INTERNATIONAL STANDARD ISO 13140-1:2016(E)
Electronic fee collection — Evaluation of on-board and
roadside equipment for conformity to ISO 13141 —
Part 1:
Test suite structure and test purposes
1 Scope
This document specifies the test suite structure (TSS) and test purposes (TP) to evaluate the conformity
of on-board units (OBU) and roadside equipment (RSE) to ISO 13141.
It provides a basis for conformance tests for dedicated short-range communication (DSRC) equipment
(on-board units and roadside units) to enable interoperability between different equipment supplied by
different manufacturers.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies. For
undated references, the latest edition of the referenced document (including any amendments) applies.
ISO 13141:2015, Electronic fee collection — Localisation augmentation communication for autonomous
systems
ISO 14906:2011/Amd 1:2015, Electronic fee collection — Application interface definition for dedicated
short-range communication/Amendment 1
ISO/TS 14907-2:2016, Electronic fee collection — Test procedures for user and fixed equipment — Part 2:
Conformance test for the on-board unit application interface
EN 15509:2014, Electronic fee collection — Interoperability application profile for DSRC
EN 15876-1:2016, Electronic fee collection — Evaluation of on-board and roadside equipment for
conformity to EN 15509 — Part 1: Test suite structure and test purposes
ETSI/TS 102 486-2-2-V1.2.1 (2008-10), Intelligent Transport Systems (ITS); Road Transport and Traffic
Telematics (RTTT); Test specifications for Dedicated Short Range Communication (DSRC) transmission
equipment; Part 2: DSRC application layer; Sub-Part 2: Test Suite Structure and Test Purposes (TSS&TP)
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— IEC Electropedia: available at http://www.electropedia.org/
— ISO Online browsing platform: available at https://www.iso.org/obp/
ISO 13140-1:2016(E)
3.1
access credentials
trusted attestation or secure module that establishes the claimed identity of an object or application
property that ensures that the actions of an entity may be traced uniquely to that entity
Note 1 to entry: Access credentials carry information needed to fulfil access conditions in order to perform the
operation on the addressed element (3.7) in the OBE (3.10). Access credentials can carry passwords, as well as
cryptography-based information such as authenticators (3.4).
[SOURCE: EN 15509:2014, 3.1]
3.2
attribute
addressable package of data consisting of a single data element or structured sequences of data
elements
[SOURCE: ISO 17575-1:2016, 3.2]
3.3
authentication
security mechanism allowing verification of the provided identity
[SOURCE: EN 301 175]
3.4
authenticator
data, possibly encrypted, that is used for authentication (3.3)
[SOURCE: EN 15509:2014, 3.3]
3.5
cryptography
principles, means and methods for the transformation of data in order to hide its information content,
prevent its undetected modification or prevent its unauthorized use
[SOURCE: EN 15509:2014, 3.6]
3.6
data group
class of closely related attributes (3.2)
[SOURCE: ISO 17575-1:2016, 3.10]
3.7
element
directory containing application information in the form of attributes (3.2)
[SOURCE: ISO 14906:2011, 3.11, modified]
3.8
implementation conformance statement
statement of capabilities and options that have been implemented defining to what extent the
implementation is compliant with a given specification
[SOURCE: ISO/TS 14907-2:2016, 3.6, modified]
3.9
implementation extra information for testing
statement containing all of the information related to the implementation under test (IUT) and its
corresponding system under test (SUT) which will enable the testing laboratory to run an appropriate
test suite against that IUT
[SOURCE: ISO/TS 14907-2:2016, 3.8]
2 © ISO 2016 – All rights reserved

ISO 13140-1:2016(E)
3.10
on-board equipment
OBE
all required equipment on-board a vehicle for performing required EFC functions and communication
services
3.11
on-board unit
OBU
single electronic unit on-board a vehicle for performing specific EFC functions and for communication
with external systems
3.12
roadside equipment
RSE
equipment located along the road either fixed or mobile
[SOURCE: ISO/TS 19299:2015, 3.34]
3.13
tester
combination of equipment, humans and processes able to perform specified conformance tests
[SOURCE: EN 15876-1:2016, 3.12]
3.14
transaction
whole of the exchange of information between two physically separated communication facilities
[SOURCE: ISO 17575-1:2016, 3.21]
4 Abbreviated terms
AC_CR Access Credentials
ADU Application Data Unit
APDU Application Protocol Data Unit (ISO 14906)
AP Application Process
ASN.1 Abstract Syntax Notation One (ISO/IEC 8824-1)
ATS Abstract Test Suite
BI Behaviour Invalid (i.e. Invalid Behaviour Tests)
B-Kernel Broadcast Kernel
BST Beacon Service Table (ISO 14906)
BV Behaviour Valid (i.e. valid behaviour Tests)
cf Confirm
DLC Data Link Control
DSRC Dedicated Short-Range Communication (ISO 14906)
DUT Device Under Test (ISO/TS 14907-2)
ISO 13140-1:2016(E)
EID Element Identifier
EFC Electronic Fee Collection (ISO 17573)
ICS Implementation Conformance Statement
LLC Logical Link Control (EN 12795)
MAC Medium Access Control (EN 12795)
PCTR Protocol Conformance Test Report
PDU Protocol Data Unit
PIXIT Protocol Implementation eXtra Information For Testing
TSS Test Suite Structure
VST Vehicle Service Table (ISO 14906)
5 Test Suite Structure (TSS)
5.1 Structure
The Test Suite Structure (TSS) including its subgroups that are inherited from other specifications is
given in Table 1.
Table 1 — Test Suite Structure
Group Type of DUT Behaviour
Physical layer On-board unit Valid Behaviour
Invalid Behaviour
Roadside equipment Valid Behaviour
Invalid Behaviour
DLC MAC sublayer On-board unit Valid Behaviour
Invalid Behaviour
Roadside equipment Valid Behaviour
Invalid Behaviour
DLC LLC sublayer On-board unit Valid Behaviour
Invalid Behaviour
Roadside equipment Valid Behaviour
Invalid Behaviour
Application layer On-board unit Valid Behaviour
Invalid Behaviour
Roadside equipment Valid Behaviour
Invalid Behaviour
Physical layer tests are to be performed in a radio wave lab. They will not form part of the ATS.
5.2 Reference to conformance test specifications
Conformance to a profile standard implies conformance to the related base standards; hence, a number
of test cases for the LAC application are exactly the same as the conformance test cases for the related
base standards. Other test cases are derived from the base standards conformance test cases by applying
4 © ISO 2016 – All rights reserved

ISO 13140-1:2016(E)
some restrictions or choices in, e.g. the parameters values, according to what is stated in the profile
standard. Finally, specific conformance test cases for the LAC application are identified for statements
contained in the LAC application, which have no equivalence in the base standards. These latter cases
cover, for example, the application layer data test purposes. This document takes into account already
defined test purposes for conformance to the base standards by referencing them, so that:
a) for test purposes that are identical to those defined in the base standards conformance test
cases (see e.g. ETSI/TS 102 486-2-2 or EN 15876-1), a direct reference is reported. For readers’
convenience, the title or a verbal description of the referenced test purpose is given, together with
the reference;
b) for test purposes that are derived from those defined in the base standards conformance test
cases, a direct reference is reported, plus an indication on how the referred test purpose has to be
modified for the profile conformance testing;
c) for test purposes that are specific to the standard profile, a complete description is given.
An indication on whether a test purpose is identical, derived or specific is given in each test purpose.
5.3 Test Purposes (TP)
5.3.1 TP Definition conventions
The TPs are defined following the rules shown in Table 2. All Test Purposes are defined in Annexes A
and B.
Table 2 — TP Definition Rules
TP ID according to the TP naming Title
conventions Reference
TP origin
Initial condition
Stimulus and expected behaviour

TP ID The TP ID is a unique identifier. It shall be specified
according to the TP naming conventions defined in the
subclause below.
Title Short description of Test Purpose objective.
Reference The reference should contain the references of the subject
to be validated by the actual TP (specification reference,
clause, paragraph), or the reference to the standard
document defining the TP.
TP origin Indicates if the TP is identical to a TP defined in another
test standard, derived from a TP defined in another test
standard or specific for this standard profile.
Initial condition The condition defines in which initial state the DUT has to
be to apply the actual TP.
Stimulus and Definition of the events the tester performs, and the events
expected behaviour that are expected from the DUT to conform to the base
specification.
5.3.2 TP naming conventions
Each TP is given a unique identification. This unique identification is built up to contain the following
string of information:
ISO 13140-1:2016(E)
TP///–
TP: to indicate that it is a Test Purpose;
: which group among those defined in Table 1 does the TP apply to;
: type of DUT (i.e. OBU or RSE);
X: type of testing (i.e. Valid Behaviour tests — BV, or Invalid Behaviour tests — BI);
: sequential TP number (01-99).
The naming conventions are as described in Table 3.
Table 3 — TP naming convention
Identifier:
TP///–

applicable for OBU/RSE PHY Physical layer
applicable for OBU/RSE MAC/LLC MAC/LLC sublayer
applicable for OBU/RSE AP-BAS Application layer — I Kernel support
applicable for OBU AP-FUN Application layer — T Kernel support
applicable for OBU AP-DAT Application layer — Data attributes support
applicable for OBU AP-SEC Application layer — Security Level 1 support
applicable for RSE AP-SET Application layer — SET-rq PDU test purposes,
applicable for RSE AP-REL Application layer — EVENT-REPORT-rq PDU test purposes
= type of DUT OBU On-Board Unit
RSE Roadside Equipment
x = Type of testing BV Valid Behaviour Tests
BI Invalid Behaviour Tests
= sequential number (01–99) Test Purpose Number
5.4 Conformance test report
The manufacturer of the OBU and RSE, respectively, is responsible for providing a conformance
test report.
The manufacturer of the OBU shall complete the protocol conformance test report (PCTR) for on-board
units as defined in Annex C.
The manufacturer of the RSE shall complete the PCTR for roadside equipment as defined in Annex D.
6 © ISO 2016 – All rights reserved

ISO 13140-1:2016(E)
Annex A
(normative)
Test purposes for on-board units
A.1 General
This annex contains the Test Purposes (TP) for the conformity evaluation of OBUs to ISO 13141.
A.1.1 Symbols in TP Descriptions
For the application layer test purposes, a special notation and symbol convention is used, as defined in
what follows.
Symbols are used in the description of the TPs, with meanings according to Table A.1.
Table A.1 — Description of TP symbols
Symbol Description
XXX.rq ⇒ The Tester sends the XXX.rq PDU to the DUT.
⇐ YYY.rs The DUT sends the YYY.rs PDU to the Tester.
A ≡ B Test Purpose A “is congruent to” Test Purpose B. The notation Test
Purpose A ≡ Test Purpose B means that the Test Purpose A is the same
as Test Purpose B. If differences in parameters or parameter values have
to be applied, these differences are indicated in the text immediately
below.
A → B Object A “is transformed” into Object B. So a notation like
“Table X → Table Y” means that for the scope of the Test Purpose, any
reference of Table X should be changed into references to Table Y.
= Means “assignment”. That is, a notation like “accessCredentials = a value”
means that the field accessCredentials is given a value.
Ø Means “empty” or “not set”. So, a notation like
“accessCredentials = Ø → accessCredentials = calculated value”, for a
given Test Purpose, means “change all occurrences in which the field
accessCredentials has not been assigned to calculation of the value
accessCredentials to a given value.
A.2 Physical layer
Per ISO 13141:2015, 5.5.2, all test purposes TP/PHY/OBU/Bx/yy defined in EN 15876-1 are applicable
for the conformity evaluation of OBUs to CEN–DSRC based LAC as claimed in ISO 13141:2015,
Table B.8, Item 1.
A.3 MAC and LLC
Per ISO 13141:2015, 5.5.2, all test purposes TP/MAC/OBU/Bx/yy and TP/LLC/OBU/Bx/yy defined in
EN 15876-1 are applicable for the conformity evaluation of OBUs to CEN–DSRC based LAC as claimed in
ISO 13141:2015, Table B.8, Item 1.
ISO 13140-1:2016(E)
A.4 Application Layer
A.4.1 Structure of BST and VST
A.4.1.1 BST
The BST general structure, as is transmitted to the OBU, is described in Table A.2.
Table A.2 — BST general structure
Length Allowed values
“1 000” indicating
T-APDUs 4 bit
initialization-request (BST)
1 bit (nonmandApplications
Option Indicator 0/1
opt.)
manufacturerid 16 bits See ISO 14816
rsu
as specified by
individualid 27 bits
manufacturer
Time 32 bits UNIX real time
1 bit (Profile ext.) 0 (= no extension)
See profile in
profile
7 bits EN 12834:2003, Annex A
and EN 13372:2004, 6.3.2.
1 bit (mandApplications ext.) 0 ( = no extension)
7 bits (number of M
applications)
LAC 1 bit (eid opt.) 0 (= eid not present)
Application
1 bit (parameter opt.) 0 (= parameter not present)
1 bit (aid ext.) 0 (= no extension)
aid
5 bits 21 (= LAC application)
Application 2 1 bit (eid opt.) 0/1
(not LAC)
1 bit (parameter opt.) 0/1
1 bit (aid ext.) 0 (= no extension)
aid
5 bits any (≠ LAC application)
1 bit (eid ext.) 0 (= no extension)
eid
Mand
7 bits any
Applications
See
parameter ApplicationContextMark
in EN 12834:2003, Annex A
… … …
1 bit (eid opt.) 0/1
1 bit (parameter opt.) 0/1
1 bit (aid ext.) 0 (= no extension)
aid
5 bits any (≠ LAC application)
1 bit (eid ext.) 0 (= no extension)
eid
7 bits any
See
parameter ApplicationContextMark
in EN 12834:2003, Annex A
8 © ISO 2016 – All rights reserved

ISO 13140-1:2016(E)
Table A.2 (continued)
Length Allowed values
1 bit (mandApplications ext.) 0 (= no extension)
7 bits (number of N
applications)
nonmand Application 1 See “Application 2 (not EFC)” of mandApplications
Applications (not EFC)
... ...
Application N See “Application 2 (not EFC)” of mandApplications
(not EFC)
1 bit (profileList ext.) 0 (= no extension)
7 bits (number of profiles) K
Profile 1 1 bit (Profile ext.) 0 (= no extension)
7 bits See profile in
EN 12834:2003, Annex A
and EN 13372:2004, 6.3.2.
... ... ...
Profile K 1 bit (Profile ext.) 0 (= no extension)
7 bits See profile in
EN 12834:2003, Annex A
and EN 13372:2004, 6.3.2.
A.4.1.2 VST
The VST general structure, as is transmitted by the OBU, is described in Table A.3.
Table A.3 — VST general structure (security level 1)
Length Allowed value
fill 4 bits any
1 bit (Profile ext.) 0 (= no extension)
profile
See Profile in EN 12834:2003,
7 bits
Annex A
1 bit (applications ext.) 0 (= no extension)

7 bits (number of applic.) M
1 bit (eid opt.) 1 (= eid present)

1 bit (parameter opt.) 1 (= parameter present)
1 bit (aid ext.) 0 (= no extension)
aid
5 bits 21 (= LAC application)
1 bit (eid ext.) 0 (= no extension)
eid
7 bits any (≠ other eid used in this VST)
1 bit (Container ext.) 0 (= no extension)

7 bits (Container CHOICE) 2 (= OCTET STRING)
1 bit (octet string ext.) 0 (= no extension)

7 bits (octet string length) 16
ISO 13140-1:2016(E)
Table A.3 (continued)
Length Allowed value
10 bits (CountryCode) See ISO 3166-1
contract
Provider
14 bits (IssuerIdentifier) See ISO 14816
LAC- typeOf
16 bits any
LAC
ContextMark Contract
Application
1 bit (contextVersion ext.) 0 (= no extension)
context
Version
7 bits any
para
meter
1 bit (Container ext.) 0 (= no extension)
7 bits (Container CHOICE) 2 (= OCTET STRING)

1 bit (octet string ext.) 0 (= no extension)
7 bits (octet string length) 2
applications
AC_Master
8 bits any
KeyRef
AC_CR-
Reference
AC_CR-
8 bits any
Diversifier
1 bit (Container ext.) 0 (= no extension)
7 bits (Container CHOICE) 2 (= OCTET STRING)

1 bit (octet string ext.) 0 (= no extension)
7 bits (octet string length) 4

RndOBE 32 bits any
1 bit (eid opt.) 0/1
1 bit (parameter opt.) 0/1
1 bit (aid ext.) 0 (= no extension)
aid
See DSRCApplicationEntityID,
5 bits
Application 2 EN 12834:2003, Annex A
1 bit (eid ext.) 0 (= no extension)
eid
7 bits any (≠ other eid used in this VST)
See ApplicationContextMark,
parameter
EN 12834:2003, Annex A
… 1 bit (eid opt.) 0/1
1 bit (parameter opt.) 0/1
1 bit (aid ext.) 0 (= no extension)
aid
See DSRCApplicationEntityID,
5 bits
EN 12834:2003, Annex A
Application M
1 bit (eid ext.) 0 (= no extension)
eid
7 bits any (≠ other eid used in this VST)

See ApplicationContextMark,
parameter
EN 12834:2003, Annex A
1 bit (obeStatus opt.) 0/1
obe
Configuration
equipmentClass 15 bits any
manufacturerId 16 bits any
obeStatus 16 bits any
A.4.2 PDUs parameters
A.4.2.1 Parameters of request PDUs
Tables A.4 and A.5 describe the valid format of the request APDUs. No other request commands are
used by LAC application.
Fill bits shall always be set to zero.
10 © ISO 2016 – All rights reserved

ISO 13140-1:2016(E)
Table A.4 — SET-Rq parameters (security level 1)
EN 12834:2003, Annex A ISO 14906:2011/ EN 15509:2014, C.4.5.5,
Amd 1:2015, Annex A Table C.16 and
ISO/TS 13141:
fill =
mode =
eid =
SET-Rq =
accessCredentials OPTIONAL mandatory
attrList =
iid OPTIONAL prohibited
Table A.5 — EVENT-REPORT-Rq parameters
EN 12834:2003, Annex A ISO 14906:2011/ EN 15509:2014,
Amd 1:2015, Annex A C.4.5.5, Table C.16
and ISO/TS 13141
mode false
eid 0
EVENT-REPORT-Rq =
eventType 0 (release)
accessCredentials OPTIONAL prohibited
eventParameters OPTIONAL prohibited
iid OPTIONAL prohibited
A.4.2.2 Parameters of response PDUs
Table A.6 describes the valid format of the response APDUs. No other response APDUs are used by LAC
application.
Fill bits shall always be set to zero.
Table A.6 — SET-Rs parameters (security level 1)
EN 12834:2003, Annex A ISO 14906:2011/ EN 15509:2014, C.4.5.5,
Amd 1:2015, Annex A Table C.16
fill =
eid =
SET-Rs =
iid OPTIONAL prohibited
ret OPTIONAL mandatory
A.4.3 Application I-kernel test purposes for On-Board Unit, security level 1
These Test Purposes apply to the security level 1 as claimed in ISO 13141:2015, Table B.6, Item 1 and to
initialization and termination as claimed in ISO 13141:2015, Table B.6, Items 1 and 5.
A.4.3.1 Data Structures
For the purpose of this conformance test, the following BSTs described in Tables A.7 and A.8 are
transmitted to the DUT. Invalid values are indicated in boldface.
ISO 13140-1:2016(E)
Table A.7 — BST1 (actual BST used, BV) valid BST
Length Value
Option Indicator 1 bit (nonmandApplications opt.) 0 (= nonmandApplications not
present)
RSU manufacturerid 16 bits registered value
individualid 27 bits any
Time 32 bits any
profile 1 bit (Profile ext.) 0 (= no extension)
7 bits 0
Mand 1 bit (mandApplications ext.) 0 (= no extension)
Applications
7 bits (number of applications) 1
LAC 1 bit (eid opt.) 0 (= eid not present)
Application
1 bit (parameter opt.) 0 (= parameter not present)
aid 1 bit (aid ext.) 0 (= no extension)
5 bits 21 (= LAC application)
profileList 1 bit (profileList ext.) 0 (= no extension)
7 bits (number of profiles) 0 (= list empty)
Table A.8 — BST2 (actual BST used, BI) invalid BST: extraneous parameter (LAC application
inserted as non mandatory application)
Length Value
Option Indicator 1 bit (nonmandApplications opt.) 1 (= nonmandApplications present)
RSU manufacturerid 16 bits registered value
individualid 27 bits any
Time 32 bits any
profile 1 bit (Profile ext.) 0 (= no extension)
7 bits 0
Mand 1 bit (mandApplications ext.) 0 (= no extension)
Applications
7 bits (number of applications) 1
Application 1 bit (eid opt.) 1 (= eid present)
#1 (not LAC)
1 bit (parameter opt.) 0 (= parameter not present)
aid 1 bit (aid ext.) 0 (= no extension)
5 bits ≠ 21 (AID that is not supported
by the OBU)
eid 1 bit (eid ext.) 0 (= no extension)
7 bits any
nonmand 1 bit (nonmandApplications ext.) 0 (= no extension)
Applications
7 bits (number of applications) 1
LAC 1 bit (eid opt.) 0 (= eid not present)
Application
1 bit (parameter opt.) 0 (= parameter not present)
aid 1 bit (aid ext.) 0 (= no extension)
5 bits 21 (= LAC application)
profileList 1 bit (profileList ext.) 0 (= no extension)
7 bits (number of profiles) 0 (= list empty)
12 © ISO 2016 – All rights reserved

ISO 13140-1:2016(E)
A.4.3.2 BV test purposes
Test subgroup objective:
— to test the behaviour of the DUT in relation to:
— valid BST;
— valid EVENT-REPORT-Rq (Release);
— to test the DUT support of:
— BeaconId;
— Time;
— Profile;
— Applications;
— LID.
TP/AP-BAS/OBU/BV/01 Receive and manage INITIALIZATION.request (BST)
TP origin Identical to TP/AL-I/OBU/BV/01 in ETSI/TS 102 486-2-2-V1.2.1
(2008-10), 5.4.1
Reference ISO 13141:2015, 6.2.2
Initial condition See TP/AL-I/OBU/BV/01 in ETSI/TS 102 486-2-2-V1.2.1 (2008-10),
5.4.1
Stimulus and expected behaviour
See TP/AL-I/OBU/BV/01 in ETSI/TS 102 486-2-2-V1.2.1 (2008-10), 5.4.1.
TP/AP-BAS/OBU/BV/02 Receive and manage EVENTREPORT request (RELEASE) with
mode = 0
TP origin Identical to TP/AL-I/OBU/BV/02 in ETSI/TS 102 486-2-2-V1.2.1
(2008-10), 5.4.1
Reference ISO 13141:2015, 6.2.4
Initial condition See TP/AL-I/OBU/BV/02 in ETSI/TS 102 486-2-2-V1.2.1
(2008-10), 5.4.1
Stimulus and expected behaviour
See TP/AL-I/OBU/BV/02 in ETSI/TS 102 486-2-2-V1.2.1 (2008-10), 5.4.1.
TP/AP-BAS/OBU/BV/03 Read and manage the BeaconID in the BST
TP origin Identical to TP/AL-I/OBU/BV/03 in ETSI/TS 102 486-2-2-V1.2.1
(2008-10), 5.4.1
Reference ISO 13141:2015, 6.2.2
Initial condition Identical to TP/AL-I/OBU/BV/03 in ETSI/TS 102 486-2-2-V1.2.1
(2008-10), 5.4.1
Stimulus and expected behaviour
See TP/AL-I/OBU/BV/03 in ETSI/TS 102 486-2-2-V1.2.1 (2008-10), 5.4.1.
ISO 13140-1:2016(E)
TP/AP-BAS/OBU/BV/04 Read and manage time of reception of BST in parameter time in
BST
TP origin Identical to TP/AL-I/OBU/BV/04 in ETSI/TS 102 486-2-2-V1.2.1
(2008-10), 5.4.1
Reference ISO 13141:2015, 6.2.2
Initial condition Identical to TP/AL-I/OBU/BV/04 in ETSI/TS 102 486-2-2-V1.2.1
(2008-10), 5.4.1
Stimulus and expected behaviour
See TP/AL-I/OBU/BV/04 in ETSI/TS 102 486-2-2-V1.2.1 (2008-10), 5.4.1.
NOTE Test purposes with ID TP/AP-BAS/OBU/BV/04 to TP/AP-BAS/OBU/BV/08 have not been used in order
to be in line with the numbering in ETSI/TS 102 486-2-2-V1.2.1.
TP/AP-BAS/OBU/BV/09 Manage profile selection
TP origin Identical to TP/AL-I/OBU/BV/09 in ETSI/TS 102 486-2-2-V1.2.1
(2008-10), 5.4.1
Reference ISO 13141:2015, 6.2.2
Initial condition See TP/AL-I/OBU/BV/09 in ETSI/TS 102 486-2-2-V1.2.1 (2008-10), 5.4.1
Stimulus and expected behaviour
See TP/AL-I/OBU/BV/09 in ETSI/TS 102 486-2-2-V1.2.1 (2008-10), 5.4.1.
TP/AP-BAS/OBU/BV/10 Verify that the DUT replies to a BST with a VST
TP origin Specific
Reference ISO 13141:2015, 6.2.2
Initial condition DUT not in sleep mode and not yet initialized
Stimulus and expected behaviour
Tester DUT
1 BST1 ⇒
2 ⇐ VST
3 Verify length and allowed values of VST
(see Table A.3 )
4 IF verification performed in step 3 was not
successful, THEN TP failed
A.4.3.3 BI test purposes
Test subgroup objective:
— to check the behaviour of the DUT in response to invalid messages.
TP/AP-BAS/OBU/BI/01 Manage profile selection
TP origin Identical to TP/AL-I/OBU/BI/01 in ETSI/TS 102 486-2-2-V1.2.1
(2008-10), 5.4.2
Reference ISO 13141:2015, 6.2.2
14 © ISO 2016 – All rights reserved

ISO 13140-1:2016(E)
Initial condition See TP/AL-I/OBU/BI/01 in ETSI/TS 102 486-2-2-V1.2.1 (2008-10), 5.4.2
Stimulus and expected behaviour
See TP/AL-I/OBU/BI/01 in ETSI/TS 102 486-2-2-V1.2.1 (2008-10), 5.4.2.
TP/AP-BAS/OBU/BI/02 Manage applications
TP origin Identical to TP/AL-I/OBU/BI/02 in ETSI/TS 102 486-2-2-V1.2.1
(2008-10), 5.4.2
Reference ISO 13141:2015, 6.2.2
Initial condition See TP/AL-I/OBU/BI/02 in ETSI/TS 102 486-2-2-V1.2.1 (2008-10), 5.4.2
Stimulus and expected behaviour
See TP/AL-I/OBU/BI/02 in ETSI/TS 102 486-2-2-V1.2.1 (2008-10), 5.4.2.
TP/AP-BAS/OBU/BI/03 Verify that the DUT handles BST with LAC application marked as
non-mandatory application
TP origin Specific
Reference ISO 13141:2015, 6.2.2
Initial condition DUT not in sleep mode and not yet initialized
Stimulus and expected behaviour
Tester DUT
1 BST2 ⇒
3 Verify that DUT does not initialize with
INITIALIZATION-response (VST).
4 IF verification performed in step 3 was not
successful, THEN TP failed
A.4.4 Application T-kernel test purposes for On-Board Unit
These Test Purposes apply to the layer 7 functions related to T-kernel as claimed in ISO 13141:2015,
Table B.7, Items 1, 2 and 5.
A.4.4.1 BV test purposes
Test subgroup objective:
— to test the behaviour of the DUT in relation to syntactically and contextual correct behaviour of the
test system.
TP/AP-FUN/OBU/BV/02 Receive SET.request and manage SET.response with LID = private
TP origin Identical to TP/AL-T/OBU/BV/02 in ETSI/TS 102 486-2-2-V1.2.1
(2008-10), 5.2.1
Reference ISO 13141:2015, 6.2.3
Initial condition See TP/AL-T/OBU/BV/02 in ETSI/TS 102 486-2-2-V1.2.1 (2008-10), 5.2.1
Stimulus and expected behaviour
See TP/AL-T/OBU/BV/02 in ETSI/TS 102 486-2-2-V1.2.1 (2008-10), 5.2.1.
NOTE: Request with accessCredentials.
ISO 13140-1:2016(E)
TP/AP-FUN/OBU/BV/13 Receive and manage non-fragmented APDUs with random PDU
number
TP origin Identical to TP/AL-T/OBU/BV/13 in ETSI/TS 102 486-2-2-V1.2.1
(2008-10), 5.2.1
Reference ISO 13141:2015, 6.2.3
Initial condition See TP/AL-T/OBU/BV/13 in ETSI/TS 102 486-2-2-V1.2.1 (2008-10), 5.2.1
Stimulus and expected behaviour
See TP/AL-T/OBU/BV/13 in ETSI/TS 102 486-2-2-V1.2.1 (2008-10), 5.2.1.
NOTE: Request with accessCredentials for SET. Test case applicable only for SET.
TP/AP-FUN/OBU/BV/14 Receive and manage multiplexed APDUs from two different
applications
TP origin Identical to TP/AL-T/OBU/BV/14 in ETSI/TS 102 486-2-2-V1.2.1
(2008-10), 5.2.1
Reference ISO 13141:2015, 6.2.3
Initial condition See TP/AL-T/OBU/BV/14 in ETSI/TS 102 486-2-2-V1.2.1 (2008-10), 5.2.1
Stimulus and expected behaviour
See TP/AL-T/OBU/BV/14 in ETSI/TS 102 486-2-2-V1.2.1 (2008-10), 5.2.1.
NOTE: Request with accessCredentials for SET. Test case applicable only for SET.
TP/AP-FUN/OBU/BV/16 Receive and manage concatenated and chained APDUs from a
single application
TP origin Identical to TP/AL-T/OBU/BV/16 in ETSI/TS 102 486-2-2-V1.2.1
(2008-10), 5.2.1
Reference ISO 13141:2015, 6.2.3
Initial condition See TP/AL-T/OBU/BV/16 in ETSI/TS 102 486-2-2-V1.2.1 (2008-10), 5.2.1
Stimulus and expected behaviour
See TP/AL-T/OBU/BV/16 in ETSI/TS 102 486-2-2-V1.2.1 (2008-10), 5.2.1.
NOTE: Request with accessCredentials for SET. Test case applicable only for SET.
TP/AP-FUN/OBU/BV/18 Support of DSRC L7 SET
TP origin Identical to TC04-A in ISO/TS 14907-2:2016, C.2.4
Reference ISO 13141:2015, 6.2.3
Initial condition See TC04-A in ISO/TS 14907-2:2016, C.2.4
Stimulus and expected behaviour
See TC04-A in ISO/TS 14907-2:2016, C.2.4.
NOTE: Request with accessCredentials.
A.4.4.2 BI test purposes
Test subgroup objective:
— to check the behaviour of the of the DUT in response to invalid stimuli and behaviour from the
test tool.
16 © ISO 2016 – All rights reserved

ISO 13140-1:2016(E)
TP/AP-FUN/OBU/BI/02 Receive and manage PDUs to broadcast kernel with awake but not
yet initialized OBU
TP origin Identical to TP/AL-T/OBU/BI/02 in ETSI/TS 102 486-2-2-V1.
...
