International Standard IEC 60749-3 has been prepared by IEC technical committee 47:
Semiconductor devices.
This second edition cancels and replaces the first edition published in 2002. This edition
constitutes a technical revision.
This edition includes the following significant technical changes with respect to the previous
edition:
a) reference to the need for ESD protection;
b) inclusion of information on the phenomenon of tin whiskers;
c) inclusion of an optional report form/checklist.

– 4 – IEC 60749-3:2017 © IEC 2017
This bilingual version (2019-08) corresponds to the monolingual English version, published in
2017-03.
The text of this standard is based on the following documents:
FDIS Report on voting
47/2345/FDIS 47/2370/RVD
Full information on the voting for the approval of this International Standard can be found in
the report on voting indicated in the above table.
The French version of this standard has not been voted upon.
This document has been drafted in accordance with the ISO/IEC Directives, Part 2.
A list of all parts in the IEC 60749 series, published under the general title Semiconductor
devices – Mechanical and climatic test methods, can be found on the IEC website.
The committee has decided that the contents of this document will remain unchanged until the
stability date indicated on the IEC website under "http://webstore.iec.ch" in the data related to
the specific document. At this date, the document will be
• reconfirmed,
• withdrawn,
• replaced by a revised edition, or
• amended.
SEMICONDUCTOR DEVICES –
MECHANICAL AND CLIMATIC TEST METHODS –

Part 3: External visual examination

1 Scope
The purpose of this part of IEC 60749 is to verify that the materials, design, construction,
markings, and workmanship of a semiconductor device are in accordance with the applicable
procurement document. External visual inspection is a non-destructive test and applicable for
all package types. The test is useful for qualification, process monitor, or lot acceptance.
2 Normative references
The following documents are referred to in the text in such a way that some or all of their
content constitutes requirements of this document. For dated references, only the edition
cited applies. For undated references, the latest edition of the referenced document (including
any amendments) applies.
IEC 61340-5-1, Electrostatics – Part 5-1: Protec
...
