EN 1859:2009

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Dimniki - Kovinski dimniki - Preskusne metodeAbgasanlagen - Metall-Abgasanlagen - PrüfverfahrenConduits de fumèe - Conduits de fumèe mètalliques - Mèthodes d'essaisChimneys - Metal chimneys - Test methods91.060.40Dimniki, jaški, kanaliChimneys, shafts, ductsICS:Ta slovenski standard je istoveten z:EN 1859:2009SIST EN 1859:2009en,fr,de01-oktober-2009SIST EN 1859:2009SLOVENSKI
STANDARDSIST EN 1859:2001/A1:2006SIST EN 1859:20011DGRPHãþD

EUROPEAN STANDARDNORME EUROPÉENNEEUROPÄISCHE NORMEN 1859May 2009ICS 91.060.40Supersedes EN 1859:2000
English VersionChimneys - Metal chimneys - Test methodsConduits de fumèe - Conduits de fumèe mètalliques -Mèthodes d'essaisAbgasanlagen - Metall-Abgasanlagen - PrüfverfahrenThis European Standard was approved by CEN on 1 May 2009.CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this EuropeanStandard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such nationalstandards may be obtained on application to the CEN Management Centre or to any CEN member.This European Standard exists in three official versions (English, French, German). A version in any other language made by translationunder the responsibility of a CEN member into its own language and notified to the CEN Management Centre has the same status as theofficial versions.CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Cyprus, Czech Republic, Denmark, Estonia, Finland,France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal,Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland and United Kingdom.EUROPEAN COMMITTEE FOR STANDARDIZATIONCOMITÉ EUROPÉEN DE NORMALISATIONEUROPÄISCHES KOMITEE FÜR NORMUNGManagement Centre:
Avenue Marnix 17,
B-1000 Brussels© 2009 CENAll rights of exploitation in any form and by any means reservedworldwide for CEN national Members.Ref. No. EN 1859:2009: ESIST EN 1859:2009

Method for measuring ambient temperature . 34 Annex B (normative)
Method for hot gas temperature measurements . 35 Annex C (informative)
Method for metal surface temperature measurements . 36 Annex D (normative)
Method for combustible wood surface temperature measurements . 37 Annex E (normative)
Locations of thermocouples for surface temperature measurements . 38 E.1 Test structure, surface temperatures . 38 E.2 Test chimney, surface temperatures . 38 E.2.1 General . 38 E.2.2 Test chimney, freestanding . 38 E.2.3 Test chimney, corner installation . 38 E.2.4 Test chimney, corner installation, enclosed. 38 Annex F (normative)
Simplified calculation of thermal resistance for circular flues . 41 Annex G (informative)
Method for applying an evenly distributed load (horizontal) . 43 Annex H (informative)
Possible test sequence . 44 Annex I (informative)
Techniques for flue gas volume flow measurements . 45 Bibliography . 46
2 Normative references The following referenced documents are indispensable for the application of this document. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 1443:2003, Chimneys - General requirements EN 1856-1:2009, Chimneys - Requirements for metal chimneys - Part 1: System chimney products EN 60068-2-59, Environmental testing - Part 2 - Test methods - Test Fe: Vibration, Sine beat method (IEC 60068-2-59:1990) EN 60529, Degrees of protection provided by enclosures (IP Code) (IEC 60529:1989) ISO 3966, Measurement of fluid flow in closed conduits. Velocity area method using Pitot static tubes 3 Definitions For the purposes of this standard, the definitions given in EN 1443:2003 and EN 1856-1:2009 apply. 4 Test methods for metal chimney products 4.1 Compressive strength 4.1.1 Sections and Fittings 4.1.1.1 Test assembly Assemble the fitting according to the manufacturer's installation instructions between two adaptors including one chimney section (see Figure 1a). The adaptors shall be supplied by the chimney manufacturer and shall transfer the test load in the usual way to the load bearing wall of the test components as it is done in the installation. The test load shall be transferred to the test components by means of a pivoted plate. 4.1.1.2 Procedure and results Increase the test load on the components without shock up to 4 times the design load where the flue liner is load bearing or 3 times the design load where the flue liner is non load bearing. The load shall be measured to an accuracy of 2 % of the design load. Record the result. Where the design load is unknown, increase the test load uniformly and record the results to allow the point of failure to be detected. Failure is deemed to have occurred when the fitting cannot sustain a further increase in load. Use the minimum value from three failure loads to determine the design load. SIST EN 1859:2009

Where the design load is unknown, increase the load uniformly and record the results to allow the point of failure to be detected. Failure is deemed to have occurred when the support cannot sustain a further increase in load. Record the displacement during the load increase. Use the minimum value from three failure loads to determine the design load. 4.2 Tensile strength 4.2.1 Test assembly Install the chimney sections according to the manufacturer's installation instructions. Apply the test load through an adaptor (see Figure 1c). The adaptor shall be supplied by the chimney manufacturer and shall transfer the test load in the usual way to the load bearing wall of the chimney sections. 4.2.2 Test procedure and results Increase the test load on the components without shock up to 1,5 times the design load. The load shall be measured to an accuracy of 2 % of the design load. Record the result. Where the design load is unknown, increase the test load uniformly and record the results to allow the point of failure to be detected. Failure is deemed to have occurred when the fitting cannot sustain a further increase in load. Use the minimum value from three failure loads to determine the design load. 4.3 Lateral strength 4.3.1 Fittings in non-vertical orientation 4.3.1.1 Test assembly Install the chimney fittings and supports at the maximum angle from vertical according to the manufacturer's installation instructions using additional vertical supports to install the sections without deflection (see Figure 2). SIST EN 1859:2009

The chimney shall be tested according to Figure 5. NOTE Figure 6 shows the arrangement for testing off-sets. 4.5.1.2 Test structure 4.5.1.2.1 General Construct a test structure consisting of two walls at right angles and two floors through which the test chimney passes, of construction as described in 4.5.1.2.2 and 4.5.1.2.3 or of equivalent thermal characteristics and dimensions. The floor opening and wall position shall enable the test chimney to be erected so that all parts of the test structure are at the manufacturer's specified clearance X mm from the chimney. The area below the first floor referenced as Zone A, the area between the first floor and second floor as Zone B, and the area above the second floor as Zone C, as shown in Figure 5. The wall/floor interface shall be fitted with nominally 20 mm x 100 mm skirting board. The vertical distance between the floor and ceiling in Zone B shall be (2 400 ± 25) mm. The height of the chimney protruding into Zone C shall not be less than 900 mm. Timbers shall have a dimensional tolerance of ± 1 mm. 4.5.1.2.2 Walls Construct walls consisting of nominal dimension 38 mm x 89 mm thick timbers in a framework (see Figure 5) faced on each side with one layer of nominally 12 mm thick plywood to give a total thickness of 113 mm ± 1 mm, insulated in the voids with mineral fibre insulant having a thermal conductivity of 0,035 W/m K ± 0,002 W/m K at 20 °C with a minimum density of 70 kg/m3. The walls shall extend at least 1 200 mm. 4.5.1.2.3 Floors Construct flooring framework of nominal dimension 50 mm x 200 mm timbers at the first floor level and nominal dimension 50 mm x 100 mm timbers at the second floor level forming an opening that enables the test chimney to be erected so that all parts of the test structure comply with the manufacturer's declared minimum distance to combustible material from the chimney fittings (see Figure 5) and covered with one thickness of nominal dimension 20 mm boarding for the floors and one thickness of nominal dimension 12 mm plywood for the ceilings, except for the second floor ceiling (exposed top), and the spaces between the timbers filled with 100 mm thick mineral wool slab with a thermal conductivity of 0,035 W/m K ± 0,002 W/m K at 20 °C, with a minimum density of 70 kg/m3. 4.5.1.3 Test chimney Construct the test chimney using the components materials and construction representing the manufacturer's product range, including a termination, and, at least 7 joints. Assemble the chimney in accordance with the manufacturer's installation instructions, including firestops or firestops and spacers to a height of not less than 4,5 m, including base support components, if used. Construct the test chimney according to Figure 5 for all sections, T pieces and inspection openings. Where a manufacturer’s product range includes bends, the test chimney shall include one offset (see Figure 6), with an offset angle of maximum 45° and an offset distance of 0.75 m ± 0.25 m. Any inspection opening shall be in Zone C
Include any finishing (e.g. non-combustible enclosures or claddings) specified in the manufacturer's instructions. SIST EN 1859:2009

through a 150 mm ± 2 mm length of stainless steel tubing, internal diameter
3mm10mmmm+ inserted through the flue pipe and flush with the flue surface and sealed by brazing, at a distance of 100 mm ± 2 mm from the entry to the test chimney. SIST EN 1859:2009

Seal only joints and openings between spacers or supports and the test structure and all joints in the enclosure casing. Install a chimney designated for use without an enclosure into the test structure, without enclosing the test chimney and without closing the floor penetrations (see Figure 7). SIST EN 1859:2009

Maintain this condition for 10 min, then shut off the hot gas generator and allow to cool for 10 min. Repeat this cycle 11 times. Measure, at ambient temperature, with an accuracy of 0.001 m, the change in vertical position of the chimney wall(s) at the top of the test sample before and after subjecting the product to the cycles. Measure and record the gas tightness according to 4.4. 4.5.3.2 Thermal shock test With the test assembly temperatures within 10 °C of the test room ambient conditions generate hot gas with the volume flow and test temperature specified in Table 1 appropriate to the diameter. Regulate the rate of rise of the hot gas temperature to achieve 1000 °C in 10 min ± 1 min. Maintain the hot gas temperature at 10005020+− °C for a period of 30 min ± 1 min, then turn off the hot gas generator. Continue to record the temperatures on the test assembly until the temperatures have reached their maximum and are decreasing. Measure and record flue regularity and measure gas tightness according to 4.4. SIST EN 1859:2009
...
