(Main)Fuel cell technologies - Part 5-1: Portable fuel cell power systems - Safety
Fuel cell technologies - Part 5-1: Portable fuel cell power systems - Safety
IEC 62282-5-1:2012 covers construction, marking and test requirements for portable fuel cell power systems intended to produce electrical power. Applies to a.c. and d.c. type portable fuel cell power systems, with a rated output voltage not exceeding 600 V a.c., or 850 V d.c. for indoor and outdoor use. The major technical changes with respect to the first edition are as follows:
- referencing an alternative test method; reduction of the limit on flammable atmospheres;
- consideration of additional effluents and criteria to establish if a system is suitable for indoor or outdoor operation;
- revision of specific criteria for oxygen detector sensor performance;
- new test method and new drop heights; addition of a table giving limits on emission of effluents.
Keywords: fuel cell
Technologies des piles à combustible - Partie 5-1: Systèmes à piles à combustible portables - Sécurité
l'IEC 62282-5-1:2012 couvre les exigences de construction, de marquage et d'essai applicables aux systèmes portatifs à pile à combustible destinés à produire de l'énergie électrique. La présente norme s'applique aux systèmes à piles à combustible portables à courant alternatif et à courant continu dont la tension de sortie assignée ne dépasse pas 600 V en courant alternatif ou 850 V en courant continu, et qui sont destinés à un usage à l'intérieur et à l'extérieur. Les modifications techniques majeures par rapport à la première édition sont les suivantes:
- faisant référence à une autre méthode d'essai en réponse à un commentaire a été mis à jour
- la prise en compte des effluents supplémentaires et des critères permettant d'établir si un système convient à une utilisation à l'intérieur ou à l'extérieur
- révision de critères spécifiques pour la performance des détecteurs d'oxygène;
- nouvelle méthode d'essai et nouvelles hauteurs de chute; ajout d'un tableau limitant les émissions d'effluents.
mots clés : pile à combustible
