Fasteners - Hexagon thin nuts (style 0) (ISO 4035:2023)

Fasteners - Hexagon thin nuts (style 0) (ISO 4035:2023)

This document specifies the characteristics of hexagon thin nuts (style 0), in steel and stainless steel, with metric coarse pitch thread M1,6 to M64, and with product grades A and B.
Thin nuts used as jam nuts are to be assembled together with a regular or high nut.
WARNING — Thin nuts (style 0) have a reduced loadability compared to regular nuts or high nuts, and are not designed to provide resistance to thread stripping (see ISO 898-2).
If in certain cases other specifications are requested, stainless steel grades and property classes can be selected from ISO 3506-2.

Verbindungselemente - Niedrige Sechskantmuttern (Typ 0) (ISO 4035:2023)

Dieses Dokument legt die Eigenschaften von niedrigen Sechskantmuttern (Typ 0) aus Stahl und nichtrostendem Stahl mit metrischen Regelgewinden M1,6 bis M64 und mit Produktklassen A und B fest.
Niedrige Muttern, die als Kontermuttern eingesetzt werden, sind zusammen mit einer normalen oder hohen Mutter zu montieren.
WARNUNG — Niedrige Muttern (Typ 0) haben im Vergleich zu normalen oder hohen Muttern eine reduzierte Belastbarkeit und sind nicht dafür ausgelegt, dem Abstreifen des Gewindes standzuhalten (siehe ISO 898 2).
Falls in bestimmten Fällen andere Festlegungen benötigt werden, können Stahlsorten nichtrostender Stähle und Festigkeitsklassen aus ISO 3506 2 entnommen werden.

Fixations - Écrous bas hexagonaux (style 0) (ISO 4035:2023)

Le présent document spécifie les caractéristiques des écrous bas hexagonaux (style 0), en acier et en acier inoxydable, à filetage métrique à pas gros M1,6 à M64, et de grades A et B.
Les écrous bas utilisés comme contre-écrou sont à assembler avec un écrou normal ou un écrou haut.
AVERTISSEMENT          Les écrous bas (style 0) ont une capacité de charge réduite par rapport aux écrous normaux ou hauts, et ne sont pas conçus pour fournir une résistance à l’arrachement des filets (voir ISO 898-2).
Si dans certains cas d’autres spécifications sont requises, les grades d’acier inoxydable et les classes de qualité peuvent être choisis dans l'ISO 3506-2.

Vezni elementi - Šestrobe nizke matice (tip 0) (ISO 4035:2023)

Ta dokument določa značilnosti šestrobih nizkih matic (tip 0) iz jekla in nerjavnega jekla, z grobim metrskim navojem velikosti od M1,6 do M64 ter razredoma izdelave A in B.
Nizke matice, ki se uporabljajo kot tesnilne matice, je treba sestaviti skupaj z običajno ali visoko matico.
OPOZORILO: Nizke matice (tip 0) imajo manjšo obremenljivost v primerjavi z običajnimi maticami ali visokimi maticami in niso zasnovane tako, da zagotavljajo odpornost proti pobiranju navojev (glej ISO 898-2).
Če se v določenih primerih zahtevajo druge specifikacije, je tipe nerjavnega jekla in razrede lastnosti mogoče izbrati v skladu s standardom ISO 3506-2.
