ASTM G62-23

This document is not an ASTM standard and is intended only to provide the user of an ASTM standard an indication of what changes have been made to the previous version. Because
it may not be technically possible to adequately depict all changes accurately, ASTM recommends that users consult prior editions as appropriate. In all cases only the current version
of the standard as published by ASTM is to be considered the official document.
Designation: G62 − 22 G62 − 23
Standard Test Methods for
Holiday Detection in Pipeline Coatingsof Coatings used to
Protect Pipelines
This standard is issued under the fixed designation G62; the number immediately following the designation indicates the year of original
adoption or, in the case of revision, the year of last revision. A number in parentheses indicates the year of last reapproval. A superscript
epsilon (´) indicates an editorial change since the last revision or reapproval.
1. Scope
1.1 These test methods cover the apparatus and procedureprocedures for detecting holidays in pipeline type coatings.pinholes and
holidays in coatings used to protect pipelines.
1.2 Method A is designed to detect holidays such as pinholes and voidsholidays in thin-film coatings from 0.0250.025 mm to 0.254
mm (1 to 10 mils) (1 mils to 10 mils) in thickness using ordinary tap water and an applied voltage of less than 100 V d-c. It is
effective on films up to 0.508 mm (20 mils) 0.508 mm (20 mils) thickness if a wetting agent is used with the water. It should be
noted, however, that this method will not detect thin spots in the coating. This may be considered to be a nondestructive test
because of the relatively low voltage.
1.3 Method B is designed to detect holidays such as pinholes and voids in pipeline coatings; but because of the higher applied
voltages, it can also be used to detect thin spots in the coating. holidays in thick-film coatings >0.508 mm (20 mils) This method
can be used on any thickness of pipeline coating and utilizes applied voltages between 900 and 20 000 V 3.4 and 35 kV d-c. This
method is considered destructive because the high voltages involved generally destroy the coating at thin spots.
1.4 The values stated in SI units to three significant decimals are to be regarded as the standard. The values given in parentheses
are for information only.
1.5 This standard does not purport to address all of the safety concerns, if any, associated with its use. It is the responsibility
of the user of this standard to establish appropriate safety, health, and environmental practices and determine the applicability of
regulatory limitations prior to use.
1.6 This international standard was developed in accordance with internationally recognized principles on standardization
established in the Decision on Principles for the Development of International Standards, Guides and Recommendations issued
by the World Trade Organization Technical Barriers to Trade (TBT) Committee.
2. Referenced Documents
2.1 ASTM Standards:
A742/A742M Specification for Steel Sheet, Metallic Coated and Polymer Precoated for Corrugated Steel Pipe
D149 Test Method for Dielectric Breakdown Voltage and Dielectric Strength of Solid Electrical Insulating Materials at
Commercial Power Frequencies
These test methods are under the jurisdiction of ASTM Committee D01 on Paint and Related Coatings, Materials, and Applications and are the direct responsibility of
Subcommittee D01.48 on Durability of Pipeline Coating and Linings.
Current edition approved Aug. 15, 2022Oct. 1, 2023. Published August 2022October 2023. Originally approved in 1979. Last previous edition approved in 20142022 as
G62 – 14.G62 – 22. DOI: 10.1520/G0062-22.10.1520/G0062-23.
For referenced ASTM standards, visit the ASTM website, www.astm.org, or contact ASTM Customer Service at service@astm.org. For Annual Book of ASTM Standards
volume information, refer to the standard’s Document Summary page on the ASTM website.
Copyright © ASTM International, 100 Barr Harbor Drive, PO Box C700, West Conshohocken, PA 19428-2959. United States
G62 − 23
D7091 Practice for Nondestructive Measurement of Dry Film Thickness of Nonmagnetic Coatings Applied to Ferrous Metals
and Nonmagnetic, Nonconductive Coatings Applied to Non-Ferrous Metals
3. Terminology
3.1 Definitions:
3.1.1 holiday, n—small faults or pinholes that permit current drainage through protective coatings on steel pipe or polymeric
precoated corrugated steel pipe.an interruption in the normal physical structure or configuration of a coating such as cracks, laps,
seams, inclusions, porosity, discontinuities, or areas of low coating thickness.
3.1.2 mil, n—0.001 in.
3.2 Definitions of Terms Specific to This Standard:
3.2.1 dielectric strength, n—the maximum voltage an insulating material can withstand without undergoing electrical breakdown.
It is typically tested in accordance with Test Method D149.
3.2.2 electrical breakdown, n—a process that occurs when an insulating material, subjected to high enough voltage, suddenly
becomes an electrical conductor and electrical current flows through it.
3.2.3 electrode, n—a conductive surface that is charged by the Holiday Detector and placed against the coating to be tested.
Common electrode configurations include sponges for low voltage detectors and brushes and springs for high voltage detectors.
3.2.4 high voltage voltmeter, n—a device capable of measuring the voltage between the electrode and the ground connection of
a High Voltage Holiday Detector. When used with a Pulse DC High Voltage Holiday Detector, the High Voltage Voltmeter shall
be a peak reading voltmeter.
3.2.5 holiday detector, n—a highly sensitive electrical device designed to locate holidays such as detect holidays, pinholes, voids,
and thin spots in the coating, not easily seen by the naked eye. These are used on the coatings of a coating having a relatively
high-electrical resistance when such coatings are applied to the surface of materials of low-electrical resistance, a surface of low
electrical resistance such as steel pipe.
3.2.2 pipeline type coating, n—coatings of relatively high-electrical resistance applied to surfaces of relatively low-electrical
resistance, such as steel pipe.
4. Summary of Test Methods
4.1 Both methods rely on electrical contact being made through thea pipeline coating because of a holiday or a low-resistance path
created by metal particles,particles or thin spots in the coating. This electrical contact will activate an alarm alerting the operator
of the incidence of a holiday.
4.2 In Method A, the applied voltage is 100 V d-c or less.
4.3 In Method B, the applied voltage is 900 to 20 000 V d-c.3.4 kV d-c to 35 kV d-c.
5. Significance and Use
5.1 Method A—Method A describes a quick, safe method for determining if pinholes, voids, or metal particles are protruding
through the coating. This method will not, however, find any thin spots in the coating. This method will determine the existence
of any gross faults in thin-film pipeline coatings.Low voltage holiday detection is used to locate holidays and pinholes in thin-film
coatings (up to 0.508 mm (20 mils) using a sponge wetted with tap water (and a wetting agent for coatings thicker than 10 mils).
The water carries the current from the electrode through the holiday to the conductive substrate. The detector is grounded to the
coated substrate. When the detector senses this flow of current it alarms.
5.2 Method B—Method B describes a method for determining if pinholes, voids, or metal particles are protruding through High
voltage holiday detection is used to locate holidays and pinholes in thick-film coatings (greater than 20 mils), but can be used on
G62 − 23
coatings as low as 10 mils thick. A test voltage is selected and set. A charged Electrode is placed in contact with the coating, and
thin spots in pipeline coatings. This method can be used to verify minimum coating thicknesses as well as voids in quality-control
applications.the Detector is grounded to the coated substrate. When Electrical Breakdown occurs, electric current flows between
the Detector’s electrode and the conductive substrate and emits an audible alarm.
5.3 This standard does not apply to holiday detection of tape wraps used to protect pipe or coatings containing conductive raw
materials such as conductive pigments and extenders.
5.4 The thickness of a coating applied to ductile iron pipe, fittings, or other iron castings may vary substantially due to the inherent
roughness of the substrate. For these applications, consult the coating manufacturer for their recommended test voltage setting
when using Method B. The coating manufacturer’s recommended test voltage setting may be subject to approval by the owner.
NOTE 1— Use of voltage settings lower than those listed in this standard may increase the likelihood of non-detection.
6. Apparatus
6.1 Low-Voltage Holiday Detector—A holiday detector tester test device having an electrical energy source of less than 100 V d-c,
such as a battery; an exploring electrode having equipped with a cellulose sponge dampened with an electrically conductive liquid
such as tap water; and an audio indicator to signal a defect in a high-electrical resistance coating on a metal substrate. A substrate;
and a ground wire connectsconnecting the detector with the low-resistance metal surface.
6.2 High-Voltage Holiday Detector—A holiday detector tester test device having an electrical energy source of 900 to 20 000 V
3.4 kV d-c to 35 kV d-c; an exploring electrode consisting of a wire brush, coil-spring, or conductive silicon electrode capable of
movingtraversing along the pipeline coating; and an audio indicator to signal a defect in a high-electrical resistance coating on a
metal substrate. A ground wire connects the detector with the low-resistance metal surface.
6.3 Peak or Crest Reading High Voltage Voltmeter—A kilovoltmeter capable of detecting a single pulse and holding it long enough
for the meter circuits to indicate.peak reading voltmeter capable of measuring the voltage difference between the electrode (or part
of the High Voltage Holiday Detector electrically continuous with, and at the same voltage as, the electrode), and the ground
connection.
7. Reagents and Materials
7.1 Tap Water, plain or with a wetting agent.
NOTE 2—Ordinary tap water will suffice to wet the sponge electrode when inspecting coatings up to 0.254 mm (10 mils) in thickness. On films between
0.2540.254 mm and 0.508 mm (10(10 mils and 20 mils), a nonsudsingnon-sudsing type wetting agent added to the water is recommended to allow for
faster penetration of the liquid into pinhole defects.pinholes.
8. Test Specimen
8.1 The test specimen shall be a representative length of production-coated pipe or polymeric precoated corrugated steel pipe.
9. Standardization of InstrumentsCalibration and Verification of Operation
9.1 The instruments shall be standardized with respect to voltage output in accordance with the manufacturer’s instructions, using
a peak or crest reading voltmeter. This is used more commonly with Method B where voltage may vary from test to test but can
also be used for verification of the voltage on a Method A test.
9.1 Method A—The low-voltage holiday detector shall be standardized Low-voltage holiday detectors shall be calibrated annually
by the equipment manufacturer, their authorized agent, or accredited calibration laboratory approved by the manufacturer and
verified for proper operation prior to each use with respect to sensitivity by having the alarm activated when a selected resistance,
having a ⁄2 W W rating, is placed across its terminals. A common factory setting for sensitivity is 100 000 Ω. MostMany units
can be reset to any predetermined sensitivity value in this manner.
9.2 Method B—High-Voltage Holiday Detectors.
G62 − 23
9.2.1 Calibration—High voltage detectors shall be calibrated annually by the equipment manufacturer, their authorized agent, or
accredited calibration laboratory approved by the manufacturer in a controlled environment using a documented process. A
Certificate of Calibration showing traceability to a National Metrological Institute shall be retained with the instrument.
9.2.2 Verification—Verification of the (a) output voltage and (b) overall function shall be performed before and after each period
of use, if the detector has been dropped, or if the electrode or coating thickness changes.
9.2.2.1 Two-point Verification of Output Voltage—Ensure that the detector is properly grounded, and that the electrode to be used
for testing is connected and in contact with the coating to be tested. Connect the ground connect from the High Voltage Voltmeter
to the ground connector of the detector. Turn the detector on, set the voltage based on the expected/measured low coating thickness,
and activate the voltage output. While the voltage output is activated, place the electrode of the High Voltage Voltmeter against
the detector’s electrode. The measured voltage on the High Voltage Voltmeter shall be within 10 % of the desired test voltage. If
required, adjust the test voltage setting on the detector and reverify. Repeat this procedure based on the expected/measured high
coating thickness.
NOTE 3— Some High Voltage Holiday Detectors contain an integrated High Voltage Voltmeter and means of adjusting the test voltage at the electrode
automatically, thereby performing the above steps automatically.
9.2.2.2 Functional Verification—Locate a known holiday in the coating, where a small area (less than 1 mm [40 mils] diameter)
of the substrate is exposed. Ensuring the Detector is properly grounded, place the electrode on the coating at least 25 mm (1 in.)
away from the known Holiday. Turn on the Detector, activate the voltage output, and sweep the electrode across the known defect
according to the procedure in Section 11. Ensure that the alarm activates when the electrode passes the known holiday.
10. Procedure for Method A
10.1 Use the low-voltage holiday detector conforming to that described in 6.1.
10.2 Assemble the wand and electrode according to the manufacturer’s instructions and attach the ground wire to the metal
surface.instructions.
10.3 Attach the electrode clamps to the end of the wand, dampen the Dampen the sponge electrode with tap water,water and place
it between the clamps. Then tighten the clamps with the screw until they are well down intoclamps at the end of the wand, then
tighten the clamps to secure the sponge electrode. Attach the ground wire (lead with battery clamp) and the wand to the terminals.
Clip the ground wire to some point where the metal surface is bare. Now To verify operation, touch the electrode to a second point
where the surface is bare and note that verify the audible signal will be activated. The detector is now ready to operate by passing
the damp sponge over the coated surface. When a holiday is picked up by the audible alarm, the electrode can be turned on end
and the exact spot of failure can be noted by searching with the tip of the electrode.is activated.
10.4 The voltage between the electrode (sponge) and the metal surface upon which the coating lies shall not exceed 100 V d-c,
measured
...
