INTRODUCTION
High performance electrical system requires a massive data exchange between processing
integrated circuit (IC) and storage IC. Stacked multiple ICs with a large number of vertical
interconnects among dies are an innovative way of providing higher data transfer rate among
dies. In addition to bumps, metal pillars, or metal pads which are traditional ways of
interconnection between dies, through-silicon vias enable to configure the integration of three
or more dies. The integration environment of multichip IC is significantly different from that of
the integration on a printed circuit board. This document describes definitions pertaining to
the multichip ICs.
– 6 – IEC 63011-1:2018 © IEC 2018
INTEGRATED CIRCUITS –
THREE DIMENSIONAL INTEGRATED CIRCUITS –

Part 1: Terminology
1 Scope
This part of IEC 63011 provides definitions pertaining to multichip integrated circuits, as
vertically stacked dies using through-silicon vias (TSVs) or micro bumps. Terms and
definitions related to the fabrication and test of the multichip integrated circuits are also
provided.
2 Normative reference
The following documents are referred to in the text in such a way that some or all of their
content constitutes requirements of this document. For dated references, only the edition
cited applies. For undated references, the latest edition of the referenced document (including
any amendments) applies.
There are no normative references in this document.
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
ISO and IEC maintain terminological databases for use in standardization at the following
addresses:
• IEC Electropedia: available at http://www.electropedia.org/
• ISO Online browsing platform: available at http://www.iso.org/obp
3.1 General
The general terms listed below relate to the secondary integration method in vertical direction
using integrated circuits fabricated on a horizontal surface of semiconductor.
3.1.1
interposer
electrical interface that connects one socket or connection to another
Note 1 to entry: The purpose of an interposer is to spread a connection to a wider pitch or to reroute a connection
to a different connection
3.1.2
multichip interconnect technology
technology that allows for the vertical stacking of layers of basic electronic components which
are connected using an interconnect fabric are as follows:
Note 1 to entry: "Basic electronic components” are elementary circuit devices such as transistors, diodes,
resistors, capacitors and inductors.
Note 2 to entry: A special case of multichip interconnect technology is the interposer structures that may only
contain interconnect layers, although in many cases other basic electronic components (in particular decoupling
capacitors) may be embedded into the interposer.

3.1.3
3-D bonding
process that joins two die or wafer surfaces together multiple surfaces mechanically or
electrically
EXAMPLE: Die-to-die, die-to-wafer, wafer-to-wafer
3.1.4
3-D stacking
3-D bonding operation that assumes electrical interconnects between the two devices
3.1.5
3-D packaging
3-D integration of multiple dies using wire bonding, package-on-package stacking, or
embedding in printed circuit boards
3.1.6
3-D wafer-level-packaging
3-D WLP
3-D integration using wafer level packaging technologies, performed after wafer fabrication,
which consists of flip-chip redistribution, redistribution interconnect, fan-in chip-size
packaging, and fan-out reconstructed wafer chip-scale packaging
Note 1 to entry: This note applies to the French language only.
3.1.7
redistribution layer
RDL
extra metal layer on a chip that makes the IO pads of an integrated circuit available in other
locations
Note 1 to entry: This note applies to the French language only.
3.1.8
system in package
SIP
integration of multiple dies, packages, or mixture of them as system in a package
Note 1 to entry: This note applies to the French language only.
3.1.9
3-D stacked integrated circuit
3-D approach using direct interconnects without wire bonding between integrated circuits of
multiple dies
Note 1 to entry: The 3-D stack uses a sequence of alternating front-end (devices) and back-end (interconnect)
layers.
3.1.10
3-D integrated circuit
3-D IC
3-D approach using direct stacking of active devices
Note 1 to entry: Interconnects are on the local on-chip interconnect levels. The 3-D stack is characterized by a
stack of front-end devices, combined with a common back-end interconnect stack.
Note 2 to entry: This note applies to the French language only.

– 8 – IEC 63011-1:2018 © IEC 2018
3.2 Test method in 3D environment
3.2.1
package stack
integrated circuit packaging method to combine vertically discrete logic and memory ball grid
array (BGA) packages
Note 1 to entry: Two or more packages are installed atop each other.
3.2.2
package-on-package
POP
package in which multiple packages are enclosed
Note 1 to entry: This note applies to the French language only.
3.2.3
multi-chip-package
MCP
package in which multiple dies are stacked vertically or placed side-by-side
Note 1 to entry: This note applies to the French language only.
3.2.4
die stack
chip in which two or more layers of active electronic components are integrated both vertically
and horizontally into a single circuit
3.2.5
contacting die stack
chip in which two or more layers of active electronic components are integrated and signals
between multiple layers are transferred via physical and electrical contacts
3.2.6
bump
stud of metal protruded on the surface of die to provide the physical and electrical contact
3.2.7
micro bump
small size bump to make an electrical contact between two dies
3.2.8
flip chip
die mounted with face down
3.2.9
through-silicon via
TSV
vertical interconnect access passing completely through a silicon wafer or die
Note 1 to entry: Examples of TSVs are shown in Figure 1.

Key
a power TSV;
b single drop signal TSV;
c multiple drop signal TSV;
d inter-die jumper;
e stacked inter-die jumper.
Figure 1 – Examples of TSVs
3.2.10
power TSV
TSV intended to deliver power from one layer to another layer of stacked silicon wafers or
dies
Note 1 to entry: Examples are shown in Figure 1.
3.2.11
single drop signal TSV
TSV intended to deliver electric signals from one layer to another layer of stacked silicon
wafers or dies
Note 1 to entry: An example is shown in Figure 1.
3.2.12
multiple drop signal TSV
TSV intended to deliver electric signals from one layer to multiple layers of stacked silicon
wafers or dies
Note 1 to entry: An example is shown in Figure 1.
3.2.13
inter-die jumper
TSV bridging circuits between adjacent two layers of stacked dies, that is not connected to
the output pin of the package
Note 1 to entry: An example is shown in Figure 1.

– 10 – IEC 63011-1:2018 © IEC 2018
3.2.14
single drop signal pin
TSV connecting the first die and to a pin of the package
3.2.15
multiple drop signal pin
TSV connecting delivering a signal from a pin of the package to multiple layers of dies
3.2.16
keep-out zone
KOZ
area around TSV in which it is recommended not to be occupied with active circuits because
the electrical properties are modified by the mechanical distortion by TSV
Note 1 to entry: This note applies to the French language only.
3.2.17
non-contacting die stack
chip in which two or more layers of active electronic components are integrated and signals
between the multiple layers are transferred without physical contacts
3.2.17.1
capacitive coupling
coupling between electric circuit elements, by which a voltage between the terminals of one of
them gives rise to an electric charge in another element
[SOURCE: IEC 60050-131:2002, 131-12-31]
3.2.17.2
inductive coupling
coupling between electric circuit elements, by which an electric current in one of them gives
rise to a linked flux between the terminals of another element
[SOURCE: IEC 60050-131:2002, 131-12-33]
3.2.18
cross-point
feature or device formed at the cross-section dimension of specific row and specific column
3.2.19
vertical transistor
transistor made to transport the charge in vertical direction
3.2.20
through-silicon via
vertical electrical connection passing completely through a silicon wafer or die
3.2.21
alignment key
apparatus to monitor or adjust the alignment of the overlaid dies
3.2.22
capacitive alignment
alignment method using differentiation of capacitance, where the maximum capacitance
appears when the top and bottom plates or chips perfectly overlap

3.2.23
inductive alignment
alignment method using differentiation of inductance, where the maximum capacitance
appears when the top and bottom plates or chips perfectly overlap
3.2.24
capacitance test
measurement of the capacitance incorporated with the t
...
