Structures for Mine Shafts — Part 4: Conveyances

Structures for Mine Shafts – Part 4: Conveyances
1. Scope
This document defines the loads and load combinations to be adopted and specifies the design
procedures to be used for the design of the steel and aluminium alloy structural members of
conveyances used for the transport of men, materials, equipment and rock in vertical and decline shafts.
The conveyances covered by this document include personnel or material cages (or both), skips,
kibbles, equipping skeleton cages, inspection cages, bridles, crossheads and counterweights.
This document is not intended to be used for the design of ropes, sheaves or attachments. The design
of ropes, i.e. sizes, is covered in the relevant national legislation.
This document does not cover chairlifts.
This document does not cover matters of operational safety which are required to comply with the
provisions of the regulations of the relevant jurisdiction. Where specific country requirements exist
which relate to and interact with the requirements of this document, or which are supplementary to this
document, it is expected that the user will take these into account when using this document.
This standard adopts a limit states design philosophy.
NOTE 1: Exceptions to the provisions of this document are permitted only if the required safety margins
are proved by acceptable analytical or experimental procedures.
2. Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
Use of appropriate national standards in place of the standards listed below should be done with
caution, always complying with national construction regulations and safety margins.
EN 485-1, Aluminium and aluminium alloys – Sheet, strip and plate – Part 1: Technical conditions for
inspection and delivery.
EN 485-2, Aluminium and aluminium alloys – Sheet, strip and plate – Part 2: Mechanical properties.
EN 485-3, Aluminium and aluminium alloys – Sheet, strip and plate – Part 3: Tolerances on dimensions
and form for hot-rolled products.
EN 485-4, Aluminium and aluminium alloys – Sheet, strip and plate – Part 4: Tolerances on shape and
dimensions for cold-rolled products.
EN 515, Aluminium and aluminium alloys – Wrought products – Temper designations.
EN 573-3, Aluminium and aluminium alloys – Chemical composition and form of wrought products –
Part 3: Chemical composition and form of products.
EN 755-1, Aluminium and aluminium alloys – Extruded rod/bar, tube and profiles – Part 1: Technical
conditions for inspection and delivery.
EN 755-2, Aluminium and aluminium alloys – Extruded rod/bar, tube and profiles – Part 2: Mechanical
properties.

DRAFT ISO 19426-4 1

---------------------- Page: 8 ----------------------
ISO/DIS 19426-4:2017(E)
EN 755-3, Aluminium and aluminium alloys – Extruded rod/bar, tube and profiles – Part 3: Round bars,
tolerances on dimensions and form.
EN 755-4, Aluminium and aluminium alloys – Extruded rod/bar, tube and profiles – Part 4: Square bars,
tolerances on dimensions and form.
EN 755-5, Aluminium and aluminium alloys – Extruded rod/bar, tube and profiles – Part 5: Rectangular
bars, tolerances on dimensions and form.
EN 755-7, Aluminium and aluminium alloys – Extruded rod/bar, tube and profiles – Part 7: Seamless
tubes, tolerances on dimensions and form.
ISO 2394, General Principles on Reliability for Structures.
EN 1999-1-1, Eurocode 9 – Part 1: Design of aluminium structures – Part 1: General structural rules.
EN 1999-1-3, Eurocode 9 – Part 1: Design of aluminium structures – Part 3: Structures susceptible to
fatigue.
EN 1999-1-4, Eurocode 9 – Par 1: Design of aluminium structures – Part 4: Cold-formed structural
sheeting.
EN 10025-1, Hot rolled products of structural steels – Part 1: General technical delivery conditions.
EN 10025-2, Hot rolled products of structural steels – Part 2: Technical delivery conditions for non-alloy
structural steels.
ISO 10721-1, Steel structures - Part 1: Materials and design.
ISO 10721-2, Steel Structures – Part 2: Fabrication and erection.
EN 12020-1, Aluminium and aluminium alloys – Extruded precision profiles in alloys EN AW-6060 and
EN AW-6063 – Part 1: Technical conditions for inspection and delivery.
EN 12020-2, Aluminium and aluminium alloys – Extruded precision profiles in alloys EN AW-6060 and
EN AW-6063 – Part 2: Tolerances on dimensions and form.
EN 10137-1, Plates and wide flats made of high yield strength structural steels in quenched and
tempered or hardened conditions. Part 1: General delivery conditions.
EN 10137-2, Plates and wide flats made of high yield strength structural steels in quenched and
tempered or hardened conditions. Part 2: Delivery conditions for quenched and tempered steels .
EN 10149-1, Specification for hot-rolled flat products made of high yield strength steels for cold forming.
Part 1: General delivery conditions.
EN 10149-2, Specification for hot-rolled flat products made of high yield strength steels for cold forming.
Part 2: Delivery conditions for thermomechanically rolled steels.
EN 10149 3, Specification for hot-rolled flat products made of high yield strength steels for cold forming.
Part 3: Delivery conditions for normalized or normalized rolled steels.
ISO 19426-1, Structures for mine shafts – Part 1: Terms and definitions.
ISO 19426-2, Structures for mine shafts – Part 2: Headgear structures.
ISO 19426-5, Structures for mine shafts – Part 5: Shaft system structures.
ISO 22111, Bases for design of structures -- General requirements.
ISO 60079, Explosive atmospheres - Equipment - General requirements.
© ISO 2017 – All rights reserved 2

---------------------- Page: 9 ----------------------
ISO/DIS 19426-4:2017(E)
3. Terms and Definitions
For the purposes of this document, the following terms and definitions apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
 ——ISO Online browsing platform: available at http://www.iso.org/obp
 ——IEC Electropedia: available at http://www.electropedia.org
For the purposes of this document, the definitions in ISO 19426-1 apply.
4. Symbols
For the purposes of this document, the following symbols apply.
A is the operating winder system acceleration/deceleration load (N)
o
A is the trip-out winder deceleration load (N)
t
is the maximum permitted deceleration of the conveyance when the dogging system
a
2
D
activates (m/s )
2
operating winder system peak acceleration/deceleration (m/s )
a
o
2
is the trip-out winder system peak deceleration (m/s )
a
t
is the impact load during loading of the conveyance (N)
C
C is the horizontal impact load from rolling stock (N)
h
C is the vertical impact load from rolling stock (N)
v
C
is the conveyed load (P, ΣM, U or R, as appropriate) (N)
y
is the dogging system load (N)
D
d is the deformation of the skip door (m)
i
E is the emergency dropback load (N)
j
E is the rope emergency load (N)
r
is the maximum moving beam misalignment of the guide (m); lateral flare dimension (see
e
figure 1)
is the design load, or load effect (N, Nm).
F
is the friction induced vertical load (N)
F
v
are the permanent loads, including the self-weight of the structure and the structural
G and G
components, in newtons (N)
1 2
is the conveyance self-weight load (N)
G
c
2
is the acceleration due to gravity (= 9,8 m/s )
g
is the lateral imposed load (N)
H

H is the rubbing block load (N)
r
H is the lateral slipper plate load (N)
s
h is the length through which the rock falls (m)
d
is the height to which the skip is filled above the lowest point of the skip door (m)
h
h
is the station-mounted holding device engagement load (N).
K
© ISO 2017 – All rights reserved 3

---------------------- Page: 10 ----------------------
ISO/DIS 19426-4:2017(E)
is the conveyance-mounted holding device load (N)
K
c
is the lateral stiffness of the steelwork at the guide mid-span or at the end of the flare (N/m)
K
g
is the buffer spring stiffness (N/m)
K
s
is the guide span, bunton to bunton, or the length of the flare (m).
L
is the distance between the pivot and the centre of gravity of the skip, or the radial door (m)
L
1
is the distance between the pivot and the return-stop (or the tipping roller) (m).
L
2
is the length of the crawler track (m).
L
T
is the load from each item of rolling stock or equipment (N)
M
is the heavier axle load (N)
M
1
is the conveyance mass including all attachments, excluding rope attachments (kg)
m
c
is the mass of largest rock that will be loaded into the skip (kg)
m
r
is the load from personnel (N)
P
2
p to p is the skip pressures (N/m )
o 3
is the dominant imposed load or load effect (N, Nm).
Q
1
are the additional independent imposed loads, or load effects (N, Nm).
Q to Q
2 n
is the emergency load or load effect (N, Nm)
Q
e
is the static rock or sludge load (N)
R
R is the bridle/transom load during filling (N)
d
R
f is the friction load on the skip door (N)
R
i is the single rock impact vertical load on the skip door (N)
R
k is the single rock impact horizontal load on the skip sides (N)
R
s is the load on skip return-stops (N)
R
t is the load on tipping rollers (N)
is the load due to the tail rope (N)
T
is the load due to underslung equipment (N)
U
is the maximum depth of rock or sludge contained in the conveyance (m)
z
is the impact energy of the falling rock (J)
Z
i
is the dynamic impact factor
α
d
is the horizontal load impact factor
α
h
is the holding device impact factor
α
k
α
is the rock impact factor
p
is the tipping impact factor.
α
t
is the vertical load impact factor
α
v
© ISO 2017 – All rights reserved 4

---------------------- Page: 11 ----------------------
ISO/DIS 19426-4:2017(E)
is the rope emergency factor
β
is the partial load factor for emergency loads.
γ
e
is the partial load factor for imposed loads
γ
fi
are the partial load factors for permanent loads;
γ and γ
g1 g2
are the partial load factors for imposed loads
γ to γ
f1 fn
is the partial load factor for permanent loads.
γ
gi
friction factor between the skip payload and the door
μ
3
is the bulk density of rock (kg/m )
ρ
are the load combination factors
Ψ to Ψ
2 n

5. Materials
5.1 Steel
Unless otherwise specified by the client, the materials used for structural steel members shall comply
with the requirements of EN 10025-1 and EN 10025-2.
5.1.1 High strength steel grades
Unless otherwise specified by the client, the materia
...
