EN 13232-5:2005+A1:2011
(Main)Railway applications - Track - Switches and crossings - Part 5: Switches
Railway applications - Track - Switches and crossings - Part 5: Switches
The scope of this European Standard is:
- establish a working definition for switches and their constituent parts and identify the main types;
- specify the minimum requirements for the manufacture of the switches and/or constituent parts;
- specify codes of practice for inspection and tolerances of both full and half sets of switches and their constituent parts;
- establish the limits and scope of supply;
- list the methods by which switches and their parts should be identified and traced;
- list the different and varying ways by which switches can be described using the following parameters:
- geometry of the switches;
- types of construction;
- performance requirements;
- design criteria;
- tolerances and inspection.
Bahnanwendungen - Oberbau - Weichen und Kreuzungen - Teil 5: Zungenvorrichtungen
Der Anwendungsbereich für diese Europäische Norm ist:
- Fachausdrücke für Zungenvorrichtungen und ihre einzelnen Bauteile zusammenzustellen und ihre Hauptteile zu benennen;
- ein Minimum an informativen Anforderungen für die Fertigung der Zungenvorrichtungen und/oder einzelner Bauteile aufzuführen;
- Ausführungsbestimmungen für die Abnahme und Grenzabweichungen sowohl für halbe als auch für ganze Zungenvorrichtungen und ihre einzelnen Bauteile zu formulieren;
- den Lieferumfang festzustellen;
- Verfahren aufzuführen, nach denen Zungenvorrichtungen und ihre einzelnen Bauteile identifiziert und rückverfolgt werden können;
- die verschiedenen Möglichkeiten aufzuführen, nach denen Zungenvorrichtungen unter der Verwendung folgender Parameter beschrieben werden können:
- Geometrie der Zungenvorrichtungen;
- Bauarten;
- Leistungsanforderungen;
- Konstruktionskriterien;
- Grenzabweichungen und Abnahme.
Applications ferroviaires - Voie - Appareils de voie - Partie 5: Aiguillages
Le domaine d’application de la présente Norme européenne est le suivant :
- établir les définitions pour les aiguillages et leurs constituants et identifier les principaux types d’aiguillages ;
- spécifier le minimum d’informations exigées pour la fabrication des aiguillages et de leurs constituants ;
- spécifier les règles pour le contrôle et les tolérances des aiguillages et des demi-aiguillages ainsi que de leurs constituants ;
- établir les limites de fourniture ;
- lister les méthodes d’identification et de traçabilité des aiguillages et de leurs constituants ;
- lister les différentes méthodes permettant la description des aiguillages en utilisant les paramètres suivants :
- tracé des aiguillages ;
- types de construction ;
- exigences de performance ;
- critères de conception ;
- tolérances et contrôle.
Železniške naprave - Zgornji ustroj - Kretnice in križišča - 5. del: Kretniška menjala
Namen tega evropskega standarda je:
- vzpostaviti delovno definicijo za kretniška menjala in njihove sestavne dele ter identificirati glavne vrste;
- določiti minimalne zahteve za izdelavo kretniških menjal in/ali njihovih sestavnih delov;
- določiti kodeks ravnanja pri pregledu in odstopanja polnih in delnih setov kretniških menjal in njihovih sestavnih delov;
- vzpostaviti meje in obseg napajanja;
- našteti metode za identifikacijo in sledenje kretniških menjal in njihovih delov;
- našteti različne in spremenljive načine za opis kretniških menjal z uporabo naslednjih parametrov:
- geometrija stikal;
– vrste strukture;
- zahteve za delovanje;
- merila za projektiranje;
- odstopanja in pregled.
