INTERNATIONAL ELECTROTECHNICAL COMMISSION
____________
Multimedia home network configuration - Basic reference model -
Part 1: System model
FOREWORD
1) The International Electrotechnical Commission (IEC) is a worldwide organization for standardization comprising
all national electrotechnical committees (IEC National Committees). The object of IEC is to promote international
co-operation on all questions concerning standardization in the electrical and electronic fields. To this end and
in addition to other activities, IEC publishes International Standards, Technical Specifications, Technical Reports,
Publicly Available Specifications (PAS) and Guides (hereafter referred to as “IEC Publication(s)”). Their
preparation is entrusted to technical committees; any IEC National Committee interested in the subject dealt with
may participate in this preparatory work. International, governmental and non-governmental organizations liaising
with the IEC also participate in this preparation. IEC collaborates closely with the International Organization for
Standardization (ISO) in accordance with conditions determined by agreement between the two organizations.
2) The formal decisions or agreements of IEC on technical matters express, as nearly as possible, an international
consensus of opinion on the relevant subjects since each technical committee has representation from all
interested IEC National Committees.
3) IEC Publications have the form of recommendations for international use and are accepted by IEC National
Committees in that sense. While all reasonable efforts are made to ensure that the technical content of IEC
Publications is accurate, IEC cannot be held responsible for the way in which they are used or for any
misinterpretation by any end user.
4) In order to promote international uniformity, IEC National Committees undertake to apply IEC Publications
transparently to the maximum extent possible in their national and regional publications. Any divergence between
any IEC Publication and the corresponding national or regional publication shall be clearly indicated in the latter.
5) IEC itself does not provide any attestation of conformity. Independent certification bodies provide conformity
assessment services and, in some areas, access to IEC marks of conformity. IEC is not responsible for any
services carried out by independent certification bodies.
6) All users should ensure that they have the latest edition of this publication.
7) No liability shall attach to IEC or its directors, employees, servants or agents including individual experts and
members of its technical committees and IEC National Committees for any personal injury, property damage or
other damage of any nature whatsoever, whether direct or indirect, or for costs (including legal fees) and
expenses arising out of the publication, use of, or reliance upon, this IEC Publication or any other IEC
Publications.
8) Attention is drawn to the Normative references cited in this publication. Use of the referenced publications is
indispensable for the correct application of this publication.
9) IEC draws attention to the possibility that the implementation of this document may involve the use of (a)
patent(s). IEC takes no position concerning the evidence, validity or applicability of any claimed patent rights in
respect thereof. As of the date of publication of this document, IEC had not received notice of (a) patent(s), which
may be required to implement this document. However, implementers are cautioned that this may not represent
the latest information, which may be obtained from the patent database available at https://patents.iec.ch. IEC
shall not be held responsible for identifying any or all such patent rights.
This redline version of the official IEC Standard allows the user to identify the changes made
to the previous edition IEC 62608-1:2014. A vertical bar appears in the margin wherever a
change has been made. Additions are in green text, deletions are in strikethrough red text.

IEC 62608-1 has been prepared by subcommittee TA 18: Multimedia home systems and
applications for end-user networks, of IEC technical committee TC 100: Audio, video and
multimedia systems and equipment. It is an International Standard.
This second edition cancels and replaces the first edition published in 2014. This edition
constitutes a technical revision.
This edition includes the following significant technical changes with respect to the previous
edition:
a) addition of devices connected via wireless LAN;
b) addition of servers on the cloud.
The text of this International Standard is based on the following documents:
Draft Report on voting
100/4200/CDV 100/4302/RVC
Full information on the voting for its approval can be found in the report on voting indicated in
the above table.
The language used for the development of this International Standard is English.
A list of all parts in the IEC 62608 series, published under the general title Multimedia home
network configuration – Basic reference model, can be found on the IEC website.
This document was drafted in accordance with ISO/IEC Directives, Part 2, and developed in
accordance with ISO/IEC Directives, Part 1 and ISO/IEC Directives, IEC Supplement, available
at www.iec.ch/members_experts/refdocs. The main document types developed by IEC are
described in greater detail at www.iec.ch/publications.
The committee has decided that the contents of this document will remain unchanged until the
stability date indicated on the IEC website under webstore.iec.ch in the data related to the
specific document. At this date, the document will be
• reconfirmed,
• withdrawn, or
• revised.
INTRODUCTION
Electronic power, as well as network connectivity, is necessary in order to use electronic
devices at home. Some applications running on the devices do not work without an inside and
outside network.
When a device connects to a home network, an appropriate network service needs to must
already be in place. Since network connections are a precondition of many applications, such
as the applications in IEC 62481-1, IEC 62481-2 and IEC 6248-3, a digital living network
alliance (DLNA) network management function is necessary.
Sometimes applications need are asked to change the configuration of another device, gateway,
and so on. Since it is too difficult to change the configuration of the device manually, an
automatic configuration mechanism is needed for the home network. IEC 62514 defines the
functions of a multimedia home gateway; this document complements the multimedia home
gateway by enabling to establish establishing network connection automatically.
This document expands the scope of management to include devices connected via wireless
LAN and servers on the cloud.
1 Scope
This part of IEC 62608 specifies the basic reference model to configure devices connected to
a home network with a configuration framework for network applications running on such
devices.
This document applies to devices that are cable or wireless LAN connected via cables and
switched on and that support IP protocol. The reference model covers inside and outside
network connectivity.
This document specifies the system model and functions that each component should support.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies.
For undated references, the latest edition of the referenced document (including any
amendments) applies.
ISO/IEC 7498-1:1994, Information technology – Open Systems Interconnection – Basic
reference model: The Basic model
IEC 62608-2, Multimedia home network configuration – Basic reference model – Part 2:
Operational model
3 Terms and definitions
For the purposes of this document, the following terms and definitions apply.
ISO and IEC maintain terminology databases for use in standardization at the following
addresses:
• IEC Electropedia: available at https://www.electropedia.org/
• ISO Online browsing platform: available at https://www.iso.org/obp
3.1
home network
network that connects equipment intended to be configured in the model
Note 1 to entry: The network is built mainly in a home.
3.2
home gateway
equipment that relays a communication from target equipment to outside the home network
facilitates bidirectional communication between target devices within a home network and
external networks
3.3
layer 1
physical layer of the commonly referenced multi-layered communication model, open systems
interconnection
3.4
layer 2
data link layer of the commonly referenced multi-layered communication model, open systems
interconnection
Note 1 to entry: A description of OSI-layers is given in ISO/IEC 7498-1:1994, Clause 6.
3.5
layer 3
network layer of the commonly referenced multi-layered communication model, open systems
interconnection
Note 1 to entry: A description of OSI-layers is given in ISO/IEC 7498-1:1994, Clause 6.
3.6
broadcast domain
segment of a network where broadcasts are shared among all devices at Layer 2 of the OSI
model
Note 1 to entry: Layer 2 broadcasts use MAC addresses for communication, making them relevant within a single
local network segment only.
3.7
configurator
entity that configures equipment
tool that manages devices, collects information from configuration agent, and configures
network functions within the home network and cloud
3.8
configuredconfiguration agent
entity that sends configuration information to the configurator
agent running on the equipment managed by the configurator, which sends configuration
information to the configurator and configures the network functions of the equipment
3.9
service server
server that collaborates with the configurator to accomplish the required function located
outside of the home
Note 1 to entry: Examples of service servers include quality check server, service failure information server, and
diagnostics server.
4 Model
4.1 General
This document defines the configurator that manages the configuration information of
equipment connected to a home network and the configuration agents that are managed by the
configurator.
4.2 Configurator
The configurator configures the equipment as needed and runs on a home network.
The configurator assumes that all devices are set up on the layer 2 network, i.e. and that all
devices are cable connected with pieces of network equipment. Based on the environment, the
configurator supports the creation of a layer 3 connection and application running on consumer
equipment.
4.3 ConfiguredConfiguration agent
The configured configuration agent sends configuration information to the configurator and
configures equipment requested by the configurator. The configured configuration agent runs
on the equipment managed by configurator.
The configured configuration agent specifies the procedure needed to establish the of
connection establishment with the configurator on the layer 2 network. Once the connection is
established, the configured configuration agent operates as required by the configurator. The
function of the configured configuration agent consists of collecting information from the devices,
changing the device configuration, and so on.
4.4 System model
Figure 1 shows the system model of the configurator and configured configuration agent. The
lines connecting the configurator and AV equipment, etc., indicate that they are on the
broadcast domain. This applies to both wired and wireless connections.
Recorder
Configurator
Configured agent
Home
gateway
Configured
agent
TV
IEC  0914/14
Figure 1 – Configurator system model
4.5 Configuration model
The configurator obtains the configuration information from the configured configuration agent
running on each item of equipment and requests it to configure as needed. The configurator
also requests configurations to the home gateway. Figure 2 shows how the configurator obtains
information and the configuration request model.
Configuration
Recorder
request
Configurator
Configured agent
Home
gateway
Configuration
Configured
information
agent
TV
IEC  0915/14
Figure 2 – Obtaining information and configuration
request model of the managed by configurator
For the use cases, see Annex A for audio and video settings in home and in studio, and Annex B
for management sensor devices in the home network.
4.6 Management model managed by the configurator
The information that the configurator collects can be divided into the categories of L1/L2
Network, L3 Network, and Service:
a) L1/L2 Network manages the physical connections and L2 connections within the home
network;
b) L3 Network manages the L3 network configuration between the home network and the cloud,
etc.;
a) Service manages the devices and applications that connect to the network and are visible
to the user.
The configurator manages all this information in a coordinated manner and makes it accessible
as needed (see Figure 3 for layered management model).

Figure 3 – Layered management model by the configurator
5 Network configuration framework
5.1 Configuration protocol
A protocol is required to communicate between the configurator, the configured configuration
agent, and the home gateway. The protocol and operational model specification will shall be as
defined in IEC 62608-2 .
5.2 Configuration data model and metadata
A data model and metadata are required in order to construct the configured agent by the
configurator for the configurator to construct the configuration agent. The specification of data
model and metadata will be described in IEC 62608-3 .

___________
Under consideration.
Annex A
(informative)
Use case of audio and video settings in home and in studio
A.1 Description of the use case
See Table A.1 to Table A.8 for description of the use case of audio and video settings in home
and in studio.
Table A.1 – Name of use case
Use case identification
ID Area / Domain(s) / Zone(s) Name of use case
N/A Audio, video and multimedia Audio and video settings in home and in studio
systems and equipment
Table A.2 – Version management
Version management
Version No. Date Name of author(s) Changes Approval status
N/A 2023 TC 100 N/A N/A
Table A.3 – Scope and objectives of use case
Scope and objectives of use case
Scope Live studio
Objective(s) Provide automatic studio setting

Related business case(s)
Table A.4 – Narrative of use case
Narrative of use case
Short description
− Producer arrives at the studio and begins setting up audio and video. He/she places all devices and
connects to the network.
− Configurator collects device information and visualizes automatically.
− Producer selects today’s setting from service server hosted in cloud.
− Configurator sets up the devices automatically.
Complete description
Table A.5 – General remarks
General remarks
The producer is an audio and video equipment expert but not a network expert.

A.2 Diagram of use case
See Figure A.1 for use case diagram of audio and video equipment setting.
Diagram(s) of use case
Figure A.1 – Use case diagram of audio and video equipment setting
A.3 Technical details
Table A.6 – Actors
Actors
Grouping Group description
N/A N/A
Actor name Actor type Actor description Further information
specific to this use case
see actor list see actor list see actor list
Producer Person Person in the studio N/A
Audio and video Equipment Audio and video equipment N/A
PC or tablet Device Device that monitors the audio and video N/A
equipment managed by the configurator
Configurator System System monitors connected devices by L1/L2 N/A
network, L3 network and Service
Service server System System manages configuration information by N/A
collaborating with the configurator
Cloud System System that hosts service server N/A

Table A.7 – Triggering event, preconditions, assumptions
Use case conditions
Actor/System/Information/ Triggering event Pre-conditions Assumption
Contract
Producer N/A Entered the studio N/A
Audio and video equipment N/A Connected network and works well N/A
Service server N/A Works well
Configurator N/A Maintained well N/A

A.4 Step by step analysis of use case
Table A.8 – Overview of scenarios
Scenario conditions
No. Scenario name Primary actor Triggering event Pre-condition Post-condition
1 Connecting Producer Connect equipment N/A N/A
2 Set up Producer Set up equipment N/A N/A
3 Request Configurator Get configuration N/A N/A
4 Configure Configurator Configure equipment N/A N/A

Annex B
(informative)
Use case of management sensor devices in the home network
B.1 Description of the use case
See Table B.1 to Table B.8 for description of the use case of management of sensor devices in
the home network.
Table B.1 – Name of use case
Use case identification
ID Area/ Domain(s)/ Zone(s) Name of use case
NA Smart home Management sensor devices in the home network

Table B.2 – Version management
Version management
Version no. Date Name of author(s) Changes Approval status
N/A 2023 TC 100 N/A N/A
Table B.3 – Scope and objectives of use case
Scope and objectives of use case
Scope Sensor device in the home network
Objective(s) Provide sensor device management simply

Related business case(s)
Table B.4 – Narrative of use case
Narrative of use case
Short description
− A user collects and manages data such as temperature and healthcare data using sensor device.
− The configurator detected that the thermometer is disconnected. Configurator notified the user when the
thermometer data stopped.
− The user checked and found that the battery was dead, so the user replaced it. The thermometer became
available again.
Complete description
Table B.5 – General remarks
General remarks
The user is not a network expert.

B.2 Diagram of use case
See Figure B.1 for use case diagram of management sensors in the home network.
Diagram(s) of Use Case
Figure B.1 – Use case diagram of management sensors in the home network
B.3 Technical details
Table B.6 – Actors
Actors
Grouping Group description
N/A N/A
Actor name Actor type Actor description Further information
specific to this use case
see Actor list see Actor list see Actor list
Person who uses sensor or healthcare device in
User Person N/A
the home
Thermometer Device Device that monitors the temperature. It is N/A
managed by configurator
Configurator System System monitors connected devices by L1/L2 N/A
network, L3 network and Service
Service server System System manages configuration information by N/A
collaborating with configurator
IoT platform System System collects and analyzes sensor data N/A
Cloud System System that hosts service server N/A

Table B.7 – Triggering event, preconditions, assumptions
Use case conditions
Actor/System/Information/ Triggering event Pre-conditions Assumption
Contract
User N/A Set the thermometer in the home N/A
Devices N/A Connected network and works well N/A
Configurator N/A Maintained well N/A

B.4 Step by step analysis of use case
Table B.8 – Overview of scenarios
Scenario conditions
No. Scenario name Primary actor Triggering event Pre-condition Post-condition
1 Alarm from application User Disconnected N/A N/A
2 Diagnose Configurator User request N/A N/A
3 Report the problem Configurator Detect the problem N/A N/A
4 Recovery User Recover the device N/A N/A

Bibliography
ISO/IEC 7498-1:1994, Information technology – Open Systems Interconnection – Basic
Reference Model: The Basic Model – Part 1
IEC 62481-1, Digital living network alliance (DLNA) home networked device interoperability
guidelines – Part 1: Architecture and protocols
IEC 62481-1-1:2017, Digital living network alliance (DLNA) home networked device
interoperability guidelines – Part 1-1: Architecture and protocols – Core architecture and
protocols
IEC 62481-1-2:2017, Digital living network alliance (DLNA)
...
