Pipe sizing – liquid phase . 30 A.1 General . 30 A.2 Viscosity of LPG . 30 A.3 Calculation of liquid velocity flow in pipework . 30 A.4 Calculation of Reynolds number . 31 A.5 Liquid flow capacity and pressure drop in pipework . 31 A.6 Liquid flow capacity and pressure drop through valves and fittings . 32 Annex B (informative)
Pipe sizing – gas phase . 37 B.1 General . 37 B.2 Calculation of full vapour flow and pressure drop in pipes . 37 B.3 Vapour flow capacity and pressure drop through valves and fittings . 37 B.4 Gas velocity . 37 Annex C (informative)
Pipework Integrity Management Systems (PIMS) . 38 C.1 Pipework Integrity Management . 38 C.2 Basic PIMS for LPG plants . 38 C.3 Assessment of condition . 38 C.4 Response (remedial action/ future monitoring or inspection) . 38 C.5 Frequency of inspection and maintenance . 39 Annex D (informative)
Environmental checklist. 40 Annex E (informative)
Manufacturing and type testing of composite pipes . 41 E.1 General . 41 E.2 Materials . 41 E.3 Physical properties . 42 E.4 Manuals . 42 E.5 Records . 43 Bibliography . 44 SIST EN 16125:2016

« t r ¹Cä In serviceá temperatures below this can be encountered during short periods, for example, when filling. In some parts of Europe and in certain applications where a lower temperature than
« t r ¹C can be encounteredá the minimum design temperature shall be
« v r ¹Câ — the maximum working temperature shall be 65°C for above ground pipework and 40 C for underground pipework; — the maximum allowable pressure for pipework shall be less than or equal to 25 bar; — pipes shall be suitable for transport and storage at
« v r ¹C and
x w ¹Cä NOTE Vacuum conditions on the pipework arising from butane at low temperature or evacuation of the pipework can expose the pipework to a vacuum of 50 mbar absolute. The minimum pressure to which pipework is normally exposed is 0 bar. 4.4 Protection against hazards 4.4.1 Protection against mechanical damage Pipework shall be protected against mechanical damage. For protection of underground pipework, see 6.6.1.4 4.4.2 Resistance to corrosive substances and atmospheres All pipework and fittings, including supports, shall be protected from corrosion according to the environment and operating conditions they will be subjected to during their service life. NOTE Stainless steel pipework and fittings can be subject to chloride induced stress cracking, e.g. coastal areas or other areas where salt laden atmospheres can occur. 4.4.3 Protection against condensation For vapour pressure pipework, precautions shall be taken to avoid problems occurring in the pipe and downstream equipment due to condensate forming. Figure 1 indicates temperatures and pressures for propane, mixes of propane/butane and butane. NOTE 1 Where the stored LPG liquid temperature is higher than the temperature of the downstream pipework, the LPG can condense to a liquid. This is known as the dew point. NOTE 2 In Figure 1, where the LPG is exposed to a pressure above the curve, the LPG vapour will condense. In order to prevent condensation of LPG, trace heating of the pipework shall be considered. Alternatively the pipework shall drain back to the vessels. If this is not possible a suitably located vapour-liquid separator (knockout pot) may be installed in the line to allow condensation to collect and subsequently boil off without causing problems. SIST EN 16125:2016

Literature Reference: Buecker,D. and Wagner, W. “Reference equations of state for thermodynamic properties of fluid phase n-Butane and Isobutane” J. Phys. Chem. Ref. Data, 35(2):929-1019,2006 Key X temperature in °C Y pressure in bar
100% Propane
80% Propane 20% Butane
50% Propane 50% Butane
20% Propane 80% Butane
