(Main)Mechanical properties of fasteners made of carbon steel and alloy steel - Part 2: Nuts with specified property classes - Coarse thread and fine pitch thread (ISO 898-2:2012)
Mechanical properties of fasteners made of carbon steel and alloy steel - Part 2: Nuts with specified property classes - Coarse thread and fine pitch thread (ISO 898-2:2012)
This part of ISO 898 specifies mechanical and physical properties of nuts with coarse thread and fine pitch
thread made of carbon steel and alloy steel when tested at an ambient temperature range of 10 °C to 35 °C.
Nuts conforming to the requirements of this part of ISO 898 are evaluated at that ambient temperature range.
It is possible that they do not retain the specified mechanical and physical properties at elevated and/or lower
temperatures.
NOTE 1 Nuts conforming to the requirements of this part of ISO 898 have been used in applications
ranging from ?50 °C to +150 °C. It is the responsibility of users to consult an experienced fastener materials expert
for temperatures outside the range of ?50 °C to +150 °C and up to a maximum temperature of +300°C to determine
appropriate choices for a given application.
NOTE 2 Information for the selection and application of steels for use at lower and elevated temperatures is given for
instance in EN 10269, ASTM F2281 and in ASTM A320/A320M.
This part of ISO 898 is applicable to nuts:
a) made of carbon steel or alloy steel;
b) with coarse thread M5 ≤ D ≤ M39, and fine pitch thread M8×1 ≤ D ≤ M39×3;
c) with triangular ISO metric thread according to ISO 68-1;
d) with diameter/pitch combinations according to ISO 261 and ISO 262;
e) with specified property classes, including proof load;
f) with different nut styles: thin nuts, regular nuts and high nuts;
g) with minimum height m ≥ 0,45D;
h) with a minimum outside diameter or width across flats s ≥ 1,45D (see Annex A);
i) able to mate with bolts, screws and studs with property classes according to ISO 898-1.
For hot dip galvanized nuts, see ISO 10684.
This part of ISO 898 does not specify requirements for properties such as:
— prevailing torque properties (see ISO 2320);
— torque/clamp force properties (see ISO 16047 for test method);
— weldability;
— corrosion resistance.
Mechanische Eigenschaften von Verbindungselementen aus Kohlenstoffstahl und legiertem Stahl - Teil 2: Muttern mit festgelegten Festigkeitsklassen - Regelgewinde und Feingewinde (ISO 898-2:2012)
Dieser Teil von ISO 898 legt mechanische und physikalische Eigenschaften von Muttern aus Kohlenstoffstahl
und legiertem Stahl mit Regelgewinde und Feingewinde fest, die in einem Bereich der Umgebungstemperatur
von 10 °C bis 35 °C geprüft werden.
Muttern, die den Anforderungen dieses Teils von ISO 898 entsprechen, werden in diesem Bereich der
Umgebungstemperatur bewertet. Es kann sein, dass sie die festgelegten mechanischen und physikalischen
Eigenschaften bei höheren Temperaturen und/oder niedrigeren Temperaturen nicht beibehalten.
ANMERKUNG 1 Muttern, die den Anforderungen dieses Teils von ISO 898 entsprechen, werden für Anwendungen im
Bereich von −50 °C bis +150 °C eingesetzt. Anwender sollten für Temperaturen außerhalb des Bereiches von −50 °C und
+150 °C sowie bis zu einer Höchsttemperatur von +300 °C einen erfahrenen Metallurgen für Verbindungselemente konsultieren,
um die geeignete Wahl für die vorgesehene Anwendung zu treffen.
ANMERKUNG 2 Informationen zur Auswahl und Anwendung von Stählen für den Einsatz bei niedrigeren und höheren
Temperaturen sind z. B. in EN 10269, ASTM F2281 und ASTM A320/A320M enthalten.
Dieser Teil von ISO 898 ist anwendbar für Muttern:
a) aus Kohlenstoffstahl oder legiertem Stahl;
b) mit Regelgewinde M5 ≤ D ≤ M39 und Feingewinde M8×1 ≤ D ≤ M39×3;
c) mit metrischem ISO-Gewinde nach ISO 68-1;
d) mit Durchmesser-Steigungskombinationen nach ISO 261 und ISO 262;
e) mit festgelegten Festigkeitsklassen einschließlich Prüfkraft;
f) unterschiedlicher Muttertypen: flache Muttern, normale Muttern und hohe Muttern;
g) mit einer Mindesthöhe m ≥ 0,45D;
h) mit einem Mindestaußendurchmesser oder einer Mindestschlüsselweite s ≥ 1,45D (siehe Anhang A);
i) die zu Schrauben mit Festigkeitsklassen nach ISO 898-1 passen.
Zu feuerverzinkten Muttern siehe ISO 10684.
Dieser Teil von ISO 898 legt keine Anforderungen für Eigenschaften fest wie:
Sicherungseigenschaften (siehe ISO 2320);
Drehmoment/Vorspannkraft (siehe ISO 16047 für entsprechende Prüfverfahren);
Schweißbarkeit;
Korrosionsbeständigkeit.
Caractéristiques mécaniques des éléments de fixation en acier au carbone et en acier allié - Partie 2: Écrous de classes de qualité spécifiées - Filetages à pas gros et filetages à pas fin (ISO 898-2:2012)
La présente partie de l'ISO 898 spécifie les caractéristiques mécaniques et physiques des écrous à filetages
à pas gros et filetages à pas fin, en acier au carbone et en acier allié, lorsqu'ils sont soumis à essai dans une
plage de températures ambiantes de 10 °C à 35 °C.
Les écrous satisfaisant aux exigences de la présente partie de l'ISO 898 sont évalués dans cette plage de
températures ambiantes. Il se peut qu'ils ne conservent pas les caractéristiques mécaniques et physiques
spécifiées à des températures plus élevées et/ou plus basses.
NOTE 1 Les écrous satisfaisant aux exigences de la présente partie de l'ISO 898 ont été utilisés pour des applications
entre −50 °C et +150 °C. Il est de la responsabilité des utilisateurs de consulter un expert en matériaux de fixation pour les
températures situées hors de la plage allant de −50 °C à +150 °C et jusqu'à une température maximale de +300 °C afin de
déterminer les choix appropriés pour une application donnée.
NOTE 2 Des informations sur la sélection et l'application des aciers pour une utilisation à basses et hautes températures
sont données par exemple dans l'EN 10269, l'ASTM F2281 et l'ASTM A320/A320M.
La présente partie de l'ISO 898 s'applique aux écrous:
a) fabriqués en acier au carbone ou en acier allié;
b) à filetage à pas gros M5 ≤ D ≤ M39, et à filetage à pas fin M8×1 ≤ D ≤ M39×3;
c) à filetage métrique ISO triangulaire conforme à l'ISO 68‑1;
d) à combinaisons diamètre/pas conformes à l'ISO 261 et ISO 262;
e) de classes de qualité spécifiées, comprenant la charge d'épreuve;
f) de différents styles: écrous bas, écrous normaux et écrous hauts;
g) de hauteur minimale m ≥ 0,45D;
h) de diamètre extérieur ou de dimensions des surplats minimum s ≥ 1,45D (voir aussi Annexe A);
i) conçus pour être utilisés avec des vis, goujons et tiges filetées de classes de qualité conformes à l'ISO 898‑1.
Pour les écrous galvanisés à chaud, voir l'ISO 10684.
La présente partie de l'ISO 898 ne spécifie pas d'exigence pour les caractéristiques telles que:
— l'autofreinage (voir l'ISO 2320);
— la relation couple/tension (voir l'ISO 16047 pour la méthode d'essai);
— la soudabilité;
— la résistance à la corrosion.
Mehanske lastnosti veznih elementov, narejenih iz ogljikovega jekla in jeklene zlitine - 2. del: Matice z določenimi razredi trdnosti - Grobi in fini navoj (ISO 898-2:2012)
Ta del standarda ISO 898 določa mehanske in fizikalne lastnosti matic z grobim in finim navojem, izdelanih iz ogljikovega jekla ter jeklene zlitine, kadar se preskušajo pri temperaturi okolja od 10 °C do 35 °C. Matice, ki izpolnjujejo zahteve iz tega dela standarda ISO 898, se ovrednotijo pri tem temperaturnem razponu okolja. Možno je, da matice pri višjih in/ali nižjih temperaturah ne ohranijo določenih mehanskih in fizikalnih lastnosti.
