– 6 – IEC 62878-2-603:2025 © IEC 2025
DEVICE EMBEDDING ASSEMBLY TECHNOLOGY –

Part 2-603: Guideline for stacked electronic module –
Test method of intra-module electrical connectivity

1 Scope
This part of IEC 62878 specifies the electrical test method to detect electrical connectivity
defects of the stacked electronic module caused by the stacking assembly process to stack
some stackable electronic modules. This method is realized to make use of bidirectional serial
communication bus interface applied to the stackable electronic modules which are assured as
"known good module" (KGM).
2 Normative references
The following documents are referred to in the text in such a way that some or all of their content
constitutes requirements of this document. For dated references, only the edition cited applies.
For undated references, the latest edition of the referenced document (including any
amendments) applies.
IEC 60194-2, Printed boards design, manufacture and assembly – Vocabulary – Part 2:
Common usage in electronic technologies as well as printed board and electronic assembly
technologies
3 Terms, definitions and abbreviated terms
3.1 Terms definitions
For the purposes of this document, the terms and definitions given in IEC 60194-2 and the
following apply.
ISO and IEC maintain terminology databases for use in standardization at the following
addresses:
• IEC Electropedia: available at https://www.electropedia.org/
• ISO Online browsing platform: available at https://www.iso.org/obp
3.1.1
known good module
KGM
electronic module, which meets quality, reliability, performance and functionality as agreed
upon between customer and supplier
3.2 Abbreviated terms
SAEM stackable electronic module
SDEM stacked electronic module

4 General
The SDEM is produced by means of stacking at least more than two stackable electronic
modules. The SAEM usually mounts components with area array type package on the surface
and does embed components with wafer-level type package or bare chip into the inner layer to
achieve miniaturization and densification. Figure 1 depicts a SAEM. Figure 2 depicts a SDEM
to stack three SAEMs.
Figure 1 – SAEM (stackable electronic module)

Figure 2 – SDEM (stacked electronic module)
The SDEM is produced by means of stacking some SAEMs which should be KGM to meet
quality, reliability, performance and functionality as agreed upon between user and supplier.
a) KGM shall be individually tested before assembly.
b) Intra-module connections of SAEMs shall be tested before stacking assembly.
c) After stacking assembly the inter-module connections of SDEM shall be tested.
Figure 3 shows inter-module connection and intra-module connection.
If a SDEM is produced by use of pre-tested SAEMs, it is sufficient to test the electrical
connections between the individual SAEMs for the purpose of assuring the functionality of the
SDEM.
In Clause 5 to Clause 7, an example is described, how this test strategy can be realized by
utilization of the bidirectional I2C (Inter-Integrated Circuit) bus.

– 8 – IEC 62878-2-603:2025 © IEC 2025

Figure 3 – Inter-module connection and intra-module connection
The external appearance test and the open or short test should be generally performed as
precondition of any electrical tests before the electrical connectivity test, so that any breakdown
should be prevented when power is supplied. The external appearance test should detect
misorientation and misalignment between SAEMs. Also, the open or short test should detect
open circuit and short circuit between power supply line and ground line.
Various test methods on external appearance test and the open or short test are developed and
widely applied respectively. Since it is so difficult to standardize them, they should be out of the
scope of this document.
5 Test specimen
5.1 General
Since the SDEM becomes an invisible, untouchable and undiagnosed structure from a viewpoint
of test and diagnosis, it is required to make use of bidirectional serial communication bus
interface applied to the SAEMs which are assured as KGM. Some bidirectional serial
communication bus interfaces are well-known and in reality, have been applied to actual
electronic products. Three representatives such as I2C, Joint Test Action Group Boundary-Scan
and SPI to mutually connect among electronic components are shown in Annex A. The test
specimen adopt I2C of a simple 2-wire serial communication interface to achieve miniaturization,
densification and to consider test design cost and accessibility of electronic components in the
marketplace as well. It also adopts lead-free solder joint method as a stacking assembly method.
Annex A shows representative examples of stacking assembly methods described in
IEC 62878-2-602:2021).
5.2 Preparation of test specimen
The test specimen is a SDEM which is produced by means of stacking at least more than two
SAEMs. Each of SAEMs should have some embedded components which are compliant with
I2C serial communication bus interface protocol. The components should have two dedicated
terminals such as SDA and SCL and do their own unique number to be distinguished from
others. The two bus lines such as SDA and SCL are connected to the two dedicated terminals
of every embedded component of the stacked module and to a test apparatus as well.

Figure 4 shows an image drawing of the test specimen which consists of the cross section of
the test specimen, the circuit diagram and the bottom view. This example stacks three SAEMs
such as Module 1, Module 2 and Module 3. Each SAEM has at least four embedded components.
That is, Module 1 has Comp-2, Comp-5, Comp-8 and Comp-11. Module 2 has Comp-1, Comp-4,
Comp-7 and Comp-10. Module 3 has Comp-0, Comp-3, Comp-6 and Comp-9. The other
components can be embedded and/or mounted in order to evaluate embedding assembly
process although they are not explicitly shown in the Figure 4. In this example, there are forty
external terminals and eight ones of them are assigned to I2C serial communication bus lines
such as SDA and SCL near four corner sides.

NOTE Blue line shows inter-module connection and red line shows intra-module connection.
Figure 4 – Image drawing of the test specimen
6 Test apparatus
The test apparatus consists of a base board, a controller and a converter box. The base board
mounts a test specimen and connect to the test specimen and the controller through
bidirectional serial communication bus. the controller manages bidirectional serial
communication bus and has test program software to test electrical connectivity of the test
specimen. Finally, the converter box bi-directionally converts between USB and other serial
communication buses.
Figure 5 shows test apparatus to choose I2C as a serial communication bus interface.

– 10 – IEC 62878-2-603:2025 © IEC 2025

Figure 5 – Test apparatus
7 Test method and test procedure
7.1 General
The test method is to test electrical connectivity of both inter-module connection and intra-
module connection of the SDEM as a test specimen to make use of bidirectional serial
communication bus interface applied to the SAEMs. The basic test procedure is common among
serial communication bus interfaces although the detailed one is slightly different.
7.2 Example of a test procedure
Figure 6 shows test procedure to choose I2C as a serial communication bus interface. I2C is a
simple 2-wire serial communication interface. The connected components have two dedicated
terminals such as SDA and SCL and have their own unique number to be distinguished from
others. The test apparatus activates the bidirectional path to reach the target component
through some inter-module connections and an intra-module connection. This procedure is
called as an I2C access test. The electric connectivity test is realized by means of continuously
repeating the I2C access test to every target component. The test program software on the PC
actually manages this test procedure and decides whether every connection successfully
establish or not.
The test begins I2C access test of Component-0 as the first target component. The test
apparatus sends a Request signal to Component-0 and receives an Acknowledge signal from
Component-0. If it cannot receive an Acknowledge signal or receives an invalid Acknowledge
signal, the path to reach Component-0 through some inter-module connections and an intra-
module connection is disconnected, that is, the electric connectivity does not establish. If it can
receive a valid Acknowledge signal, the path to reach Component-0 through some inter-module
connections and an intra-module connection is connected, that is, the electric connectivity does
establish. The I2C access test continues to choose Component-1 as the next target component
and repeat up to Component-N as the last target component. If all I2C tests pass, the electric
connectivity of the test specimen is successfully established.

Key
Req-number: the number of requested component
Ack-number: the number of acknowledged component
N: the number of components
Figure 6 – Test procedure
– 12 – IEC 62878-2-603:2025 © IEC 2025
Annex A
(informative)
Representatives of bidirectional serial bus communication interface
Table A.1 depicts three representatives of bidirectional serial communication bus interface to
mutually connect among electronic components.
Table A.1 – Representatives of bidirectional serial communication bus interface
Name JTAG
I2C SPI
Items Boundary-Scan
Joint Test Action Group
Full name Inter-Integrated Circuit Serial Peripheral Interface
Boundary-Scan
Category De facto standard Forum standard De facto standard
(Ownership) ®a (IEEE 1149.1 standard) ®b
(Phillips semiconductors (Motorola developed)
developed)
Widely used in embedded Used in testing and diagnosis Used for direct
Main purpose
system design and various of circuit boards. Most logic communication between
control architectures. Most ICs such as CPU, FPGA and micro controllers and
electronic components adopt DSP adopt peripherals
Features A simple bidirectional 2-wire A bidirectional 4-wire serial A master/slave 4-wire serial
serial communication bus. It communication bus. It communication bus. It
consists of 2 signals such as consists of 4 signals such as consists of 4 signals such as
serial
...
