EN 115-1:2008+A1:2010

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Sicherheit von Fahrtreppen und Fahrsteigen - Teil 1: Konstruktion und EinbauSécurité des escaliers mécaniques et trottoirs roulants - Partie 1: Construction et installationSafety of escalators and moving walks - Part 1: Construction and installation91.140.90Lifts. EscalatorsICS:Ta slovenski standard je istoveten z:EN 115-1:2008+A1:2010SIST EN 115-1:2009+A1:2010en,fr,de01-julij-2010SIST EN 115-1:2009+A1:2010SLOVENSKI
STANDARDSIST EN 115-1:20091DGRPHãþD

EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 115-1:2008+A1
March 2010 ICS 91.140.90 Supersedes EN 115-1:2008English Version
Safety of escalators and moving walks - Part 1: Construction and installation
Sécurité des escaliers mécaniques et trottoirs roulants - Partie 1: Construction et installation
Sicherheit von Fahrtreppen und Fahrsteigen - Teil 1: Konstruktion und Einbau This European Standard was approved by CEN on 29 May 2008 and includes Amendment 1 approved by CEN on 23 February 2010.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2010 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 115-1:2008+A1:2010: ESIST EN 115-1:2009+A1:2010

Building interfaces . 62Annex B (normative)
Electronic components - Failure exclusion . 67Annex C (normative)
Drafting and assessing fail safe circuits. 72Annex D (normative)
!Testing of fail safe circuits containing electronic components and/or programmable electronic systems (PESSRAE)" . 73Annex E (informative)
Design guide-line for safety circuits . 76Annex F (informative)
Examples of possible dynamic torsional tests for steps and pallets . 77Annex G (normative)
Safety signs for the user of escalators and moving walks . 80Annex H (informative)
Guidelines for selection and planning of escalators and moving walks . 82Annex I (normative)
Requirements on escalators and moving walks intended to transport shopping trolleys and baggage carts . 83Annex J (informative)
Determination of anti-slip properties of the tread surfaces of steps and pallets, of comb plates and cover plate . 85Annex K (informative)
Determination of sliding properties of footwear on balustrade skirting . 87Annex L (informative)
Interpretations of EN 115-1:2008 . 88Annex ZA (informative)
!Relationship between this European Standard and the Essential Requirements of EU Directive 2006/42/EC" . 91Bibliography . 92 SIST EN 115-1:2009+A1:2010

Some individuals, in particular older people, might have more than one impairment. Some individuals are not able to use an escalator or moving walk independently and rely on assistance/support being provided by a companion. Furthermore some individuals can be encumbered by objects or be responsible for other persons, which can affect their mobility. The extent to which an individual is incapacitated by impairments and encumbrances often depends on the usability of products, facilities and the environment. The use of wheelchairs on escalators and moving walks can lead to dangerous situations which cannot be mitigated by machine designs and therefore should not be permitted. The use of lifts is the preferred method of vertical travel for most people with disabilities and in particular wheelchair users and persons with guide dogs. Additional signs should be provided to indicate the location of other facilities, these facilities should be in close proximity to the escalators and moving walks and easy to find.
It is assumed that negotiations have been made for each contract between the customer and the supplier/installer (see also Annex A) about: a) intended use of the escalator or moving walk; b) environmental conditions; c) civil engineering problems; d) other aspects related to the place of installation. If escalators or moving walks are intended to be operated under special conditions, such as directly exposed to the weather or explosive atmosphere, or in exceptional cases serve as emergency exits, appropriate design criteria, components, materials and instructions for use should be used that satisfy the particular conditions. An Interpretation Committee has been established to clarify, if necessary, the spirit in which the clauses of the standard have been drafted and to specify the requirements appropriate to particular cases. Interpretation Requests can be sent to the National Standard Bodies which will contact the responsible Technical Committee CEN/TC 10. The formats of an interpretation request and the interpretation are given in Annex L. SIST EN 115-1:2009+A1:2010

(IEC 60068-2-6:1995 + Corrigendum 1995) EN 60068-2-14, Environmental testing — Part 2: Tests — Test N: Change of temperature
(IEC 60068-2-14:1984 + A1:1986) EN 60068-2-27:1993, Basic environmental testing procedures — Part 2: Tests — Test Ea and guidance: Shock (IEC 60068-2-27:1987) EN 60068-2-29, Basic environmental testing procedures — Part 2: Tests; Test Eb and guidance: Bump
(IEC 60068-2-29:1987) EN 60204-1:2006, Safety of machinery — Electrical equipment of machines — Part 1: General requirements (IEC 60204-1:2005, modified) EN 60269-1, Low-voltage fuses - Part 1: General requirements (IEC 60269-1:2006) EN 60439-1:1999, Low-voltage switchgear and controlgear assemblies — Part 1: Type-tested and partially type-tested assemblies (IEC 60439 1:1999) EN 60529, Degrees of protection provided by enclosures (IP code) (IEC 60529:1989) EN 60664-1:2007, Insulation coordination for equipment within low-voltage systems — Part 1: Principles, requirements and tests (IEC 60664-1:2007) EN 60947-4-1, Low-voltage switchgear and controlgear — Part 4-1: Contactors and motor-starters; Electromechanical contactors and motor-starters (IEC 60947-4-1:2000) EN 60947-5-1, Low-voltage switchgear and controlgear - Part 5-1: Control circuit devices and switching elements — Electromechanical control circuit devices (IEC 60947-5-1:2003) EN 61249 series, Materials for printed boards and other interconnecting structures (IEC 61249 series) EN 61558-1:2005, Safety of power transformers, power supplies, reactors and similar products — Part 1: General requirements and tests (IEC 61558-1:2005) !EN 62061, Safety of machinery — Functional safety of safety-related electrical, electronic and programmable electronic control systems (IEC 62061:2005)" EN 62326-1, Printed boards — Part 1: Generic specification (IEC 62326-1:2002) EN ISO 12100-1:2003, Safety of machinery — Basic concepts, general principles for design — Part 1: Basic terminology, methodology (ISO 12100-1:2003) EN ISO 12100-2:2003, Safety of machinery — Basic concepts, general principles for design — Part 2: Technical principles (ISO 12100-2:2003) !deleted text" EN ISO 13850, Safety of machinery — Emergency stop — Principles for design (ISO 13850:2006) SIST EN 115-1:2009+A1:2010

angle of inclination maximum angle to the horizontal in which the steps, the pallets or the belt move 3.1.2 balustrade part of the escalator/moving walk which ensures the user's safety by providing stability, protecting from moving parts and supporting the handrail 3.1.3 balustrade decking transverse member of the balustrade which meets the handrail guidance profile and which forms the top cover of the balustrade
3.1.4 brake load load on the step/pallet/belt which the brake system is designed to stop the escalator/moving walk 3.1.5 a comb pronged section at each landing that meshes with the grooves SIST EN 115-1:2009+A1:2010

NOTE Escalators are machines - even when they are out of operation - and cannot be considered as fixed staircases. 3.1.9 exterior panel
part of the exterior side of the enclosure of an escalator or moving walk 3.1.10 fail safe circuit safety related electrical and/or electronic system with defined failure mode behaviour 3.1.11 handrail power-driven moving rail for persons to grip while using the escalator or moving walk 3.1.12 interior panel panel located between the skirting or lower inner decking and the handrail guidance profile or balustrade decking 3.1.13 a lower inner decking profile that connects the skirting with the interior panel when they do not meet at a common point 3.1.13 b lower outer decking profile that connects the exterior panels with the interior panel 3.1.14 machinery escalator or moving walk machine(s) mechanisms and associated equipment 3.1.15 machinery spaces space(s) inside or outside of the truss where the machinery as a whole or in parts is placed 3.1.16 maximum capacity maximum flow of persons that can be achieved under operational conditions SIST EN 115-1:2009+A1:2010

NOTE Moving walks are machines - even when they are out of operation – and should not be used as a fixed access. 3.1.18 newel end of the balustrade 3.1.19 nominal speed speed in the direction of the moving steps, pallets or the belt, when operating the equipment under no load condition (i.e. without persons), stated by the manufacturer as that for which the escalator or moving walk has been designed NOTE Rated speed is the speed the escalator/moving walk moves under rated load conditions. !3.1.20 programmable electronic system in safety related applications for escalators and moving walks (PESSRAE) system for control, protection or monitoring based on one or more programmable electronic devices, including all elements of the system such as power supplies, sensors and other input devices, data highways and other communication paths, and actuators and other output devices, used in safety related applications as listed in Table 6" 3.1.21 rated load load which the equipment is designed to move NOTE For maximum capacity, see Annex H. 3.1.22 rise vertical distance between the upper and lower finished floor levels 3.1.23 safety circuit part of the electric safety system consisting of electrical safety devices !3.1.24 safety integrity level (SIL) discrete level for specifying the safety integrity requirements of the safety functions to be allocated to the PESSRAE NOTE In this European Standard SIL 1 is representing the lowest level and SIL 3 the highest, even when it does not make use of SIL 3." 3.1.25 skirting vertical part of the balustrade interfacing with the steps, pallets or belt 3.1.26 skirt deflector device to minimise the risk of trapping between the step and the skirting SIST EN 115-1:2009+A1:2010

mm 4 v Nominal speed m/s - x1 Step height m 5 y1 Step depth m 5 z1 Nominal width for the load carrying area (step, pallet or belt) m 3, 5 z2 Horizontal distance between skirting m 3 z3 Transverse distance between the supporting rollers mm 8 α Angle of inclination of the escalator or moving walk °(degree) 2 ß Design angle of the teeth of the comb °(degree) 2 γ Cross-sectional angle of inclination of the lower inner decking °(degree) 3 µ Friction coefficient - -
4 List of significant hazards 4.1 General This clause contains all the significant hazards, hazardous situations and events, as far as they are dealt with in this standard, identified by risk assessment as significant for escalators and moving walks and which require action to eliminate or reduce the risk. These significant hazards are based upon EN ISO 14121-1 [2]. 4.2 Mechanical hazards Mechanical hazards on escalators and moving walks and in their immediate vicinity can occur because of the design of the machine or access to it. SIST EN 115-1:2009+A1:2010

4.9 Slipping, tripping and falling hazards Most of the dangerous situations on escalators and moving walks are caused by the slipping and falling of persons. These include:  slipping on steps/pallets/belt, on the comb plate and floor plate (see 5.3.1, 5.5.4, 5.7.1);  falling caused by handrail speed deviation (incl. standstill) (see 5.6.1, Fig. G.1, Fig. G.3);  falling caused by change of the direction of movement (see 5.4.2.3); SIST EN 115-1:2009+A1:2010

NOTE 2
For definition of materials and test methods, see Annex J. 5.3.2 Dimensions 5.3.2.1 General For escalators and moving walks the nominal width z1 shall be not less than 0,58 m and not exceed 1,10 m. For moving walks with an angle of inclination up to 6° widths up to 1,65 m are permitted. 5.3.2.2 Step treads and pallets (see Figure 2, detail X and Figure 5) 5.3.2.2.1 The step height x1 shall not exceed 0,24 m. 5.3.2.2.2 The step depth y1 shall be not less than 0,38 m. 5.3.2.2.3 The surface of the step treads and pallets shall have grooves in the direction of movement with which the teeth of the combs mesh.
5.3.2.2.4 The step risers shall be cleated and the surface of the cleat shall be smooth. The ends of the step tread shall mesh with the cleating of the next step riser. 5.3.2.2.5 The width b7 of the grooves shall be at least 5 mm and not exceed 7 mm. 5.3.2.2.6 The depth h7 of the grooves shall be not less than 10 mm. 5.3.2.2.7 The web width b8 shall be at least 2,5 mm and not exceed 5 mm. 5.3.2.2.8 The step treads and step risers or pallets shall not finish with a groove at their side edges. 5.3.2.2.9 The edge between the surface of the step tread and the riser shall have any sharpness relieved. 5.3.2.3 Belts (see Figure 2, detail X) 5.3.2.3.1 The belts shall have grooves in the direction of travel with which the teeth of the comb mesh. 5.3.2.3.2 The width b7 of the grooves shall be at least 4,5 mm and not exceed 7 mm, and shall be measured at the tread surface of the belt. 5.3.2.3.3 The depth h7 of the grooves shall be not less than 5 mm. 5.3.2.3.4 The web width b8 shall be at least 4,5 mm and not exceed 8 mm and shall be measured at the tread surface of the belt. 5.3.2.3.5 The belt shall not finish with a groove at the side edge of the belt. SIST EN 115-1:2009+A1:2010

NOTE 6 000 N/m2 is derived from a static load of 5 000 N/m2 (see 5.2.5) plus an impact factor of 1,2. To establish the dimensions of the belt and its supporting system, an area of effective width x 1,0 m length shall be taken as a basis for this corresponding load (in addition the requirements of 5.3.3.2.4 shall be complied with). Assembled steps and pallets shall be designed such that all component parts e.g. inserts or fixings are securely attached and do not become loose during their life cycle. The inserts and fixings shall withstand the reaction force of operating the comb/comb plate electric safety device (Table 6 g)). 5.3.3.2 Static test 5.3.3.2.1 Steps The step shall be tested for deflection with a single force of 3 000 N (including weight of the plate) applied perpendicular to the tread surface on a steel plate 0,20 m x 0,30 m in size and at least 25 mm thick, in the centre of the tread surface. The edge of the plate being 0,20 m long shall be arranged parallel to the front edge of the step, the edge of the plate being 0,30 m long at right angles to the front edge of the step. During this test, the deflection mea
...
