EN 1648-1:2012

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Bewohnbare Freizeitfahrzeuge - Elektrische Anlagen für DC 12 V - Teil 1: CaravansVéhicules habitables de loisirs - Installations électriques à très basse tension de 12 V en courant continu - Par-tie 1: CaravanesLeisure accommodation vehicles - 12 V direct current extra low voltage electrical installations - Part 1: Caravans43.100Osebni avtomobili. Bivalne prikolice in lahke prikolicePassenger cars. Caravans and light trailers43.040.10RSUHPDElectrical and electronic equipmentICS:Ta slovenski standard je istoveten z:EN 1648-1:2012SIST EN 1648-1:2012en,de01-oktober-2012SIST EN 1648-1:2012SLOVENSKI
STANDARDSIST EN 1648-1:20051DGRPHãþD

EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 1648-1
July 2012 ICS 43.040.10; 43.100 Supersedes EN 1648-1:2004English Version
Leisure accommodation vehicles - 12 V direct current extra low voltage electrical installations - Part 1: Caravans
Véhicules habitables de loisirs - Installations électriques à très basse tension de 12 V en courant continu - Partie 1: Caravanes
Bewohnbare Freizeitfahrzeuge - Elektrische Anlagen für DC12 V - Teil 1: Caravans This European Standard was approved by CEN on 16 June 2012.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2012 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 1648-1:2012: ESIST EN 1648-1:2012

Relation of cable cross-sectional area, current flow and cable length for fixed wiring installations . 15SIST EN 1648-1:2012

3 A.1 General. 15A.2 Graphs for obtaining minimum cross-sectional areas . 15A.3 Calculation of the minimum cross-sectional areas . 16Bibliography . 18 Figures Figure 1 — Overview of relevant European Standards applying to leisure accommodation vehicles . 6Figure A.1 — Graph for obtaining minimum cross-sectional area for conductors for fixed wiring installations with a voltage drop of 0,8 V
.......................................................................................................................................... 15Figure A.2 — Graph for obtaining minimum cross-sectional area for conductors for battery cable installations with a voltage drop of 0,3 V
.......................................................................................................................................... 16Tables Table 1 — Functional allocation and cross-sectional areas of the single cores of the connecting cable(s) .............. 11 SIST EN 1648-1:2012

b) Requirements on tube diameter deleted in 4.3.4 b); c) Reference to EC directive 2007/46/EC, Annex II added in 4.3.4; d) Clarification added to 4.3.5 and Clause 8 that the warning notice shall be written in the language(s) of the country in which the caravan is to be sold for the first time; e) Sub-clause 4.5 amended; f) Footnotes added in Table 1 for clarification; g) Sub-clause 5.3 "Fixed wiring" amended; h) Note added in 6.2; i) Clause 7 "Installation of appliances" amended; j) Normative references adapted according to above listed changes; k) Annex A revised editorially; l) Figure 1 added to Foreword. EN 1648, Leisure accommodation vehicles - 12 V direct current extra low voltage electrical installations contains the following parts:  Part 1: Caravans (the present document);  Part 2: Motor caravans. This document is based on ISO 8818 “Leisure accommodation vehicles — Caravans — 12 V direct current extra low voltage electrical installations” and takes into consideration specific aspects relating to electrical installations in caravans. The requirements of relative ISO/IEC and CENELEC publications were taken into consideration during the preparation of this European Standard. This document is one of a series covering the habitation aspects of leisure accommodation vehicles. SIST EN 1648-1:2012

5 Requirements for 12 V direct current extra low voltage electrical installations for motor caravans are specified in EN 1648-2. According to the CEN/CENELEC Internal Regulations, the national standards organisations of the following countries are bound to implement this European Standard: Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and the United Kingdom. SIST EN 1648-1:2012

Figure 1 — Overview of relevant European Standards applying to leisure accommodation vehicles SIST EN 1648-1:2012

7 1 Scope This European Standard specifies safety, health and functional requirements for 12 V direct current (DC) extra low voltage (ELV) electrical installations for habitation aspects of caravans. It covers the design and integration of the caravan system with the towing vehicle system. It does not apply to commercial trailers; nor does it include requirements for ELV road lighting and signalling lamps and their installations, except for safety requirements for the routing of cables in LPG storage compartments. This European Standard also specifies the ELV output requirements of low voltage (LV) equipment that may be used to provide an ELV supply but it does not specify safety, technical and functional requirements for LV appliances and installations. Requirements for LV installations are specified in HD 60364-7-721. 2 Normative references The following documents, in whole or in part, are normatively referenced in this document and are indispensable for its application. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 1645-1, Leisure accommodation vehicles — Caravans — Part 1: Habitation requirements relating to health and safety EN 13878:2003, Leisure accommodation vehicles — Terms and definitions EN 60529, Degrees of protection provided by enclosures (IP code) (IEC 60529) EN 60898-2, Electrical accessories — Circuit-breakers for overcurrent protection for household and similar installations — Part 2: Circuit-breakers for a.c. and d.c. operation (IEC 60898-2) EN ISO 11446, Road vehicles — Connectors for the electrical connection of towing and towed vehicles — 13-pole connectors for vehicles with 12 V nominal supply voltage (ISO 11446) HD 21 (series), Cables of rated voltages up to and including 450/750 V and having thermoplastic insulation HD 22 (series), Cables of rated voltages up to and including 450/750 V and having cross-linked insulation ISO 1724, Road vehicles — Connectors for the electrical connection of towing and towed vehicles — 7-pole connector type 12 N (normal) for vehicles with 12 V nominal supply voltage ISO 3732, Road vehicles — Connectors for the electrical connection of towing and towed vehicles — 7-pole connector type 12 S (supplementary) for vehicles with 12 V nominal supply voltage ISO 6722 (series), Road vehicles — 60 V and 600 V single-core cables
ISO 7010, Graphical symbols — Safety colours and safety signs — Registered safety signs ISO 8820-1, Road vehicles — Fuse-links — Part 1: Definitions and general test requirements ISO 8820-3, Road vehicles — Fuse-links — Part 3: Fuse-links with tabs (blade type) Type C (medium), Type E (high current) and Type F (miniature) ISO 8820-4, Road vehicles — Fuse-links — Part 4: Fuse-links with female contacts (type A) and bolt-in contacts (type B) and their test fixtures 3 Terms and definitions For the purposes of this document the terms and definitions given in EN 13878:2003 apply. SIST EN 1648-1:2012

NOTE A power supply with a nominal voltage different than DC 12 V is not allowed. 4.2 Sources of supply The supply shall be obtained from one or more of the following sources: a) the electrical installation of the towing vehicle; b) an auxiliary battery mounted within the caravan (see 4.3); c) LV supply via an on-board mounted AC/DC converter (e.g. transformer, switching power supply) that complies with the requirements of the relevant standards in accordance with directive 2006/95/EC and subsequent amendments; d) DC generator (see 4.4.1); e) regenerative energy sources (see 4.4.2). If several sources of supply are used it shall be ensured that there is no unfavourable interaction. 4.3 Auxiliary batteries 4.3.1 Type of battery An auxiliary battery shall be of the rechargeable type. Non-rec
...
