service primitive. The brackets indicate that this part of the parameter list may be empty.
The service primitives define how a service user (e.g. diagnostic application) cooperates with a service
provider (e.g. network layer). The following service primitives are specified in this document: request,
indication and confirm.
— Using the service primitive request (service_name.request), a service user requests a service
from the service provider.
— Using the service primitive indication (service_name.indication), the service provider
informs a service user about an internal event of the network layer
...
