Installation couplers intended for permanent connection in fixed installations

IEC 61535:2023 is available as IEC 61535:2023 RLV which contains the International Standard and its Redline version, showing all changes of the technical content compared to the previous edition.IEC 61535:2023 applies to two-wire, up to five-wire installation couplers, with or without earthing contact, if provided, with a rated voltage up to and including 500 V AC or 500 V DC and a rated connecting capacity up to and including 10 mm2 and a rated current not exceeding 32 A for permanent connection in electrical installations. Installation couplers with additional contacts for voltages other than mains voltages are outside the scope of this document. This third edition cancels and replaces the second edition published in 2019. This edition constitutes a technical revision. This edition includes the following significant technical changes with respect to the previous edition: a) inclusion of a definition for "live part" based on IEC 61140; b) additional optional cross medial documentation, e.g. marking with QR-Code; c) corrections on the consistent use of the expressions "earth", "earthing contact", "earthing circuit" and "protective earth(ing)" throughout the document; d) addition of missing compliance provisions to 13.3; e) update of Figure D.1 of Annex D; f) inclusion of new Annex F for cold climate requirements.

Installationssteckverbinder für dauernde Verbindung in festen Installationen

Coupleurs d'installation pour connexions permanentes dans les installations fixes

IEC 61535:2023 est disponible sous forme de IEC 61535:2023 RLV qui contient la Norme internationale et sa version Redline, illustrant les modifications du contenu technique depuis l'édition précédente.L'IEC 61535:2023 s'applique aux coupleurs d'installation qui comportent deux à cinq conducteurs, avec ou sans contact de terre (le cas échéant), de tension continue ou alternative assignée jusqu'à 500 V inclus et de capacité assignée de connexion jusqu'à 10 mm2 inclus, avec un courant assigné qui ne dépasse pas 32 A, pour connexion permanente dans les installations électriques. Les coupleurs d'installation avec des contacts supplémentaires pour des tensions autres que la tension d'alimentation du réseau ne relèvent pas du domaine d'application du présent document. Cette troisième édition annule et remplace la deuxième édition parue en 2019. Cette édition constitue une révision technique. Cette édition inclut les modifications techniques majeures suivantes par rapport à l'édition précédente: a) inclusion d'une définition issue de l'IEC 61140 pour "partie active"; b) documentation facultative supplémentaire disponible sur plusieurs supports, par exemple marquage avec QR code; c) corrections relatives à l'utilisation cohérente des expressions "terre", "contact de terre", "circuit de terre" et "(mise à la) terre de protection" dans l'ensemble du document; d) ajout de dispositions de conformité manquantes au 13.3; e) mise à jour de la Figure D.1 de l'Annexe D; f) ajout d'une nouvelle Annexe F pour les exigences relatives aux climats froids.

Inštalacijske spojke za trajni spoj v fiksnih napeljavah (inštalacijah)

General Information

Status
Published
Publication Date
29-Aug-2024
Drafting Committee
Current Stage
6060 - Document made available - Publishing
Start Date
30-Aug-2024
Completion Date
30-Aug-2024

Relations

Buy Standard

Draft
prEN IEC 61535:2022
English language
54 pages
sale 10% off
Preview
sale 10% off
Preview
e-Library read for
1 day

Standards Content (Sample)


SLOVENSKI STANDARD
oSIST prEN IEC 61535:2022
01-marec-2022
Inštalacijske spojke za trajni spoj v fiksnih napeljavah (inštalacijah)
Installation couplers intended for permanent connection in fixed installations
Installationssteckverbinder für dauernde Verbindung in festen Installationen
Coupleurs d'installation pour connexions permanentes dans les installations fixes
Ta slovenski standard je istoveten z: prEN IEC 61535:2022
ICS:
29.120.99 Druga električna dodatna Other electrical accessories
oprema
oSIST prEN IEC 61535:2022 en,fr,de
2003-01.Slovenski inštitut za standardizacijo. Razmnoževanje celote ali delov tega standarda ni dovoljeno.

oSIST prEN IEC 61535:2022
oSIST prEN IEC 61535:2022
23/991/CDV
COMMITTEE DRAFT FOR VOTE (CDV)
PROJECT NUMBER:
IEC 61535 ED3
DATE OF CIRCULATION: CLOSING DATE FOR VOTING:
2022-01-07 2022-04-01
SUPERSEDES DOCUMENTS:
23/964/CD, 23/971A/CC
IEC TC 23 : ELECTRICAL ACCESSORIES
SECRETARIAT: SECRETARY:
Belgium Mr Wim De Kesel
OF INTEREST TO THE FOLLOWING COMMITTEES: PROPOSED HORIZONTAL STANDARD:

Other TC/SCs are requested to indicate their interest, if
any, in this CDV to the secretary.
FUNCTIONS CONCERNED:
EMC ENVIRONMENT QUALITY ASSURANCE SAFETY
SUBMITTED FOR CENELEC PARALLEL VOTING NOT SUBMITTED FOR CENELEC PARALLEL VOTING
Attention IEC-CENELEC parallel voting
The attention of IEC National Committees, members of
CENELEC, is drawn to the fact that this Committee Draft
for Vote (CDV) is submitted for parallel voting.
The CENELEC members are invited to vote through the
CENELEC online voting system.
This document is still under study and subject to change. It should not be used for reference purposes.
Recipients of this document are invited to submit, with their comments, notification of any relevant patent rights of
which they are aware and to provide supporting documentation.

TITLE:
Installation couplers intended for permanent connection in fixed installations

PROPOSED STABILITY DATE: 2027
NOTE FROM TC/SC OFFICERS:
The comments to this CDV will be discussed during the next meeting of TC 23 MT6 which is scheduled
for May 3rd/4th 2022.
download this electronic file, to make a copy and to print out the content for the sole purpose of preparing National
Committee positions. You may not copy or "mirror" the file or printed version of the document, or any part of it,
for any other purpose without permission in writing from IEC.

oSIST prEN IEC 61535:2022
IEC CDV 61535 © IEC 2021 2 23/991/CDV

1 CONTENTS
2 CONTENTS . 2
3 FOREWORD . 6
4 INTRODUCTION . 8
5 1 Scope . 9
6 2 Normative references. 9
7 3 Terms and definitions . 10
8 4 General requirements . 12
9 5 Conditions for tests . 12
10 5.1 General . 12
11 5.2 Test conditions . 13
12 5.3 Tests on non-rewirable installation couplers . 13
13 5.4 Order of tests . 13
14 5.5 Specification of tests . 13
15 5.6 Compliance requirements . 13
16 5.7 Routine tests for non-rewirable installation couplers . 13
17 6 Ratings . 14
18 6.1 Rated voltage . 14
19 6.2 Rated current . 14
20 6.3 Rated connecting capacity . 15
21 6.4 Tests . 15
22 7 Classification . 15
23 8 Marking and documentation . 16
24 8.1 General . 16
25 8.2 Use of symbols or letters . 16
26 8.3 Markings . 16
27 8.4 Documentation . 17
28 9 Dangerous compatibility . 18
29 9.1 Unintended or improper connection . 18
30 9.2 Engagement . 18
31 9.3 Compatibility of different installation coupler systems . 18
32 9.4 Compatibility with standard systems . 18
33 10 Protection against electric shock . 19
34 10.1 Degree of protection against ingress of solid foreign objects . 19
35 10.2 Access to live parts . 19
36 10.3 External parts . 19
37 11 Terminals, terminations and connectable conductors . 19
38 11.1 Terminals and terminations . 19
39 11.1.1 General . 19
40 11.1.2 Terminals of rewirable installation couplers . 20
41 11.1.3 Terminations of non-rewirable installation couplers . 20
42 11.2 Connectable conductors . 20
43 12 Construction . 21
44 12.1 Connection between earthing contacts . 21
45 12.2 Locking against rotation . 21
46 12.3 Mechanical strength of contacts . 21

oSIST prEN IEC 61535:2022
IEC CDV 61535 © IEC 2021 3 23/991/CDV

47 12.4 Housing of rewirable installation couplers . 21
48 12.5 Housing of non-rewirable installation couplers . 22
49 12.6 Dismantling and opening of rewirable installation couplers . 22
50 12.7 Earthing contact and earthing terminal . 22
51 12.8 Loose conductor strands . 22
52 12.8.1 General . 22
53 12.8.2 Strand test for rewirable installation couplers . 23
54 12.8.3 Strand test for non-rewirable non-molded-on installation couplers . 23
55 12.8.4 Strand test for non-rewirable moulded-on installation couplers . 23
56 12.9 Incorporation of electrical devices . 23
57 12.10 Retaining means . 24
58 12.11 Distribution blocks . 24
59 12.12 Shrouds . 24
60 12.13 Factory wiring . 24
61 12.14 Stress test . 24
62 12.14.1 General . 24
63 12.14.2 Stress test of rewirable installation couplers . 24
64 12.14.3 Stress test of non-rewirable installation couplers . 25
65 12.15 Separation of non-rewirable installation couplers . 25
66 13 Protection against harmful ingress of solid foreign objects and against harmful
67 ingress of water . 25
68 13.1 General . 25
69 13.2 Protection against harmful ingress of solid foreign objects. 25
70 13.3 Protection against harmful ingress of water . 25
71 14 Insulation resistance and electric strength . 26
72 14.1 General . 26
73 14.2 Insulation resistance . 26
74 14.3 Electric strength . 26
75 15 Construction of contacts . 27
76 15.1 Resiliency . 27
77 15.2 Resistance of connections . 27
78 15.3 Contact pressure . 28
79 16 Temperature rise . 28
80 17 Breaking capacity . 29
81 18 Forces necessary to disengage the parts of the installation coupler . 29
82 19 Cables and their connection . 30
83 19.1 Capability of being fitted . 30
84 19.2 Relief from pull, thrust and torsion . 30
85 19.3 Cable anchorage . 30
86 19.4 Capability to connect cables with different cross-sectional area . 30
87 19.5 Sharp edges . 33
88 20 Mechanical strength . 33
89 21 Resistance to heat and ageing . 34
90 21.1 Resistance to heat . 34
91 21.2 Dry heat storage . 34
92 21.3 Ball pressure test . 34
93 21.4 Ageing of elastomeric and thermoplastic material . 35
94 21.5 Current cycling test . 35

oSIST prEN IEC 61535:2022
IEC CDV 61535 © IEC 2021 4 23/991/CDV

95 22 Screws, current-carrying parts and connections . 36
96 22.1 Screws and nuts . 36
97 22.2 Screws and insulating material . 37
98 22.3 Screws and rivets for electrical and mechanical connections . 38
99 22.4 Metals of cur
...
