CISPR 32:2015

CISPR 32 ®
Edition 2.0 2015-03
INTERNATIONAL
STANDARD
NORME
INTERNATIONALE
colour
inside
INT ERNATIONAL SPECIAL COMMITTEE ON RADIO INTERFERENCE
C OMITÉ INTERNATIONAL SPÉCIAL DES PERTURBATIONS RADIOÉLECTRIQUES

Electromagnetic compatibility of multimedia equipment – Emission
requirements
Compatibilité électromagnétique des équipements multimédia – Exigences
d'émission
