EN 13082:2008+A1:2012
(Main)Tanks for transport of dangerous goods - Service equipment for tanks - Vapour transfer valve
Tanks for transport of dangerous goods - Service equipment for tanks - Vapour transfer valve
This European Standard covers the vapour transfer valve, used for the transfer of vapour between the tank compartment and the pipework connecting to the vapour collection adaptor.
This European Standard specifies the performance requirements and the critical dimensions of the vapour transfer valve. It also specifies the tests necessary to verify the compliance of the equipment with this European Standard. The equipment specified by this standard is suitable for use with liquid petroleum products and other dangerous substances of Class 3 of ADR [2] which have a vapour pressure not exceeding 110 kPa at 50 °C and petrol, and which have no sub-classification as toxic or corrosive.
Tanks für die Beförderung gefährlicher Güter - Bedienungsausrüstung von Tanks - Gaspendelventil
Diese Europäische Norm behandelt das Gaspendelventil, das zur Weiterleitung von Gas zwischen dem
Tankabteil und der Verbindungsleitung zur VKG-Kupplung dient.
In dieser Europäischen Norm sind die Leistungsanforderungen und die wesentlichen Maße des
Gaspendelventils festgelegt. Weiterhin sind die Prüfungen festgelegt, mit denen nachgewiesen werden kann,
ob die Ausrüstung den Anforderungen dieser Europäischen Norm entspricht. Die in dieser Norm beschriebene
Ausrüstung ist zum Umfüllen flüssiger Erdölerzeugnisse und anderer gefährlicher Güter der Klasse 3 des
ADR [2] geeignet, deren Dampfdruck bei 50 °C max. 110 kPa beträgt (einschließlich Ottokraftstoff) und die
nicht als giftig oder ätzend eingestuft sind.
Citernes de transport de matières dangereuses - Équipement de service pour citernes - Évent de transfert des vapeurs récupérées
La présente Norme européenne traite de l’évent de transfert des vapeurs récupérées utilisé pour le transfert des vapeurs entre la citerne et la tuyauterie de raccordement à l’adaptateur pour la récupération des vapeurs.
La présente Norme européenne spécifie les caractéristiques de performance et les dimensions essentielles de l’évent de transfert des vapeurs récupérées. Elle spécifie également les essais à réaliser pour vérifier la conformité des équipements à la présente Norme européenne. Les équipements spécifiés par la présente norme conviennent à une utilisation avec des produits pétroliers liquides et autres matières dangereuses de la classe 3 de l’ADR [2], dont la tension de vapeur ne dépasse pas 110 kPa à 50 °C (y compris l’essence), et qui n’appartiennent à aucune sous-classe de produits toxiques ou corrosifs.
Cisterne za prevoz nevarnega blaga - Oprema za obratovanje cistern - Ventil za izenačitev parnega tlaka (vključno z dopolnilom A1)
Ta evropski standard zajema ventil za izenačitev parnega tlaka, ki se uporablja za prenos pare med oddelkom s cisterno in cevovodom, ki je povezan s spojko za zbiralnik pare. Ta evropski standard določa zahteve za učinkovitost in kritične mere ventila za izenačitev parnega tlaka. Določa tudi preskuse, potrebne za preverjanje skladnosti opreme s tem evropskim standardom. Oprema, ki jo določa ta standard, je primerna za uporabo s tekočimi naftnimi proizvodi in drugimi nevarnimi snovmi kategorije 3 ADR, katerih parni tlak ne presega 110 kPa pri 50 °C, ter z motornim bencinom, pri čemer niso dodatno opredeljeni kot strupeni ali korozivni.
General Information
- Status
- Published
- Publication Date
- 14-Feb-2012
- Technical Committee
- CEN/TC 296 - Tanks for transport of dangerous goods
- Current Stage
- 9093 - Decision to confirm - Review Enquiry
- Start Date
- 03-Dec-2024
- Completion Date
- 23-Sep-2025
Relations
- Effective Date
- 19-Jan-2023
- Effective Date
- 07-Dec-2011
Overview
EN 13082:2008+A1:2012 is a CEN European Standard for vapour transfer valves used on tanks for transport of dangerous goods. It defines the performance requirements, critical dimensions and mandatory tests for valves that transfer vapour between the tank compartment and the pipework connecting to the vapour collection adaptor. The standard applies to liquid petroleum products and other ADR Class 3 substances (including petrol) with vapour pressures ≤ 110 kPa at 50 °C, provided they are not classified as toxic or corrosive. EN 13082 supports compliance with vapour collection and VOC control requirements (Directive 94/63/EC).
Key Topics
- Scope and applicability: Vapour transfer valves for tank vehicles and associated vapour collection manifolds; ADR Class 3 liquids and petrol with specified vapour-pressure limits.
- Design requirements:
- Default design temperature range: −20 °C to +50 °C (extendable to −40 °C or +70 °C where required).
- Actuation: remote operation allowed; valves may have sequential functions and must return to closed position on failure.
- Open indication: valve shall be provided with a means to indicate when it is open.
- Materials: manufacturer must provide full material specification for wetted parts.
- Dimensional requirements:
- Maximum assembly height above mounting face: 150 mm.
- Flanged and through-hole connection dimensions specified (flange sizes, spigot diameters, bolt patterns, threaded spigot up to 98 mm).
- Performance:
- Manufacturer to provide pressure-drop curve up to 300 standard m³/h of air at 20 °C.
- Maximum Working Pressure (MWP) referenced for strength tests.
- Testing regime:
- Production tests (sampling per ISO 2859-1 AQL 2.5): shell tightness, internal seat tightness (5.5 kPa), operability.
- Type tests (minimum two samples): shell strength (500 kPa or 1.5×MWP), shell tightness, seat tightness (5.5 kPa and 25 kPa), mechanical endurance, drop test.
- Test procedures reference EN 12266‑1 and EN 12266‑2.
Applications
- Manufacturers of tank vehicle service equipment and vapour collection systems.
- Valve and component designers developing certified vapour transfer valves.
- Tank builders, fleet operators and service-station engineers specifying vapour recovery interfaces for loading/unloading.
- Certification bodies and test laboratories performing production and type testing to meet ADR and VOC control requirements.
Related Standards
- EN 13081 (vapour collection adaptor and coupler)
- EN 13083, EN 13308, EN 13314, EN 13315, EN 13316, EN 13317, EN 13922, EN 14595, EN 14596, EN 15208
- Test standards: EN 12266‑1, EN 12266‑2
- Sampling: ISO 2859‑1
- CEN Technical Report: CEN/TR 15120
Keywords: EN 13082:2008+A1:2012, vapour transfer valve, tanks for transport of dangerous goods, vapour collection system, VOC, ADR Class 3, valve testing, EN 12266.
Frequently Asked Questions
EN 13082:2008+A1:2012 is a standard published by the European Committee for Standardization (CEN). Its full title is "Tanks for transport of dangerous goods - Service equipment for tanks - Vapour transfer valve". This standard covers: This European Standard covers the vapour transfer valve, used for the transfer of vapour between the tank compartment and the pipework connecting to the vapour collection adaptor. This European Standard specifies the performance requirements and the critical dimensions of the vapour transfer valve. It also specifies the tests necessary to verify the compliance of the equipment with this European Standard. The equipment specified by this standard is suitable for use with liquid petroleum products and other dangerous substances of Class 3 of ADR [2] which have a vapour pressure not exceeding 110 kPa at 50 °C and petrol, and which have no sub-classification as toxic or corrosive.
This European Standard covers the vapour transfer valve, used for the transfer of vapour between the tank compartment and the pipework connecting to the vapour collection adaptor. This European Standard specifies the performance requirements and the critical dimensions of the vapour transfer valve. It also specifies the tests necessary to verify the compliance of the equipment with this European Standard. The equipment specified by this standard is suitable for use with liquid petroleum products and other dangerous substances of Class 3 of ADR [2] which have a vapour pressure not exceeding 110 kPa at 50 °C and petrol, and which have no sub-classification as toxic or corrosive.
EN 13082:2008+A1:2012 is classified under the following ICS (International Classification for Standards) categories: 13.300 - Protection against dangerous goods; 23.020.20 - Vessels and containers mounted on vehicles; 23.060.20 - Ball and plug valves. The ICS classification helps identify the subject area and facilitates finding related standards.
EN 13082:2008+A1:2012 has the following relationships with other standards: It is inter standard links to EN 13082:2008, EN 13082:2008/FprA1. Understanding these relationships helps ensure you are using the most current and applicable version of the standard.
EN 13082:2008+A1:2012 is associated with the following European legislation: EU Directives/Regulations: 2008/68/EC; Standardization Mandates: M/086. When a standard is cited in the Official Journal of the European Union, products manufactured in conformity with it benefit from a presumption of conformity with the essential requirements of the corresponding EU directive or regulation.
You can purchase EN 13082:2008+A1:2012 directly from iTeh Standards. The document is available in PDF format and is delivered instantly after payment. Add the standard to your cart and complete the secure checkout process. iTeh Standards is an authorized distributor of CEN standards.
Standards Content (Sample)
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Tanks für die Beförderung gefährlicher Güter - Bedienungsausrüstung von Tanks - GaspendelventilCiternes de transport de matières dangereuses - Équipement de service pour citernes - Évent de transfert des vapeurs récupéréesTanks for transport of dangerous goods - Service equipment for tanks - Vapour transfer valve23.060.20Zapirni ventili (kroglasti in pipe)Ball and plug valves23.020.20Posode in vsebniki, montirani na vozilaVessels and containers mounted on vehicles13.300Varstvo pred nevarnimi izdelkiProtection against dangerous goodsICS:Ta slovenski standard je istoveten z:EN 13082:2008+A1:2012SIST EN 13082:2009+A1:2012en,fr,de01-junij-2012SIST EN 13082:2009+A1:2012SLOVENSKI
STANDARDSIST EN 13082:20091DGRPHãþD
EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 13082:2008+A1
February 2012 ICS 13.300; 23.020.20; 23.060.20 Supersedes EN 13082:2008English Version
Tanks for transport of dangerous goods - Service equipment for tanks - Vapour transfer valve
Citernes de transport de matières dangereuses - Équipement de service pour citernes - Évent de transfert des vapeurs récupérées
Tanks für die Beförderung gefährlicher Güter - Bedienungsausrüstung von Tanks - Gaspendelventil This European Standard was approved by CEN on 13 September 2008 and includes Amendment 1 approved by CEN on 24 December 2011.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2012 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 13082:2008+A1:2012: ESIST EN 13082:2009+A1:2012
Drop test apparatus . 13Annex B (normative)
Maximum height - Installation requirement . 14Bibliography . 15 SIST EN 13082:2009+A1:2012
...
