EN 15094:2008
(Main)Safety of Machinery - Safety requirements for cold flat rolling mills
Safety of Machinery - Safety requirements for cold flat rolling mills
This European Standard specifies the safety requirements for cold rolling mills for flat products (coiled or as heavy plates) as defined in 3.1.
This European Standard deals with significant hazards, hazardous situations and events relevant to cold rolling mills for flat products. It deals not only with circumstances where the machinery is used as intended, but also includes other conditions foreseen by the manufacturer, such as foreseeable faults, malfunctions or misuse (see clauses 4 and 5).
This European standard applies to: Machinery and equipment used for the manufacturing of metal cold rolled flat products from the material entry station (1), through the forming stations (2), to the exit (3) (see Figure 1).
The following equipment is outside the scope of this European Standard:
- furnaces in accordance with EN 746-1, EN 746-2 and EN 746-3;
- pickling plants according to EN 15061;
- strip processing lines according to EN 15061;
- abrasive blasting plants according to EN 1248;
- roll shop equipment;
- hook conveyors according to EN 619;
- storage equipment (e. g., high-bay warehouses);
- cranes, fork lifts, trucks and railway trucks and other vehicles.
This European Standard is not applicable to cold rolling mills for flat products, manufactured before the date of publication of this standard by CEN.
Sicherheit von Maschinen - Sicherheitsanforderungen an Kaltflachwalzwerke
Diese Europäische Norm spezifiziert die allgemeinen Sicherheitsanforderungen von Kaltwalzwerken für Flach-produkte (gehaspelt oder als Grobblech) wie in 3.1 beschrieben.
Diese Europäische Norm behandelt die für Kaltflachwalzwerke zutreffenden signifikanten Gefährdungen, Gefährdungs¬situationen und -ereignisse. Sie behandelt nicht nur die Gegebenheiten, bei denen die Maschine bestimmungsgemäß genutzt wird, sondern beinhaltet auch andere Bedingungen, die der Hersteller voraus-gesehen hat wie vorhersehbare Fehler, Fehlfunktionen oder fehlerhafte Nutzung (siehe Abschnitte 4 und 5).
Diese Europäische Norm gilt für: Anlagen und Ausrüstung zur Herstellung von kaltgewalzten Flach¬erzeug-nissen aus Metall, vom Material-Einlaufteil (1) durch die Walzstationen (2) zum Auslauf (3) (siehe Bild 1).
Die folgende Ausrüstung ist vom Anwendungsbereich dieser Europäischen Norm ausgenommen:
Öfen in Übereinstimmung mit EN 746-1, EN 746-2 und EN 746-3;
Beizanlagen in Übereinstimmung mit EN 15061;
Bandbehandlungsanlagen in Übereinstimmung mit EN 15061;
Strahlanlagen in Übereinstimmung mit EN 1248;
Ausrüstung der Walzenwerkstatt;
Hakenbahnen in Übereinstimmung mit EN 619;
Lagerausrüstung (z. B. Hochregallager);
Krane, Gabelstapler, Transportwagen, Güterwagen und andere Fahrzeuge.
Diese Europäische Norm gilt nicht für Kaltflachwalzwerke, die vor dem Datum der Veröffentlichung dieser Norm durch das CEN hergestellt wurden.
Sécurité des machines - Prescriptions de sécurité relatives aux laminoirs à froid pour produits plats
La présente Norme européenne spécifie les prescriptions générales de sécurité pour les laminoirs à froid pour
produits plats (roulés ou tôles lourdes) comme défini en 3.1.
La présente Norme européenne traite des phénomènes dangereux significatifs, des situations et événements
dangereux associés aux laminoirs à froid pour produits plats. Elle ne prend pas seulement en compte les
conditions liées à l’utilisation normale de la machine mais elle inclut aussi d’autres conditions prévues par le
fabricant, comme les défauts, les dysfonctionnements ou le mauvais usage prévisible (voir Articles 4 et 5).
La présente Norme européenne s’applique aux : installations et équipements utilisés pour la fabrication de
produits métalliques plats laminés à froid depuis le poste d’alimentation en matière jusqu’à l’entrée (1) vers la
sortie (3) en passant par les postes de formage (2) (voir Figure 1).
Varnost strojev - Varnostne zahteve za valjarne (hladno valjanje)
General Information
- Status
- Withdrawn
- Publication Date
- 30-Sep-2008
- Withdrawal Date
- 20-Jan-2026
- Drafting Committee
- CEN/TC 322/WG 3 - Rolling mills and finishing line equipment
- Current Stage
- 9960 - Withdrawal effective - Withdrawal
- Start Date
- 04-May-2022
- Completion Date
- 21-Jan-2026
- Directive
- 98/37/EC - Machinery
Relations
- Effective Date
- 11-May-2022
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Refers
EN ISO 13850:2006 - Safety of machinery - Emergency stop - Principles for design (ISO 13850:2006) - Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
- Effective Date
- 28-Jan-2026
Frequently Asked Questions
EN 15094:2008 is a standard published by the European Committee for Standardization (CEN). Its full title is "Safety of Machinery - Safety requirements for cold flat rolling mills". This standard covers: This European Standard specifies the safety requirements for cold rolling mills for flat products (coiled or as heavy plates) as defined in 3.1. This European Standard deals with significant hazards, hazardous situations and events relevant to cold rolling mills for flat products. It deals not only with circumstances where the machinery is used as intended, but also includes other conditions foreseen by the manufacturer, such as foreseeable faults, malfunctions or misuse (see clauses 4 and 5). This European standard applies to: Machinery and equipment used for the manufacturing of metal cold rolled flat products from the material entry station (1), through the forming stations (2), to the exit (3) (see Figure 1). The following equipment is outside the scope of this European Standard: - furnaces in accordance with EN 746-1, EN 746-2 and EN 746-3; - pickling plants according to EN 15061; - strip processing lines according to EN 15061; - abrasive blasting plants according to EN 1248; - roll shop equipment; - hook conveyors according to EN 619; - storage equipment (e. g., high-bay warehouses); - cranes, fork lifts, trucks and railway trucks and other vehicles. This European Standard is not applicable to cold rolling mills for flat products, manufactured before the date of publication of this standard by CEN.
This European Standard specifies the safety requirements for cold rolling mills for flat products (coiled or as heavy plates) as defined in 3.1. This European Standard deals with significant hazards, hazardous situations and events relevant to cold rolling mills for flat products. It deals not only with circumstances where the machinery is used as intended, but also includes other conditions foreseen by the manufacturer, such as foreseeable faults, malfunctions or misuse (see clauses 4 and 5). This European standard applies to: Machinery and equipment used for the manufacturing of metal cold rolled flat products from the material entry station (1), through the forming stations (2), to the exit (3) (see Figure 1). The following equipment is outside the scope of this European Standard: - furnaces in accordance with EN 746-1, EN 746-2 and EN 746-3; - pickling plants according to EN 15061; - strip processing lines according to EN 15061; - abrasive blasting plants according to EN 1248; - roll shop equipment; - hook conveyors according to EN 619; - storage equipment (e. g., high-bay warehouses); - cranes, fork lifts, trucks and railway trucks and other vehicles. This European Standard is not applicable to cold rolling mills for flat products, manufactured before the date of publication of this standard by CEN.
EN 15094:2008 is classified under the following ICS (International Classification for Standards) categories: 77.180 - Equipment for the metallurgical industry. The ICS classification helps identify the subject area and facilitates finding related standards.
EN 15094:2008 has the following relationships with other standards: It is inter standard links to EN 15094:2022, EN ISO 12100-2:2003, EN ISO 4414:2010, EN 614-1:2006, EN 894-2:1997+A1:2008, EN ISO 11202:2010, EN 1063:1999, EN ISO 11688-1:2009, EN ISO 13850:2006, EN ISO 13851:2019, EN 894-1:1997+A1:2008, EN 14253:2003+A1:2007, EN 15004-1:2024, EN 13861:2011, EN 12198-3:2002+A1:2008. Understanding these relationships helps ensure you are using the most current and applicable version of the standard.
EN 15094:2008 is associated with the following European legislation: EU Directives/Regulations: 2006/42/EC, 98/37/EC; Standardization Mandates: M/079, M/396. When a standard is cited in the Official Journal of the European Union, products manufactured in conformity with it benefit from a presumption of conformity with the essential requirements of the corresponding EU directive or regulation.
EN 15094:2008 is available in PDF format for immediate download after purchase. The document can be added to your cart and obtained through the secure checkout process. Digital delivery ensures instant access to the complete standard document.
Standards Content (Sample)
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Varnost strojev - Varnostne zahteve za valjarne (hladno valjanje)Sicherheit von Maschinen - Sicherheitsanforderungen an KaltflachwalzwerkeSécurité des Machines - Prescriptions de sécurité relatives aux laminoirs a froid pour produits platsSafety of Machinery - Safety requirements for cold flat rolling mills25.120.20Rolling, extruding and drawing equipment13.110Varnost strojevSafety of machineryICS:Ta slovenski standard je istoveten z:EN 15094:2008SIST EN 15094:2008en01-december-2008SIST EN 15094:2008SLOVENSKI
STANDARD
EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 15094October 2008ICS 77.180 English VersionSafety of Machinery - Safety requirements for cold flat rollingmillsSécurité des machines - Prescriptions de sécurité relativesaux laminoirs à froid pour produits platsSicherheit von Machinen - Sicherheitsanforderungen anKaltflachwalzwerkeThis European Standard was approved by CEN on 24 August 2008.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the CEN Management Centre or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as theofficial versions.CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland,France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal,Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre: rue de Stassart, 36
B-1050 Brussels© 2008 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 15094:2008: ESIST EN 15094:2008
Safety requirements and/or measures for electrical equipment and control systems at cold rolling mills.43 A.1 General.43 A.2 Special requirements for controls.43 A.3 Special requirements for shut-down equipment.44 A.3.1 Stop functions/emergency stop functions.44 A.3.2 Selection of stop functions.44 A.3.3 Emergency stop areas.44 A.3.4 Stop functions.45 Annex B (normative)
Noise test code.47 B.1 Introduction.47 B.2 Determination of A-weighted sound power level.47 B.3 Determination of A-weighted emission sound pressure levels.48 B.3.1 Determination of the emission sound pressure level at specified measuring points.48 B.3.2 Determination of emission sound pressure level at work stations.48 B.4 Measurement uncertainty.48 B.5 Operating conditions.48 B.6 Information to be recorded and reported.49 B.7 Declaration and verification of noise emission values.49 Annex C (normative)
Protection of persons in case of using asphyxiant gases in fire fighting systems.52 C.1 General.52 C.2 Warning devices.52 C.3 Restraint devices.53 C.4 Preliminary warning time.53 C.5 Interrupt device for extinguishing gas.54 C.6 Blocking devices.54 C.7 Pipes.54 C.8 Rooms and adjacent areas.54 C.9 Escape routes.54 C.10 Doors.54 C.11 Marking.55 C.12 Instruction handbook.55 Annex D (informative)
Example for manufacturer's safety instructions for maintenance at cold flat rolling mills.56 D.1 Precautions to reduce hazards caused by.56 D.1.1 Lack of instructions.56 D.1.2 Visual or audible checks at machinery in motion.56 D.1.3 Unintentional movements during maintenance.56 D.1.4 Work during standstill with safeguards disabled.57 D.1.5 Work with hazardous substances.57 D.1.6 Plant re-start.57 Annex E (informative)
Machines and/or equipment covered by this standard.58 SIST EN 15094:2008
Roll spalling.59 F.1 Hazard.59 F.2 Causes.59 F.3 Safety measures.59 Annex G (informative)
Example for the risk analysis due to interfaces.60 Annex ZA (informative)
Relationship between this European Standard and the Essential Requirements of EU Directive 98/37/EC.61 Annex ZB (informative)
Relationship between this European Standard and the Essential Requirements of EU Directive 2006/42/EC.62 Bibliography.63
Tables Table 1 — Significant hazards, hazardous situations, safety requirements and/or measures.20 Table 2 — Main noise sources of cold flat rolling mills equipment and exemplary noise reduction measures.37 Table A.1 — Stop functions.45 Table B.1 — Example of declared dual-number noise emission values for work stations and specified measuring points.51
Key 1 entry section 2 cold rolling mill 3 exit section 4 roll changing device 5 border of the plant
Figure 1 — Exemplary layout of a cold flat rolling mill The following equipment is outside the scope of this European Standard: furnaces in accordance with EN 746-1, EN 746-2 and EN 746-3; pickling plants according to EN 15061; strip processing lines according to EN 15061; abrasive blasting plants according to EN 1248; roll shop equipment; hook conveyors according to EN 619; storage equipment (e. g., high-bay warehouses); cranes, fork lifts, trucks and railway trucks and other vehicles. SIST EN 15094:2008
EXAMPLES coiled strip, heavy plates.
NOTE Machines and equipment which are covered by this standard are listed in Annex E. SIST EN 15094:2008
This standard assumes that: installations are operated and maintained by adequately trained and competent personnel; manual intervention for setting, adjustment and maintenance is accepted as part of the normal use of the equipment; the machinery is used with adequate workplace lighting conforming to EN 12464-1 or to local regulations. In general, risks and associated hazards are production and plant-related. The main differences arising from the processing of different materials in different qualities and the surrounding (i. e. different combination of machines, different boundary conditions, see Annex G). The resulting variety of "different plants" could not be covered in all details in a standard. To deal with this fact an individual risk assessment of the cold flat rolling mill in question shall be carried out (see 4) considering the safety requirements of this standard. Where the means of reducing the risk is by the physical arrangement or positioning of the installed machines, the manufacturer shall include in the Information for use a reference to the reduction means to be provided, and to any limiting value of the requirement, and, if appropriate, to the means of verification. Where the means of reducing the risk is by a safe system of working the line, the manufacturer shall include in the Information for use details of the system and of the elements of information required by the operating personnel. This shall include protective measures used according 4.11.9 and 4.11.10 of EN ISO 12100-SIST EN 15094:2008
...
