SIST EN 15275:2015

2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.Konstrukcijska lepila - Karakterizacija anaerobnih lepil za koaksialne kovinske konstrukcije v stavbah in objektihStrukturklebstoffe - Charakterisierung anaerober Klebstoffe für koaxiale Metallverbindungen im BauwesenAdhésifs structuraux - Caractérisation des adhésifs anaérobies pour assemblages métalliques coaxiaux dans les bâtiments et ouvrages de génie civilStructural adhesives - Characterisation of anaerobic adhesives for co-axial metallic assembly in building and civil engineering structures91.080.10Kovinske konstrukcijeMetal structures83.180LepilaAdhesivesICS:Ta slovenski standard je istoveten z:EN 15275:2015SIST EN 15275:2015en,fr,de01-julij-2015SIST EN 15275:2015SLOVENSKI
STANDARDSIST EN 15275:2009/AC:2011SIST EN 15275:20091DGRPHãþD

EUROPEAN STANDARD NORME EUROPÉENNE EUROPÄISCHE NORM
EN 15275
April 2015 ICS 83.180 Supersedes EN 15275:2007English Version
Structural adhesives - Characterisation of anaerobic adhesives for co-axial metallic assembly in building and civil engineering structures
Adhésifs structuraux - Caractérisation des adhésifs anaérobies pour assemblages métalliques coaxiaux dans les bâtiments et ouvrages de génie civil
Strukturklebstoffe - Charakterisierung anaerober Klebstoffe für koaxiale Metallverbindungen im Bauwesen This European Standard was approved by CEN on 25 January 2015.
CEN members are bound to comply with the CEN/CENELEC Internal Regulations which stipulate the conditions for giving this European Standard the status of a national standard without any alteration. Up-to-date lists and bibliographical references concerning such national standards may be obtained on application to the CEN-CENELEC Management Centre or to any CEN member.
This European Standard exists in three official versions (English, French, German). A version in any other language made by translation under the responsibility of a CEN member into its own language and notified to the CEN-CENELEC Management Centre has the same status as the official versions.
CEN members are the national standards bodies of Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and United Kingdom.
EUROPEAN COMMITTEE FOR STANDARDIZATION
COMITÉ EUROPÉEN DE NORMALISATION EUROPÄISCHES KOMITEE FÜR NORMUNG
CEN-CENELEC Management Centre:
Avenue Marnix 17,
B-1000 Brussels © 2015 CEN All rights of exploitation in any form and by any means reserved worldwide for CEN national Members. Ref. No. EN 15275:2015 ESIST EN 15275:2015

Indicative values for performance characteristics . 19 Annex ZA (informative)
Clauses of this European Standard addressing the provisions of the EU Construction Products Regulation . 20 ZA.1 Scope and relevant characteristics . 20 ZA.2 Procedure for AVCP of anaerobic adhesives . 21 ZA.2.1 System of AVCP . 21 ZA.2.2 Declaration of performance (DoP) . 22 ZA.2.2.1 General . 22 SIST EN 15275:2015

For relationship with EU Regulation see informative Annex ZA, which is an integral part of this document. According to the CEN-CENELEC Internal Regulations, the national standards organizations of the following countries are bound to implement this European Standard: Austria, Belgium, Bulgaria, Croatia, Cyprus, Czech Republic, Denmark, Estonia, Finland, Former Yugoslav Republic of Macedonia, France, Germany, Greece, Hungary, Iceland, Ireland, Italy, Latvia, Lithuania, Luxembourg, Malta, Netherlands, Norway, Poland, Portugal, Romania, Slovakia, Slovenia, Spain, Sweden, Switzerland, Turkey and the United Kingdom. SIST EN 15275:2015

This European Standard only applies to metallic substrates. 2 Normative references The following documents, in whole or in part, are normatively referenced in this document and are indispensable for its application. For dated references, only the edition cited applies. For undated references, the latest edition of the referenced document (including any amendments) applies. EN 751-1, Sealing materials for metallic threaded joints in contact with 1st, 2nd and 3rd family gases and hot water — Part 1: Anaerobic jointing compounds EN 923:2005+A1:2008, Adhesives —Terms and definitions EN 13999-1, Adhesives — Short term method for measuring the emission properties of low-solvent or solvent-free adhesives after application — Part 1: General procedure EN 13999-2, Adhesives — Short term method for measuring the emission properties of low-solvent or solvent-free adhesives after application — Part 2: Determination of volatile organic compounds EN 15337, Adhesives — Determination of shear strength of anaerobic adhesives using pin-and-collar specimens (ISO 10123) EN 15865, Adhesives — Determination of torque strength of anaerobic adhesives on threaded fasteners (ISO 10964) 3 Terms and definitions For the purposes of this document, the terms and definitions given in EN 923:2005+A1:2008 and the following applies. 3.1 anaerobic adhesive adhesive that cures in absence of oxygen, curing being inhibited by the presence of oxygen and catalysed by metal ions Note 1 to entry: Deviating from this definition, anaerobic adhesives may be defined also as anaerobic polymerisable compounds, or anaerobic jointing compounds including liquid, gel like or pasty sealants. 4 Performance characteristics for intended uses The manufacturer shall undertake initial performance tests on the product in accordance with Table 1 and corresponding to the type of the defined application [e.g. retaining co-axial assemblies (see 5.1), threaded fasteners (see 5.2) and threaded joints in contact with 1st, 2nd and 3rd family gases and hot water (see 5.3)]. SIST EN 15275:2015

5 Nm, otherwise the input torque has to be explicitly mentioned in brackets (Input Torque in Nm). If unseated assemblies have been used, use the expression Unseated Assemblies in brackets. 3 Prevailing torque 5.2.1 Nm EN 15865 4 Durability a 5.1.2 N/mm²
or as ratio to shear strength at room temperature, No. 1 EN 15337 Shear Strength after 1 000 h exposure to 100 ºC. Only for products intended for use for retaining metallic co-axial cylindrical joints such as load bearing tubular or pin-and-collar-type cylindrical assemblies. Expresses durability as shear strength or retention of the shear strength measured in accordance with EN 15337 after 1 000 h exposure to 100 ºC (and if required to 150 °C). 5 Durability a 5.2.2 Nm or as ratio to breakaway torque at room temperature, No. 2 EN 15865 Breakaway Torque after 1 000 h exposure to
100 ºC. Only for products intended for use for securing or locking metallic threaded assemblies. Expresses durability as torque strength or retention of the torque strength measured in accordance to EN 15865 after 1 000 h exposure to 100 °C (and if required to 150 °C, after 168 h in boiling water, or after 2 h exposure to -20 °C). 6 Heat resistance 5.1.3 N/mm2 EN 15337 Shear strength at 100 ºC. Only for products intended for use for retaining metallic co-axial cylindrical joints such as load bearing tubular or pin-and-collar-type cylindrical assemblies. 7 Heat resistance 5.2.3 Nm EN 15865 Breakloose torque at 100 ºC. Only for products intended for use for securing or locking metallic threaded assemblies. 8 Sealing ability 5.3 - EN 751-1 Only for products intended for use to seal threaded metallic joints in contact with 1st, 2nd and 3rd family gases and hot water of heating systems. The sealing ability includes the resistance to gas condensates, resistance to hot water, resistance to temperature cycling, and resistance to vibration as defined in EN 751-1. Use the expression Meets the Requirements Accordingly to EN 751-1. SIST EN 15275:2015

EN 13999-2
a The determination of the strength and torque strength under the additional environmental conditions is only partly needed for specific applications by demand of the user or operator. To assess the heat resistance of an anaerobic adhesive measurement of the static shear strength in accordance with EN 15865 or torque strength in accordance with EN 15337 may be conducted at other specified environmental conditions. Indicative performance requirements are given in Annex A depending on the intended use. These values are drawn from laboratory and practical experience and can be considered to indicate satisfactory performance under normal practical use and conditions. The torque strength of anaerobic adhesives on threaded fasteners is expressed as breakloose torque measured on assemblies preloaded with an input torque of 5 Nm. Also, identical input torque is assumed to be applied to the specimens when measuring the prevailing torque. Attention shall be drawn to the fact, that shear strength properties measured in accordance with EN 15337 and EN 15865 are valid for low-carbon respectively zinc-phosphated steel substrate materials. In general, curing of anaerobic adhesives may be significantly affected by the nature of the used adherends, thus testing using the specific materials of the intended application is recommended. It is also recommended to evaluate heat resistance or durability of the intended joint under conditions reflecting the environmental loading expected to encounter in practice. 5 Test methods The test methods could be divided according to the type of the application, and the properties relevant to meet the requirements by the joint as follows: 5.1 Retaining co-axial assemblies 5.1.1 Static shear strength The static shear strength expresses the bond strength of an adhesive joint formed between a metal pin and a metal collar measured as compressive force required to push out the pin from the collar at constant crosshead speed according to EN 15337. The test method is primarily to be used for the determination of the shear strength capability of retaining metallic co-axial joints such as tubular lap joints or pin-and-collar type joints. The test method can be also used to determine the shear strength of threaded fasteners. However, in this case it is recommended to assess the bond ability of the threaded assembly by means of the torque strength according to EN 15865. 5.1.2 Durability Durability is expressed as retention of the static shear strength measured in accordance with EN 15337 after 1 000 h exposure to 100 ºC and if required to 150 ºC. NOTE If required durability can be assessed at other specified environmental conditions in accordance with EN 15337. SIST EN 15275:2015

EN 13999-2 1 Subclause 5.4 Sealing ability (including vibration resistance) Subclause 5.3 EN 751-1 1 Subclause 5.3 6.2.3 Test reports The results of the determination of the product type shall be documented in test reports. All test reports shall be retained by the manufacturer for at least 10 years after the last date of production of the anaerobic adhesives to which they relate. 6.2.4 Shared other party results A manufacturer may use the results of the product type determination obtained by someone else (e.g. by another manufacturer, as a common service to manufacturers, or by a product developer), to justify his own declaration of performance regarding a product that is manufactured according to the same design (e.g. dimensions) and with raw materials, constituents and manufacturing methods of the same kind, provided that: — the results are known to be valid for products with the same essential characteristics relevant for the product performance; — in addition to any information essential for confirming that the product has such same performances related to specific essential characteristics, the other party who has carried out the determination of the product type concerned or has had it carried out, has expressly accepted1) to transmit to the
1 The formulation of such an agreement can be done by licence, contract, or any other type of written consent. SIST EN 15275:2015
...
