TECHNICAL SPECIFICATION ISO/TS 21219-21:2018(E)
Intelligent transport systems — Traffic and travel
information via transport protocol experts group,
generation 2 (TPEG2) —
Part 21:
Geographic location referencing (TPEG-GLR)
1 Scope
This document defines a method of using geographic location referencing (GLR) that can be used by
relevant TPEG applications. The GLR type is defined in this document. It is used for defining geographic
location references (points, polylines, and geographical areas). The GLR method is intended to be one
of the methods that can be transported inside a TPEG-location referencing container (TPEG-LRC) for
those TPEG applications providing information for primarily geographical locations (e.g. weather).
The GLR specification is kept basic and compact on purpose, such that it can also be employed
advantageously in non-navigation devices for simple TPEG services such as weather information,
safety alerts, etc. As such, the GLR location referencing method is intended to be complementary to
map-related location referencing methods, where the focus rather is on the referencing of man-made
artefacts such as roads and highways.
The scope of GLR is limited to geographic locations on the Earth’s surface for the above-mentioned
rationale.
2 Normative references
There are no normative references in this document.
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— IEC Electropedia: available at http://www.electropedia.org/
— ISO Online browsing platform: available at http://www.iso.org/obp
3.1
point of interest
specific point location that someone may find useful or interesting
Note 1 to entry: An example is a point on the Earth representing the location of the Eiffel Tower, in Paris, France,
or a location of a weather station on top of Mount Washington in New Hampshire, VT, USA, or a location of a fuel
station.
4 Abbreviated terms
ACID Application and Content Identifier
ADC Application Data Container
CEN Comité Européen de Normalisation
EBU European Broadcasting Union
GLR Geographic Location Reference
LRC Location Referencing Container
MMC Message Management Container
OSI Open Systems Interconnection
POI Point Of Interest
SFW TPEG Service Framework: Modelling and Conversion Rules
TISA Traveller Information Services Association
TPEG Transport Protocol Expert Group
TTI Traffic and Travel Information
UML Unified Modeling Language
5 Toolkit specific constraints
5.1 Version number signalling
Version numbering is used to track the separate versions of a toolkit through its development and
deployment. The differences between these versions may have an impact on client devices.
The version numbering principle is defined in ISO/TS 21219-1.
Table 1 shows the current version numbers for signalling GLR within TPEG-ML.
Table 1 — Current version numbers for signalling of GLR toolkit
major version number 2
minor version number 0
5.2 Extendibility
Future toolkit extensions may insert new components without losing backward compatibility. A GLR
decoder shall be able to detect and skip unknown components.
6 GLR toolkit structure
6.1 General
The geographic location reference toolkit provides a component for simple geographic location
references. This component can be inserted in a location referencing container inside a TPEG message,
when this type of location reference is relevant and suitable for the particular TPEG application.
2 © ISO 2018 – All rights reserved

Figure 1 shows the structure of the GLR toolkit. The GLR location reference offers several variants of
geographic location references. Each instance however shall contain only a single type of the provided
various types of geographic location references.
Figure 1 — Structure of the geographic location reference toolkit
In a GLR location reference, coordinates are specified in the WGS-84 geodetic system, unless explicitly
signalled otherwise at service or service component level (see also 8.8).
The geographic location reference toolkit contains two versions of bounding areas, and point, line, and
area location references. In the next subclauses, each of these variants of geographic location references
is explained in more detail.
6.2 Geographic bounding box location reference
A geographic bounding box location reference defines a rectangular area to indicate, e.g. a search
area or encompassing area of a collection of features, e.g. fuel stations or other POIs. Figure 2 shows
a bounding box, with its defining north-west and south-east corners. For example, this bounding box
location reference delineates the locations of a collection of fuel stations in Manhattan, NY, USA.
Figure 2 — Geographic bounding box indicating, e.g. a delineating search area for a set of fuel
stations
Geographic bounding box location references may optionally indicate the altitude above mean sea level
of the area, and optionally have an area name as descriptor.
6.3 Geographic bounding circle or sector of circle location reference
A geographic bounding circle location reference is very similar in nature as the geographic bounding
box location reference. The chief difference is the definition of the encompassing area as, in this case, a
circle rather than a rectangle. This circle is defined by a centre point and a radius (see Figure 3).
Figure 3 — Example of a geographic bounding circle location reference
Geographic bounding circle location references may optionally indicate the altitude above mean sea
level of the area, and optionally have an area name as descriptor.
When a geographic bounding is to be limited to only a sector of a circle with a defined radius, this
is specified through two azimuth angles. These angles specify the angular start and angular end of
the sector (in clockwise direction) respectively. Both these angles are measured with respect to the
geographic north (see Figure 4).
4 © ISO 2018 – All rights reserved

Figure 4 — Definition of a sector of a circle with sectorStartAngle and sectorEndAngle
6.4 Geographic point location reference
A geographic point location reference references the location of a point-type feature, e.g. a weather
station, a theatre, or one of the individual fuel stations in Figures 2 and 3. If the location is approximate,
e.g. the location of a highway intersection, the location reference can indicate this through an attribute
“isFuzzyPoint” (see Figure 1).
Furthermore, for geographic location references of features close to roads, the road name of the adjacent
road may optionally be indicated and optionally, the direction of travel on that road, leading to the
primary entry point of that feature. Geographic point location references also may optionally indicate
the altitude above mean sea level of the area, and optionally contain a point feature name as descriptor.
6.5 Geographic line location reference
A geographic line location reference references the location of a line-type feature, e.g. a squall line or
the San Andreas Fault line in California, USA. If the location is approximate, e.g. the location of a squall
line, the location reference can indicate this through an attribute “isFuzzyLine” (see Figure 1).
Geographic line location references also may optionally indicate the altitude above mean sea level of the
area, and optionally have a line feature name as descriptor.
Figure 5 — Tornado watch location indication (source NOAA)
6.6 Geographic area location reference
A geographic area location reference references the location of an area-type feature, e.g. the location
of a forest fire or a tornado warning. If the location is approximate, e.g. the location of a forest fire, the
location reference can indicate this through an attribute “isFuzzyArea” (see Figure 1). Geographic area
location references also may optionally indicate the altitude above mean sea level of the area.
Furthermore, geographic area location references may optionally include an area feature name as
descriptor, or one or more hierarchical area names as descriptor. Hierarchical area names are for used
in e.g. weather reporting for a tornado watch (see Figure 5).
For the example tornado watch shown in Figure 5, the hierarchal name descriptor is composed of two
states, Louisiana and Mississippi, and for each of these two states the following parishes/counties,
indicating the parts of that state for which the tornado watch is issued.
— Louisiana: Ascension, East Baton Rouge, East Feliciana, Iberville, Livingston, Pointe Coupee, St.
Helena, St. Tammany, Tangipahoa, Washington, West Baton Rouge, West Feliciana
— Mississippi: Adams, Amite, Claiborne, Clarke, Copiah Covington, Forrest Franklin, Hinds, Jasper,
Jefferson, Jefferson Davis, Jones, Lamar, Lauderdale, Lawrence, Lincoln, Madison, Marion, Newto,
Pearl River, Pike, Rankin Scott, Simpson, Smith, Walthall, Warren, Wilkinson
In the geographic area location reference for this example tornado watch, these composite locations
can be encoded with two HierarchicalAreaName data structures, one for each state.
6 © ISO 2018 – All rights reserved

7 GLR message components
7.1 GeographicLocationReference
Table 2 shows the geographic location reference: toolkit component for simple geographic location
references. This component shall contain only one single type of the various provided types of
geographic location references.
Table 2 — GeographicLocationReference
Name Type Multiplicity Description
geographicBoundingBox GeographicBoundingBox 0.1 BoundingBox-type
geographic location
reference.
geographicBoundingSector GeographicBoundingCircleSector 0.1 Bounding area
geographic location
reference as sector of a
circle or complete circle.
geographicPointReference GeographicPointReference 0.1 Point-type geographic
location reference.
geographicLineReference GeographicLineReference 0.1 Line-type geographic
location reference.
geographicAreaReference GeographicAreaReference 0.1 Area-type geographic
location reference.
8 GLR datatypes
8.1 CircleSector
Table 3 shows the data structure to specify the relevant sector of the circle.
Table 3 — CircleSector
Name Type Multiplicity Description
sectorStartAngle IntUnTi 1 Azimuth angle to start of circle sector of interest.
The sectorStartAngle is measured clockwise from geo-
graphic north, expressed in units of 360/256 degrees.
sectorEndAngle IntUnTi 1 Azimuth angle to end of circle sector of interest.
The sectorEndAngle is measured clockwise from geo-
graphic north, expressed in units of 360/256 degrees.
8.2 GeographicAreaReference
Table 4 shows the geographic area specified as a polygon.
A GeographicAreaReference shall include at most one of the attributes "areaFeatureName" and
"hierarchicalAreaFeatureName", but not both.
Table 4 — GeographicAreaReference
Name Type Multiplicity Description
polygonPoints Coordinate 3.* A sequence of points forming a
closed, simple (i.e. non-self
intersecting) contour of a geo-
graphic polygon.
The polygon contour is formed by
line segments connecting the
successive points, and finally the
polygon contour is closed by the
line segment connecting the last
point to the first point.
The resulting area polygon shall be
non-self intersecting.
Recommended is to limit the num-
ber of points of the polygon to 32
or less.
isFuzzyArea Boolean 1 If set, the “isFuzzyArea” attribute
indicates that the polygon shape
represents a fuzzy area, i.e. the
polygon shape is an approximate
description of the location of the
referenced feature.
altitudeMSL IntSiLoMB 0.1 Average elevation of location in
metres above/below mean sea level
(MSL).
areaFeatureName LocalisedShortString 0.* Feature name of the area reference
in the local languages of interest.
hierarchicalAreaFeatureName HierarchicalAreaName 0.* Attribute to express area name(s)
as hierarchical feature name. Sev-
eral hierarchical area names are
allowed to express, e.g. a region of
a number of countries, or a number
of states.
Each such hierarchical area name
structure indicates the local lan-
guage of interest. Multiple hierar-
chical area names in a single local
language may be supplied.
8.3 GeographicBoundingBox
Table 5 shows the geographic area defined as a bounding box. A bounding box area is an approximate
geometric description completely encompassing the actual location of an area or a collection of point
locations intended to be referenced.
8 © ISO 2018 – All rights reserved

Table 5 — GeographicBoundingBox
Name Type Multiplicity Description
northWes
...
