SIST prEN IEC 60966-2-8:2026 is an international standard published by the International Electrotechnical Commission (IEC) under Technical Committee 46. It provides a detailed specification for radio frequency (RF) and coaxial cable assemblies specifically designed for radio and TV receivers. This second edition, published in 2025, updates the 2022 version with significant technical revisions including parameters for straight and right-angled F-Quick connectors, screening requirements, and improved electrical performance metrics.
The standard covers cable assemblies using IEC 61169-47 connectors and requires quad-shield screening class A++ according to IEC 61196-6-5. It addresses cable assemblies operating in the frequency range up to 3000 MHz and ensures high screening effectiveness, minimal insertion and return loss, and reliable mechanical performance.
Key Topics
- Scope: The specification applies to cable assemblies for radio and TV receivers using F-Quick male connectors with 75 Ω nominal impedance and quad-shield screening class A++.
- Frequency Range and Impedance:
- Frequency up to 3000 MHz.
- Nominal impedance of 75 Ω.
- Connector Types: Includes straight and right-angled male F-Quick connectors; female F-connectors are excluded as they are not standardized by IEC 61169-47.
- Electrical Performance:
- Reflection properties (Return Loss) differ for straight and right-angled connectors, e.g., ≥ 23 dB up to 1 GHz (straight).
- Insertion loss calculation factors adjusted for connector orientation.
- Loop resistance set to ≤ 1 Ω for the entire cable length.
- Screening and Shielding:
- Quad-shielding class A++ for superior EMI protection.
- Transfer impedance limits and screening attenuation thresholds ensure excellent electromagnetic compatibility (EMC).
- Mechanical Requirements:
- Tensile, flexure, and crushing tests to ensure durability and reliability.
- Inner and outer conductor continuity and positioning must meet interface dimension specifications.
- Marking and Identification:
- Assemblies must be marked with assembly type, screening class, IEC standard number, and manufacturer ID.
- Color-coded taper sleeves on connectors assist identification.
Applications
This standard is crucial for manufacturers, designers, and quality assurance professionals involved in the production and deployment of coaxial cable assemblies for broadcast, cable TV, satellite receivers, and other RF communication devices. Applications include:
- Cable assemblies for residential and commercial radio and television receivers.
- High-performance RF cabling systems requiring minimal signal loss and maximum EMI shielding.
- Production of RF connectors and assemblies compatible with IEC 61169-47 F-Quick connectors.
- Quality assurance protocols for testing electrical and mechanical properties of coaxial cables under demanding use cases.
By adhering to SIST prEN IEC 60966-2-8:2026, organizations ensure product interoperability, enhanced signal integrity, and compliance with international benchmarks, which are critical for maintaining broadcasting quality and user satisfaction.
Related Standards
- IEC 61169-47: Specification for F-Quick radio-frequency coaxial connectors used in 75 Ω cable networks.
- IEC 61196-6-5: Detail specification for Type A quad-shield CATV drop cables with screening class A++.
- IEC 60966-1:2019: Generic specification and test methods for radio frequency and coaxial cable assemblies.
- IEC 60966-2-1: Sectional specification for flexible coaxial cable assemblies.
- IEC 62153-4-7: Test methods for electromagnetic compatibility, measuring screening attenuation and transfer impedance of cables and connectors.
- IEC 61196-1-101: Electrical test methods for conductor DC resistance of cables.
Understanding these interconnected standards supports full compliance, detailed quality control, and the design of robust RF systems tailored to global market requirements.
Keywords: SIST prEN IEC 60966-2-8:2026, radio frequency cable assemblies, coaxial cable assemblies, F-Quick connectors, quad-shield screening, screening class A++, IEC 61169-47, radio and TV receivers, return loss, insertion loss, EMI shielding, coaxial connectors, 75 ohm cable, RF signal integrity, IEC standards for cables.
