EN 12493:2013+A2:2018

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Flüssiggas-Geräte und Ausrüstungsteile - Geschweißte Druckbehälter aus Stahl für Straßentankwagen für Flüssiggas (LPG) - Auslegung und HerstellungÉquipements pour GPL et leurs accessoires - Réservoirs sous pression en acier soudés des camions-citernes pour GPL - Conception et constructionLPG equipment and accessories - Welded steel pressure vessels for LPG road tankers - Design and manufacture43.080.10Tovornjaki in priklopnikiTrucks and trailers23.020.32Pressure vesselsICS:Ta slovenski standard je istoveten z:EN 12493:2013+A2:2018SIST EN 12493:2013+A2:2018en,fr,de01-november-2018SIST EN 12493:2013+A2:2018SLOVENSKI
STANDARDSIST EN 12493:2013+A1:2014/AC:2015SIST EN 12493:2013+A1:20141DGRPHãþD

EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 12493:2013+A2
June
t r s z ICS
t uä r t rä u râ
t uä r t rä u w Supersedes EN
s t v { uã t r s u ªA sã t r s vEnglish Version
LPG equipment and accessories æ Welded steel pressure vessels for LPG road tankers æ Design and manufacture Équipements pour GPL et leurs accessoires æ Rßservoirs sous pression en acier soudßs des camionsæciternes pour GPL æ Conception et construction
FlüssiggasæGeräte und Ausrüstungsteile æ Geschweißte Druckbehälter aus Stahl für Straßentankwagen für This European Standard was approved by CEN on
t t May
t r s v and includes Corrigendum
s issued by CEN on
s July
t r s w and Amendment
t approved by CEN on
t t January
t r s zä
egulations which stipulate the conditions for giving this European Standard the status of a national standard without any alterationä Upætoædate lists and bibliographical references concerning such national standards may be obtained on application to the CENæCENELEC Management Centre or to any CEN memberä
translation under the responsibility of a CEN member into its own language and notified to the CENæCENELEC Management Centre has the same status as the official versionsä
CEN members are the national standards bodies of Austriaá Belgiumá Bulgariaá Croatiaá Cyprusá Czech Republicá Denmarká Estoniaá Finlandá Former Yugoslav Republic of Macedoniaá Franceá Germanyá Greeceá Hungaryá Icelandá Irelandá Italyá Latviaá Lithuaniaá Luxembourgá Maltaá Netherlandsá Norwayá Polandá Portugalá Romaniaá Serbiaá Slovakiaá Sloveniaá Spainá Swedená Switzerlandá Turkey and United Kingdomä
EUROPEAN COMMITTEE FOR STANDARDIZATION COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
CEN-CENELEC Management Centre:
Rue de la Science 23,
B-1040 Brussels
t r s z CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Membersä Refä Noä EN
s t v { uã t r s u ªA tã t r s z ESIST EN 12493:2013+A2:2018

Guidance on selection of material grades . 27 Annex B (normative)
Reference temperatures for design . 28 B.1 Introduction. 28 B.2 General . 28 B.3 Developed pressure . 28 SIST EN 12493:2013+A2:2018

Alternative reference temperatures for design . 29 C.1 Introduction . 29 C.2 General . 29 C.3 Developed pressure . 29 C.4 Filling . 29 Annex D (normative)
Design . 30 D.1 Design stresses . 30 D.2 Design pressure . 30 D.3 Design formulae . 30 D.3.1 Cylindrical shell calculation . 30 D.3.2 Dished ends . 31 D.3.3 Conical shell calculations . 34 D.4 Nozzle reinforcement . 38 D.5 Nozzle reinforcement by pads or flanges . 40 D.6 Nozzle reinforcement by branches . 40 Annex E (informative)
Example of joints . 45 Annex F (normative)
Allowable tolerances . 49 F.1 Pressure vessels . 49 F.1.1 External diameter . 49 F.1.2 Out of roundness . 49 F.1.3 Deviation of straightness. 49 F.1.4 Irregularities in profile . 49 F.2 Dished end tolerance . 50 F.2.1 Thickness of material . 50 F.2.2 Profile . 50 F.3 Assembly tolerances . 52 F.3.1 Middle line alignment . 52 F.3.2 Surface alignment . 52 F.4 Attachments, nozzles and fittings . 52 F.5 Overall length . 53 Annex G (normative)
Heat treatment . 54 G.1 Method of post-weld heat treatment . 54 G.2 Temperature control . 54 G.3 Temperature limit . 54 G.4 Temperature measurement . 54 Annex H (informative)
Typical method for measurement of shell peaking . 55 H.1 Profile gauge . 55 H.2 Peaking survey . 55 Annex I (normative)
Welding imperfections and test specimens . 58 I.1 Imperfections . 58 I.2 Test specimens . 61 Annex J (informative)
Choice of non-destructive test methods for welds . 63 J.1 Internal imperfections . 63 J.2 Surface imperfections . 63 Annex K (normative)
Hydraulic pressure test . 64 K.1 Temporary fittings . 64 K.2 Pressure gauges . 64 K.3 Pressurizing agent . 64 SIST EN 12493:2013+A2:2018

EN ISO 14000 series (#see [8], [9] and [10]$). Provisions need to be restricted to a general guidance. Limit values are specified in national laws. It has been assumed in the drafting of this European Standard that the execution of its provisions is entrusted to appropriately qualified and experienced people. All pressures are gauged unless otherwise stated. NOTE This European Standard requires measurement of material properties, dimensions and pressures. All such measurements are subject to a degree of uncertainty due to tolerances in measuring equipment, etc. It might be beneficial to refer to the leaflet “measurement uncertainty leaflet" SP INFO 2000 27 #[15]$. SIST EN 12493:2013+A2:2018

NOTE 4 This standard is intended for LPG only; however for other liquefied gases see EN 14025.$ 2 Normative references The following documents, in whole or in part, are normatively referenced in this document and are indispensable for its application. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. #deleted text$ EN 837-2, Pressure gauges — Part 2: Selection and installation recommendations for pressure gauges EN 10025-2, Hot rolled products of structural steels — Part 2: Technical delivery conditions for non-alloy structural steels EN 10028-2, Flat products made of steels for pressure purposes — Part 2: Non-alloy and alloy steels with specified elevated temperature properties EN 10028-3, Flat products made of steels for pressure purposes — Part 3: Weldable fine grain steels, normalized EN 10204:2004, Metallic materials — Types of inspection documents EN 12252, LPG equipment and accessories — Equipping of LPG road tankers EN 13445-2, Unfired pressure vessels — Part 2: Materials EN 13445-3, Unfired pressure vessels — Part 3: Design EN 14717, Welding and allied processes — Environmental check list EN ISO 148-1, Metallic materials — Charpy pendulum impact test — Part 1: Test method (ISO 148-1) EN ISO 3452-1, Non-destructive testing — Penetrant testing — Part 1: General principles (ISO 3452-1) SIST EN 12493:2013+A2:2018

EN ISO 5579, Non-destructive testing — Radiographic testing of metallic materials using film and X- or gamma rays — Basic rules (ISO 5579)$ EN ISO 5817:2007, Welding — Fusion-welded joints in steel, nickel, titanium and their alloys (beam welding excluded) — Quality levels for imperfections (ISO 5817:2003, corrected version:2005, including Technical Corrigendum 1:2006)) EN ISO 6520-1:2007, Welding and allied processes — Classification of geometric imperfections in metallic materials — Part 1: Fusion welding (ISO 6520-1:2007) EN ISO 6520-2:2013, Welding and allied processes — Classification of geometric imperfections in metallic materials — Part 2: Welding with pressure (ISO 6520-2:2013) EN ISO 6892-1, Metallic materials — Tensile testing — Part 1: Method of test at room temperature (ISO 6892-1) EN ISO 9016, Destructive tests on welds in metallic materials — Impact tests — Test specimen location, notch orientation and examination (ISO 9016) #
EN ISO 9606-1, Qualification testing of welders — Fusion welding — Part 1: Steels (ISO 9606-1)$ EN ISO 9712, Non-destructive testing — Qualification and certification of NDT personnel (ISO 9712) EN ISO 14732, Welding personnel — Qualification testing of welding operators and weld setters for mechanized and automatic welding of metallic materials (ISO 14732) EN ISO 15609-1, Specification and qualification of welding procedures for metallic materials — Welding procedure specification — Part 1: Arc welding (ISO 15609-1) EN ISO 15614-1, Specification and qualification of welding procedures for metallic materials — Welding procedure test — Part 1: Arc and gas welding of steels and arc welding of nickel and nickel alloys (ISO 15614-1) EN ISO 17636-1, Non-destructive testing of welds — Radiographic testing — Part 1: X- and gamma-ray techniques with film (ISO 17636-1) EN ISO 17636-2, Non-destructive testing of welds — Radiographic testing — Part 2: X- and gamma-ray techniques with digital detectors (ISO 17636-2) EN ISO 17637, Non-destructive testing of welds — Visual testing of fusion-welded joints (ISO 17637) SIST EN 12493:2013+A2:2018

EN ISO 19232-1, Non-destructive testing — Image quality of radiographs — Part 1: Determination of the image quality value using wire-type image quality indicators (ISO 19232-1)$ EN ISO 19232-2, Non-destructive testing — Image quality of radiographs — Part 2: Determination of the image quality value using step/hole-type image quality indicators (ISO 19232-2) 3 Terms and definitions For the purposes of this document, the following terms and definitions apply. 3.1 liquefied petroleum gas LPG low pressure liquefied gas composed of one or more light hydrocarbons which are assigned to UN 1011, UN 1075, UN 1965, UN 1969 or UN 1978 only and which consists mainly of propane, propene, butane, butane isomers, butene with traces of other hydrocarbon gases 3.2 yield strength upper yield strength ReH or, for steels that do not exhibit a definite yield (non-proportional elongation), the 0,2 % proof strength 3.3 cold forming forming at temperatures not less than 25 °C below the maximum permissible temperature for stress relieving, in accordance with the applicable material specifications 3.4 hot forming forming at temperatures above the temperature for stress relieving as stated in the material specifications SIST EN 12493:2013+A2:2018

(1) where A1 minimum elongation at fracture (%) of steel chosen under tensile stress; e1 minimum shell thickness in chosen steel, in mm; e0 minimum thickness in reference steel, in mm; Rm1 minimum tensile strength of steel chosen, in N/mm2. #
5.2.4 The minimum shell thickness will not be less than calculated in accordance with the ADR.$ 5.3 Surge plates 5.3.1 Where it is intended that pressure vessels will be operated in excess of 20 % full or less than 80 % full, surge plates shall be fitted. The surge plates shall be designed to permit full internal inspection of the pressure vessel. The volume between any two plates or a plate and the end of the pressure vessel shall not exceed 7 500 l. #
