SIST EN 1995-1-1:2005
(Main)Eurocode 5: Design of timber structures - Part 1-1: General - Common rules and rules for buildings
Eurocode 5: Design of timber structures - Part 1-1: General - Common rules and rules for buildings
General rules for the structural design of buildings and civil engineering works made of timber and/or wood-based panels, either singly or compositely with concrete, steel or other materials. Detailed rules for structural design of buildings.
Eurocode 5: Bemessung und Konstruktion von Holzbauten - Teil 1-1: Allgemeines - Allgemeine Regeln und Regeln für den Hochbau
(1)P EN 1995 gilt für die Bemessung und Konstruktion von Hochbauten und Ingenieurbauwerken aus Holz (Vollholz, gesägt, gehobelt oder als Rundholz, Brettschichtholz oder andere Bauprodukte aus Holz für tragende Zwecke, wie z. B. Furnierschichtholz) oder Holzwerkstoffen, die mit Klebstoffen oder mechanischen Verbindungsmitteln zusammengefügt sind. Er erfüllt die Grundsätze und Anforderungen nach EN 1990:2002 an die Sicherheit und die Gebrauchstauglichkeit der Bauwerke und die Bemessungs- und Nachweisverfahren.
(2)P EN 1995 behandelt nur die Anforderungen an die Tragfähigkeit, die Gebrauchstauglichkeit, die Dauerhaftigkeit und den Feuerwiderstand von Holzbauten. Andere Anforderungen, z. B. hinsichtlich des Wärme- und Schallschutzes, werden nicht behandelt.
(3) EN 1995 ist vorgesehen für die Verwendung in Verbindung mit den folgenden Normen:
EN 1990:2002, Grundlagen der Tragwerksplanung
EN 1991, Einwirkungen auf Tragwerke
ENs für Bauprodukte für Holzbauten
EN 1998, Auslegung von Bauwerken gegen Erdbeben, wenn die Bauten in Erdbebengebieten liegen.
(4) EN 1995 ist in mehrere Teile gegliedert:
EN 1995-1, Allgemeine Regeln
EN 1995-2, Brücken
(5) EN 1995-1, Allgemeine Regeln umfasst:
EN 1995-1-1, Allgemeines Allgemeine Regeln und Regeln für den Hochbau
EN 1995-1-2, Allgemeine Regeln Tragwerkbemessung für den Brandfall
