Standard Practice for Creation of Walkway Tribometer Interlaboratory Study Reports and Test Procedures
SIGNIFICANCE AND USE
5.1 The test procedures and interlaboratory study report that result from coordinator compliance with this Practice are intended to include all information required for an ASTM Test Method and its associated Research Report; the interlaboratory study is to be conducted in compliance with Practice E691, also as required for an ASTM Test Method.3 The reason that the content of this Practice is not prepared as an actual ASTM Test Method is as follows. ASTM regulations preclude reference (in a Standard) to patented or otherwise proprietary test apparatus where “alternatives exist”.4 While a proprietary apparatus may be mentioned in the Test Method’s Research Report, this would prevent the Test Method from being a standalone document containing all information necessary for testing. As such, a standalone Test Method could only be for a non-proprietary apparatus design, with this design expressed in terms of physical characteristics and performance specifications sufficient to enable the reader to fabricate their own “identical” copy of the design. Further, to achieve consensus approval and publication of such a Test Method, it could be considered necessary that ILS results for this design include data from devices made by different entities. However, typical walkway tribometer designs (versus other types of test apparatus) are sufficiently complex that full documentation of all performance-affecting physical characteristics (sufficient that a reader could build one) may be impractical. European standard EN 16165 Annexes C and D illustrate what physical and performance characteristics are and are not documented in that standard’s specifications for two non-proprietary tribometers. In general, each different tribometer design may have advantages and disadvantages for testing different surfaces, and this Practice provides a rigorous and standardized structure for creating tribometer test procedures and interlaboratory study reports that would comply with the requirements fo...
SCOPE
1.1 This practice covers creation of interlaboratory study reports and test procedures for the use of portable walkway tribometers for obtaining walkway surface friction measurements.
1.2 This practice does not address the interpretation of data relative to pedestrian safety.
1.3 This practice does not address the suitability of a walkway surface for a particular application.
1.4 This practice does not directly address the important issue of the frictional homogeneity and stability of reference materials and in-use walkway materials.
1.5 Conformance to this practice does not result in an ASTM Test Method.
1.6 Values stated in SI (metric) units are to be regarded as the standard. Values in parentheses are for information only.
1.7 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of regulatory limitations prior to use.
1.8 This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
General Information
Relations
Buy Standard
Standards Content (Sample)
This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the
Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
Designation: F3539 − 24
Standard Practice for
Creation of Walkway Tribometer Interlaboratory Study
1
Reports and Test Procedures
This standard is issued under the fixed designation F3539; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope E177 Practice for Use of the Terms Precision and Bias in
ASTM Test Methods
1.1 This practice covers creation of interlaboratory study
E691 Practice for Conducting an Interlaboratory Study to
reports and test procedures for the use of portable walkway
Determine the Precision of a Test Method
tribometers for obtaining walkway surface friction measure-
F3132 Practice for Selection of Walkway Surfaces When
ments.
Considering Pedestrian Safety
1.2 This practice does not address the interpretation of data
2.2 Other Standards:
relative to pedestrian safety.
EN 16165 Determination of Slip Resistance of Pedestrian
1.3 This practice does not address the suitability of a
Surfaces – Methods of Evaluation
walkway surface for a particular application.
ISO Guide 30 Reference materials Selected terms and defi-
1.4 This practice does not directly address the important nitions
ISO Guide 35 Reference materials Guidance for character-
issue of the frictional homogeneity and stability of reference
materials and in-use walkway materials. ization and assessment of homogeneity and stability
1.5 Conformance to this practice does not result in an
3. Terminology
ASTM Test Method.
3.1 Definitions:
1.6 Values stated in SI (metric) units are to be regarded as
3.1.1 accepted reference value, n—a value that serves as an
the standard. Values in parentheses are for information only.
agreed-upon reference for comparison, and which is derived
1.7 This standard does not purport to address all of the
as: (1) a theoretical or established value, based on scientific
safety concerns, if any, associated with its use. It is the
principles, (2) an assigned or certified value, based on experi-
responsibility of the user of this standard to establish appro-
mental work of some national or international organization, or
priate safety, health, and environmental practices and deter-
(3) a consensus or certified value, based on collaborative
mine the applicability of regulatory limitations prior to use.
experimental work under the auspices of a scientific or
1.8 This international standard was developed in accor-
engineering group. E177
dance with internationally recognized principles on standard-
3.1.2 available friction, n—an inherent characteristic of a
ization established in the Decision on Principles for the
Development of International Standards, Guides and Recom- walkway surface that would result in measurable friction upon
the attempted or actual sliding of another object across that
mendations issued by the World Trade Organization Technical
Barriers to Trade (TBT) Committee. surface; can only be measured using a method, apparatus and
contaminant (if any) that have their own inherent influences on
2. Referenced Documents the measurement value itself. F3132
2
2.1 ASTM Standards:
3.1.3 bias, n—the difference between the expectation of the
test results and an accepted reference value. E177
3.1.4 friction, n—the resistance to sliding of one surface
1
This practice is under the jurisdiction of ASTM Committee F13 on Pedestrian/
across another surface; may be evaluated through different
Walkway Safety and Footwear and is the direct responsibility of Subcommittee
methodologies and described using different terms. F3132
F13.10 on Traction.
Current edition approved April 1, 2024. Published April 2024. Originally
3.1.5 precision, n—the closeness of agreements between
approved in 2022. Last previous edition approved in 2022 as F3539 – 22. DOI:
independent test results obtained under stipulated conditions.
10.1520/F3539-24.
2
E177
For referenced ASTM standards, visit the ASTM website, www.astm.org, or
contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM
3.1.6 reference material, n—material, sufficiently homoge-
Standards volume information, refer to the standard’s Document Summary page on
the ASTM website. neous and stable with respect to one or more specified
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
1
---------------------- Page: 1 ----------------------
F3539 − 24
3
properties, which has been established to be fit for its intended also as required for an ASTM Test M
...
This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: F3539 − 22 F3539 − 24
Standard Practice for
Creation of Walkway Tribometer Interlaboratory Study
1
Reports and Test Procedures
This standard is issued under the fixed designation F3539; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope
1.1 This practice covers creation of interlaboratory study reports and test procedures for the use of portable walkway tribometers
for obtaining walkway surface friction measurements.
1.2 This practice does not address the interpretation of data relative to pedestrian safety.
1.3 This practice does not address the suitability of a walkway surface for a particular application.
1.4 This practice does not directly address the important issue of the frictional homogeneity and stability of reference materials
and in-use walkway materials.
1.5 Conformance to this practice does not result in an ASTM Test Method.
1.6 Values stated in SI (metric) units are to be regarded as the standard. Values in parentheses are for information only.
1.7 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility
of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of
regulatory limitations prior to use.
1.8 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
2. Referenced Documents
2
2.1 ASTM Standards:
E177 Practice for Use of the Terms Precision and Bias in ASTM Test Methods
E691 Practice for Conducting an Interlaboratory Study to Determine the Precision of a Test Method
F3132 Practice for Selection of Walkway Surfaces When Considering Pedestrian Safety
2.2 Other Standards:
EN 16165 Determination of Slip Resistance of Pedestrian Surfaces – Methods of Evaluation
ISO Guide 30 Reference materials Selected terms and definitions
1
This practice is under the jurisdiction of ASTM Committee F13 on Pedestrian/Walkway Safety and Footwear and is the direct responsibility of Subcommittee F13.10
on Traction.
Current edition approved Feb. 1, 2022April 1, 2024. Published March 2022April 2024. Originally approved in 2022. Last previous edition approved in 2022 as F3539 – 22.
DOI: 10.1520/F3539-22.10.1520/F3539-24.
2
For referenced ASTM standards, visit the ASTM website, www.astm.org, or contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM Standards
volume information, refer to the standard’s Document Summary page on the ASTM website.
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
1
---------------------- Page: 1 ----------------------
F3539 − 24
ISO Guide 35 Reference materials Guidance for characterization and assessment of homogeneity and stability
3. Terminology
3.1 Definitions:
3.1.1 accepted reference value, n—a value that serves as an agreed-upon reference for comparison, and which is derived as: (1)
a theoretical or established value, based on scientific principles, (2) an assigned or certified value, based on experimental work of
some national or international organization, or (3) a consensus or certified value, based on collaborative experimental work under
the auspices of a scientific or engineering group. E177
3.1.2 available friction, n—an inherent characteristic of a walkway surface that would result in measurable friction upon the
attempted or actual sliding of another object across that surface; can only be measured using a method, apparatus and contaminant
(if any) that have their own inherent influences on the measurement value itself. F3132
3.1.3 bias, n—the difference between the expectation of the test results and an accepted reference value. E177
3.1.4 friction, n—the resistance to sliding of one surface across another surface; may be evaluated through different methodologies
and described using different terms. F3132
3.1.5 precision, n—the closeness of agreements between independent test results obtained under stipulated conditions. E177
3.1.6 reference material, n—material, sufficiently homogeneous
...
