INTERNATIONAL STANDARD ISO 14817-1:2015(E)
Intelligent transport systems — ITS central data
dictionaries —
Part 1:
Requirements for ITS data definitions
1 Scope
This part of ISO 14817 specifies the logical structure (framework) and the data content (substance) of
intelligent transport systems (ITS) data dictionaries (DDs).
Specifically, this part of ISO 14817 specifies the following:
— framework used to identify and define all data concepts;
— meta-attributes used to describe, standardize and manage each of the data concepts defined within
this framework;
— requirements used to record these definitions;
— naming conventions for the data concepts;
— a set of preferred data concepts within the ITS domain;
— data modelling method for defining ITS data concepts, when used.
DDs support data concepts derived from any number of international, regional or national system
architecture methodologies and/or techniques. Common data formats and operating procedures will
ease migration and interoperability between such approaches.
A data concept registry is an electronic data dictionary that supports some additional features. The
CIDCR refers to the specific implementation of an ITS data concept registry that is operated under the
auspices of ISO/TC 204. The term “data concept registries” may refer to the CIDCR and/or any other
national or regional data concept registry that chooses to conform to this part of ISO 14817.
2 Conformance
This part of ISO 14817 prescribes a conceptual model, not a physical implementation. An implementation
of this part of ISO 14817 may use different data concepts, different meta-attributes, or different
data concepts and different meta-attributes; however, a conforming implementation of this part of
ISO 14817 shall provide an unambiguous mapping to and from the physical implementation model and
the conceptual meta-model defined by this part of ISO 14817.
Regional and National DDs have the option of adopting data concept definitions from the CIDCR, but are
not required to do so.
Table 1 indicates the conformance requirements of data concept registries and data dictionaries.
© ISO 2015 – All rights reserved 1

---------------------- Page: 8 ----------------------
ISO 14817-1:2015(E)

a
Table 1 — Data dictionary and data concept registry conformance
Feature Data Dictionary Data Concept
b
Registry
c
Support all data concepts  
d
Support all mandatory identification meta-attributes  
e
Support all mandatory definitional meta-attributes  
f
Support all mandatory relational meta-attributes  
g
Support all mandatory representational meta-attributes  
h
Support all mandatory administrative meta-attributes 
i
Electronic storage with automated administrative rules 
a
Annex A identifies which meta-attributes are mandatory for specific data concepts.
b
For data concept registries, “mandatory” meta-attributes shall also include all “assigned” meta-attributes.
c
As defined in Clause 6.
d
As defined in 7.1.
e
As defined in 7.2.
f
As defined in 7.3.
g
As defined in 7.4.
h
As defined in ISO 14817-2.
i
As defined in ISO 14817-2.
3 Normative references
The following documents, in whole or in part, are normatively referenced in this document and are
indispensable for its application. For dated references, only the edition cited applies. For undated
references, the latest edition of the referenced document (including any amendments) applies.
1)
ISO 14817-3:— , Intelligent transport systems — ITS data dictionaries — Part 3: Object identifier
assignments for ITS data concepts
2)
ISO/IEC 8824-1:— , Information technology — Abstract Syntax Notation One (ASN.1): Specification of
basic notation
ISO/IEC 9834-1, Information technology — Procedures for the operation of object identifier registration
authorities: General procedures and top arcs of the international object identifier tree
NIMA TR8350.2, Third Edition – Amendment 1, January 2000, Department of Defence – World Geodetic
System 1984, Its Definition and Relationships With Local Geodetic Systems, issued by National Imagery
and Mapping Agency (NIMA), US Department of Defence
4 Terms and definitions
For the purposes of this document, the terms and definitions given in ISO 14817-3 and the following apply.
4.1
abstract
indication of whether the object class is purely abstract or can be instantiated with member objects;
abstract object classes typically have non-abstract specializations
1) To be published.
2) To be published. (Revision of ISO 8824-1:2008)
2 © ISO 2015 – All rights reserved

---------------------- Page: 9 ----------------------
ISO 14817-1:2015(E)

4.2
aggregate domain
data concept that defines a grouping of data elements and/or data frames
4.3
ASN.1 name
name of a data concept expressed as a valid “typereference” as defined by ISO/IEC 8824-1
4.4
association
semantic relationship between two object classes
4.5
constraint
notation which can be used in association with a type, to define a subtype of that type
[SOURCE: ISO/IEC 8824-1:2008]
4.6
context
universe of discourse in which a name or definition is used
[SOURCE: ISO/IEC 11179-3:2003, 3.3.31]
4.7
contextual name
descriptive word or group of words that labels a data concept within its defined context
4.8
data
re-interpretable representation of information in a formalized manner suitable for communication,
interpretation or processing
Note 1 to entry: Data can be processed by human or automatic means.
[SOURCE: ISO 11179-1:2004]
4.9
data concept
item that may be stored in a data dictionary that refers to an abstraction or thing in the natural world
that can be identified with explicit boundaries and meaning and whose properties and behaviour all
follow the same rules
Note 1 to entry: Data concepts can be classified into the following types: object class, value domain, data element,
aggregate domain, data frame, message, interface dialogue, dictionary document, or module
4.10
data concept identifier
numeric identifier that shall uniquely and unambiguously identify a data concept within the scope of
the DD being managed
4.11
data concept instance
occurrence of a data concept
© ISO 2015 – All rights reserved 3

---------------------- Page: 10 ----------------------
ISO 14817-1:2015(E)

4.12
data concept registry
electronic data dictionary that follows precise documented rules for the registration and management
of stored data concepts; it typically also includes advanced features for adding, retrieving, and working
with its contents
Note 1 to entry: The data concept registry contains meta-attributes about data concepts in terms of their names
and representational forms as well as the semantics associated with the data concepts. A data concept registry
may contain data that assists information interchange and re-use, both from the perspective of human users and
for machine-interpretation of data concepts.
4.13
data concept revision
integer that represents the number of edits that have been made to the data concept since the last
update to the major version number
4.14
data concept type
categorization of the kind of data concept
4.15
data concept version
integer that represents the number of normative changes that have been made to approved versions of
the associated data concept
4.16
data dictionary
listing of data concepts and their meta-attributes in a consistent format
4.17
data element
data concept represented by a specific value domain and that describes a single atomic property about
an object class
Note 1 to entry: A data element is composed of an object class, a property of the represented object class and a
value domain.
4.18
data frame
data concept represented by a specific aggregate domain and that describes information of interest
through a useful grouping of more atomic properties about one or more object classes
Note 1 to entry: The grouping may be a set, sequence, or a choice.
4.19
data model
graphical and/or lexical representation of data, specifying their properties, structure, and inter-
relationships
[SOURCE: ISO 11179-1:2004, 3.2.7]
EXAMPLE A data model might specify that a “Vehicle” may be described by a variety of properties, such as:
“make”, “model”, “year”, and “vin” (vehicle identification number). Likewise, a “Collision” might be described by
properties such as “occurenceTime”, “severity”, and “vehiclesInvolvedCount”. Finally, the model might depict that a
Collision has a many-to-many relationship to a Vehicle. The following provides a sample graphic of this data model.
Note 1 to entry: Within the scope of this part of ISO 14817, data models are depicted using UML Class Diagrams.
4 © ISO 2015 – All rights reserved

---------------------- Page: 11 ----------------------
ISO 14817-1:2015(E)

Figure 1 — Sample data model
4.20
data type
set of distinct values, characterized by properties of those values and by operations
...
