INTERNATIONAL STANDARD ISO 21219-2:2019(E)
Intelligent transport systems — Traffic and travel
information (TTI) via transport protocol experts group,
generation 2 (TPEG2) —
Part 2:
UML modelling rules (TPEG2-UMR)
1 Scope
This document specifies rules for the creation and extending of TPEG application UML models. The
rules are intended to ensure that TPEG application UML models can be interpreted unambiguously for
conversion to physical format representations. TPEG application UML models that are defined according
to these rules can be used for automatic generation of TPEG standards and for automatic generation of
TPEG application physical format descriptions.
This document also specifies the preferred structure of TPEG application specifications.
The TPEG abstract data types and the set of TPEG tables of common use are specified in the annexes.
2 Normative references
There are no normative references in this document.
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
ISO and IEC maintain terminological databases for use in standardization at the following addresses:
— ISO Online browsing platform: available at https: //www .iso .org/obp
— IEC Electropedia: available at http: //www .electropedia .org/
3.1
abstract data type
data type of atomic nature
3.2
attribute compartment
graphical section of a UML class box positioned directly under the class name compartment (3.3)
3.3
class name compartment
top most graphical section of a class box defining the name of the class and optionally a stereotype,
inherited class and package scope
3.4
data structure
data type being composed of other data types being either of abstract (3.1) or complex data type, not
having a component header (3.6), stereotyped as <>
3.5
component
revisable, named, complex data type, not stereotyped as <>
3.6
component header
data structure (3.4) consisting of a component identifier, component length indicator and attribute
length indicator
3.7
element
component (3.5) or data structure (3.4)
3.8
link
relation between two or more elements (3.7)
3.9
TPEG Application
set of classes and rules defining TPEG information services at the highest layer of the ISO OSI model
4 Abbreviated terms
IPR Intellectual Property Right(s)
ISO International Organization for Standardization
LRC Location Referencing Container
MMC Message Management Container
OSI Open Systems Interconnection
PTI PTI Public Transport Information
TISA Traveller Information Services Association
TPEG Transport Protocol Experts Group
UML Unified Modelling Language
5 TPEG UML model definition
5.1 Allowed UML elements
[1]
TPEG UML models are based on the UML standard , but only use a subset of the elements defined in
the standard. This clause provides a description of the elements of UML that are used for modelling
TPEG. This clause also defines restrictions on these elements. TPEG UML models shall only use the UML
elements described in this clause. The defined restrictions shall be obeyed.
5.1.1 Class
A class provides a description of the structure of the data stored in an instance of a class. The data are
stored in the class attributes.
Classes shall be named according to the following regular expression: “^[a-zA-Z]\w*$” which is
equivalent to “class names shall start with an English alphabet character, followed by zero or
more English alphabet characters, digits or underscores”. As an exception, classes stereotyped as
enumerations shall be named according to the following regular expression: “^[a-z]{3}\d{3}:[azA-
Z]\w*$” which is equivalent to “enumeration class names shall start with three lower-case English
alphabet characters, followed by three digits, a colon, a English alphabet character, then zero or more
English alphabet characters, digits or underscores”. Upper camel case should be used for class names,
2 © ISO 2019 – All rights reserved

with the first letter of every word capitalized. Additionally, class names shall be unique within their
TPEG application or TPEG toolkit scope.
5.1.2 Abstract class
Abstract classes may be used to define shared properties of specialized child classes.
5.1.3 Attribute
An attribute provides a data type description of data that is stored in a class. Attributes can be either of
primitive data type or compound data type.
An attribute shall be named according to the following regular expression: “^[a-zA-Z]\w*$” which
is equivalent to “attribute names shall start with an English alphabet character, followed by zero or
more English alphabet characters, digits or underscores“. As an exception, attributes within classes
stereotyped as enumerations shall be named as defined in 5.2.3.5. Lower camel case should be used
for attribute names, with the first letter in lowercase and the first letters of subsequent words in
uppercase. Additionally, attributes shall be named uniquely within their class.
Within a class, an attribute has a multiplicity. If not explicitly indicated, the multiplicity is one. Other
multiplicities may be indicated between square brackets: [minOccurs . maxOccurs].
minOccurs and maxOccurs shall be positive integers, where maxOccurs shall be greater or equal to
minOccurs. Alternatively, maxOccurs may be theoretically unbounded, in which case an asterisk “*” is
modelled. However, in physical formats there may be upper bounds due to length restrictions and size
indicator data type limitations.
Attribute multiplicity shall be interpreted as listed in Table 1. If no multiplicity is indicated, a multiplicity
of one (mandatory attribute) is implied.
Table 1 — TPEG multiplicity
Multiplicity TPEG meaning
minOccurs=1 and maxOccurs=1 mandatory attribute
minOccurs=1 and maxOccurs>1 mandatory list of attributes
minOccurs=0 and maxOccurs=1 optional attribute
minOccurs=0 and maxOccurs>1 optional list of attributes
minOccurs>1 mandatory list of attributes with a minimum occurrence
Attributes in classes are always modelled as public. Each attribute must have a data type. Attributes
occur in the order as listed in the class definition in TPEG physical formats, unless this is overruled by
the stereotype <> .
NOTE Optional list of attributes with a minimum occurrence can be modelled as optional attribute including
a data structure including a mandatory list of attributes with minOccurs>1.
5.1.4 Dependency
Figure 1 is the graphical representation used for ordered components (attributes stereotyped
as <> ) and DataStructures to show the hierarchical structure of the
UML model.
Figure 1 — UML dependency relation
NOTE Aggregation and composition associations are deprecated in TPEG models; the preferred method is
inclusion as an attribute.
5.1.5 Specialization
A specialization (see Figure 2) relates a parent class to a child class. The child class inherits properties
from the parent class. Classes shall not inherit from multiple parent classes. Classes shall only inherit
from classes with the same stereotype.
Derived classes copy all attributes from the parent class. Parent classes shall contain classes not
stereotyped as <> or <>. Parent classes shall be modelled as
abstract class. In future versions of a standard, parent classes shall not be extended. Classes shall not be
both parent and child class.
NOTE Extending parent classes in future versions of a standard breaks backwards compatibility.
4 © ISO 2019 – All rights reserved

Figure 2 — UML specialization relation
5.1.6 Stereotype
A stereotype is used to provide an additional classification of UML properties. A physical format
specification may use stereotype information to select a rule set for converting UML to the physical
format.
The stereotypes as listed in Table 2 may be used for UML modelling of TPEG applications. Other
stereotypes shall not be used.
Table 2 — TPEG stereotypes
UML element Stereotype TPEG meaning
Package TPEG Application Self standing protocol specification for a given application.
Package TPEG Toolkit Specification of general interest being referenced by
different other specifications.
Package TPEG DataTypes Specification defining data structures and tables
belonging to one single package.
Class DataStructure TPEG data structure.
Class Enumeration List of defined, constant expressions not containing
attributes or sub data elements.
Class External TPEG Component defined in an external document.
Class BinaryDataContainer Component carrying binary data in its body that is not
further specified within TPEG.
Attribute OrderedComponentGroup Attribute is of component type, and belongs to the group
of components occurring in the order as defined by the
attribute order.
Attribute UnorderedComponentGroup Attribute is of component type, and belongs to the group
of components that may occur in random order, after all
other attributes.
5.1.7 Tagged values
Tagged values may be used to provide additional information on a UML element, used for the creation of
the specification document.
Only the tagged values listed in Table 3 shall be used.
Table 3 — Allowed tagged values
Tag UML Element TPEG meaning Example
ApplicationAbbreviation Package Abbreviation of the ap- TEC
plication name as string.
ApplicationName Package Name of the application Traffic Event Compact
as string.
ApplicationNo Package Part number to be A value of „2“ will result in:
included in the target
Intelligent transport systems — Traffic
specification title.
and Travel Information (TTI) via
Transport Protocol Expert Group,
Generation 2 (TPEG2) — Part 2: UML
Modeling Rules (TPEG2-UMR_1.1/001)
ApplicationRoot Package Name of the root class of TECMessage
an application as string.
ApplicationVersion Package Version of the specifi- 3.1
cation that is generated
from this model. Major.
Minor VersionNumber.
ApplicationRelease Package Integer that is Integer/345
increased each time the
model is changed
TableEntryExample Enumeration Comment for a table
attribute entry
Documentation Description of generic
properties of a class
Description Description of single
attributes within a class
GCId Class Positive integer value 1
in the range of [0.255]
that uniquely identifies a
class in the binary
physical format.
ModelingRulesVersion Package Technical version num- 1.2
ber (MajorMinorVer-
sion) of the UML Model-
ling Rules specification
to which this model
complies.
tpegMLprefix Class For classes stereotypes Tec
as <> an
namespace prefix may
be given here.
tpegMLuri Class For classes stereotypes http: //www .tisa .org/tpeg/.
as <> an
namespace URI may be
given here.
In UML packages that are stereotyped as <> , the ApplicationAbbreviation,
ApplicationName, ApplicationRoot ApplicationNo and ModelingRulesVersion tagged values are
mandatory.
6 © ISO 2019 – All rights reserved

5.1.8 Notes
Notes may be used to provide additional information that is used for generating the specification
document.
5.2 Modelling rules and recommendations
5.2.1 General
TPEG UML models are used to generate TPEG specifications. A fundamental assumption is that
applications will develop and new features will be added. Correct designs permit applications to be
upgraded and extended over time, providing new features to new decoders, and yet permit existing
decoders to continue to operate. This clause describes design principles that shall be obeyed when
building and upgrading TPEG applications.
5.2.2 Order of elements
In a physical format, attributes shall occur in the same order as listed in the UML class definition
(see Figure 3).
When components may occur in any order (independent of the order in which they
are listed in the UML class definition), they should be modelled as attributes with the
stereotype <> and of the type of the corresponding class. The unordered
components shall be linked by the embedding class using a dependency relation.
When components shall occur in a specific order, they shall be modelled as attributes with the
stereotype <> and of the type of the corresponding class. The ordered
components shall be linked by the embedding class using a dependency relation.
Mandatory attributes should occur before optional attributes. Mandatory Booleans should occur
after the other mandatory attributes. Optional attributes should occur after mandatory attributes.
Components shall occur after all other attributes. Ordered components shall occur before unordered
components.
Figure 3 — Ordering of class elements
NOTE Special rules for extending TPEG UML models for newer revisions of a standard are provided in 5.3.
Extending TPEG UML models in a backwards compatible way can break the recommendations for ordering
mandatory and optional elements described in 5.2.2.
5.2.3 Stereotypes
5.2.3.1 TPEG Application
The <> stereotype is used to identify a UML package as TPEG Application.
NOTE UML packages that are stereotyped as <> can as well be stereotyped as < Toolkit>> if the use of classes is encouraged in other applications.
5.2.3.2 TPEG Toolkit
TPEG Toolkits are used to share common functionality between different TPEG Applications. For
example the Location Referencing Container and Message Management Container are toolkits that
are used by all TPEG applications. A TPEG Application therefore can refer to a data type definition not
specified in the same model.
TPEG Toolkits are designed such that its root components are defined as templates which can be used as
external reference within other packages. A TPEG Application using a toolkit template therefore needs
to specify a unique interface class for this instantiation of the imported toolkit interface’s component.
All subsequent components in a toolkit are defined as out of the scope of the TPEG application, i.e. the
toolkit on its own defines subcomponents beginning with local identifiers.
The <> stereotype is applied at UML package level.
5.2.3.3 TPEG DataTypes
General TPEG datatypes and TPEG Application specific datatypes as well as classes stereotyped as
<> are defined in separate UML packages. This only applies for elementary data types
and classes that are stereotyped as <> .
The <> stereotype is applied at UML package level.
5.2.3.4 DataStructure
The TPEG binary format distinguishes between components and datastructures. In this physical
representation, a component is a compound data type, containing a header, providing type and length
information. The type information of a component shall be unique within an application. A datastructure
is a compound datatype not containing this type and length information.
Datastructures shall explicitly be stereotyped as <> . Classes that are not explicitly
stereotyped as <> shall be interpreted as component. The differentiation between
components and datastructures is not relevant for tpegML as both variants are represented as xs:
element.
Components shall be included in datastructures by using attributes typed as this component.
The <> stereotype is applied at UML class level.
The specific usage of datastructures or components depends on the requirements of the particular
application. Components should be used wherever future extensions are envisioned, and where ‘future
proofing’ is a strong requirement. Datastructures are more bandwidth efficient as they contain no
header information but are not extendible in a backwards-compatible manner.
5.2.3.5 Enumeration
TPEG Tables are modelled as enumerations and shall have no more than 256 entries. Each enumeration
shall have a unique name which consists of two parts. The first part is the abbreviation of the application
where the enumeration is specified in, appended with a three-digit decimal number, starting at value
8 © ISO 2019 – All rights reserved

001. The second part is a description of the content of the table in camel-case. The two parts are
separated by a colon.
EXAMPLE typ001: LanguageCode.
When applicable, the enumeration entry with index zero should have the value “unknown”. If tables are
likely to be extended in future versions of a standard, a default value shall be defined. This default value
shall have index 255.
Additionally, enumeration entry names shall be named according to the following regular expression:
“^(25[0- 5]|2[0-4][0-9]|[01]?[0-9][0-9]?):.+$”, which is equivalent to “enumeration entry names shall start
with a numerical value between 0 and 255, followed by a colon and one or more arbitrary characters”,
where the text following the colon should only contain printable characters and whitespaces.
EXAMPLE See Figure 4.
Figure 4 — Enumeration stereotype
The <> stereotype is applied at UML class level.
5.2.3.6 External
TPEG applications can use classes that are not defined in the same package, but are defined elsewhere.
These classes shall be stereotyped as <> .
The <> stereotype is applied at UML class level.
Classes stereotyped as <> shall not contain or inherit any attributes, but define the container
formats only, while the content is defined in the referenced class/specification.
There are three different levels of external references:
1) Classes defined in other TPEG applications or TPEG toolkits.
In this case, the class shall be derived from the class in the other package. Additionally, the
tpegMLprefix and tpegMLuri shall be used.
In the case where a class stereotyped as <> has already been derived from another
class, this second external generalisation is valid. Classes imported via this mechanism shall not be
abstract.
2) Classes not defined according to this document, but an XSD is available.
In this case, the class shall not be derived from a class in another package, but the tpegMLprefix
and tpegMLuri shall be specified as tagged values for this class.
3) Classes not defined according to this document with only proprietary binary data being available.
In this case, the class shall not be derived from a class in another package and the tpegMLprefix
and tpegMLuri shall not be used.
5.2.3.7 UnorderedComponentGroup
By default, components that are included in classes should be modelled as being unordered:
The order in which the components appear in a model has no influence on the order in a
physical format representation. These components shall be modelled as attributes with the
stereotype <> .
The <> stereotype is applied at UML attribute level.
5.2.3.8 OrderedComponentGroup
By default, components that are included in classes are unordered (see 5.2.3.7). When
components should appear in a fixed order, they shall be modelled as attributes with the
stereotype <> and of the type of the corresponding class. See 5.2.2 for
details on ordering of attributes.
The <> stereotype is applied at UML attribute level.
5.2.3.9 BinaryDataContainer
TPEG applications can use classes that carry binary data which is not defined in TPEG, but is defined
elsewhere.
These classes shall be stereotyped as <>.
The <> stereotype is applied at UML class level.
Classes stereotyped as <> shall not contain or inherit any attributes, but define
the container formats only, while the content is defined elsewhere. Such classes shall have no child
classes and no classes shall be derived from them.
5.2.4 Data types
An overview of TPEG abstract data types is given in Annex A.
5.2.5 Optional Booleans
Due to encoding in the binary physical format, usage of optional Booleans is deprecated. The preferred
solution is to use two mandatory Booleans, with the first one indicating the validity of the second
Boolean. Alternatively, the enumeration as defined in typ008: OptionalBoolean (see Annex B) may be
used as attribute.
5.2.6 Tables and Switching Tables
TPEG Tables represent defined groupings of pre-defined concepts (see 5.2.3.5 for details on the
modelling of tables and Annex B for an overview of the general TPEG tables). TPEG enables hierarchical
tables (see example below) by using ‘Switching Tables’. Switching Tables are modelled in UML using
abstract classes. The switched table is referenced by including an attribute of the abstract table class
type (see Figure 5).
10 © ISO 2019 – All rights reserved

Figure 5 — TPEG Switching Table concept
The Application Specification shall define an unambiguous relation between the mainTable entry and
the switchedTable type. It is recommended that the name of the switchedTable matches the entry in the
mainTable and that the switchedTable number has a direct relation with the mainTable number.
EXAMPLE ‘One table called ‘xyz001: furniture’ has one entry ‘1:chair’. One hierarchical level below the
‘xyz001: furniture’ table might be a table called ‘xyz101: chair’, having entries ‘1:computer chair’, ‘2:rocking chair’,
etcetera. If an attribute of type xyz001: furniture has value 1, the referenced table is of type xyz101: chair.
5.2.7 Inclusion of DataStructures
Classes that are stereotyped as <> shall be included in a class by an attribute of
type of this DataStructure, which shall not be stereotyped <> or
<>.
5.2.8 Inclusion of Components in DataStructures
When a class stereotyped as <> shall include a component, this class shall be modelled
as an attribute stereotyped as <> .
5.2.9 Linking abstract classes
Classes can link to abstract classes. In this case, an instance of exactly one of the child classes is
instantiated. If one of the child classes is stereotyped as <> the abstract class itself shall not
contain any attributes.
EXAMPLE The LinkingClass has one attribute of abstract type, which can be instantiated with ChildClass1
and ChildClass2 (see Figure 6). The class only links to the abstract class. Each linked instance is of one of the two
child class types.
Figure 6 — Linking of abstract class
NOTE Linking of classes is often referred to as switching classes.
5.2.10 Graphical representation
Linked classes should be represented below the linking class. This provides a graphical hierarchical
representation, improving readability.
5.2.11 Documentation
Each class shall contain a functional description of the class and its attributes.
NOTE More information on documenting TPEG UML models is given in 5.4.
5.3 Extending TPEG UML models
TPEG provides means for extending applications without breaking backward compatibility. Classes can
be extended by appending components, mandatory and optional attributes.
For each revision of a standard, the following rules shall be obeyed:
Classes that are stereotyped as <> or <> shall not be extended.
Mandatory attributes shall be appended after all previously defined attributes and before all
components that are modelled as attributes with the stereotype <> .
Optional attributes shall be appended after all previously defined attributes and newly added
mandatory attributes and before all components that are modelled as attributes with the
stereotype <> .
The order and the multiplicity of the attributes shall not be changed.
Newly added ordered components shall occur only after the last ordered component of the extended class.
No additional rules for adding components not stereotyped as <> apply.
12 © ISO 2019 – All rights reserved

Newly added unordered components shall only occur after the last unordered component
of the extended class. No additional rules for adding components not stereotyped
as <> apply.
Attributes shall not be added to parent classes (classes that other classes inherit from), this would cause
breaking backward compatibility.
Other application extensions break backward compatibility and are therefore strongly depreciated.
EXAMPLE Figure 7 shows a co
...
