1 Scope This document defines the cabling specifications for an onboard data transmission bus between the different parts of equipment for service operations and monitoring of the fleet. This document is applicable to equipment installed onboard buses, trolley buses and tramways only as part of a bus fleet operation. This equipment include operations aid systems, automatic passenger information systems, fare collection systems, etc. Equipment directly related to the functioning of the vehicle (e.g. driver dashboard, engine management, brake systems, door opening systems) are excluded from the scope of this document and are dealt with in other standardisation bodies. This document is not applicable to tramways operated as part of a train, subway or metro operation. Two alternative transmission buses will be accepted. This document refers to one of them (known as WORLFIP and specified in EN 50170). A second set of standards will be published for the other solution (so called CAN). The selected bus system, between the two standardised alternatives, shall be subject to an agreement between each transport operating organisation and its equipment providers. This document covers the link between equipment inside a single vehicle. Although it could be applied to multiple vehicles, this application is not explicitly covered by this document. This document is the second part of a set of standards related to the onboard transmission bus, which will define the following aspects for each allowed transmission bus: — choice of the bus and general application’s rules (EN 13149-1) — cabling specifications (EN 13149-2, this document) — message content specifications (prCEN TS 13149-3, under development) 2 Normative references The following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 50170
General purpose field communication system EN 61158-2:1994
Fieldbus standard for use in industrial control systems; part 2: physical layer specification and service definition (IEC 61158-2:1993)
3 Cabling specifications 3.1 General remarks The principles for the coupling of devices to the data transmission bus focus upon the longer term objectives which are to achieve the least necessary number of variants, rather than to allow for the profusion of interim and migratory solutions which may occur initially. This is especially important for public transport road vehicles, which are generally equipped in different non-correlated stages (for example, first the fare collection system, then the radio and automatic location system some months or years later, etc.) SIST EN 13149-2:2005

Pair 1
Wire 1 (White) - Data +
Wire 2 (Black) - Data
- 3.4 Signal conductors The signal conductors shall not be used for powering any devices. 3.5 Connections between devices The one pair cable can be run between devices in a daisy chain fashion but shall be terminated with a 150 Ω resistor at each end.
Key A device 1 B device 2 C device N X Data + White Y Data - Black Figure 1 — Connection between devices 3.6 Connection/disconnection of a device
To avoid the disruption to the trunk continuity when a device is removed, the cable shall be joined on the trunk side of the device connector. This will allow removal of a device without causing a failure to the remaining network. SIST EN 13149-2:2005

Key A device 1 D data Figure 2 —Connection/disconnection of a device
3.7 Spur length To minimise the mismatch caused by a spur, the cable connection at the device shall be within 2,5 cm of the coupling transformer.
Key A coupling transformer B connector D data Figure 3 — Spur length
Cable Side
- Socket (receptacles)
Device Side
- Plug (pins)
Four way connectors
Nine way connectors
Terminal 1 a Data +
Terminal 1 Screen
2 b Data -
3 c DC + ve
4 d DC - ve
6 Data +
7 Data -
8 DC +
9 DC - When a connection that breaks into the trunk circuit is required a tap connection can be provided. This could be provided using a two pair branch cable. 3.9 Branch cable polarity: The polarity of the signal conductors shall be maintained.
Pair 1
Wire 1
White
Data +
Wire 2
Black
Data -
Pair 2
Wire 1
Red
Data +
Wire 2
Green
Data -
See additional tables in annex, A which refers to cables for up to six pairs for additional circuits.
Key A device 1 D+W data+white D-B data-black W white B black R red G green 1 Data+ 2 Branch cable 3 Drain wire connections to shields 4 Tap box Figure 4 — Branch cable polarity SIST EN 13149-2:2005

3.10 Cable jointing The wires shall be joined to maintain the data polarity. These shall be crimped and insulated to maintain the circuit integrity. The screen continuity shall be maintained by the drain wire. The cable sheath shall be clamped to provide strain relief. See Figures 5 and 6.
Key A ground terminal (only when required) B trunk C insulated screened box D branch Figure 5 — Cable tap with branch cable
Key B trunk Figure 6 — Cable join with a connector (CC1)
3.11 Clustered connections to the bus Provided that individual devices are not less than 8kOhms input impedance, and up to 2,5 cm length spur as required in 3.6, then up to a maximum of four devices may
...
