ASTM F1364-03(2022)

This international standard was developed in accordance with internationally recognized principles on standardization established in the Decision on Principles for the
Development of International Standards, Guides and Recommendations issued by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
Designation: F1364 − 03 (Reapproved 2022)
Standard Practice for
Use of a Calibration Device to Demonstrate the Inspection
Capability of an Interferometric Laser Imaging
Nondestructive Tire Inspection System
This standard is issued under the fixed designation F1364; the number immediately following the designation indicates the year of
original adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A
superscript epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope 3. Terminology
1.1 This practice describes the construction and use of a 3.1 Definitions:
calibration device for demonstrating the anomaly detection
3.1.1 analysis, n—an act of inspecting the S/H image and
capability of interferometric laser imaging nondestructive tire
associating this image with a known calibration reference.
inspection system.Acommon practice within the industry is to
F538
refer to these systems as shearographic/holographic (S/H)
3.1.2 shearogram/hologram, n—the common term for an
systems.
interferometric image provided by S/H systems. F538
1.2 This standard practice applies to S/H systems that are
3.1.3 shearographic or holographic (S/H) systems, n—a
used for evaluating the structural integrity of pneumatic tires,
shearographic or holographic system using interferometric
(forexample,presenceorabsenceofanomalieswithinthetire).
laser imaging to nondestructively inspect tires. F538
1.3 This standard does not purport to address all of the
3.1.4 straining block, n—a test block containing a number
safety concerns, if any, associated with its use. It is the
of anomalies, that is capable of simulating an anomaly in a tire.
responsibility of the user of this standard to establish appro-
F538
priate safety, health, and environmental practices and deter-
3.1.5 straining block anomoly, n—a change in the strain
mine the applicability of regulatory limitations prior to use.
patternofthedeformablesurfaceofastrainingblockasaresult
1.4 This international standard was developed in accor-
of applied stress brought about through a change in atmo-
dance with internationally recognized principles on standard-
spheric pressure on the deformable surface.
ization established in the Decision on Principles for the
3.1.5.1 Discussion—A distinction is made between an
Development of International Standards, Guides and Recom-
anomaly in the straining block and an anomaly in the a tire.
mendations issued by the World Trade Organization Technical
F538
Barriers to Trade (TBT) Committee.
3.1.6 straining block holding fixture, n—a device for hold-
2. Referenced Documents
ing one or more straining blocks in the S/H system during the
inspection process (see Fig. 1). F538
2.1 ASTM Standards:
F538 Terminology Relating to Characteristics and Perfor-
4. Summary of Practice
mance of Tires
4.1 The straining block is designed to create an image of a
2.2 ASTM Adjuncts:
Straining Block Drawings known anomaly against which the performance of the S/H
system may be evaluated. The block is constructed by securing
a flexible membrane over a rigid block that contains a series of
holes of various sizes and shapes. The membrane should be
This practice is under the jurisdiction ofASTM Committee F09 on Tires and is
made of a material that retains its physical properties over time
the direct responsibility of Subcommittee F09.10 on Equipment, Facilities and
Calibration.
with minimal aging effects. The interior holes in the block are
Current edition approved Oct. 1, 2022. Published November 2022. Originally
either vented to atmospheric pressure or sealed at a nominal
approved in 1992. Last previous edition approved in 2015 as F1364 – 03 (2015).
pressure, allowing a differential pressure to exist on the
DOI: 10.1520/F1364-03R22.
membrane when the block is subjected to a vacuum. It is the
For referenced ASTM standards, visit the ASTM website, www.astm.org, or
contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM
deflection of the surface under this differential pressure that is
Standards volume information, refer to the standard’s Document Summary page on
measured by the S/H system.The thickness of material must be
the ASTM website.
selected to give deflections that are representative of those
Available from ASTM International Headquarters. Order Adjunct No.
ADJF1364. Original adjunct produced in 1992. associated with anomalies found in a tire.
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
F1364 − 03 (2022)
5. Significance and Use
5.1 All S/H systems change with time and use. Therefore, a
calibration procedure for evaluating the operation of an S/H
system is desirable. This calibration procedure provides a
method of obtaining an optimized interferometric image pat-
tern associated with a given size anomaly.
5.2 The use of straining blocks as calibration devices
provides a means for ensuring the continued optimal perfor-
mance of the S/H system. Straining blocks can also be used to
compare performance of S/H systems in different facilities.
5.3 At not greater than a three (3) month interval the S/H
system shall be calibrated following the procedures described
FIG. 1 Straining
...
