Packaging of components for automatic handling - Part 3: Packaging of surface mount components on continuous tapes

Relates to the tape packaging of electronic components without leads or with lead stumps which are intended to be connected to electronic circuits. Includes only those dimensions which are essential for the taping of components for the above-mentioned purposes.

Gurtung und Magazinierung von Bauelementen für automatische Verarbeitung - Teil 3: Gurtung von oberflächenmontierbaren Bauelementen

Emballage de composants pour opérations automatisées - Partie 3: Emballage des composants appropriés au montage en surface en bandes continues

Concerne la mise en bande des composants électroniques sans fils de sorties ou avec tronçons de sorties destinés à être connectés à des circuits électroniques Seules les dimensions essentielles pour la mise sur bande de composants destinés aux opérations mentionnées ci-dessus sont données.

Packaging of components for automatic handling - Part 3: Packaging of surface mount components on continuous tapes (IEC 60286-3:1997)

General Information

Status: Withdrawn
Publication Date: 05-Feb-1998
Withdrawal Date: 30-Sep-1998

ICS: 31.020 - Electronic components in general
: 55.060 - Spools. Bobbins

Technical Committee: CLC/SR 40 - Capacitors and resistors for electronic equipment
Drafting Committee: IEC/TC 40 - IEC_TC_40
Parallel Committee: IEC/TC 40 - IEC_TC_40

Current Stage: 9960 - Withdrawal effective - Withdrawal
Start Date: 01-Sep-2010
Completion Date: 01-Sep-2010

Ref Project: SIST EN 60286-3:2002 - Packaging of components for automatic handling -- Part 3: Packaging of surface mount components on continuous tapes
