Amendement 1 - Household and similar electrical appliances - Safety - Part 2-103: Particular requirements for drives for gates, doors and windows

Amendement 1 - Appareils électrodomestiques et analogues - Sécurité - Partie 2-103: Règles particulières pour les motorisations de portails, portes et fenêtres

General Information

Status
Published
Publication Date
06-Oct-2010
Current Stage
DELPUB - Deleted Publication
Completion Date
15-Apr-2015
Ref Project

Relations

Buy Standard

Standard
IEC 60335-2-103:2006/AMD1:2010 - Amendement 1 - Household and similar electrical appliances - Safety - Part 2-103: Particular requirements for drives for gates, doors and windows Released:10/7/2010
English and French language
9 pages
sale 15% off
Preview
sale 15% off
Preview

Standards Content (Sample)


IEC 60335-2-103 ®
Edition 2.0 2010-10
INTERNATIONAL
STANDARD
NORME
INTERNATIONALE
AMENDMENT 1
AMENDEMENT 1
Household and similar electrical appliances – Safety –
Part 2-103: Particular requirements for drives for gates, doors and windows

Appareils électrodomestiques et analogues – Sécurité –
Partie 2-103: Règles particulières pour les motorisations de portails, portes
et fenêtres
IEC 60335-2-103:2006/A1:2010
All rights reserved. Unless otherwise specified, no part of this publication may be reproduced or utilized in any form or by
any means, electronic or mechanical, including photocopying and microfilm, without permission in writing from either IEC or
IEC's member National Committee in the country of the requester.
If you have any questions about IEC copyright or have an enquiry about obtaining additional rights to this publication,
please contact the address below or your local IEC member National Committee for further information.

Droits de reproduction réservés. Sauf indication contraire, aucune partie de cette publication ne peut être reproduite
ni utilisée sous quelque forme que ce soit et par aucun procédé, électronique ou mécanique, y compris la photocopie
et les microfilms, sans l'accord écrit de la CEI ou du Comité national de la CEI du pays du demandeur.
Si vous avez des questions sur le copyright de la CEI ou si vous désirez obtenir des droits supplémentaires sur cette
publication, utilisez les coordonnées ci-après ou contactez le Comité national de la CEI de votre pays de résidence.

IEC Central Office
3, rue de Varembé
CH-1211 Geneva 20
Switzerland
Email: inmail@iec.ch
Web: www.iec.ch
About the IEC
The International Electrotechnical Commission (IEC) is the leading global organization that prepares and publishes
International Standards for all electrical, electronic and related technologies.

About IEC publications
The technical content of IEC publications is kept under constant review by the IEC. Please make sure that you have the
latest edition, a corrigenda or an amendment might have been published.
ƒ Catalogue of IEC publications: www.iec.ch/searchpub
The IEC on-line Catalogue enables you to search by a variety of criteria (reference number, text, technical committee,…).
It also gives information on projects, withdrawn and replaced publications.
ƒ IEC Just Published: www.iec.ch/online_news/justpub
Stay up to date on all new IEC publications. Just Published details twice a month all new publications released. Available
on-line and also by email.
ƒ Electropedia: www.electropedia.org
The world's leading online dictionary of electronic and electrical terms containing more than 20 000 terms and definitions
in English and French, with equivalent terms in additional languages. Also known as the International Electrotechnical
Vocabulary online.
ƒ Customer Service Centre: www.iec.ch/webstore/custserv
If you wish to give us your feedback on this publication or need further assistance, please visit the Customer Service
Centre FAQ or contact us:
Email: csc@iec.ch
Tel.: +41 22 919 02 11
Fax: +41 22 919 03 00
A propos de la CEI
La Commission Electrotechnique Internationale (CEI) est la première organisation mondiale qui élabore et publie des
normes internationales pour tout ce qui a trait à l'électricité, à l'électronique et aux technologies apparentées.

A propos des publications CEI
Le contenu technique des publications de la CEI est constamment revu. Veuillez vous assurer que vous possédez
l’édition la plus récente, un corrigendum ou amendement peut avoir été publié.
ƒ Catalogue des publications de la CEI: www.iec.ch/searchpub/cur_fut-f.htm
Le Catalogue en-ligne de la CEI vous permet d’effectuer des recherches en utilisant différents critères (numéro de référence,
texte, comité d’études,…). Il donne aussi des informations sur les projets et les publications retirées ou remplacées.
ƒ Just Published CEI: www.iec.ch/online_news/justpub
Restez informé sur les nouvelles publications de la CEI. Just Published détaille deux fois par mois les nouvelles
publications parues. Disponible en-ligne et aussi par email.
ƒ Electropedia: www.electropedia.org
Le premier dictionnaire en ligne au monde de termes électroniques et électriques. Il contient plus de 20 000 termes et
définitions en anglais et en français, ainsi que les termes équivalents dans les langues additionnelles. Egalement appelé
Vocabulaire Electrotechnique International en ligne.
ƒ Service Clients: www.iec.ch/webstore/custserv/custserv_entry-f.htm
Si vous désirez nous donner des commentaires sur cette publication ou si vous avez des questions, visitez le FAQ du
Service clients ou contactez-nous:
Email: csc@iec.ch
Tél.: +41 22 919 02 11
Fax: +41 22 919 03 00
IEC 60335-2-103 ®
Edition 2.0 2010-10
INTERNATIONAL
STANDARD
NORME
INTERNATIONALE
AMENDMENT 1
AMENDEMENT 1
Household and similar electrical appliances – Safety –
Part 2-103: Particular requirements for drives for gates, doors and windows

Appareils électrodomestiques et analogues – Sécurité –
Partie 2-103: Règles particulières pour les motorisations de portails, portes
et fenêtres
INTERNATIONAL
ELECTROTECHNICAL
COMMISSION
COMMISSION
ELECTROTECHNIQUE
PRICE CODE
INTERNATIONALE
E
CODE PRIX
ICS 13.120; 91.060.50 ISBN 978-2-88912-217-2
– 2 – 60335-2-103 Amend. 1 © IEC:2010
FOREWORD
This amendment has been prepared by IEC technical committee 61: Safety of household and
similar electrical appliances.
The text of this amendment is based on the following documents:
FDIS Report on voting
61/4048/FDIS 61/4078/RVD
Full information on the voting for the approval of this amendment can be found in the report
on voting indicated in the above table.
This amendment allows IEC 60335-2-103 Ed 2.0 to be used in conjunction with the fifth
edition of IEC 60335-1 (2010).
The committee has decided that the contents of this amendment and the base publication will
remain unchanged until the stability date indicated on the IEC web site under
"http://webstore.iec.ch" in the data related to the specific publication. At this date, the
publication will be
• reconfirmed,
• withdrawn,
• replaced by a revised edition, or
• amended.
NOTE The attention of National Committees is drawn to the fact that equipment manufacturers and testing
organizations may need a transitional period following publication of a new, amended or revised IEC publication in
which to make products in accordance with the new requirements and to equip themselves for conducting new or
revised tests.
It is the recommendation of the committee that the content of this publication be adopted for implementation
nationally not earlier than 12 months or later than 36 months from the date of publication.
___________
INTRODUCTION
Replace the fifth paragraph by the following:
When a part 2 standard does not include additional requirements to cover hazards dealt with
in Part 1, Part 1 applies.
NOTE 1 This means that the technical committees responsible for the part 2 standards have determined that it is
not necessary to specify particular requirements for the appliance in question over and above the general
requirements.
This standard is a product family standard dealing with the safety of appliances and takes
precedence over horizontal and generic standards covering the same subject.
NOTE 2 Horizontal and generic standards covering a hazard are not applicable since they have been taken into
consideration when developing the general and particular requirements for the IEC 60335 series of standards. For
example, in the case of temperature requirements for surfaces on many appliances, generic standards, such as
ISO 13732-1 for hot surfaces, are not applicable in addition to Part 1 or part 2 standards.

60335-2-103 Amend. 1 © IEC:2010 – 3 –
1 Scope
Replace the two dashed items in the fifth paragraph by the following:
– persons (including children) whose
• physical, sensory or mental capabilities; or
• lack of experience and knowledge
prevents them from using the appliance safely without supervision or instruction;
– children playing with the appliance.
7 Marking and instructions
7.12 In the fifth dashed item of the second paragraph replace the words “fire-sensing” with
the words “smoke control”.
th
7.12.1 In the third paragraph, delete the 10 dashed item.
20 Stability and mechanical hazards
20.2 Replace Note 101 by the following and renumber the other notes accordingly.
Moving parts of drives intended to be installed at a height of at least 2,5 m above the ground
or other access level are considered to be positioned so to provide adequate protection
against personal injury in normal use.
20.107 Replace the second paragraph of the test specification by the following:
For drives, other than drives for windows, incorporating an entrapment protection system
that allows the driven part to contact a person, compliance is checked by the relevant tests
specified in 20.107.2.
For drives for windows incorporating an entrapment protection system that allows the
driven part to contact a person, compliance is checked by the relevant tests specified in
20.107.2 except 20.107.2.3.
20.107.1.3 Replace the text by the following:
20.107.1.3 The obstacle used in 20.107.1.1 is located with the 700 mm dimension positioned
vertically and is moved at a speed of 3 m/s ± 0,6 m/s.
For both horizontally and vertically moving driven parts, the obstacle is moved in a straight
line through the plane of the driven part opening at the most unfavourable angle.
For pedestrian doors, the obstacle is placed initially at 5 m away from the opening and then
moved in a straight line through the centre of the opening plane and also at each 45° angle on
each side of the door.
The drive is operated to close the driven part. The driven part shall stop or reverse its
movement without contacting the obstacle.

– 4 – 60335-2-103 Amen
...
