1 Scope
This document specifies a summary of optimizations for encoders and receiving systems for conducting
machine analysis tasks on coded video content. It provides a concept-level overview of recent practices and
provides comments on technical aspects and cautions to be taken when interpreting the results. This
document describes technologies that have recently been studied and demonstrated benefits to coding
efficiency for some machine analysis tasks.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content constitute
requirements of this document. For dated references, only the edition cited applies. For undated references,
the latest edition of the referenced document (including any amendments) applies.
Rec. ITU-T H.266 | ISO/IEC 23090-3, Versatile video coding
Rec. ITU-T H.265 | ISO/IEC 23008-2, High efficiency video coding
Rec. ITU-T H.264 | ISO/IEC 14496-10, Advanced video coding
Rec. ITU-T H.274 | ISO/IEC 23002-7, Versatile supplemental enhancement information messages for coded video
bitstreams
3 Terms and definitions
For the purposes of this document, the terms and definitions given in Rec. ITU-T H.266 | ISO/IEC 23090-3,
Rec. ITU-T H.265 | ISO/IEC 23008-2, Rec. ITU-T H.264 | ISO/IEC 14496-10, Rec. ITU-T H.274 | ISO/IEC
23002-7 and the following apply.
ISO and IEC maintain terminology databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https://www.iso.org/obp
— IEC Electropedia: available at https://www.electropedia.org/
3.1 3.1
machine consumption
applying a machine analysis task such as object detection, segmentation or object tracking
4 Abbreviated terms
AVC Advanced Video Coding (Rec. ITU-T H.264 | ISO/IEC 14496-10)
© ISO/IEC 2025 – All rights reserved

ISO/IEC DTR 23888-3:(en)
BD-rate Bjøntegaard delta bit rate
CTU coding tree unit
HEVC High Efficiency Video Coding (Rec. ITU-T H.265 | ISO/IEC 23008-2)
mAP mean average precision
MOTA multiple object tracking accuracy
NNPF neural-network post-filter
NNPFA neural-network post-filter activation
NNPFC neural-network post-filter characteristics
OMI object mask information
PSNR peak signal-to-noise ratio
QP quantization parameter
RoI region of interest
RPR reference picture resampling
SEI supplemental enhancement information
TID temporal identifier
URI uniform resource identifier
VSEI Versatile Supplemental Enhancement Information Messages for Coded Video Bitstreams
(Rec. ITU-T H.274 | ISO/IEC 23002-7)
VVC Versatile Video Coding (Rec. ITU-T H.266 | ISO/IEC 23090-3)
Y′C C colour space representation commonly used for video/image distribution, also written as
B R
YUV
YUV colour space representation commonly used for video/image distribution, also written as
Y′C C
B R
5 Overview
5.1 General overview
Most video processing systems consist of four main processing steps, as shown in Figure 1.Figure 1. This
document describes technologies for optimization of encoders and receiving systems, such as pre-processing,
encoding and post-processing for machine consumption. The decoding process, on the other hand, is fully
specified in the respective Rec. ITU-T H.266 | ISO/IEC 23090-3 Versatile Video Coding (VVC), Rec. ITU-T
H.265 | ISO/IEC 23008-2 High Efficiency Video Coding (HEVC) and Rec. ITU-T H.264 | ISO/IEC 14496-10
Advanced Video Coding (AVC) video coding standards, amongst others. Hence, the samples of the decoded
video are fully specified by the given input bitstream.
input pre- post- machine
encoding decoding
video processing processing consumption

Figure 1 — Figure 1 — General video coding and processing pipeline
2 © ISO #### /IEC 2025 – All rights reserved
ISO/IEC DTR 23888-3:(en)
An overview of the commonly used practices for evaluating encoder optimization technologies for machine
consumption can be found in clause 6.6. Descriptions of pre-processing technologies can be found in
clause 7.7. Encoder optimization technologies are described in clause 88 and post-processing technologies are
described in clause 9.9. Metadata that is useful for machine consumption is described in clause 10. 10.
It is noted that depending on specific use cases, the technologies outlined in this document can be
implemented individually or in combination to optimize the machine consumption performance within the
constraints of the system capabilities. When employing multiple technologies simultaneously, it is important
to consider that certain combinations can be impractical or infeasible due to inherent methodological
constraints. Tested combinations of two or more technologies are listed in Annex BAnnex B.
5.2 Use cases and applications
There are various use cases and applications using encoded video that benefit from optimizing both encoders
and receiving systems for machine consumption. Some of them are highlighted below:
— Surveillance: A considerable amount of bandwidth is needed to transmit a high volume of data generated
by a large number of sensors. The number of sensors also has an impact on the computational load on the
server side, as having to analyse the input from many sensors can become a huge burden. This can be
eased by distributing the computation to the front-end devices.
— Intelligent transportation: A key aspect for vehicular applications is interoperability between not only
vehicles from different vendors, but also the infrastructures of various locations. Connected vehicles are
expected to play a significant role in future transport systems and the tremendous number of vehicles
emphasizes the need of reducing the amount of data being transmitted between them to avoid overloading
the network.
— Intelligent industry: One example in this area is visual content analysis, checking and screening. Machine
automation is desirable for increasing efficiency.
[ ]
A more detailed description of use cases can be found in ISO/IEC TR 23888-1 [1]. 0 .
6 Evaluation methodology
6.1 General
A set of assessment metrics are used for the evaluation of encoder and receiving systems optimization
technologies for machine consumption. An overview evaluation framework is shown in Figure 2.Figure 2.
Here the input video is encoded to generate a bitstream. This bitstream is then decoded, and the decoded video
is used for machine consumption. In this diagram, the “encoder” includes both pre-processing and encoding
steps, and the “decoder” includes both decoding and post-processing steps, as shown in Figure 1.Figure 1.
© ISO/IEC 2025 – All rights reserved

ISO/IEC DTR 23888-3:(en)
YUV PSNR
calculation
input
encoder decoder output video
video
bit rate
task
ground machine
performance
truth consumption
calculation
Figure 2 — Figure 2 — Evaluation framework and points of measurement
6.16.2 Bit rate
The bit rate is determined based on the encoded bitstream and parameters of the input video such as frame
rate and the number of total frames. The following equationformula is applied to calculate the bit rate:
8 ∗ 𝑓𝑖𝑙𝑒𝑆𝑖𝑧𝑒𝐼𝑛𝐵𝑦𝑡𝑒𝑠 ∗ 𝑓𝑝𝑠 8 ∗ 𝑓𝑖𝑙𝑒𝑆𝑖𝑧𝑒𝐼𝑛𝐵𝑦𝑡𝑒𝑠 ∗ 𝑓𝑝𝑠
𝑏𝑖𝑡𝑟𝑎𝑡𝑒 =
𝑛𝑢𝑚𝐹𝑟𝑎𝑚𝑒𝑠 ∗ 1000 𝑛𝑢𝑚𝐹𝑟𝑎𝑚𝑒𝑠 ∗ 1000
6.26.3 PSNR
Encoding for video distribution is ordinarily performed in the Y′C C domain (nicknamed YUV herein for
B R
brevity and ease of typing). For standard-dynamic range video, the distortion metric primarily used in the
video coding standardization community has been the Peak Signal to Noise Ratio (PSNR). The following two
equationsformulae are used to calculate PSNR:
𝑛−1 𝑚−1 𝑛−1 𝑚−1
2 2
𝑀𝑆𝐸 = ∑ ∑ ‖𝑥(𝑖, 𝑗) − 𝑦(𝑖, 𝑗)‖ ∑ ∑ ∥ 𝑥(𝑖, 𝑗) − 𝑦(𝑖, 𝑗) ∥
𝑚 ∗ 𝑛
𝑖=0 𝑗=0 𝑖=0 𝑗=0
(𝑏𝑖𝑡𝑑𝑒𝑝𝑡ℎ−8) 2 (𝑏𝑖𝑡𝑑𝑒𝑝𝑡ℎ−8) 2
(255 ∗ 2 ) (255 ∗ 2 )
𝑃𝑆𝑁𝑅 = 10 ∗ 𝑙𝑜𝑔 ( ) 𝑙𝑜𝑔 ( )
10 10
𝑀𝑆𝐸 𝑀𝑆𝐸
4 © ISO #### /IEC 2025 – All rights reserved
ISO/IEC DTR 23888-3:(en)
where x(i,j) is the decoded sample value of a certain color component, y(i,j) is the corresponding original
sample value, and bitdepth is the bit depth of the input video. It is a common practice to calculate PSNR values
for each of the color component Y, U and V.
6.36.4 mAP
The performance of object detection and segmentation tasks are measured by mean average precision (mAP).
This metric indicates what percentage of objects are correctly identified by having sufficient overlap between
the detected object and the ground truth as well as being assigned to the correct object class. Then the share
of correctly identified objects for each class is determined, and finally the score for each class is averaged. The
calculation of mAP is as follows:
𝑚𝐴𝑃
𝑛𝑢𝑚𝑂𝑣𝑒𝑟𝑙𝑎𝑝𝑠
𝑛𝑢𝑚𝐶𝑙𝑎𝑠𝑠𝑒𝑠
𝑛𝑢𝑚𝑂𝑣𝑒𝑟𝑙𝑎𝑝𝑠
𝑛𝑢𝑚𝐶𝑙𝑎𝑠𝑠𝑒𝑠
1 1 𝑐𝑜𝑟𝑟𝑒𝑐𝑡𝑂𝑏𝑗𝑒𝑐𝑡𝑠 1 𝑐𝑜𝑟𝑟𝑒𝑐𝑡𝑂𝑏𝑗𝑒𝑐𝑡𝑠
𝑖𝑖 𝑖𝑖
= ∑ ( ∑ ( )) ∑ ( ∑ ( ))
𝑛𝑢𝑚𝑂𝑣𝑒𝑟𝑙𝑎𝑝𝑠 𝑛𝑢𝑚𝐶𝑙𝑎𝑠𝑠𝑒𝑠 𝑡𝑜𝑡𝑎𝑙𝑂𝑏𝑗𝑒𝑐𝑡𝑠 𝑛𝑢𝑚𝐶𝑙𝑎𝑠𝑠𝑒𝑠 𝑡𝑜𝑡𝑎𝑙𝑂𝑏𝑗𝑒𝑐𝑡𝑠
𝑖𝑖 𝑖𝑖
𝑖=1 𝑖𝑖=1
𝑖𝑖=1
𝑖=1
Some commonly used variants of this metric are:
— mAP@0.5: An object is counted as correctly identified if the Intersection over Union (IoU) between the
detected bounding box and the ground truth bounding box is at least 0.5. Sometimes this variant of the
mAP metric is also referred to as mAP50.
— mAP@[0.5:0.05:0.95]: In this variant a total of ten mAP scores with increasing IoU thresholds are
calculated. The IoU threshold starts at 0.5 and increases by 0.05 after each iteration, until it reaches to the
upper bound value 0.95. Once all ten scores are determined, the average of these scores is calculated to
produce the final mAP.
6.46.5 MOTA
Object tracking performance is measured by Multiple Object Tracking Accuracy (MOTA). This metric accounts
for all object configuration errors made by the tracker, false positives, misses (true negative), mismatches,
overall frames. The calculation of MOTA is as follows:
∑ (𝐹𝑁 + 𝐹𝑃 + 𝑚𝑚𝑒 )
∑ ( )
𝐹𝑁 + 𝐹𝑃 + 𝑚𝑚𝑒
𝑡 𝑡 𝑡
𝑡 𝑡 𝑡 𝑡
𝑡
𝑀𝑂𝑇𝐴 = 1 − , ,
∑ 𝑔 ∑ 𝑔
𝑡 𝑡 𝑡 𝑡
where 𝐹𝑁 𝐹𝑁 , 𝐹𝑃 𝐹𝑃 , 𝑚𝑚𝑒 𝑚𝑚𝑒 and 𝑔 are the number of false negatives, the number of false positives,
𝑡 𝑡 𝑡 𝑡 𝑡 𝑡 𝑡
the number of mismatch error (ID Switching between 2 successive frames), and the number of objects in the
ground truth respectively at time 𝑡.
6.56.6 BD-rate
To compare the performance of a technology against the reference, the well-known Bjøntegaard delta rate
[ ]
(BD-rate) metric [2] 2 is used. Instead of using PSNR as the distortion metric as is typical for human vision
performance evaluation, machine consumption distortion metrics, e.g., mAP and MOTA, are used in machine
BD-rate calculation.
The distortion measurement of machine consumption (e.g., mAP and MOTA) can sometimes be non-
monotonic to the bit rate due to the characteristics of the machine analysis task and possible limitations of
© ISO/IEC 2025 – All rights reserved

ISO/IEC DTR 23888-3:(en)
machine networks. Polynomial curve fitting is applied to ensure rate-distortion monotonicity and thus valid
BD-rate calculation.
3 2 2
( )
𝑓 𝑥 = 𝑏 (𝑥) = 𝑏 ∗ 𝑥 + 𝑏 ∗ 𝑥 𝑏 ∗ 𝑥 + 𝑏 𝑏 ∗ 𝑥 + 𝑏 + 𝑏
0 0 1 1 2 2 3 3
For a given polynomial function in the above formula, 𝑏 , 𝑏 , 𝑏 , and 𝑏 are coefficients of the function, 𝑥 is the
0 1 2 3
input (bit rate) and 𝑓(𝑥) is the output (quality). The following two constraints are invoked to ensure its
monotonicity and convexity:
-— the first order derivative of the polynomial shown below is positive in the given 𝑥 range
′ 2 2
( )
𝑓 𝑥 = 3 ∗ 𝑏 ∗ 𝑥 + 2 ∗ 𝑏 ∗ 𝑥 + 𝑏 (𝑥) = 3 ∗ 𝑏 ∗ 𝑥 + 2* 𝑏 ∗ 𝑥 + 𝑏
0 1 2 0 1 2
-— the second order derivative of the polynomial shown below is negative in the given 𝑥 range
′′ ″
𝑓 (𝑥) = 𝑓 (𝑥) = 6 ∗ 𝑏 ∗ 𝑏 ∗ 𝑥 + +2 ∗ 𝑏 * 𝑏
0 0 1 1
Parameters (𝑏 , 𝑏 , 𝑏 , 𝑏 ) in the polynomial function are solved by sequential least squares programming
0 1 2 3
(SLSQP) and applied to curve fitting.
NOTE: It is a common practice to have the minimal quality value of the fitted curve no smaller than the minimal
quality value of the original curve and the maximum quality value of the fitted curve no greater than the maximum quality
value of the original curve.
7 Pre-processing technologies
7.1 Region of interest-based methods
One often-used optimization method is region of interest (RoI)-based coding. Here the input video is analysed
in some way and then the encoder can optimize the encoding towards machine consumption based on the
analysis results. The analysis can be done using various methods, e.g., neural networks. An example of a
pipeline that can be used for RoI-based approaches is shown in Figure 3.Figure 3.
analysis
input machine
encoder decoder
video consumption
Figure 3 — Figure 3 — Pipeline for RoI-based systems
In one implementation example, an object detection network is used to analyse the input data. This network
produces a list of objects that can be found in the current picture. The information used to describe each object
includes the index of the picture in which the object can be found and the position of the object in the picture.
6 © ISO #### /IEC 2025 – All rights reserved
ISO/IEC DTR 23888-3:(en)
Some networks can provide more information than this and the encoder can choose to select a subset of all
objects by filtering based on, for example, the class of an object or the estimated likelihood of an object of the
described class being at the described position. In a similar approach, a segmentation network can be used
where the object is not described by a bounding box but by a segmentation mask indicating exactly which
samples the segmentation network estimates belonging to the object. The list produced during the analysis
can then be used by the encoder, for example, to separate foreground and background with the purpose of
encoding the foreground at a better quality and the background at a lower quality. One such encoding method
is described in 8.1.8.1. In this example, the analysis does not change the input video, but directly forwards it
to the encoder.
In other RoI-based methods, the pre-processing changes the input video, for example, by applying different
pre-processing methods on the foreground and background, or specific parts of the video, such as subsampling
the background area of the input video.
In one implementation example, an object segmentation network is first used to analyse the input data. The
network produces a list of objects segmented with the object shapes in the current picture. The object shapes
and positions could be represented, for example, by segmentation masks. More information such as the object
class or the estimated likelihood of the object segment could also be provided by the network to identify the
objects. Based on the object information, it is possible to derive spatial complexity and temporal complexity
for the different segments, and then RoI-based pre-processing of the input video can be adapted based on the
spatial and temporal complexity. The spatial complexity here indicates the averaged object size which can be
calculated by dividing the percentage of the area covered by the objects by the total number of the objects.
Temporal complexity indicates the content changes between two pictures which can be calculated by various
methods, for example, by taking the mean absolute difference of the collocated samples in two pictures.
7.2 Foreground and background processing
After pre-analysis that determines the foreground and background areas, one straightforward way to handle
the background that is less critical to machine consumption is to “eliminate” it by setting the corresponding
sample values to a constant value. However, some portions of the background samples, for example those
immediately surrounding the foreground area, could still be useful for machine consumption. Therefore, the
background regions relevant to machine consumption can be preserved to a certain extent with low-pass
filtering, such as a Gaussian filter with a sliding window, where the window size can be set based on the input
video resolution.
Moreover, extracted features can reveal importance information of the input video. In other words, compared
with binary classification of foreground and background, these extracted features can provide importance
information at a finer granularity. Therefore, such extracted features can be used to determine how to process
foreground and background differently. In one implementation example, a feature map is extracted by a
feature extraction network, and based on the feature map, the parameters of a Gaussian smoothing filter are
adapted and then the adaptive filtering is applied to the picture. As the background area and foreground area
have different features and even within the background or foreground area, different regions can have
different features, the Gaussian smooth filter can be controlled at a finer granularity, which finally results in a
more efficient pre-processing.
An implementation example with more detailed description can be found in A.2A.2.
7.3 Temporal subsampling
In some use cases, for example when the frame rate is high, a way to reduce the bit rate without a strong
negative impact on the machine consumption performance can be to skip certain frames and encode the video
at a lower frame rate. One example is to remove every other frame from the input video and encode the video
at half frame rate. This can be done in a dynamic manner, for example by evaluating the motion between two
© ISO/IEC 2025 – All rights reserved

ISO/IEC DTR 23888-3:(en)
or more frames and if there is only little motion, a frame can be removed. In some cases, if the receiving system
requires a specific frame rate, a corresponding post-processing technology that up-samples the video to the
full frame rate can be applied.
An implementation example with more detailed description can be found in A.4A.4.
7.4 Spatial subsampling
If the analysis of a video shows that it contains primarily large objects, one way to improve the BD-rate
performance is to perform spatial subsampling on the input video. This will result in fewer samples in the
subsampled frames to be encoded, and thus likely lead to faster encoding and bit rate savings. The optimum
downscaling factor is content dependent. It is possible that the machine consumption performance drops
when subsampling is too aggressive. Therefore, it is advisable to apply spatial subsampling adaptively, for
example, based on the characteristics of the video content (such as the averaged object spatial area and the
number of objects) and the target bit rate. Moreover, the spatial subsampling can also be dependent on the
picture types. For example, depending on whether the input video is captured by regular camera as natural
scenes, or is captured by infrared sensor as thermal images, different spatial subsampling methods can be
applied.
One tool specified in the Rec. ITU-T H.266 | ISO/IEC 23090-3 (VVC) standard that can be used for the purpose
of spatial resampling is called reference picture resampling (RPR). This tool allows the encoder to choose to
encode some pictures of the input video at different resolutions. For example, based on the analysis of
keyframes, without encoding an intra picture at the specified changed resolution, inter predictions can be
made from all allowed pictures regardless of their resolution.
In one implementation example, the RPR tool can be used at the frame level, where the input video can be
analysed as described in 7.1.7.1. In this case, the unmodified input video is forwarded to the encoder with a
scale factor list generated by the analyser. Specifically, an object detection network is used to analyse the input
video in both full resolution and at least one spatially subsampled resolution. This network produces a list of
objects with object information that can be found in the current picture and the spatially resampled picture.
The object information describes the position and size of the detected objects for both the current picture and
the spatially resampled picture. Based on the object information, an object occupancy distribution (i.e., the
distribution of the ratio of object size to the corresponding picture resolution) can be generated for both the
current picture and the spatially resampled picture. The scale factor can be derived for the current picture by
comparing the correlation of object occupancy distributions, and then the list of all scale factors is passed on
to the encoder for utilization of the RPR tool.
7.5 Noise filtering
Under some circumstances, various types of noise can be present in the video content. Denoising filters can be
applied on such content to reduce unnecessary bit rate increases and avoid machine consumption
performance degradation by filtering out the undesirable noise from the video content while preserving
information important to machine consumption. Various types of denoising filters can be applied according to
the characteristics of the noise. The strength of the filter can be adjusted based on the noise, and the filter can
adaptively be enabled and disabled for either an entire picture or sequence, or only a part thereof.
It is noted that some existing denoising filters such as bilateral or anisotropic diffusion filters can preserve
local details during denoising. For applications that benefit from such local details being preserved, filtering
the entire picture using the same strength can be detrimental.
8 © ISO #### /IEC 2025 – All rights reserved
ISO/IEC DTR 23888-3:(en)
8 Encoding technologies
8.1 RoI-based quantization parameter adaption
One method that is available in many video coding standards is adaptive quantization parameter (QP). Here
the encoder can change the QP value at a sub-picture level, for example the coding tree unit (CTU) level, to
optimize the encoding for the application. Due to this versatility, adaptive QP can be used in many different
use cases to improve performance.
The decision on where to change the QP value and by how much can be made by the encoder based on an
analysis of the input video. Another option is to utilize the output of an external analyser such as described in
7.1.7.1. In this case, the encoder receives information about the positions and sizes of objects in each frame to
make a differentiation between foreground and background.
One option is to use a base QP value of the picture for areas that contain objects, i.e., foreground areas, and an
increased QP value for background areas, resulting in fewer bits being used to encode the background. As the
background is usually not critical to machine consumption, this is a straight-forward way to reduce the bit
rate without affecting the machine consumption performance. As an extension, it can also be beneficial to
encode large objects with slightly higher QP values. As it is generally easier to detect larger objects, reducing
the bit rate for large objects usually does not reduce the performance of machine consumption.
However, it is noted that when utilizing the analysis, complexity can be traded against bit rate. For example, if
a light-weight neural network is used to perform the analysis, it is possible that not all relevant objects have
been found and thus it couldcan be detrimental to reduce the quality for the background too much as there
are possibly objects that the initial analysis missed. These objects are possibly still important for machine
consumption and if the background is encoded in sufficient quality, the machine consumption network has a
chance of detecting objects in the background even if they are coded in lower quality than the foreground area.
On the other hand, if the encoding system has a lot of resources, it can employ a neural network of higher
complexity for the analysis. With a better and more certain analysis, the bit rate for the background can be
reduced more as there are likely fewer objects that have been missed in the initial analysis.
A more detailed description with a link to an implementation can be found in A.1A.1.
8.2 Quantization step adjustment for temporal layers
It is a common practice that the encoder places different pictures on different temporal layers, i.e., assigning
different temporal identifiers (TID). This has the purpose of creating hierarchical structures that indicate from
which previously coded pictures the encoder can create predictions for the current picture. One aspect of these
hierarchical structures is that pictures cannot be referenced by other pictures on a higher temporal layer. This
way, it is not necessary to store every decoded picture in the decoded picture buffer. Another aspect of the
hierarchical structure is that pictures on higher temporal layers can be encoded with higher QP values, i.e.,
lower quality, as they will not be used, or less often used, as references by other pictures. An example of a
hierarchical structure is shown in Figure 4.Figure 4. The display order is left-to-right, and the numbers specify
the order of the coded pictures in the bitstream.
© ISO/IEC 2025 – All rights reserved

ISO/IEC DTR 23888-3:(en)
Figure 4 — Figure 4 — An example hierarchical referencing structure in a Rec. ITU-T H.266 |
ISO/IEC 23090-3 (VVC) random access configuration bitstream
This hierarchy of pictures can be exploited by encoding pictures on higher temporal layers using higher QP
values, i.e., reducing the number of bits spent on these pictures in total. This is also done in the case of the
common test conditions for standard definition range for Rec. ITU-T H.266 | ISO/IEC 23090-3 (VVC). In the
use case of coding video content for machine consumption, this characteristic can be exploited further by
increasing the QP value for pictures on higher temporal layers more. Taking advantage of motion
compensation, many bits can be saved when compressing pictures in high temporal layers while these pictures
are still able to be reconstructed with high quality. Compressing the highest temporal layer with at a high QP
can be seen as being similar in spirit to reducing the frame rate as discussed in 7.3.7.3. As an example, lowering
the bit rate substantially on every odd-numbered frame can be seen as a step towards completely removing
them.
8.3 Chroma QP offset setting
Many machine analysis methods are performed using 4:4:4 colour format input data. Therefore, encoding in
4:2:0 colour format, which has lower chroma resolution that 4:4:4 colour format, can sometimes have a
negative impact on the machine analysis performance. This can sometimes be compensated for by using a
negative chroma QP offset, which increases the quality of the low-resolution chroma components.
9 Post-processing technologies
9.1 Temporal resampling
When the receiving system requires a specific frame rate that is different from the frame rate of the decoded
sequences, temporal resampling can be applied on the decoded video by utilizing conventional temporal filters
(e.g., motion compensated interpolation filters) or neural network-based filters, or just frame repetition. An
implementation example with more detailed description can be found in A.4A.4.
10 ©
...
