SIST EN 300 676-2 V1.5.1:2011
(Main)Ground-based VHF hand-held, mobile and fixed radio transmitters, receivers and transceivers for the VHF aeronautical mobile service using amplitude modulation - Part 2: Harmonized EN covering essential requirements of article 3.2 of the R&TTE Directive
- Abstract
The present document applies to DSB AM ground base stations, with channel separations of 8,33 kHz or 25 kHz
intended for analogue speech intended for ACARS data communication. The scope of the present document is limited
to ground based stations, ground mobile and hand held radios for ground use. These radio equipment types are capable
of operating in all or any part of the Aeronautical frequency band- between 118 MHz and 136,975 MHz.
The present document is intended to cover the provisions of Directive 1999/5/EC (R&TTE Directive) [i.1], article 3.2,
which states that "... radio equipment shall be so constructed that it effectively uses the spectrum allocated to
terrestrial/space radio communications and orbital resources so as to avoid harmful interference".
In addition to the present document, other ENs that specify technical requirements in respect of essential requirements
under other parts of article 3 of the R&TTE Directive [i.1] as well as essential requirements under the SES
Interoperability Regulation 552/2004 [i.2] and related implementing rules may apply to equipment within the scope of
the present document.
- Status
- Published
- Publication Date
- 20-Oct-2011
- Technical Committee
- MOC - Mobile Communications
- Current Stage
- 6060 - National Implementation/Publication (Adopted Project)
- Start Date
- 20-Sep-2011
- Due Date
- 25-Nov-2011
- Completion Date
- 21-Oct-2011
Buy Documents
en_30067602v010500o - Ground-based VHF hand-held, mobile and fixed radio transmitters, receivers and transceivers for the VHF aeronautical mobile service using amplitude modulation; Part 2: Harmonized EN covering essential requirements of article 3.2 of the R&TTE Directive
en_30067602v010501p - Ground-based VHF hand-held, mobile and fixed radio transmitters, receivers and transceivers for the VHF aeronautical mobile service using amplitude modulation; Part 2: Harmonized EN covering essential requirements of article 3.2 of the R&TTE Directive
SIST EN 300 676-2 V1.5.1:2011 is the Slovenian adoption of ETSI EN 300 676-2, a Harmonized European Standard for ground-based VHF hand-held, mobile and fixed radio transmitters, receivers and transceivers using amplitude modulation in the aeronautical mobile service. It specifies the essential requirements of article 3.2 of the R&TTE Directive, so the document is about effective spectrum use and avoiding harmful interference for ground equipment operating in the 118 MHz to 136,975 MHz band.
What does SIST EN 300 676-2 V1.5.1:2011 specify?
SIST EN 300 676-2 V1.5.1:2011 applies to DSB AM ground base stations, ground mobile radios and hand-held radios for ground use. The scope is limited to equipment intended for analogue speech and ACARS data communication in the aeronautical frequency band.
The document is organized into five clauses and three annexes:
| Annex | What it covers |
|---|---|
| Annex A | Normative HS Requirements and conformance Test specifications Table (HS-RTT) |
| Annex B | The EN title in the official languages |
| Annex C | Bibliography |
Clause 1 states the scope, Clause 2 gives references, Clause 3 defines terms and abbreviations, Clause 4 sets technical requirements, and Clause 5 sets the compliance test approach.
What are the key requirements of SIST EN 300 676-2 V1.5.1:2011?
SIST EN 300 676-2 V1.5.1:2011 ties each requirement to EN 300 676-1 and then adds the requirements needed for presumption of conformity under article 3.2. In practice, this means a manufacturer or test house uses Part 1 for the technical detail and Part 2 for the harmonized compliance target.
- Clause 4.1 - Environmental profile: the supplier shall declare the operating environmental profile, and the equipment shall meet the technical requirements throughout that declared range. In practice, the declared conditions become part of the compliance claim and the test plan.
- Clause 4.2.1 - Transmitter performance: the transmitter requirements cover frequency error, carrier power, adjacent channel power, conducted spurious emissions, and cabinet radiation. For base stations only, intermodulation attenuation and keying transient frequency behaviour also apply. This is the core of spectrum discipline: the transmitter must stay on frequency and limit unwanted emissions.
- Clause 4.2.2 - Receiver performance: the receiver requirements cover sensitivity, adjacent channel rejection, spurious response rejection, intermodulation response rejection, blocking or desensitisation, conducted spurious emissions, cross modulation rejection, and cabinet radiation. This matters because aeronautical VHF use depends on clear reception in crowded RF conditions.
- Clause 5.1 - Test conditions: testing follows the environmental conditions and procedures in clauses 5 and 6 of EN 300 676-1. This keeps the compliance tests aligned with the companion measurement standard.
- Clause 5.2 - Measurement uncertainty: the test report shall include the uncertainty for each measured parameter, and the uncertainty shall stay within the limits in Table 1. The figures are to be calculated using ETSI TR 100 028, so labs must document uncertainty, not only the measured value.
- Clause 5.3 - Essential radio test suites: transmitter and receiver tests are defined by cross reference to EN 300 676-1, and cabinet radiation uses the EN 300 113-1 test procedure. This gives a clear route from requirement to test method for type testing and conformance work.
- Annex A - HS-RTT: the requirements table marks each item as unconditional or conditional, and each test as essential or other. That helps decide which items are mandatory for a given equipment configuration, especially base-station-only functions.
What terms does SIST EN 300 676-2 V1.5.1:2011 define?
- ACARS (Aircraft Communications Addressing and Reporting System): a data communication system used in the aeronautical environment, named here because the scope includes equipment intended for ACARS data communication.
- AM (Amplitude Modulation): the modulation method used by the equipment covered by the standard.
- DSB (Double Side Band): the specific AM form named in the scope for the ground base stations.
- environmental profile: the declared range of operating environmental conditions within which the equipment must comply.
- ground base station: aeronautical station equipment for use with an external antenna and intended for a fixed location.
- conducted measurements: measurements made through a direct RF connection to the equipment under test.
- radiated measurements: measurements that use a radiated field rather than a direct connection.
Who uses SIST EN 300 676-2 V1.5.1:2011?
Manufacturers of aeronautical VHF ground radios use this standard when designing and declaring conformity for transmitters, receivers and transceivers. Test laboratories use it to set up type tests, record uncertainty and map results to the essential requirements.
Quality managers, conformity assessment teams and buyers use it to check whether equipment is intended for the right frequency band, station type and compliance route. It is also relevant to organizations that specify or procure ground equipment for analogue speech and ACARS-related communication.
Which standards are used with SIST EN 300 676-2 V1.5.1:2011?
- ETSI EN 300 676-1 (V1.5.2): provides the technical characteristics, measurement methods, limits and test procedures that Part 2 references for transmitter and receiver compliance.
- ETSI EN 300 113-1 (V1.6.2): provides the test procedure used for cabinet radiation measurements.
- ETSI TR 100 028 (V1.4.1): provides the method for calculating measurement uncertainties.
What does the SIST EN 300 676-2 V1.5.1:2011 document contain?
Annex A contains the HS-RTT table that links each requirement to its clause, shows whether it is unconditional or conditional, and identifies the essential test specification. Clause 5 also explains how measurement uncertainty is to be reported and how test results are interpreted against limits.
The document therefore serves as a compliance map rather than a full technical handbook. It tells a test house what to verify, which clauses to use, and which companion ETSI documents supply the detailed methods and limits.
Buy Documents
en_30067602v010500o - Ground-based VHF hand-held, mobile and fixed radio transmitters, receivers and transceivers for the VHF aeronautical mobile service using amplitude modulation; Part 2: Harmonized EN covering essential requirements of article 3.2 of the R&TTE Directive
en_30067602v010501p - Ground-based VHF hand-held, mobile and fixed radio transmitters, receivers and transceivers for the VHF aeronautical mobile service using amplitude modulation; Part 2: Harmonized EN covering essential requirements of article 3.2 of the R&TTE Directive
Get Certified
Connect with accredited certification bodies for this standard
BUREAU VERITAS Certification Germany
Bureau Veritas certification in Germany.
Element Materials Technology
Materials testing and product certification.
ANCE
Mexican certification and testing association.
Sponsored listings
Frequently Asked Questions
SIST EN 300 676-2 V1.5.1:2011 is a standard published by the Slovenian Institute for Standardization (SIST). Its full title is "Ground-based VHF hand-held, mobile and fixed radio transmitters, receivers and transceivers for the VHF aeronautical mobile service using amplitude modulation - Part 2: Harmonized EN covering essential requirements of article 3.2 of the R&TTE Directive". This standard covers: The present document applies to DSB AM ground base stations, with channel separations of 8,33 kHz or 25 kHz intended for analogue speech intended for ACARS data communication. The scope of the present document is limited to ground based stations, ground mobile and hand held radios for ground use. These radio equipment types are capable of operating in all or any part of the Aeronautical frequency band- between 118 MHz and 136,975 MHz. The present document is intended to cover the provisions of Directive 1999/5/EC (R&TTE Directive) [i.1], article 3.2, which states that "... radio equipment shall be so constructed that it effectively uses the spectrum allocated to terrestrial/space radio communications and orbital resources so as to avoid harmful interference". In addition to the present document, other ENs that specify technical requirements in respect of essential requirements under other parts of article 3 of the R&TTE Directive [i.1] as well as essential requirements under the SES Interoperability Regulation 552/2004 [i.2] and related implementing rules may apply to equipment within the scope of the present document.
The present document applies to DSB AM ground base stations, with channel separations of 8,33 kHz or 25 kHz intended for analogue speech intended for ACARS data communication. The scope of the present document is limited to ground based stations, ground mobile and hand held radios for ground use. These radio equipment types are capable of operating in all or any part of the Aeronautical frequency band- between 118 MHz and 136,975 MHz. The present document is intended to cover the provisions of Directive 1999/5/EC (R&TTE Directive) [i.1], article 3.2, which states that "... radio equipment shall be so constructed that it effectively uses the spectrum allocated to terrestrial/space radio communications and orbital resources so as to avoid harmful interference". In addition to the present document, other ENs that specify technical requirements in respect of essential requirements under other parts of article 3 of the R&TTE Directive [i.1] as well as essential requirements under the SES Interoperability Regulation 552/2004 [i.2] and related implementing rules may apply to equipment within the scope of the present document.
SIST EN 300 676-2 V1.5.1:2011 is classified under the following ICS (International Classification for Standards) categories: 33.060.20 - Receiving and transmitting equipment; 49.090 - On-board equipment and instruments. The ICS classification helps identify the subject area and facilitates finding related standards.
SIST EN 300 676-2 V1.5.1:2011 is associated with the following European legislation: EU Directives/Regulations: 1999/5/EC, TRRTP124. When a standard is cited in the Official Journal of the European Union, products manufactured in conformity with it benefit from a presumption of conformity with the essential requirements of the corresponding EU directive or regulation.
SIST EN 300 676-2 V1.5.1:2011 is available in PDF format for immediate download after purchase. The document can be added to your cart and obtained through the secure checkout process. Digital delivery ensures instant access to the complete standard document.
Standards Content (Sample)
Final draft ETSI EN 300 676-2 V1.5.0 (2011-04)
Harmonized European Standard
Ground-based VHF hand-held, mobile and
fixed radio transmitters, receivers and
transceivers for the VHF aeronautical mobile service
using amplitude modulation;
Part 2: Harmonized EN covering essential requirements
of article 3.2 of the R&TTE Directive
2 Final draft ETSI EN 300 676-2 V1.5.0 (2011-04)
Reference
REN/ERM-JTFEA-007
Keywords
aeronautical, AM, DSB, radio, testing, VHF
ETSI
650 Route des Lucioles
F-06921 Sophia Antipolis Cedex - FRANCE
Tel.: +33 4 92 94 42 00 Fax: +33 4 93 65 47 16
Siret N° 348 623 562 00017 - NAF 742 C
Association à but non lucratif enregistrée à la
Sous-Préfecture de Grasse (06) N° 7803/88
Important notice
Individual copies of the present document can be downloaded from:
http://www.etsi.org
The present document may be made available in more than one electronic version or in print. In any case of existing or
perceived difference in contents between such versions, the reference version is the Portable Document Format (PDF).
In case of dispute, the reference shall be the printing on ETSI printers of the PDF version kept on a specific network drive
within ETSI Secretariat.
Users of the present document should be aware that the document may be subject to revision or change of status.
Information on the current status of this and other ETSI documents is available at
http://portal.etsi.org/tb/status/status.asp
If you find errors in the present document, please send your comment to one of the following services:
http://portal.etsi.org/chaircor/ETSI_support.asp
Copyright Notification
No part may be reproduced except as authorized by written permission.
The copyright and the foregoing restriction extend to reproduction in all media.
© European Telecommunications Standards Institute 2011.
All rights reserved.
TM TM TM TM
DECT , PLUGTESTS , UMTS , TIPHON , the TIPHON logo and the ETSI logo are Trade Marks of ETSI registered
for the benefit of its Members.
TM
3GPP is a Trade Mark of ETSI registered for the benefit of its Members and of the 3GPP Organizational Partners.
LTE™ is a Trade Mark of ETSI currently being registered
for the benefit of its Members and of the 3GPP Organizational Partners.
GSM® and the GSM logo are Trade Marks registered and owned by the GSM Association.
ETSI
3 Final draft ETSI EN 300 676-2 V1.5.0 (2011-04)
Contents
Intellectual Property Rights . 5
Foreword . 5
Introduction . 5
1 Scope . 6
2 References . 6
2.1 Normative references . 6
2.2 Informative references . 6
3 Definitions and abbreviations . 7
3.1 Definitions . 7
3.2 Abbreviations . 7
4 Technical requirements specifications . 8
4.1 Environmental profile . 8
4.2 Conformance requirements . 8
4.2.1 Transmitter requirements . 8
4.2.1.1 Frequency error . 8
4.2.1.2 Carrier power (conducted) . 8
4.2.1.3 Adjacent channel power . 8
4.2.1.4 Conducted spurious emissions . 8
4.2.1.5 Intermodulation attenuation (Applicable to Base stations only) . 8
4.2.1.6 Keying transient frequency behaviour (Applicable to base stations only) . 8
4.2.1.7 Cabinet radiation . 8
4.2.2 Receiver requirements . 9
4.2.2.1 Sensitivity . 9
4.2.2.2 Adjacent channel rejection . 9
4.2.2.3 Spurious response rejection . 9
4.2.2.4 Intermodulation response rejection . 9
4.2.2.5 Blocking or desensitisation . 9
4.2.2.6 Conducted spurious emissions . 9
4.2.2.7 Cross modulation rejection . 9
4.2.2.8 Cabinet radiation . 9
5 Testing for compliance with technical requirements . 9
5.1 Environmental conditions for testing . 9
5.2 Interpretation of the measurement results . 10
5.3 Essential radio test suites . 10
5.3.1 Transmitter test specifications . 10
5.3.1.1 Frequency error . 10
5.3.1.2 Carrier power (conducted) . 10
5.3.1.3 Adjacent channel power . 11
5.3.1.4 Conducted spurious emissions . 11
5.3.1.5 Intermodulation attenuation . 11
5.3.1.6 Keying transient frequency behaviour . 11
5.3.1.7 Cabinet Radiation . 11
5.3.2 Receiver test specifications . 11
5.3.2.1 Sensitivity . 11
5.3.2.2 Adjacent channel rejection . 11
5.3.2.3 Spurious response rejection . 11
5.3.2.4 Intermodulation response rejection . 11
5.3.2.5 Blocking or desensitisation . 11
5.3.2.6 Conducted spurious emissions . 11
5.3.2.7 Cross modulation rejection . 11
5.3.2.8 Cabinet radiation . 11
ETSI
4 Final draft ETSI EN 300 676-2 V1.5.0 (2011-04)
Annex A (normative): HS Requirements and conformance Test specifications Table (HS-
RTT) . 12
Annex B (informative): The EN title in the official languages . 15
Annex C (informative): Bibliography . 16
History . 17
ETSI
5 Final draft ETSI EN 300 676-2 V1.5.0 (2011-04)
Intellectual Property Rights
IPRs essential or potentially essential to the present document may have been declared to ETSI. The information
pertaining to these essential IPRs, if any, is publicly available for ETSI members and non-members, and can be found
in ETSI SR 000 314: "Intellectual Property Rights (IPRs); Essential, or potentially Essential, IPRs notified to ETSI in
respect of ETSI standards", which is available from the ETSI Secretariat. Latest updates are available on the ETSI Web
server (http://webapp.etsi.org/IPR/home.asp).
Pursuant to the ETSI IPR Policy, no investigation, including IPR searches, has been carried out by ETSI. No guarantee
can be given as to the existence of other IPRs not referenced in ETSI SR 000 314 (or the updates on the ETSI Web
server) which are, or may be, or may become, essential to the present document.
Foreword
This final draft Harmonized European Standard (EN) has been produced by ETSI Technical Committee
Electromagnetic compatibility and Radio spectrum Matters (ERM), and is now submitted for the ETSI standards
One-step Approval Procedure.
The present document has been produced by ETSI in response to a mandate from the European Commission issued
under Council Directive 98/34/EC (as amended) [i.4] laying down a procedure for the provision of information in the
field of technical standards and regulations.
The title and reference to the present document are intended to be included in the publication in the Official Journal of
the European Union of titles and references of Harmonized Standard under the Directive 1999/5/EC [i.1].
See article 5.1 of Directive 1999/5/EC [i.1] for information on presumption of conformity and Harmonised Standards or
parts thereof the references of which have been published in the Official Journal of the European Union.
The requirements relevant to Directive 1999/5/EC [i.1] are summarised in annex A.
The present document is part 2 of a multi-part deliverable covering the Ground-based VHF hand-held, mobile and fixed
radio transmitters, receivers and transceivers for the VHF aeronautical mobile service using amplitude modulation; as
identified below:
Part 1: "Technical characteristics and methods of measurement";
Part 2: "Harmonized EN covering essential requirements under article 3.2 of the R&TTE Directive".
Proposed national transposition dates
Date of latest announcement of this EN (doa): 3 months after ETSI publication
Date of latest publication of new National Standard
or endorsement of this EN (dop/e): 6 months after doa
Date of withdrawal of any conflicting National Standard (dow): 18 months after doa
Introduction
The present document is part of a set of standards developed by ETSI and is designed to fit in a modular structure to
cover all radio and telecommunications terminal equipment within the scope of the R&TTE Directive [i.1]. The
modular structure is shown in EG 201 399 [i.3].
ETSI
6 Final draft ETSI EN 300 676-2 V1.5.0 (2011-04)
1 Scope
The present document applies to DSB AM ground base stations, with channel separations of 8,33 kHz or 25 kHz
intended for analogue speech intended for ACARS data communication. The scope of the present document is limited
to ground based stations, ground mobile and hand held radios for ground use. These radio equipment types are capable
of operating in all or any part of the Aeronautical frequency band- between 118 MHz and 136,975 MHz.
The present document is intended to cover the provisions of Directive 1999/5/EC (R&TTE Directive) [i.1], article 3.2,
which states that ". radio equipment shall be so constructed that it effectively uses the spectrum allocated to
terrestrial/space radio communications and orbital resources so as to avoid harmful interference".
In addition to the present document, other ENs that specify technical requirements in respect of essential requirements
under other parts of article 3 of the R&TTE Directive [i.1] as well as essential requirements under the Single European
Sky Interoperability Regulation (as amended) [2] and related implementing rules may apply to equipment within the
scope of the present document.
NOTE: A list of such ENs is included on the web site http://www.newapproach.org.
2 References
References are either specific (identified by date of publication and/or edition number or version number) or
non-specific. For specific references, only the cited version applies. For non-specific references, the latest version of the
reference document (including any amendments) applies.
Referenced documents which are not found to be publicly available in the expected location might be found at
http://docbox.etsi.org/Reference.
NOTE: While any hyperlinks included in this clause were valid at the time of publication ETSI cannot guarantee
their long term validity.
2.1 Normative references
The following referenced documents are necessary for the application of the present document.
[1] ETSI EN 300 676-1 (V1.5.2): "Ground-based VHF hand-held, mobile and fixed radio transmitters,
receivers and transceivers for the VHF aeronautical mobile service using amplitude modulation;
Part 1: Technical characteristics and methods of measurement".
[2] ETSI EN 300 113-1 (V1.6.1): "Electromagnetic compatibility and Radio spectrum Matters (ERM);
Land mobile service; Radio equipment intended for the transmission of data (and/or speech) using
constant or non-constant envelope modulation and having an antenna connector; Part 1: Technical
characteristics and methods of measurement".
[3] ETSI TR 100 028 (all parts) (V1.4.1): "Electromagnetic compatibility and Radio spectrum Matters
(ERM); Uncertainties in the measurement of mobile radio equipment characteristics".
2.2 Informative references
The following referenced documents are not necessary for the application of the present document but they assist the
user with regard to a particular subject area.
[i.1] Directive 1999/5/EC of the European Parliament and of the Council of 9 March 1999 on radio
equipment and telecommunications terminal equipment and the mutual recognition of their
conformity; amended by Regulation (EC) No 1882/2003 of the European Parliament and of the
Council of 29/09/2003.
ETSI
7 Final draft ETSI EN 300 676-2 V1.5.0 (2011-04)
[i.2] Regulation (EC) 552/2004 of the European Parliament and Council of 10 March 2004 on the
interoperability of the European Air Traffic Management network (the interoperability
Regulation); Officia
...
Harmonized European Standard
Ground-based VHF hand-held, mobile and
fixed radio transmitters, receivers and
transceivers for the VHF aeronautical mobile service
using amplitude modulation;
Part 2: Harmonized EN covering essential requirements
of article 3.2 of the R&TTE Directive
2 ETSI EN 300 676-2 V1.5.1 (2011-09)
Reference
REN/ERM-JTFEA-007
Keywords
aeronautical, AM, DSB, radio, testing, VHF
ETSI
650 Route des Lucioles
F-06921 Sophia Antipolis Cedex - FRANCE
Tel.: +33 4 92 94 42 00 Fax: +33 4 93 65 47 16
Siret N° 348 623 562 00017 - NAF 742 C
Association à but non lucratif enregistrée à la
Sous-Préfecture de Grasse (06) N° 7803/88
Important notice
Individual copies of the present document can be downloaded from:
http://www.etsi.org
The present document may be made available in more than one electronic version or in print. In any case of existing or
perceived difference in contents between such versions, the reference version is the Portable Document Format (PDF).
In case of dispute, the reference shall be the printing on ETSI printers of the PDF version kept on a specific network drive
within ETSI Secretariat.
Users of the present document should be aware that the document may be subject to revision or change of status.
Information on the current status of this and other ETSI documents is available at
http://portal.etsi.org/tb/status/status.asp
If you find errors in the present document, please send your comment to one of the following services:
http://portal.etsi.org/chaircor/ETSI_support.asp
Copyright Notification
No part may be reproduced except as authorized by written permission.
The copyright and the foregoing restriction extend to reproduction in all media.
© European Telecommunications Standards Institute 2011.
All rights reserved.
TM TM TM
DECT , PLUGTESTS , UMTS and the ETSI logo are Trade Marks of ETSI registered for the benefit of its Members.
TM
3GPP and LTE™ are Trade Marks of ETSI registered for the benefit of its Members and
of the 3GPP Organizational Partners.
GSM® and the GSM logo are Trade Marks registered and owned by the GSM Association.
ETSI
3 ETSI EN 300 676-2 V1.5.1 (2011-09)
Contents
Intellectual Property Rights . 5
Foreword . 5
Introduction . 5
1 Scope . 6
2 References . 6
2.1 Normative references . 6
2.2 Informative references . 6
3 Definitions and abbreviations . 7
3.1 Definitions . 7
3.2 Abbreviations . 7
4 Technical requirements specifications . 8
4.1 Environmental profile . 8
4.2 Conformance requirements . 8
4.2.1 Transmitter requirements . 8
4.2.1.1 Frequency error . 8
4.2.1.2 Carrier power (conducted) . 8
4.2.1.3 Adjacent channel power . 8
4.2.1.4 Conducted spurious emissions . 8
4.2.1.5 Intermodulation attenuation (Applicable to Base stations only) . 8
4.2.1.6 Keying transient frequency behaviour (Applicable to base stations only) . 8
4.2.1.7 Cabinet radiation . 8
4.2.2 Receiver requirements . 9
4.2.2.1 Sensitivity . 9
4.2.2.2 Adjacent channel rejection . 9
4.2.2.3 Spurious response rejection . 9
4.2.2.4 Intermodulation response rejection . 9
4.2.2.5 Blocking or desensitisation . 9
4.2.2.6 Conducted spurious emissions . 9
4.2.2.7 Cross modulation rejection . 9
4.2.2.8 Cabinet radiation . 9
5 Testing for compliance with technical requirements . 9
5.1 Environmental conditions for testing . 9
5.2 Interpretation of the measurement results . 10
5.3 Essential radio test suites . 10
5.3.1 Transmitter test specifications . 10
5.3.1.1 Frequency error . 10
5.3.1.2 Carrier power (conducted) . 10
5.3.1.3 Adjacent channel power . 11
5.3.1.4 Conducted spurious emissions . 11
5.3.1.5 Intermodulation attenuation . 11
5.3.1.6 Keying transient frequency behaviour . 11
5.3.1.7 Cabinet Radiation . 11
5.3.2 Receiver test specifications . 11
5.3.2.1 Sensitivity . 11
5.3.2.2 Adjacent channel rejection . 11
5.3.2.3 Spurious response rejection . 11
5.3.2.4 Intermodulation response rejection . 11
5.3.2.5 Blocking or desensitisation . 11
5.3.2.6 Conducted spurious emissions . 11
5.3.2.7 Cross modulation rejection . 11
5.3.2.8 Cabinet radiation . 11
ETSI
4 ETSI EN 300 676-2 V1.5.1 (2011-09)
Annex A (normative): HS Requirements and conformance Test specifications Table (HS-
RTT) . 12
Annex B (informative): The EN title in the official languages . 15
Annex C (informative): Bibliography . 16
History . 17
ETSI
5 ETSI EN 300 676-2 V1.5.1 (2011-09)
Intellectual Property Rights
IPRs essential or potentially essential to the present document may have been declared to ETSI. The information
pertaining to these essential IPRs, if any, is publicly available for ETSI members and non-members, and can be found
in ETSI SR 000 314: "Intellectual Property Rights (IPRs); Essential, or potentially Essential, IPRs notified to ETSI in
respect of ETSI standards", which is available from the ETSI Secretariat. Latest updates are available on the ETSI Web
server (http://ipr.etsi.org).
Pursuant to the ETSI IPR Policy, no investigation, including IPR searches, has been carried out by ETSI. No guarantee
can be given as to the existence of other IPRs not referenced in ETSI SR 000 314 (or the updates on the ETSI Web
server) which are, or may be, or may become, essential to the present document.
Foreword
This Harmonized European Standard (EN) has been produced by ETSI Technical Committee Electromagnetic
compatibility and Radio spectrum Matters (ERM).
The present document has been produced by ETSI in response to a mandate from the European Commission issued
under Council Directive 98/34/EC (as amended) [i.4] laying down a procedure for the provision of information in the
field of technical standards and regulations.
The title and reference to the present document are intended to be included in the publication in the Official Journal of
the European Union of titles and references of Harmonized Standard under the Directive 1999/5/EC [i.1].
See article 5.1 of Directive 1999/5/EC [i.1] for information on presumption of conformity and Harmonised Standards or
parts thereof the references of which have been published in the Official Journal of the European Union.
The requirements relevant to Directive 1999/5/EC [i.1] are summarised in annex A.
The present document is part 2 of a multi-part deliverable covering the Ground-based VHF hand-held, mobile and fixed
radio transmitters, receivers and transceivers for the VHF aeronautical mobile service using amplitude modulation; as
identified below:
Part 1: "Technical characteristics and methods of measurement";
Part 2: "Harmonized EN covering essential requirements of article 3.2 of the R&TTE Directive".
National transposition dates
Date of adoption of this EN: 4 August 2011
Date of latest announcement of this EN (doa): 30 November 2011
Date of latest publication of new National Standard
or endorsement of this EN (dop/e): 31 May 2012
Date of withdrawal of any conflicting National Standard (dow): 31 May 2013
Introduction
The present document is part of a set of standards developed by ETSI and is designed to fit in a modular structure to
cover all radio and telecommunications terminal equipment within the scope of the R&TTE Directive [i.1]. The
modular structure is shown in EG 201 399 [i.3].
ETSI
6 ETSI EN 300 676-2 V1.5.1 (2011-09)
1 Scope
The present document applies to DSB AM ground base stations, with channel separations of 8,33 kHz or 25 kHz
intended for analogue speech intended for ACARS data communication. The scope of the present document is limited
to ground based stations, ground mobile and hand held radios for ground use. These radio equipment types are capable
of operating in all or any part of the Aeronautical frequency band- between 118 MHz and 136,975 MHz.
The present document is intended to cover the provisions of Directive 1999/5/EC (R&TTE Directive) [i.1], article 3.2,
which states that ". radio equipment shall be so constructed that it effectively uses the spectrum allocated to
terrestrial/space radio communications and orbital resources so as to avoid harmful interference".
In addition to the present document, other ENs that specify technical requirements in respect of essential requirements
under other parts of article 3 of the R&TTE Directive [i.1] as well as essential requirements under the SES
Interoperability Regulation 552/2004 [i.2] and related implementing rules may apply to equipment within the scope of
the present document.
NOTE: A list of such ENs is included on the web site http://www.newapproach.org.
2 References
References are either specific (identified by date of publication and/or edition number or version number) or
non-specific. For specific references, only the cited version applies. For non-specific references, the latest version of the
reference document (including any amendments) applies.
Referenced documents which are not found to be publicly available in the expected location might be found at
http://docbox.etsi.org/Reference.
NOTE: While any hyperlinks included in this clause were valid at the time of publication ETSI cannot guarantee
their long term validity.
2.1 Normative references
The following referenced documents are necessary for the application of the present document.
[1] ETSI EN 300 676-1 (V1.5.2): "Ground-based VHF hand-held, mobile and fixed radio transmitters,
receivers and transceivers for the VHF aeronautical mobile service using amplitude modulation;
Part 1: Technical characteristics and methods of measurement".
[2] ETSI EN 300 113-1 (V1.6.2): "Electromagnetic compatibility and Radio spectrum Matters (ERM);
Land mobile service; Radio equipment intended for the transmission of data (and/or speech) using
constant or non-constant envelope modulation and having an antenna connector; Part 1: Technical
characteristics and methods of measurement".
[3] ETSI TR 100 028 (all parts) (V1.4.1): "Electromagnetic compatibility and Radio spectrum Matters
(ERM); Uncertainties in the measurement of mobile radio equipment characteristics".
2.2 Informative references
The following referenced documents are not necessary for the application of the present document but they assist the
user with regard to a particular subject area.
[i.1] Directive 1999/5/EC of the European Parliament and of the Council of 9 March 1999 on radio
equipment and telecommunications terminal equipment and the mutual recognition of their
conformity; amended by Regulation (EC) No 1882/2003 of the European Parliament and of the
Council of 29/09/2003.
ETSI
7 ETSI EN 300 676-2 V1.5.1 (2011-09)
[i.2] Regulation (EC) No 552/2004 of the European Parliament and of the Council of 10 March 2004 on
the interoperability of the European Air Traffic Management network (interoperability
Regulation), OJ L 96, 31.03.2004, p. 26 as amended by Regulation (EC) No 1070/2009,
OJ L 300, 14.11.2009, p. 34.
[i.3] ETSI EG 201 399: "Electromagnetic compatibility and Radio spectrum
...
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.LWXGQR'LUHFWLYH49.090On-board equipment and instruments33.060.20Sprejemna in oddajna opremaReceiving and transmitting equipmentICS:Ta slovenski standard je istoveten z:EN 300 676-2 Version 1.5.1SIST EN 300 676-2 V1.5.1:2011en01-december-2011SIST EN 300 676-2 V1.5.1:2011SLOVENSKI
STANDARD
Harmonized European Standard SIST EN 300 676-2 V1.5.1:2011
ETSI ETSI EN 300 676-2 V1.5.1 (2011-09) 2
Reference REN/ERM-JTFEA-007 Keywords aeronautical, AM, DSB, radio, testing, VHF ETSI 650 Route des Lucioles F-06921 Sophia Antipolis Cedex - FRANCE
Tel.: +33 4 92 94 42 00
Fax: +33 4 93 65 47 16
Siret N° 348 623 562 00017 - NAF 742 C Association à but non lucratif enregistrée à la Sous-Préfecture de Grasse (06) N° 7803/88
Important notice Individual copies of the present document can be downloaded from: http://www.etsi.org The present document may be made available in more than one electronic version or in print. In any case of existing or perceived difference in contents between such versions, the reference version is the Portable Document Format (PDF). In case of dispute, the reference shall be the printing on ETSI printers of the PDF version kept on a specific network drive within ETSI Secretariat. Users of the present document should be aware that the document may be subject to revision or change of status. Information on the current status of this and other ETSI documents is available at http://portal.etsi.org/tb/status/status.asp If you find errors in the present document, please send your comment to one of the following services: http://portal.etsi.org/chaircor/ETSI_support.asp Copyright Notification No part may be reproduced except as authorized by written permission. The copyright and the foregoing restriction extend to reproduction in all media.
© European Telecommunications Standards Institute 2011. All rights reserved.
DECTTM, PLUGTESTSTM, UMTSTM and the ETSI logo are Trade Marks of ETSI registered for the benefit of its Members. 3GPPTM and LTE™ are Trade Marks of ETSI registered for the benefit of its Members and of the 3GPP Organizational Partners. GSM® and the GSM logo are Trade Marks registered and owned by the GSM Association. SIST EN 300 676-2 V1.5.1:2011
ETSI ETSI EN 300 676-2 V1.5.1 (2011-09) 3 Contents Intellectual Property Rights . 5 Foreword . 5 Introduction . 5 1 Scope . 6 2 References . 6 2.1 Normative references . 6 2.2 Informative references . 6 3 Definitions and abbreviations . 7 3.1 Definitions . 7 3.2 Abbreviations . 7 4 Technical requirements specifications . 8 4.1 Environmental profile . 8 4.2 Conformance requirements . 8 4.2.1 Transmitter requirements . 8 4.2.1.1 Frequency error . 8 4.2.1.2 Carrier power (conducted) . 8 4.2.1.3 Adjacent channel power . 8 4.2.1.4 Conducted spurious emissions . 8 4.2.1.5 Intermodulation attenuation (Applicable to Base stations only) . 8 4.2.1.6 Keying transient frequency behaviour (Applicable to base stations only) . 8 4.2.1.7 Cabinet radiation . 8 4.2.2 Receiver requirements . 9 4.2.2.1 Sensitivity . 9 4.2.2.2 Adjacent channel rejection . 9 4.2.2.3 Spurious response rejection . 9 4.2.2.4 Intermodulation response rejection . 9 4.2.2.5 Blocking or desensitisation . 9 4.2.2.6 Conducted spurious emissions . 9 4.2.2.7 Cross modulation rejection . 9 4.2.2.8 Cabinet radiation . 9 5 Testing for compliance with technical requirements . 9 5.1 Environmental conditions for testing . 9 5.2 Interpretation of the measurement results . 10 5.3 Essential radio test suites . 10 5.3.1 Transmitter test specifications . 10 5.3.1.1 Frequency error . 10 5.3.1.2 Carrier power (conducted) . 10 5.3.1.3 Adjacent channel power . 11 5.3.1.4 Conducted spurious emissions . 11 5.3.1.5 Intermodulation attenuation . 11 5.3.1.6 Keying transient frequency behaviour . 11 5.3.1.7 Cabinet Radiation . 11 5.3.2 Receiver test specifications . 11 5.3.2.1 Sensitivity . 11 5.3.2.2 Adjacent channel rejection . 11 5.3.2.3 Spurious response rejection . 11 5.3.2.4 Intermodulation response rejection . 11 5.3.2.5 Blocking or desensitisation . 11 5.3.2.6 Conducted spurious emissions . 11 5.3.2.7 Cross modulation rejection . 11 5.3.2.8 Cabinet radiation . 11 SIST EN 300 676-2 V1.5.1:2011
ETSI ETSI EN 300 676-2 V1.5.1 (2011-09) 4 Annex A (normative): HS Requirements and conformance Test specifications Table (HS-RTT) . 12 Annex B (informative): The EN title in the official languages . 15 Annex C (informative): Bibliography . 16 History . 17
ETSI ETSI EN 300 676-2 V1.5.1 (2011-09) 5 Intellectual Property Rights IPRs essential or potentially essential to the present document may have been declared to ETSI. The information pertaining to these essential IPRs, if any, is publicly available for ETSI members and non-members, and can be found in ETSI SR 000 314: "Intellectual Property Rights (IPRs); Essential, or potentially Essential, IPRs notified to ETSI in respect of ETSI standards", which is available from the ETSI Secretariat. Latest updates are available on the ETSI Web server (http://ipr.etsi.org). Pursuant to the ETSI IPR Policy, no investigation, including IPR searches, has been carried out by ETSI. No guarantee can be given as to the existence of other IPRs not referenced in ETSI SR 000 314 (or the updates on the ETSI Web server) which are, or may be, or may become, essential to the present document. Foreword This Harmonized European Standard (EN) has been produced by ETSI Technical Committee Electromagnetic compatibility and Radio spectrum Matters (ERM). The present document has been produced by ETSI in response to a mandate from the European Commission issued under Council Directive 98/34/EC (as amended) [i.4] laying down a procedure for the provision of information in the field of technical standards and regulations. The title and reference to the present document are intended to be included in the publication in the Official Journal of the European Union of titles and references of Harmonized Standard under the Directive 1999/5/EC [i.1]. See article 5.1 of Directive 1999/5/EC [i.1] for information on presumption of conformity and Harmonised Standards or parts thereof the references of which have been published in the Official Journal of the European Union. The requirements relevant to Directive 1999/5/EC [i.1] are summarised in annex A. The present document is part 2 of a multi-part deliverable covering the Ground-based VHF hand-held, mobile and fixed radio transmitters, receivers and transceivers for the VHF aeronautical mobile service using amplitude modulation; as identified below: Part 1: "Technical characteristics and methods of measurement"; Part 2: "Harmonized EN covering essential requirements of article 3.2 of the R&TTE Directive".
National transposition dates Date of adoption of this EN: 4 August 2011 Date of latest announcement of this EN (doa): 30 November 2011 Date of latest publication of new National Standard or endorsement of this EN (dop/e):
31 May 2012 Date of withdrawal of any conflicting National Standard (dow): 31 May 2013
Introduction The present document is part of a set of standards developed by ETSI and is designed to fit in a modular structure to cover all radio and telecommunications terminal equipment within the scope of the R&TTE Directive [i.1]. The modular structure is shown in EG 201 399 [i.3].
ETSI ETSI EN 300 676-2 V1.5.1 (2011-09) 6 1 Scope The present document applies to DSB AM ground base stations, with channel separations of 8,33 kHz or 25 kHz intended for analogue speech intended for ACARS data communication. The scope of the present document is limited to ground based stations, ground mobile and hand held radios for ground use. These radio equipment types are capable of operating in all or any part of the Aeronautical frequency band- between 118 MHz and 136,975 MHz. The present document is intended to cover the provisions of Directive 1999/5/EC (R&TTE Directive) [i.1], article 3.2, which states that ". radio equipment shall be so constructed that it effectively uses the spectrum allocated to terrestrial/space radio communications and orbital resources so as to avoid harmful interference". In addition to the present document, other ENs that specify technical requirements in respect of essential requirements under other parts of article 3 of the R&TTE Directive [i.1] as well as essential requirements under the SES Interoperability Regulation 552/2004 [i.2] and related implementing rules may apply to equipment within the scope of the present document. NOTE: A list of such ENs is included on the web site http://www.newapproach.org. 2 References References are either specific (identified by date of publication and/or edition number or version number) or non-specific. For specific references, only the cited version applies. For non-specific references, the latest version of the reference document (including any amendments) applies. Referenced documents which are not found to be publicly available in the expected location might be found at http://docbox.etsi.org/Reference. NOTE: While any hyperlinks included in this clause were valid at the time of publication ETSI cannot guarantee their long term validity. 2.1 Normative references The following referenced documents are necessary for the application of the present document. [1] ETSI EN 300 676-1 (V1.5.2): "Ground-based VHF hand-held, mobile and fixed radio transmitters, receivers and transceivers for the VHF aeronautical mobile service using amplitude modulation; Part 1: Technical characteristics and methods of measurement". [2] ETSI EN 300 113-1 (V1.6.2): "Electromagnetic compatibility and Radio spectrum Matters (ERM); Land mobile service; Radio equipment intended for the transmission of data (and/or speech) using constant or non-constant envelope modulation and having an antenna connector; Part 1: Technical characteristics and methods of measurement". [3] ETSI TR 100 028 (all parts) (V1.4.1): "Electromagnetic compatibility and Radio spectrum Matters (ERM); Uncertainties in the measurement of mobile radio equipment characteristics". 2.2 Informative references The following referenced documents are not necessary for the application of the present document but they assist the user with regard to a particular subject area. [i.1] Directive 1999/5/EC of the European Parliament and of the Council of 9 March 1999 on radio equipment and telecommunications terminal equipment and the mutual recognition of their conformity; amended by Regulation (EC) No 1882/2003 of the European Parliament and of the Council of 29/09/2003. SIST EN 300 676-2 V1.5.1:2011
ETSI ETSI EN 300 676-2 V1.5.1 (2011-09) 7 [i.2] Regulat
...
