Publication numbering
As from 1 January 1997 all IEC publications are issued with a designation in the

60000 series. For example, IEC 34-1 is now referred to as IEC 60034-1.

Consolidated editions
The IEC is now publishing consolidated versions of its publications. For example,

edition numbers 1.0, 1.1 and 1.2 refer, respectively, to the base publication, the

base publication incorporating amendment 1 and the base publication incorporating

amendments 1 and 2.
Further information on IEC publications
The technical content of IEC publications is kept under constant review by the IEC,
thus ensuring that the content reflects current technology. Information relating to
this publication, including its validity, is available in the IEC Catalogue of
publications (see below) in addition to new editions, amendments and corrigenda.
Information on the subjects under consideration and work in progress undertaken
by the technical committee which has prepared this publication, as well as the list
of publications issued, is also available from the following:
• IEC Web Site (www.iec.ch)
• Catalogue of IEC publications
The on-line catalogue on the IEC web site (www.iec.ch/searchpub) enables you to
search by a variety of criteria including text searches, technical committees
and date of publication. On-line information is also available on recently issued
publications, withdrawn and replaced publications, as well as corrigenda.
• IEC Just Published
This summary of recently issued publications (www.iec.ch/online_news/ justpub)
is also available by email. Please contact the Customer Service Centre (see
below) for further information.
• Customer Service Centre
If you have any questions regarding this publication or need further assistance,
please contact the Customer Service Centre:

Email: custserv@iec.ch
Tel: +41 22 919 02 11
Fax: +41 22 919 03 00
PUBLICLY
IEC
AVAILABLE
PAS 61996-2
SPECIFICATION
First edition
Pre-Standard
2005-07
Maritime navigation and radiocommunication
equipment and systems –
Shipborne voyage data recorder (VDR) –

Part 2:
Simplified voyage data recorder (S-VDR) –
Performance requirements –
Methods of testing and required test results

 IEC 2005  Copyright - all rights reserved
No part of this publication may be reproduced or utilized in any form or by any means, electronic or
mechanical, including photocopying and microfilm, without permission in writing from the publisher.
International Electrotechnical Commission, 3, rue de Varembé, PO Box 131, CH-1211 Geneva 20, Switzerland
Telephone: +41 22 919 02 11 Telefax: +41 22 919 03 00 E-mail: inmail@iec.ch Web: www.iec.ch
PRICE CODE
Commission Electrotechnique Internationale
XA
International Electrotechnical Commission
Международная Электротехническая Комиссия
For price, see current catalogue

– 2 – PAS 61996-2 © IEC:2005(E)

CONTENTS
FOREWORD.3

INTRODUCTION.5

1 Scope .6

2 Normative references .6

3 Terms, definitions and abbreviations .7

3.1 Terms and definitions .7
3.2 Abbreviations .8
4 Performance requirements.9
4.1 General .9
4.2 Purpose .9
4.3 Operational requirements.10
4.4 Data selection and security .12
4.5 Continuity of operation.13
4.6 Data items to be recorded.14
5 Technical characteristics .16
5.1 Co-relation in date and time .16
5.2 Particular design requirements for the protective capsule .16
5.3 Location beacon(s) for the protective capsule.17
5.4 Survivability of recorded data.18
5.5 Information to be included in the manufacturer’s documentation .19
5.6 Bridge audio specifications .20
5.7 Communications audio.21
5.8 Radar data – Post-display selection .21
6 Methods of testing and required test results .22
6.1 General .22
6.2 Data items to be recorded.29
Annex A (informative) IEC 61162 sentence formats .46
Annex B (informative) Mandatory alarms .47
Annex C (informative) Requirement/test – Cross-references .49
Annex D (informative) Cross-references between VDR and S-VDR .51

Bibliography .52

PAS 61996-2 © IEC:2005(E) – 3 –

INTERNATIONAL ELECTROTECHNICAL COMMISSION

____________
MARITIME NAVIGATION AND RADIOCOMMUNICATION

EQUIPMENT AND SYSTEMS –
SHIPBORNE VOYAGE DATA RECORDER (VDR) –

Part 2: Simplified voyage data recorder (S-VDR) –

Performance requirements –
Methods of testing and required test results

FOREWORD
1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of IEC is to promote
international co-operation on all questions concerning standardization in the electrical and electronic fields. To
this end and in addition to other activities, IEC publishes International Standards, Technical Specifications,
Technical Reports, Publicly Available Specifications (PAS) and Guides (hereafter referred to as “IEC
Publication(s)”). Their preparation is entrusted to technical committees; any IEC National Committee interested
in the subject dealt with may participate in this preparatory work. International, governmental and non-
governmental organizations liaising with the IEC also participate in this preparation. IEC collaborates closely
with the International Organization for Standardization (ISO) in accordance with conditions determined by
agreement between the two organizations.
2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international
consensus of opinion on the relevant subjects since each technical committee has representation from all
interested IEC National Committees.
3) IEC Publications have the form of recommendations for international use and are accepted by IEC National
Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC
Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any
misinterpretation by any end user.
4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications
transparently to the maximum extent possible in their national and regional publications. Any divergence
between any IEC Publication and the corresponding national or regional publication shall be clearly indicated in
the latter.
5) IEC provides no marking procedure to indicate its approval and cannot be rendered responsible for any
equipment declared to be in conformity with an IEC Publication.
6) All users should ensure that they have the latest edition of this publication.
7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and
members of its technical committees and IEC National Committees for any personal injury, property damage or
other damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and
expenses arising out of the publication, use of, or reliance upon, this IEC Publication or any other IEC
Publications.
8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is

indispensable for the correct application of this publication.
9) Attention is drawn to the possibility that some of the elements of this IEC Publication may be the subject of
patent rights. IEC shall not be held responsible for identifying any or all such patent rights.
A PAS is a technical specification not fulfilling the requirements for a standard but made
available to the public.
IEC-PAS 61996-2 has been processed by IEC technical committee 80: Maritime navigation
and radiocommunication equipment and systems.
The text of the PAS is based This PAS was approved for
on the following document: publication by the P-members of the
committee concerned as indicated
in the following document:
Draft PAS Report on voting
80/401/NP-PAS 80/406/RVN
– 4 – PAS 61996-2 © IEC:2005(E)

Following publication of this PAS, the technical committee or subcommittee concerned will

investigate the possibility of transforming the PAS into an International Standard.

IEC 61996 consists of the following parts, under the general title Maritime navigation and

radiocommunication equipment and systems – Shipborne voyage data recorder (VDR):

Part 1: Performance requirements – Methods of testing and required test results (currently

available as IEC 61996:2000)
Part 2: Simplified voyage data recorder (S-VDR) – Performance requirements – Methods of

testing and required test results

This PAS shall remain valid for an initial maximum period of three years starting from

2005-07. The validity may be extended for a single 3-year period, following which it shall be
revised to become another type of normative document or shall be withdrawn.

PAS 61996-2 © IEC:2005(E) – 5 –

INTRODUCTION
This document is issued as an IEC Publicly Available Specification according to the IEC/PAS

approval process. This agreed process allows the new information needed to implement the

simplified voyage data recorder (S-VDR) to be placed in the public domain in a shorter time-

scale than revising the appropriate International Standards.

The S-VDR has been introduced by the IMO for fitting to existing ships as a simplified

alternative to the voyage data recorder (VDR) which is required for all new ships.

This document provides information on the testing requirements for S-VDR as defined in IMO

performance standard MSC.163(78).
The specification for S-VDR differs significantly from that for VDR in two areas:
a) the requirements for monitoring certain sensors are reduced when the data is not provided
in IEC 61162 format;
b) the requirements for the protective S-VDR capsule are different from the VDR capsule,
both for the fixed and float-free versions.
Annex D provides a cross-reference between this document and IEC 61996 to aid test houses
which may already have test results for VDRs which are being submitted as S-VDRs.

– 6 – PAS 61996-2 © IEC:2005(E)

MARITIME NAVIGATION AND RADIOCOMMUNICATION

EQUIPMENT AND SYSTEMS –
SHIPBORNE VOYAGE DATA RECORDER (VDR) –

Part 2: Simplified voyage data recorder (S-VDR) –

Performance requirements –
Methods of testing and required test results

1 Scope
This PAS specifies the minimum performance requirements, technical characteristics and
methods of testing, and required test results, for simplified shipborne voyage data recorders
(S-VDRs) as required by IMO MSC.163(78). It takes into account IMO resolution A.694(17)
and is associated with IEC 60945. When a requirement in this standard is different from IEC
60945, the requirement in this standard takes precedence.
NOTE All text of this standard, whose wording is identical to that of IMO MSC.163(78) is printed in italics, and the
Resolution and associated performance standard paragraph numbers are indicated in brackets.
2 Normative references
The following referenced documents are indispensable for the application of this document.
For dated references, only the edition cited applies. For undated references, the latest edition
of the referenced document (including any amendments) applies.
IEC 60068-2-27:1987, Environmental testing – Part 2: Tests – Test Ea and guidance: Shock
IEC 60268:1998, Sound system equipment – Part 16: Objective rating of speech intelligibility
by speech transmission index
IEC 60936-1:1999, Maritime navigation and radiocommunication equipment and systems –
Radar – Part 1: Shipborne radar – Performance requirements – Methods of testing and
required test results
Amendment 1 (2002)
IEC 60936-3: Maritime navigation and radiocommunication equipment and systems – Radar –

Part 3: Shipborne radar with chart facilities – Methods of testing and required test results
IEC 60945:2002, Maritime navigation and radiocommunication equipment and systems –

General requirements – Methods of testing and required test results
IEC 61097-2: 2002, Global maritime distress and safety system (GMDSS) – Part 2: COSPAS
SARSAT EPIRB – Satellite emergency position-indicating radio beacon operating on 406 MHz
– Operational and performance requirements, methods of testing and required test results
IEC 61097-7:1996, Global maritime distress and safety system (GMDSS) – Part 7: Shipborne
VHF radiotelephone transmitter and receiver – Operational and performance requirements,
methods of testing and required test results
IEC 61162 (all parts), Maritime navigation and radiocommunication equipment and systems –
Digital interfaces
IEC 61260:Electroacoustics – Octave-band and fractional-octave-band filters
———————
There exists a consolidated edition 1.1 (2002) that includes edition 1.0 and its amendment.

PAS 61996-2 © IEC:2005(E) – 7 –

IEC 61672 (all parts), Electroacoustics – Sound level meters

IEC 61993-2, Maritime navigation and radiocommunication equipment and systems –

Automatic identification systems (AIS) – Part 2: Class A shipborne equipment of the universal

automatic identification systems (AIS) – Operational and performance requirements, methods

of test and required test results

IEC 61996 (all parts), Maritime navigation and radiocommunication equipment and systems –

Shipborne voyage data recorder (VDR)

IMO A.658(16): Use and fitting of retro-reflective materials on life-saving appliances

IMO A.662(16): Performance standards for float-free release and activation arrangements for
emergency radio equipment
IMO A.694(17): General requirements for shipborne radio equipment forming part of the
Global Maritime Distress and Safety System (GMDSS) and for electronic navigational aids
IMO A.810(19): Performance standards for float-free satellite emergency position-indicating
radio beacons (EPIRBs) operating on 406 MHz
IMO A.830(19):1995, Code on alarms and indicators
IMO A.861(20): Performance standards for shipborne voyage data recorders (VDRs)
IMO MSC.81(70): Testing of life-saving appliances
IMO MSC.163(78): Performance standards for shipborne simplified voyage data recorders
(S-VDR).
Eurocae: ED56A – Minimum operational performance specification (MOPS) for cockpit voice
recorder system
VESA:1996, Video electronics standards association – Discrete monitor timings standard 1.0,
Revision 0.7 (DMTS)
SAE AS8045:1988, Engineering society for advancing mobility land, sea, air, and space –
Minimum performance standard for underwater locating devices – Acoustic-self-powered

3 Terms, definitions and abbreviations
3.1 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
3.1.1
recorder (S-VDR) (MSC.163(78) 4.1)
complete system, including any items required to interface with the sources of input data, for
processing and encoding the data, the final recording medium in its capsule, the power supply
and dedicated reserve power source

– 8 – PAS 61996-2 © IEC:2005(E)

3.1.2
sensor (MSC.163(78) 4.2)
any unit external to the S-VDR to which the S-VDR is connected and from which it obtains

data to be recorded
3.1.3
final recording medium (MSC.163(78) 4.3)

any item of hardware on which the data is recorded such that access to it would enable the

data to be recovered and played back by use of suitable equipment

3.1.4
playback equipment (MSC.163(78) 4.4)
any equipment, compatible with the recording medium and the format used during recording,
employed for recovering the data. It includes also the display or presentation hardware and
software that is appropriate to the original data source equipment. Playback equipment is not
normally installed on a ship and is not regarded as part of a S-VDR within this standard
3.1.5
dedicated reserve power source (MSC.163(78) 4.5)
secondary battery, with suitable automatic charging arrangements, dedicated solely to the
VDR, of sufficient capacity to operate it as required by 4.5.3
3.1.6
resolution
smallest detectable increment between two values
3.1.7
data
any item of information received by the S-VDR for recording, including numerical values, text
and audio or radar signals, except where specifically stated or the context dictates otherwise
3.1.8
activation of a suitable alarm
mutable audible alarm and persistent visual indication, given according to the requirements of
A.830(19) and IEC 60945
3.1.9
bridge work station
position at which a person is expected to be when performing one of the normal bridge duties
at, for example, the following work stations:
• centre line conning
• bridge wing(s)
• main radar
• chart table
• helms
• communication
3.2 Abbreviations
AIS Automatic identification system
ALR IEC 61162 sentence: Set alarm state
DPT IEC 61162 sentence: Depth relative to the transducer
DTM  IEC 61162 sentence: Geodetic datum reference
EPFS Electronic position fixing system
EPIRB Emergency position indicating radio beacon
EUT Equipment under test
PAS 61996-2 © IEC:2005(E) – 9 –

GMDSS Global maritime distress and safety system

GNS IEC 61162 sentence: GNSS fix data

GNSS Global Navigation Satellite System

HDT  IEC 61162 sentence: True heading

HDG  IEC 61162 sentence: Magnetic compass heading

HTC  IEC 61162 sentence: Heading/track control command

HTD  IEC 61162 sentence: Heading/track control data

IMO International Maritime Organization

INS Integrated navigation system
ITU International Telecommunication Union
MWV IEC 61162 sentence: Wind and speed angle
OOW Officer of the watch
RSA IEC 61162 sentence: Rudder sense angle
RPM IEC 61162 sentence: Revolutions per minute
ROV Remotely operated vehicle
SAR Search and rescue
SENC System electronic navigation chart
SINAD Signal to noise and distortion
STI  Sound transmission index
TXT IEC 61162 sentence: Text message
VDO IEC 61162 sentence: AIS - VHF data link own-vessel message
VDM IEC 61162 sentence: AIS - VHF data link message
VHF Very high frequency
VBW IEC 61162 sentence: Dual ground water speed
XDR IEC 61162 sentence: Transducer measurements
ZDA  IEC 61162 sentence: Time and date
NOTE For IEC 1162 sentences, see Annex A.
4 Performance requirements
Performance requirements described in the following clauses are specified, where relevant,
by reference to the numbered paragraphs of IMO MSC.163(78), if not otherwise indicated.

4.1 General
Requirements specified in this PAS are only relevant to equipment designated as an S-VDR
and required to meet IMO MSC.163(78).
For equipment designated as a VDR to IMO performance standards defined in resolution
A.861(20) refer to IEC 61996.
A table of cross-references between this PAS and IEC 61996 is included in Annex D.
4.2 Purpose
(MSC.163(78) 1)
The purpose of a simplified voyage data recorder (S-VDR) is to maintain a store, in a secure
and retrievable form, of information concerning the position, movement, physical status,

– 10 – PAS 61996-2 © IEC:2005(E)

command and control of a vessel over the period leading up to, and following, an incident

having an impact thereon. Information contained in a S-VDR should be made available to

both the Administration and the shipowner. This information is for use during any subsequent

investigation to identify the cause(s) of the incident.

4.3 Operational requirements
(MSC.163(78) 5)
4.3.1 Design and construction
(MSC.163(78) 5.1.4)
The design and construction, which shall be in accordance with the requirements of resolution
A.694(17) and international standards acceptable to the Organization , shall take special
account of the requirements for data security and continuity of operation as detailed in
IMO MSC.163(78) 5.2 and 5.3 and in 4.3, 4.4 and 4.5 of this PAS.
4.3.2 Maintenance of sequential records
(MSC.163(78) 5.1.1)
The S-VDR shall continuously maintain sequential records of pre-selected data items relating
to the status and output of the ship's equipment, and command and control of the ship,
referred to in 4.6.
4.3.3 Co-relation in date and time
(MSC.163(78) 5.1.2, 5.4.1)
To permit subsequent analysis of factors surrounding an incident, the method of recording
shall ensure that the various data items can be co-related in date and time during playback on
suitable equipment.
The recording method shall be such that the timing of all other recorded data items can be
derived on playback with a resolution sufficient to reconstruct the history of an incident in
detail (see 4.6.1).
4.3.4 Protective capsule
4.3.4.1 Final recording medium
(MSC.163(78) 5.1.3)
The final recording medium shall be installed in a protective capsule. The capsule may be
designed to remain fixed to the ship in all circumstances. Alternatively, it may be designed to
float free automatically if the ship sinks (see 5.2). The capsule may also comply with the

requirements of IEC 61996.
4.3.4.1.1 Fixed capsule
(MSC.163(78) 5.1.3.2)
The fixed type protective capsule shall comply with the requirements set out in resolution
A.861(20) and this PAS with the exception of the resulting requirements for withstanding
penetration.
4.3.4.1.2 Float-free capsule
(MSC.163(78) 5.1.3.3)
In addition to meeting the requirements of this PAS, the float-free type protective capsule
shall
———————
Refer to IEC 60945: Maritime navigation and radiocommunication equipment and systems – General
requirements, methods of testing and required test results.

PAS 61996-2 © IEC:2005(E) – 11 –

a) be so constructed as to comply with the requirements specified in resolutions A.810(19);

b) be fitted with means to facilitate grappling and recovery and be designed with due regard to

preventing it from being fouled during release;

c) be so constructed as to minimise the risk of loss or damage to the recording medium

during recovery operations.
4.3.4.2 Access to capsule
(MSC.163(78) 5.1.3.1.1)(See also 5.2)

The capsule shall be capable of being accessed following an incident but secure against

tampering.
The capsule shall enclose the final recording medium. The final recording medium shall not
be accessible by standard operating procedures during normal ship operations.
A means shall be provided to retrieve stored information via an external device without
opening the protective capsule.
4.3.4.3 Location and identification
(See also 5.2)
4.3.4.3.1 Location
(MSC.163(78) 5.1.3.1.4)(See 5.3)
The capsule shall be fitted with an appropriate device to aid location.
4.3.4.3.2 Visibility and marking
(MSC.163(78) 5.1.3.1)
The capsule, together with any outermost shell, shall be of a highly visible fluorescent orange
colour, marked with retro-reflective materials that comply with the relevant requirements of
IMO A.658(16) and marked with the legend:
“VOYAGE DATA RECORDER – DO NOT OPEN -
REPORT TO AUTHORITIES”
4.3.5 Assessment of recording medium
Where the storage medium cannot be readily and reliably inspected after an incident, means
shall be provided to enable an accident investigator to determine, prior to an attempted

replay, whether the storage medium has been subjected to an excessive level of heat, where
the survival of the stored data may be in doubt.
4.3.6 Interfaces
(MSC.163(78) 7)
Interfacing to the various sensors required shall be in accordance with the relevant
international interface standard, IEC 61162, where possible.
NOTE See Annex A.
The interfaces for bridge audio, communications audio and radar are defined in 5.6.1, 5.7.1
and 5.8.1 respectively.
Any interface units which may be required to convert non-IEC 61162 signals, shall conform to
the requirements of IEC 60945.

– 12 – PAS 61996-2 © IEC:2005(E)

In all cases, any connection to any item of the ship's equipment shall be such that the

operation of that equipment suffers no deterioration, even if the S-VDR system develops

faults.
NOTE No loss of steering or propulsion is allowed.

4.4 Data selection and security

(MSC.163(78) 5.2)
4.4.1 Selection of data items
(MSC.163(78) 5.2.1)
The minimum selections of operational data items to be recorded by the S-VDR are specified
in 4.6. Optionally, additional items may be recorded provided that the requirements for the
recording and storage of the specified selections are not compromised.
In addition to the operational data referred to in the preceding paragraph, a data block
defining the configuration of the S-VDR and the sensors to which it is connected shall be
written into the final recording medium during commissioning of the S-VDR. This configuration
data shall be permanently retained in the final recording medium and protected from
modification other than by a duly authorized person following any change to the configuration.
Any change to the configuration of this data block shall not affect the recording of the
mandatory items.
The following system configuration information and data source identity shall be included in
this data block:
a) type approval authority and reference;
b) IMO vessel identification number;
c) software version(s) used;
d) microphone locations and recording port allocation;
NOTE This does not imply channelization.
e) VHF communications – which VHF channel(s) recorded;
f) date and time – from which source obtained;
g) ship’s position – from which EPFS obtained and relative position on the vessel;
h) other data inputs – identification of which equipment is supplying recorded data; sign
conventions and identity of all alarm/door inputs;
i) automatic insertion of date and time of last amendment.
4.4.2 Resistance to tampering
(MSC.163(78) 5.2.2)
The equipment shall be so designed that, as far as is practical, it is not possible to tamper
with the selection of data being input to the equipment, the data itself nor that which has
already been recorded. Any attempt to interfere with the integrity of the data or the recording
shall be recorded.
4.4.3 Recording integrity
(MSC.163(78) 5.2.3)
The recording method shall be such that each item of the recorded data is checked for
integrity, for example, it is identical to the data being received, and an alarm given if a non-
correctable error is detected.
The S-VDR shall automatically continuously monitor the following (see 6.1.10):
a) power supply;
PAS 61996-2 © IEC:2005(E) – 13 –

b) record function;
c) bit error rate;
d) microphone functionality.
Malfunction of any of the above shall generate an alarm in accordance with the relevant

requirements of IMO A.830(19) at the position from which the vessel is normally navigated. It

shall be possible to mute the alarm but a visual indication shall remain until the equipment is

serviceable. It shall also indicate its alarm status by means of contacts of a relay (or

equivalent) which is held energized in the no-alarm condition.

4.5 Continuity of operation
4.5.1 Operation
(MSC.163(78) 6)
The unit shall be entirely automatic in normal operation. Means shall be provided to ensure
that the recorded data can be saved by an appropriate method following an incident, with
minimal interruption to the recording process and without requiring opening of the protective
capsule.
a) Controls for use during the saving process shall be simple to use.
b) The recording process to the final recording medium shall not be interrupted for more than
10 min during the saving process. The data recorded in the final recording medium shall
not be erased.
c) The data saved shall be automatically checked to ensure that it is identical to the recorded
data on the final recording medium. Any failure shall be indicated.
d) When the saving process is completed, means shall be provided to enable copies to be
made of this or of data relating to subsequent incidents.
NOTE “Saving process” means preserving a copy of the data contained in the final recording medium.
4.5.2 Power source
(MSC.163(78) 5.3.1)
To ensure that the S-VDR continues to record events during an incident, it shall be capable of
operating from the ship's emergency source of electrical power. Whenever electrical power is
available the S-VDR shall operate, except as permitted in 4.5.4. (see 6.1.15).
4.5.3 Alternative power source
(MSC.163(78) 5.3.2)
If the ship's emergency source of electrical power supply fails, the S-VDR shall continue to

record bridge audio (see 4.6.5) from a dedicated reserve source of power for a period of 2 h.
At the end of this 2 h period all recording shall cease automatically.
4.5.4 Recording period and duration
(MSC.163(78) 5.3.3)
Recording shall be continuous unless interrupted briefly in accordance with 4.5.1 or
terminated in accordance with 4.5.3. The time for which all stored data items are retained
shall be at least 12 h. Data items which are older than this may be overwritten with new data.
Recording may also be terminated, by means of a key or other secure method.
NOTE This may occur under the following circumstances:
a) during essential maintenance purposes whilst the vessel is in port;
b) when the vessel is laid up.

– 14 – PAS 61996-2 © IEC:2005(E)

4.6 Data items to be recorded
(MSC.163(78) 5.4)
4.6.1 Date and time
(MSC.163(78) 5.4.1)
Date and time referenced to UTC, shall be obtained from a source external to the ship (for

example, an EPFS or radio time signal) if available, or from an internal clock at least once

per hour. The recording shall indicate which source is in use. The recording method shall be
such that the timing of all other recorded data items can be derived on playback with a
resolution sufficient to reconstruct the history of the incident in detail, not worse than 1 s.

4.6.2 Ship’s position
(MSC.163(78) 5.4.2)
Latitude and longitude, and the datum used, shall be derived from a designated EPFS or INS
if available. The recording shall ensure that the identity and status of the source can always
be determined on playback. The ship’s position shall be recorded, as available on the ship, up
to a resolution of 0,0001 min of arc.
4.6.3 Speed
(MSC.163(78) 5.4.3)
Speed through the water, or speed over the ground (transverse as well as longitudinal in
either case, as available on the ship), including an indication from which it is, derived from the
ship’s designated speed and distance measuring equipment, shall be recorded, as available
on the ship, up to a resolution of 0,1 kn.
4.6.4 Heading
(MSC.163(78) 5.4.4)
As indicated by a designated ship's compass. The ship’s heading shall be recorded, as
available on the ship, up to a resolution of 0,1°.
4.6.5 Bridge audio
(MSC.163(78) 5.4.5)
One or more microphones positioned on the bridge shall be placed, such that conversation at
or near the conning stations, radar displays, chart tables, etc., (for example, at work stations
as defined in 3.1.9 may be adequately recorded. As far as is practicable, the positioning of
microphones shall also capture the input and output of intercom, public address systems and
the audible alarms on the bridge (bridge-mounted equipment).

(See 5.6 for technical characteristics.)
The audio signals at all work stations shall be recorded continuously. Optionally, means may
be provided so that the originating work station can be identified with the audio signal being
analysed during playback of the recorded information.
4.6.6 Communications audio
(MSC.163(78) 5.4.6)
VHF communications relating to ship operations shall be recorded, independently of the
bridge audio. The recording shall include both transmitted and received audio signals and
shall be continuous from a directly connected fixed VHF set to be designated at installation.
(See 5.7 for technical characteristics.)
4.6.7 Radar data – Post-display selection
(MSC.163(78) 5.4.7)
PAS 61996-2 © IEC:2005(E) – 15 –

This shall include electronic signal information from within one of the ship's radar installations

which records all the information which was actually being presented on the master display of

that radar at the time of recording. This shall include any range rings or markers, bearing

markers, electronic plotting symbols, radar maps, whatever parts of the SENC or other

electronic chart or map that were selected, the voyage plan, navigational data, navigational

alarms and the radar status data that were visible on the display. The recording method shall

be such that, on playback, it is possible to present a faithful replica of the entire radar display
that was on view at the time of recording, albeit within the limitations of any bandwidth

compression techniques that are essential to the working of the S-VDR.

(See 5.8.)
4.6.8 AIS
(MSC.163(78) 5.4.8)
Where there is no commercial off-the-shelf interface available to obtain radar data then AIS
target data shall be recorded as a source of information regarding other ships, otherwise AIS
information may be recorded additionally as a beneficial secondary source of information on
both other and own ship.
The VDM message shall be recorded in such a way that all target data available from the
onboard AIS are acquired.
If the VDO message is recorded, this shall be additional to the recording of individual sensor
data according to 4.6.1 to 4.6.4.
4.6.9 Other Items
(MSC.163(78) 5.4.9)
Any additional data items listed by IMO with the requirements set out in resolution A.861(20)
(4.6.10 to 4.6.17 below) shall be recorded where the data is available in accordance with the
international digital interface standards using approved sentence formatters.
4.6.10 Echo sounder
(A.861/5.4.8)
This shall include depth under keel,up to a resolution of 0,1 m as available on the ship. The
depth scale currently being displayed and other status information shall be recorded where
available.
4.6.11 Main alarms
(A.861/5.4.9)
This shall include the status of all IMO mandatory alarms on the bridge.
(See Annex B.)
The status of all IMO mandatory alarms shall be recorded by the bridge audio and as a data
parameter where practicable.
4.6.12 Rudder order and response
(A.861/5.4.10)
Both rudder order and response angles shall be recorded up to a resolution of 1º as available
and permitted on the ship. Status and settings of heading or track controller, if fitted, shall
also be recorded.
———————
Refer to IEC 61162.
– 16 – PAS 61996-2 © IEC:2005(E)

4.6.13 Engine order and response

(A.861/5.4.11)
This shall include the positions of any engine telegraphs or direct engine/propeller controls,

including shaft(s) r.p.m.(or equivalent), and feedback indications, if fitted, including

ahead/astern indicators. This shall also include status of bow and stern thrusters if fitted.

RPM shall be recorded up to a resolution of 1 r.p.m and pitch shall be recorded up to a
o
resolution of 1 .
4.6.14 Hull openings (doors) status

(A.861/5.4.12)
This shall include all IMO mandatory status information required to be displayed on the
bridge.
4.6.15 Watertight and fire door status
(A.861/5.4.13)
This shall include all IMO mandatory status information required to be displayed on the
bridge.
4.6.16 Accelerations and hull stresses
(A.861/5.4.14)
Where a ship is fitted with IMO-mandated hull stress and response monitoring equipment, all
the data items that have been pre-selected within that equipment and are available shall be
recorded.
4.6.17 Wind speed and direction
(A.861/5.4.15)
This shall be applicable where a ship is fitted with a suitable sensor. Either relative or true
wind speed and direction may be recorded, but an indication of which it is shall be recorded.
5 Technical characteristics
5.1 Co-relation in date and time
(A.861/5.1.2 and 5.4.1)
To ensure that relative timings can be determined within a resolution of 0,1 s, all data items
shall, when sampled by the VDR, be recorded with a time index derived from a VDR system

clock with an resolution of 0,05 s. The drift of this system clock shall be not more than 1 s in
1 h.
5.2 Particular design requirements for the protective capsule
(MSC.163(78), 5.1.3)
The final recording medium shall be installed in a protective capsule of either a fixed or float-
free type, which shall meet all of the following requirements (IMO MSC.163(78), 5.1.3.1):
a) maintain the recorded data for a period of at least 2 years following termination of
recording;
b) be of a highly visible colour and marked with retro-reflective materials.
5.2.1 Fixed protective capsule
(MSC.163(78) 5.1.3.2)
PAS 61996-2 © IEC:2005(E) – 17 –

5.2.1.1 Design of the fixed capsule

The capsule containing the final recording medium shall be designed to be installed on the

external deck of the vessel.
The capsule shall be designed to protect the stored data against the following (see

IEC 61996, 5.4, except penetration):

– shock;
– fire;
– deep-sea pressure and immersion.

5.2.1.2 Release mechanism
The fixed capsule shall have a release mechanism to facilitate recovery under water both by a
diver or a remotely operated vehicle (ROV). Possible items to be considered are
a) the use of break-away bolts;
b) release levers;
c) twist lock.
To ensure that the capsule may be retrieved safely after release, suitable large pad eyes or
handles shall be incorporated.
NOTE It should be borne in mind that the manipulator jaws of typical underwater recovery machines have a
maximum opening of only 300 mm, a gripping force limit of about 1 kN, and a pulling force limit of about 500 N.
5.3 Location beacon(s) for the protective capsule
(MSC.163(78) 5.1.3.1.4)
The capsule shall be fitted with an appropriate device to aid location, as follows.
5.3.1 Device for the location of the fixed capsule
The capsule shall include an acoustic underwater beacon meeting SAE AS 8045, operating in
the frequency band of 25 kHz to 50 kHz with a battery life of at least 30 days.
5.3.2 Device(s) for the location of the float-free capsule
(MSC.163(78) 5.1.3.3.3)
5.3.2.1 Homing transmitter
The float-free capsule shall include a homing transmitter operating on 121,5 MHz, complying
with Annex B of IEC 61097-2, except that a Morse letter “V” ( –) shall be inserted with a
• • •
repetition period varying between 47,5 s to 52,5 s, with a dot length (one unit) equal to
115 ms ± 5 %.
5.3.2.2 Light
The float-free capsule shall have a light conforming to the relevant requirements of
IEC 61097-2. In addition, this light shall remain activated during daylight hours.
5.3.2.3 Position
The float-free capsule shall be capable of resolving and transmitting its last received position
or its current position with a minimum accuracy of 4 s of arc.

– 18 – PAS 61996-2 © IEC:2005(E)

5.3.2.4 Combined EPIRB/S-VDR capsule

In the case of a combined EPIRB/S-VDR capsule, this shall, in addition to the requirements of

this PAS, meet IEC 61097-2, except as modified herein.

5.3.2.5 Operation of transmitters

(MSC.163(78) 5.1.3.3.3)
The transmitters shall
a) be capable of operating for a minimum of 7 days maintaining the specified duty cycle;

b) if the device includes the capability of being remotely controlled (see note), it shall be
capable of transmitting an initial locating signal:
1) for a period of at least 2 h;
2) in the case of a combined EPIRB/S-VDR capsule, for at least 48 h, after which time
period it shall automatically switch to a stand-by mode; and, in addition,
3) have the capability of being commanded to transmit further locating/homing signals for
a cumulative period of at least 48 h at the specified duty cycle over not less than 7
days/168 h; and
4) if it does not receive a command to transmit within 5 days/120 h, it shall automatically
switch into the transmission mode for at least 48 h.
NOTE A return signal path must be implemented to command and control the locating device signal (after initial
activation) to ensure that the 48 h transmission period is achieved over a total time span of 7 days. Therefore, this
function may be implemented after such return path and guidance for its use by authorities has been specified and
after this standard has been ame
...
