Board Level Drop Test Method of
Components for Handheld Electronic
Products
JESD22-B111
JULY 2003
JEDEC SOLID STATE TECHNOLOGY ASSOCIATION

PAS 62050 © IEC:2004 (E)
INTERNATIONAL ELECTROTECHNICAL COMMISSION

____________
BOARD LEVEL DROP TEST METHOD OF COMPONENTS

FOR HANDHELD ELECTRONIC PRODUCTS

FOREWORD
1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising all

national electrotechnical committees (IEC National Committees). The object of IEC is to promote international co-

operation on all questions concerning standardization in the electrical and electronic fields. To this end and in

addition to other activities, IEC publishes International Standards, Technical Specifications, Technical Reports,
Publicly Available Specifications (PAS) and Guides (hereafter referred to as “IEC Publication(s)”). Their preparation
is entrusted to technical committees; any IEC National Committee interested in the subject dealt with may
participate in this preparatory work. International, governmental and non-governmental organizations liaising with
the IEC also participate in this preparation. IEC collaborates closely with the International Organization for
Standardization (ISO) in accordance with conditions determined by agreement between the two organizations.
2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international
consensus of opinion on the relevant subjects since each technical committee has representation from all interested
IEC National Committees.
3) IEC Publications have the form of recommendations for international use and are accepted by IEC National
Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC
Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any
misinterpretation by any end user.
4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications
transparently to the maximum extent possible in their national and regional publications. Any divergence between
any IEC Publication and the corresponding national or regional publication shall be clearly indicated in the latter.
5) IEC provides no marking procedure to indicate its approval and cannot be rendered responsible for any equipment
declared to be in conformity with an IEC Publication.
6) All users should ensure that they have the latest edition of this publication.
7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and
members of its technical committees and IEC National Committees for any personal injury, property damage or
other damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and expenses
arising out of the publication, use of, or reliance upon, this IEC Publication or any other IEC Publications.
8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is
indispensable for the correct application of this publication.
9) Attention is drawn to the possibility that some of the elements of this IEC Publication may be the subject of patent
rights. IEC shall not be held responsible for identifying any or all such patent rights.
A PAS is a technical specification not fulfilling the requirements for a standard but made available
to the public.
IEC-PAS 62050 was submitted by JEDEC and has been processed by IEC technical committee
47: Semiconductor devices.
The text of this PAS is based on the This PAS was approved for

following document: publication by the P-members of the
committee concerned as indicated in
the following document
Draft PAS Report on voting
47/1753/NP 47/1791/RVN
Following publication of this PAS, the technical committee or subcommittee concerned will
investigate the possibility of transforming the PAS into an International Standard
An IEC-PAS licence of copyright and assignment of copyright has been signed by the IEC and
JEDEC and is recorded at the Central Office.
This PAS shall remain valid for an initial maximum period of three years starting from
2004-11. The validity may be extended for a single three-year period, following which it shall be
revised to become another type of normative document or shall be withdrawn.
Page i
JEDEC Standard No. 22-B111
BOARD LEVEL DROP TEST METHOD OF COMPONENTS

FOR HANDHELD ELECTRONIC PRODUCTS

Introduction
The handheld electronic products fit into the consumer and portable market segments. Included in the

handheld electronic products are cameras, calculators, cell phones, pagers, palm size PCs, Personal

Computer Memory Card International Association (PCMCIA) cards, smart cards, mobile phones,

personal digital assistants (PDAs) and other electronic products that can be conveniently stored in a
pocket and used while held in user’s hand.

These handheld electronic products are more prone to being dropped during their useful service life
because of their size and weight. This dropping event can not only cause mechanical failures in the
housing of the device but also create electrical failures in the printed circuit board (PCB) assemblies
mounted inside the housing due to transfer of energy through PCB supports. The electrical failures may
result from various failure modes such as cracking of circuit board, trace cracking on the board, cracking
of solder interconnections between the components and the board, and the component cracks. The
primary driver of these failures is excessive flexing of circuit board due to input acceleration to the board
created from dropping the handheld electronic product. This flexing of the board causes relative motion
between the board and the components mounted on it, resulting in component, interconnects, or board
failures. The failure is a strong function of the combination of the board design, construction, material,
thickness, and surface finish; interconnect material and standoff height; and component size.

Page ii
JEDEC Standard No. 22-B111
Page 1
BOARD LEVEL DROP TEST METHOD OF COMPONENTS

FOR HANDHELD ELECTRONIC PRODUCTS

(From JEDEC Board Ballot JCB-03-38, formulated under the cognizance of the JC-14.1 Subcommittee

on Reliability Test Methods for Packaged Devices)

1 Scope
The Board Level Drop Test Method is intended to evaluate and compare drop performance of surface
mount electronic components for handheld electronic product applications in an accelerated test
environment, where excessive flexure of a circuit board causes product failure. The purpose is to
standardize the test board and test methodology to provide a reproducible assessment of the drop test
performance of surface mounted components while duplicating the failure modes normally observed
during product level test.
The purpose of this document is to prescribe a standardized test method and reporting procedure. This is
not a component qualification test and is not meant to replace any system level drop test that maybe
needed to qualify a specific handheld electronic product. The standard is not meant to cover the drop test
required to simulate shipping and handling related shock of electronic components or PCB assemblies.
These requirements are already addressed in JESD22-B104-B and JESD22-B110. The method is
applicable to both area-array and perimeter-leaded surface mounted packages.

Correlation between test and field conditions is not yet fully established. Consequently, the test
procedure is presently more appropriate for relative component performance than for use as a pass/fail
criterion. Rather, results should be used to augment existing data or establish baseline for potential
investigative efforts in package/board technologies.

The comparability between different test sites, data acquisition methods, and board manufacturers has
not been fully demonstrated by existing data. As a result, if the data are to be used for direct comparison
of component performance, matching study must first be performed to prove that the data are in fact
comparable across different test sites and test conditions.

This method is not intended to substitute for full characterization testing, which might incorporate
substantially larger sample sizes and increased number of drops. Due to limited sample size and number

of drops specified here, it is possible that enough failure data may not be generated in every case to
perform full statistical analysis.

2 Apparatus
As per JESD22-B104-B and JESDD22-B110

JEDEC Standard No. 22-B111
Page 2
3 Terms and definitions
For purposes of this standard, the following definitions shall apply

component: A packaged semiconductor device.

single-sided PCB assembly: A printed circuit board assembly with components mounted on only one

side of the board
double-sided PCB assembly: A printed circuit board assembly with components mounted on top and
bottom sides of the board.
handheld electronic product: A product that can conveniently be stored in a pocket (of sufficient size)
and used when held in user’s hand.

NOTE Included in handheld electronic products are cameras, calculators, cell phones, pagers, palm-size PCs
(formerly called ‘pocket organizers’), Personal Computer Memory Card International Association (PCMCIA) cards,
smart cards, mobile phones, personal digital assistants (PDAs), and other communication devices.

peak acceleration: The maximum acceleration during the dynamic motion of the test apparatus.

pulse duration; acceleration interval: The time interval between the instant when the acceleration first
reaches 10% of its specified peak level and the instant when the acceleration first returns to 10% of the
specified peak level after having reach that peak level.

table drop height: The free-fall drop height of the drop table needed to attain the prescribed peak
acceleration and pulse duration.

event: An electrical discontinuity of resistance greater than 1000 ohms lasting for 1 microsecond or
longer.
event detector: A continuity test instrument capable of detecting electrical discontinuity of resistance
greater than 1000 ohms lasting for 1 microsecond or longer.

4 Applicable documents
JESD22-B104-B, Mechanical Shock
JESD22-B110, Subassembly Mechanical Shock
IPC-SMT-782, Surface Mount Design and Land Pattern Standard
IPC-A-600, Acceptability of Printed Boards
J-STD-020, Moisture/Reflow Sensitivity Classification for Non-hermetic Solid State Surface Mount
Devices
J-STD-033, Standard for Handling, Packing, Shipping and Use of Moisture/Reflow Sensitive Surface
Mount Devices
IPC-9701, Performance Test Methods and Qualification Requirements for Surface Mount Solder
Attachments
JEDEC Standard No. 22-B111
Page 3
5 Test Components and Board
5.1 Components
This standard covers all area arrays and perimeter-leaded surface-mountable packaged semiconductor

devices such as BGAs, LGAs, CSPs, TSOPs, and QFNs typically used in handheld electronic product.

Since components with body sizes larger than 15 mm x 15 mm in size are not used in these applications,
the maximum size of the component body covered in this standard is 15 mm x 15 mm. All components

used for this testing must be daisy-chained. The daisy chain should either be done at the die level or by
providing daisy chain links at the lead-frame or substrate level. In case of non-daisy chain die, a mechanical
dummy die must be used inside the package to simulate the actual structure of the package. The die size
and thickness should be similar to the functional die size to be used in application. The component
materials, dimensions, and assembly processes shall be representative of typical production device.

5.2 Test board
Since the drop test performance is a function of the test board used for evaluation, this standard defines a
preferred test board construction, dimensions, and material that is representative of those used in
handheld electronic products. If another board construction/material better represents a specific
application, the test board construction, dimensions and material should be documented. The test data
generated using such a board shall be correlated at least once by generating the same data on same
component using the preferred board defined in this document.

5.2.1 Preferred board construction, material, and design

The preferred test board shall use built-up multilayer technology incorporating microvias using 1+6+1
stack-up. This is required as typical PCB assemblies used in handheld electronic systems are constructed
using high density, buildup technology. The test board shall have a nominal thickness of 1.0 mm. Table 1
provides the thickness, copper coverage, and the material for each layer. The dielectric materials shall
meet the mechanical properties requirements as given in Table 2. The PCB shall have Organic
Solderability Preservatives (OSP) as surface finish to avoid any copper oxidation before component
mounting. The glass transition temperature, Tg, of each dielectric material as well as of the composite
o
board shall be 125 C or greater. The modulus and Tg of the dielectric materials shall be specified. The
composite values (Modulus, and Tg) shall be measured on at least one representative test board at
component mounting location. The boards shall be symmetric in construction about the mid-plane of the
board, except for the minor differences in the top and bottom two layers.

Since a typical product board may have a combination of microvia in pad and no vias in pad for area

array packages for routing purposes, it is required that such components (BGAs, CSPs, etc) be tested on
board with both microvia and non-microvia PCB pads. This shall be accomplished by designing double
sided boards with mirror component footprint on each side (top and bottom) of the board. The board Side
A shall have microvias in pads (“via in pad”) on all component mounting pads while the board Side B
shall have no microvias in pads (“no via in pads”). For board Side A, the microvias in pads shall be
created with laser ablation with via diameter of 110 microns. The vias shall then be plated resulting in
straight or near straight walls. The capture pad diameter shall be at least 220 microns. Although two
sided boards are to be designed, the component shall only be mounted on one side at a time, resulting in
two single sided assemblies (“Side A assembly” and “Side B assembly”), unless the component is
anticipated for use in mirror-sided board assemblies. In that case, the components shall be mounted on
each side of the board.
JEDEC Standard No. 22-B111
Page 4
5.2 Test board (cont’d)
5.2.1 Preferred board construction, material, and design )cont’d)

As perimeter-leaded devices do not typically require microvia in pad, the test board for such devices

(TSOP, QFP, etc) does not need to include microvias. The board shall still be designed as double-sided

with footprint of similar sized components on each side.

Although daisy-chain nets will typically not require plated though holes (PTH) other than those required

for manual probe pads and connectors, the test board shall contain PTH in the component region (1.2X
the area covered by component) to approximate mechanical effect of vias on actual application boards.
There shall be 20 plated through holes per square centimeter in the component region. The actual
location and distribution of plated through holes will depend on component size and I/O. The through
holes shall have the drill diameter of 300 microns and finished plated hole diameter of 250 microns. The
PTH pad diameters shall be 550 microns for the outer layer and 600 microns for the inner layers.

It is recommended that the component mounting pads on the PCB be designed as per the specification in
Table 3 for area array devices. The pad design for leaded and perimeter I/O devices shall be according to
IPC-SM-782 guidelines. All component attachment pads shall be non-solder-mask-defined (NSMD) with
solder mask clearance of 75 microns between the edge of the pad and the edge of solder mask. Smaller
clearance can be used as long as it does not cause any solder mask encroachment on pads due to mis-
registration. Solder mask registration tolerance shall not exceed 50 microns

Table 1 — Test board stack-up and material
Thickness
Board Layer Copper Coverage (%) Material
(microns)
Solder Mask 20 LPI
Layer 1 35 Pads + traces Copper
*
Dielectric 1-2 65 RCC
Layer 2 35 40% including daisy chain links Copper
†
Dielectric 2-3 130 FR4
Layer 3 18 70% Copper
†
Dielectric 3-4 130 FR4
Layer 4 18 70% Copper
†
Dielectric 4-5 130 FR4
Layer 5 18 70% Copper
†
Dielectric 5-6 130 FR4
Layer 6 18 70% Copper
†
Dielectric 6-7 130 FR4
Layer7 35 40% Copper
*
Dielectric 7-8 65 RCC
Layer 8 35 Pads + Traces + daisy chain links Copper
Solder Mask 20 LPI
*
Suggested RCC Material: Polyclad PCL-CF-400 12/35/35
†
Suggested FR4 Material: NELCO N-4000-6 or equivalent

JEDEC Standard No. 22-B111
Page 5
5.2 Test board (cont’d)
5.2.1 Preferred board construction, material, and design )cont’d)

Table 2 — Mechanical property requirements for dielectric materials

Property Unit FR4 RCC
Tensile Strength MPa >100 >50
Tensile Modulus GPa 20 ± 2 2 ± 1
Tensile Elongation % >3 >3
In-plane CTE ppm/°C 15 ± 2 60-80
(below Tg)
Tg °C >130 >130
Cu Peel kgf/cm >1 >1
Table 3 — Recommended test board pad sizes and solder mask openings
Component I/O Pitch PCB Pad Diameter Solder Mask Opening
(mm) (mm) (mm)
0.50 0.28 0.43
0.65 0.30 0.45
0.75/0.80 0.35 0.50
1.00 0.45 0.60
The trace widths on the suggested test board shall be 75 microns within the component area. This
includes all traces making contact with solder joint interconnect as well as all internal layers. A trace
width of 100 microns shall be used for all traces outside of component region. The board shall have
matching daisy chain pattern such that one or multiple nets are formed through all interconnects after
component mounting. Wherever necessary, additional test points within each net shall be incorporated
for failure location identification. Each additional test point shall be clearly labeled using row column

format of the package. All routing and traces within and just outside the component footprint shall be
done on layer 2 and layer 8 for area array packages and layer 1 and layer 8 for perimeter leaded packages.

The suggested test board shall have component mounting features such as Pin 1 identification and
global/local fiducials.
JEDEC Standard No. 22-B111
Page 6
5.2 Test board (cont’d)
5.2.1 Preferred board construction, material, and design (cont’d)

Figure 1 — Test board size and layout

Table 4 — X, Y locations for components’ center
(Center of lower left screw hole as datum)
Component ID X location of Y location of
component center (mm) component center (mm)
U1 5 + CompX/2 5 + CompY/2
U2 28.75 + CompX/4 5 + CompY/2
U3 52.5 5 + CompY/2
U4 76.25 - CompX/4 5 + CompY/2
U5 100 - CompX/2 5 + CompY/2
U6 5 + CompX/2 35.5
U7 28.75 + CompX/4 35.5
U8 52.5 35.5
U9 76.25 - CompX/4 35.5
U10 100 - CompX/2 35.5
U11 5 + CompX/2 66 - CompY/2
U12 28.75 + CompX/4 66 - CompY/2
U13 52.5 66 - CompY/2
U14 76.25 - CompX/4 66 - CompY/2
U15
...
